Ross M DM2 C Series User manual

F3.16 © 2016, ROSS CONTROLS®. All Rights Reserved.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS, WARNINGS on the inside back cover.
Online Version
Rev. 11/14/16
2
3
Mounting brackets are required to install valve in the system, see M DM2® Series C accessories for ordering information page F3.18.
Construction: Dual Poppet.
Mounting Type: Base mounted.
Pilot Solenoids: According to VDE 0580. Enclosure rating according to
DIN 400 50 IP 65. Three solenoids, rated for continuous duty.
Standard Voltages: 24 volts DC.
Pilot Solenoids Power Consumption (each solenoid):
Primary and reset solenoids: 1.2 watts on DC.
Enclosure Rating: IP65, IEC 60529.
Solenoid & Status Indicator Connection:
M12, 5-pin Male Receptacle, A-Coded.
Ambient Temperature: 15° to 122°F (-10° to 50°C).
Media Temperature: 40° to 175°F (4° to 80°C).
Flow Media: Filtered, lubricated or unlubricated (mineral oils according to
DIN 51519, viscosity classes 32-46); 5-micron recommended.
Inlet Pressure: 30 to 150 psig (2 to 10 bar). Under certain circumstances,
such as maximum restriction of the adjustable flow control or a very large
downstream system volume, the minimum inlet pressure may need to be
set up to 60 psig (4 bar) to prevent nuisance valve faults.
Pressure Switch (Status Indicator) Rating: 5 amps at 30 volts DC.
Monitoring: Dynamically, cyclically, internally during each actuating and
de-actuating movement. Monitoring function has memory and requires
an overt act to reset unit after lockout.
Mounting Orientation: Vertically with pilot solenoids on top.
Functional Safety Data: Category 4 PL e; B10d: 20,000,000; PFHd:
7.71x10 -9 ; MTTFd: 301.9 (nop: 662400).
Certifications: CE Marked for applicable directives, CSA/UL.
Vibration/Impact Resistance: Tested to BS EN 60068-2-27.
Port Size Basic Size Transducer Valve Model Number*CVWeight
lb (Kg)
Inlet Outlet 1 to 2 2 to 3
3/4 3/4 8 With MDM2CNA55A23 3.7 8.5 16.3 (7.4)
3/4 3/4 8 Without MDM2CNA55A21 3.7 8.5 16.1 (7.3)
*NPT port threads. For BSPP threads , replace “N” in the model number with a “D”, e.g., MDM2CDA55A23.
STANDARD SPECIFICATIONS (for valves on this page):
Double Valves with Dynamic Monitoring & Memory
10.78
(273.8)
5.73
(145.5)
5.35 (136.0)
5.81 (147.6)
Adjustable Flow Control
Inlet
Outlet
1.63 (41.3)
GRAY
(Equip. Ground)
WHITE
(N.O. Status Contact)
BROWN
(+24 Volts DC)
BLUE
(Common)
5 Pin “A” Code
Female Connector
BLACK
(N.C. Status Contact)
12
5
43
GRAY
(Reset)
WHITE
(Sol 2)
BROWN
(+24 Volts DC)
BLACK
(Sol 1)
BLUE
(Common)
5 Pin “A” Code
Male Connector
21
5
34
Valve Wiring
Dynamic Monitoring With Memory: Memory, monitoring, and air flow control functions are integrated into
two identical valve elements. Valves lock-out if asynchronous movement of valve elements occurs during
actuation or de-actuation, resulting in a residual outlet pressure of less than 1% of supply.
An Action is Required for Reset: Cannot be reset by removing and re-applying supply pressure. Reset
can be accomplished by the integrated electrical (solenoid) reset or by the manual reset button.
Basic 3/2 Normally Closed Valve Function: Dirt tolerant, wear compensating poppet design for quick
response and high flow capacity. PTFE back-up rings on pistons to enhance valve endurance – operates
with or without inline lubrication.
LED Indication: Light-emitting diode (LED) indicators of main solenoid operation, reset solenoid operation,
and status indicator condition.
Status Indicator: Includes a pressure switch with both normally open (NO) and normally closed (NC)
contacts to provide status feedback to the control system indicating whether the valve is in the lockout or
ready-to-run condition.
Transducer (optional): For monitoring of downstream pressure in the system.
Silencers: All models include high flow, clog resistant silencers.
Control Reliable Modular Double Valves
with Integrated Soft Start
M DM2® Series C
Air Dump / Release
U.S. Patent
No. 6840258, 6840259
(Worldwide Patents
Pending)
4
Simplified Schematic
F
F3
Valve Dimensions – inches (mm)
ISO 13849-1:2006
Category 4 PL e
applications
HSM 15022
Sicherheit seprüft
tested safety
√
This valve is not designed for controlling clutch/brake mechanisms on mechanical power presses,
see DM2® series D for mechanical power press applications.

F3.17
www.rosscontrols.com
Online Version
Rev. 11/14/16
Status Indicator:
The status indicator pressure switch will actuate when the
main valve is operating normally, and will de-actuate when
the main valve is in the locked-out position or inlet pressure is
removed. This device is not part of the valve lockout function,
but, rather, only reports the status of the main valve. If the
valve is in a ready-to-run condition, a green “STATUS” LED
will be displayed. If the valve is faulted or there is no air
pressure at the inlet, a red “STATUS” LED will be displayed.
Resetting the valve: The valve will remain in the locked-out position, even if the inlet air
supply is removed and re-applied.
A remote reset signal must be applied to reset the valve. A momentary, remote electrical
signal must be applied to the reset solenoid to apply pressure to the reset pistons in the valve.
Actuationoftheresetpistonphysicallypushesthe mainvalve elementsto theirclosedposition.
Inlet air fully pressurizes the crossovers and holds
the inlet poppets on seat. Actuation of the reset
pistonopenstheresetpoppet,thereby,immediately
exhausting pilot supply air, thus, preventing valve
operation during reset (Reset adapter added to
illustration.). De-actuation of reset pistons causes
the reset poppets to close and pilot supply to fully
pressurize. Reset air pressure is applied by a 3/2
normally closed solenoid, or a manual push button
mountedontheresetadapterinthe top valvecover.
A green“RESET SOL.” LED will be displayed when
the reset solenoid is energized.
The reset procedure is as follows:
•Remove the electrical signals to the main coils
•Ensure there is air supplied to the valve
•Energize the reset solenoid for a minimum of 200 ms
• Allow a 200 ms delay after de-energizing the reset solenoid and re-energizing the main
solenoids
Valve locked-out: Whenever the valve elements operate in a sufficiently asynchronous manner, either on
actuation or de-actuation, the valve will move to a locked-out position. In the locked-out position, one crossover
and its related timing chamber will be exhausted, and the other crossover and its related timing chamber will be
fully pressurized. The valve element (side B) that is partially actuated has pilot air available to fully actuate it, but
no air pressure on the return piston to fully de-actuate the valve element.
Air pressure in the crossover acts on the differential of side B stem diameters creating a latching force. Side A is in
a fully closed position, and has no pilot air available to actuate, but has full pressure on the inlet poppet and return
piston to hold the element in the fully closed position. Inlet air flow on side A into its crossover is restricted, and
flows through the open inlet poppet on side B, through the outlet into the exhaust port, and from the exhaust port
to atmosphere. Residual pressure in the outlet is less than 1% of inlet pressure. The return springs are limited in
travel, and can only return the valve elements to the intermediate (locked-out) position. Sufficient air pressure acting
on the return pistons is needed to return the valve elements to a fully closed position.
Valve actuated: Energizing the pilot valves simultaneously applies
pressure to both pistons, forcing the internal parts to move to their
actuated (open) position, where inlet air flow to crossover passages is
fully open, inlet poppets are fully open and exhaust poppets are fully closed. The outlet is then pressurized at
a rate allowed by the fixed orifice and the adjusted flow control. Once the air pressure in the outlet chamber
reaches approximately 60% of inlet pressure, the air piloted 2-way normally closed poppet valve opens fully
and the pressure in the inlet, crossovers, outlet, and timing chambers are quickly equalized. The adjustable
flow control will control the time it takes for the outlet air pressure to reach approximately 60% of inlet pressure.
Green “SOL. 1” and SOL. 2” LEDs will be displayed when the main solenoids are energized.
De-energizing the pilots quickly causes the valve elements to return to the ready-to-run position.
E
X
H
A
U
S
T
T
T
T
T
T
T
I
N
L
E
T
O
U
T
L
E
T
EXHAUST
OUTLET
INLET
AB
ADJUSTING NEEDLE
E
X
H
A
U
S
T
T
T
T
T
T
T
T
I
N
L
E
T
O
U
T
L
E
T
EXHAUST
OUTLET
INLET
AB
ADJUSTING NEEDLE
EXHAUST
OUTLET
INLET
AB
ADJUSTING NEEDLE
Status indicator
in normal
ready-to-run position
Valve de-actuated (ready-to-run): The flow of inlet air pressure to the inlet chamber of the main valve
internals is restricted by a fixed orifice and an adjustable flow control as well as an air piloted 2-way normally
closed poppet valve. The flow of inlet air pressure into the crossover passages is restricted by the size of
the passage between the stem and the valve body opening. Flow is sufficient to quickly pressurize pilot
supply/timing chambers A and B. The inlet poppets prevent air flow from crossover passages into the outlet
chamber. Air pressure acting on the inlet poppets and return pistons securely hold the valve elements in
the closed position. (Reset adapter omitted for clarity.)
Reset
port
Pressure
Switch
Exh.
Exh. Exh.
2
1
3
E
X
H
A
U
S
S
T
T
T
T
T
T
I
N
L
E
T
O
U
T
L
E
T
EXHAUST
OUTLET
INLET
AB
ADJUSTING NEEDLE
Schematic - Valve de-actuated
Control Reliable Modular Double Valves
with Integrated Soft Start
M DM2® Series C
Valve Operation
F
F3

F3.18 © 2016, ROSS CONTROLS®. All Rights Reserved.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS, WARNINGS on the inside back cover.
Online Version
Rev. 11/14/16
Mounting Accessories
Digital Pressure Transducer Precision digital pressure transducer with 5 pin female connection
• Two PNP digital outputs which may be set individually, 4-20 mA analog output
• Three operation modes: Easy, Window and Hysteresis
• Selectable response times to eliminate output chattering
• Powered by 12-24 vots DC
• 6 pressure unit conversions
• Lockable keypad
• Fast zero reset
BROWN
Input
Power +
GREY
Power Input
WHITE
Digital
Output Signal
BLUE
Digital
Output 2 Signal
BLACK
Analog
Output Signal
12
3
4
5
Wiring Kits
Mounting Bracket Kit includes bracket and bolts
to mount to the valve end plate.
At least two mounting brackets should be used.
This can consist of two clamp mounting brackets or one clamp mounting bracket and one mounting bracket Kit Number 2433H77.
0.75 (19.1)
0.375
(9.5)
3.2 (81.3)
0.34
(81.3)
0.25
(6.4)
0.44
(11.1) 3.0 (76.2)
3.875 (98.4)
8X
R 0.13
3.0
(76.2)
3.0 (76.2)
R 0.063
90°
1.82
(46.2)
Control Reliable Modular Double Valves
with Integrated Soft Start
M DM2® Series C
Accessories & Options
Model Number
2447H77
Kit Number Length
2431H77 Wiring Kit - 5 meters (16.4 feet). Includes two cords, and the cord grips.
2432H77 Wiring Kit with Transducer - 5 meters (16.4 feet). Includes three cords, and the cord grips.
Kit Number 2433H77
F
An extra port block can be placed between modules to provide
two auxiliary 1/4 NPTF ports. Its mounting position can be
rotated to obtain the most convenient operating orientation. If
only one auxiliary port is to be used, the unused port must be
closed with a pipe plug. (The inlet and outlet are not threaded.)
Specially designed clamps provide a quick and easy assembly
or disassembly of MD3TM modules. Two allen-head bolts quickly
tighten or loosen the clamp using a 5/32 or 4mm hex key. The
clamp contains a plate carrying two O-rings to provide positive
sealing between modules.
Order clamp by part number R-A118-105.
Combined clamp and bracket (below) can be ordered by part
number R-A118-105M.
Mounting Bracket
Part No. R-A118-103
Module Connecting Clamp
Part No. R-A118-105
Combined Clamp & Bracket
Part No. R-A118-105M
Port Size Part Number*
1/4 R-118-106-2
3/8 R-118-106-3
1/2 R-118-106-4
* For BSPP threads, add a “W” suffix to the model number,
e.g., R-118-106-2W.
Port
Size
Male Part
Number*
Port
Size
Female Part
Number*
1/4 R-118-109-2F 1/4 R-118-100-2
3/8 R-118-109-3F 3/8 R-118-100-3
1/2 R-118-109-4F 1/2 R-118-100-4
3/4 R-118-109-6F 3/4 R-118-100-6
* For BSPP threads, add a “W” suffix to the model number,
e.g., R-118-109-2FW.
Clamp for Module Connections
Two brackets are normally used to mount an FRL to a vertical
surface. The mounting bracket attaches to the module
connecting clamp (see above) with a single screw. Each bracket
then employs two bolts (1/4” or 6mm) to connect the assembly
to the mounting surface.
Order bracket and screw by part number R-A118-103.
Combined bracket and
clamp (above) can be ordered by part
number R-A118-105M.
Mounting Brackets
Either male or female end ports can be attached to threaded inlet
and outlet lines. This allows all modules of an FRL assembly to
be removed easily and quickly without having to unthread the
end modules. The end ports are attached to the modules with
clamps (see at left). End ports can be included in an assembled
FRL or ordered separately by the following part numbers:
Male and Female End Ports
Extra Port Blocks
Mounting Bracket Kit
F3

IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS, WARNINGS on the inside back cover.
F3.19www.rosscontrols.com
Online Version
Rev. 11/14/16
DM1Series E Double Valves, Manual Lockout L-O-X® Valves with Integrated Filter/Regulator
DM2® Series E Double Valves, Manual Lockout L-O-X® Valves with Integrated Filter/Regulator
NOTE: Per specications and regulations, these products are dened as energy isolation devices, NOT AS EMERGENCY STOP DEVICES.
RC Series
Air Entry Packages
with DM Series E Double Valves - Control Reliable Energy Isolation
Pre-engineered panel-mounted design with air entry via a filter and regulator “FR”, or filter, regulator
and lubricator “FRL”.
Includes DM1 Series E Double Valve with Monitoring:
a) Self-contained dynamic monitoring system requires no further valve monitoring controls,
b) Ready-to-run: If an abnormality clears itself upon the removal of electricity to both solenoids, it
will be ready-to-run again. It does not remember the abnormality & stay in a locked-out state until
intentionally reset. Therefore, cumulative abnormalities may go undetected,
c) Status indicator switch for valve condition (ready-to-run) feedback.
Mounting plate included.
Air Entry Combination
Port Size
Model Number*Air Entry
Type
CVDimensions inches (mm)
1, 2 3 1-2 2-3 Length Width Depth
Cat-4 with DM1 Series E 1/4 1/2 RC304-09** FR 1.3 2.4 13.00 (330.0) 11.00 (279.0) 5.40 (134.7)
Cat-4 with DM1 Series E 3/8 1/2 RC306-09** FR 2.2 2.4 13.00 (330.0) 11.00 (279.0) 5.40 (134.7)
Cat-4 with DM1 Series E 1/4 1/2 RC304L-09** FRL 1.3 2.4 13.00 (330.0) 11.00 (279.0) 5.40 (134.7)
Cat-4 with DM1 Series E 3/8 1/2 RC306L-09** FRL 2.2 2.4 13.00 (330.0) 11.00 (279.0) 5.40 (134.7)
*NPT pressure port threads.
** Specify voltage when ordering. Insert voltage code: “W” = 24 volts DC; “Z” = 110-120 volts AC, 50/60 Hz; e.g., RC304-09W.
M12 connectors available, consult ROSS.
Standard Air Entry Packages supplied with metal bowl and manual drain. For automatic drain insert an “A” before the dash
(-) in the model number, e.g., RC304A-09.
4
Pre-engineered panel-mounted design with air entry via a filter and regulator “FR”, or filter, regulator
and lubricator “FRL”.
Includes DM2® Series E Double Valve with Monitoring & Memory:
a) Self-contained dynamic monitoring system requires no further valve monitoring controls,
b) Dynamic memory of abnormal function prevents unintentional reset with removal of air or electricity.
All necessary features for safety applications are included:
a) Electrical reset valve,
b) Status indicator switch for valve condition (ready-to-run) feedback.
Mounting plate included.
Air Entry
Combination
Port Size Model
Number*
Air Entry
Type
CVDimensions inches (mm)
1, 2 3 1-2 2-3 Length Width Depth
Cat-4 with DM2®Series E 1/4 1/2 RC404-09** FR 1.3 2.4 13.00 (330.0) 11.00 (279.0) 5.40 (134.7)
Cat-4 with DM2®Series E 3/8 1/2 RC406-09** FR 2.2 2.4 13.00 (330.0) 11.00 (279.0) 5.40 (134.7)
Cat-4 with DM2®Series E 1/4 1/2 RC404L-09** FRL 1.3 2.4 13.00 (330.0) 11.00 (279.0) 5.40 (134.7)
Cat-4 with DM2®Series E 3/8 1/2 RC406L-09** FRL 2.2 2.4 13.00 (330.0) 11.00 (279.0) 5.40 (134.7)
*NPT pressure port threads.
** Specify voltage when ordering. Insert voltage code: “W” = 24 volts DC; “Z” = 110-120 volts AC, 50/60 Hz; e.g., RC404-09W.
M12 connectors available, consult ROSS.
Standard Air Entry Packages supplied with metal bowl and manual drain. For automatic drain insert an “A” before the
dash (-) in the model number, e.g., RC404A-09.
Pressure
Switch
not shown
Custom designs available, consult ROSS.
4
Custom designs available, consult ROSS.
F
F3

F3.20 © 2016, ROSS CONTROLS®. All Rights Reserved.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS, WARNINGS on the inside back cover.
Online Version
Rev. 11/14/16
DM2® Series C Double Valves, Manual Lockout L-O-X® Valves with Filter and Regulator
Custom designs available, consult ROSS.
Air Entry Packages
DM Series C Double Valves - Control Reliable Energy Isolation RC Series
Pre-engineered panel-mounted design with air entry via a filter and regulator “FR”, or filter,
regulator and lubricator “FRL”
Includes DM2® Series C Double Valve with Monitoring & Memory:
a) Self-contained dynamic monitoring system requires no further valve monitoring controls,
b) Dynamic memory of abnormal function prevents unintentional reset with removal of air or electricity
All necessary features for safety applications are included:
a) Electrical reset valve,
b) Status indicator switch for valve condition (ready to run) feedback
4
Air Entry
Combination
Port Size Model
Number*
Air Entry
Type
CVDimensions inches (mm)
1, 2 3 1-2 2-3 Length Width Depth
Cat-4 with DM2®Series C 1/2 1/2 RC408-06** FR 3 10 24.0 (610) 14.5 (369) 7.4 (187)
Cat-4 with DM2®Series C 1/2 1/2 RC408L-06** FRL 4.4 13 24.0 (610) 15.7 (399) 8.3 (211)
Cat-4 with DM2®Series C 3/4 3/4 RC412-06** FR 4.4 13 27.0 (686) 19.0 (483) 9.0 (229)
Cat-4 with DM2®Series C 3/4 3/4 RC412L-06** FR 3 10 24.0 (610) 14.5 (369) 7.4 (187)
Cat-4 with DM2®Series C 1 1 RC416-06** FRL 4.4 13 24.0 (610) 15.7 (399) 8.3 (211)
Cat-4 with DM2®Series C 1 1 RC416L-06** FRL 4.4 13 31.0 (788) 19.0 (483) 9.0 (229)
*NPT pressure port threads.
** Specify voltage when ordering. Insert voltage code: “W” = 24 volts DC; “Z” = 110-120 volts AC, 50/60 Hz; e.g., RC408-06W.
M12 connectors available, consult ROSS.
Standard Air Entry Packages supplied with metal bowl and manual drain. For automatic drain insert an “A” before the dash
(-) in the model number, e.g., RC408A-06.
MDM2® Series C Double Valves with Integrated Soft Start, Manual Lockout L-O-X® Valves
with Integrated Filter/Regulators
Pre-engineered panel mountable design with air entry via a filter and regulator “FR”, or filter,
regulator and lubricator “FRL”
Includes M DM2® Series C Double Valve with Monitoring & Memory:
a) Self-contained dynamic monitoring system requires no further valve monitoring controls,
b) Dynamic memory of abnormal function prevents unintentional reset with removal of air or electricity
All necessary features for safety applications are included:
a) Electrical reset valve,
b) Status indicator switch for valve condition (ready to run) feedback
M5 1 1 X A2 1 2 1 1
HOW TO ORDER
(Choose your options (in red) to configure your valve assembly model number.)
PIPE SIZE
1/2 NPTF 4
3/4 NPTF 5
1/2 BSPP D
3/4 BSPP E
LOCKOUT VALVE TYPE
Modular L-O-X®1
L-O-X®2
No L-O-X® X
FILTER-REGULATOR
(0-125 psi with 0-200 gauge)
5 Micron, Manual Drain, Metal Bowl 1
5 Micron, Auto Drain, Metal Bow 2
None X
LUBRICATOR
FILL TYPE
Fill Port 2
No lubricator X
EXTRA PORTS
(Prior to M DM2
®
Exhaust Valve)
1/4 2
3/8 3
1/2 4
None X
M DM2
®
VALVE
Without Transducer 1
With Transducer 3
EXTRA PORTS
(Downstream of M DM2
®
)
1/4 2
3/8 3
1/2 4
None X
DOWNSTREAM PRESSURE SWITCH
(includes 1/4” Extra Port)
586A86 1
None X
CABLE OPTIONS
Yes 1
No X
4
Custom designs available, consult ROSS.
Explosion proof solenoid pilot available, for more information consult ROSS.
F
F3
NOTE: Per specications and regulations, these products are dened as energy isolation devices, NOT AS EMERGENCY STOP DEVICES.

10 © 2016, ROSS CONTROLS®. Content subject to change.Online Version
Rev. 11/14/16
General Information
Thread Types by Model Prefix Letter
Pneumatic Port Prefix Threaded Electrical
Threads Letter Opening
NPT (ANSI B2.1) None NPT
ISO 228 - DIN 259 Parallel, BSPP#C*—
ISO 228 - DIN 259 Parallel, BSPP#DG
ISO 228 - JIS B0203 Tapered#JISO
SAE 1926- ISO 11926 SNPT
* Used only for filters, regulators, lubricators.
# ISO 228 threads superseds BSPP, G and JIS thread types.
Order Placement
For order placement, consult ROSS or your local ROSS distributor.
For a current list of countries and local distributors, visit ROSS’ website at www.rosscontrols.com.
Standard Specifications
The standard specifications for the products on each page of this
catalog are given on the same page or referenced. For solenoid pilot
valves, models with internal pilot supply are listed. Most models are
also available for use with external pilot supply or have a built-in pilot
supply selector valve.
Theproducts inthiscatalog areintended for use inindustrial pneumatic
systems. Mostproducts are adaptable to otheruses andconditions not
covered by the standard specifications given in this catalog. Weights
shown are approximate and are subject to change. Dimensions given,
unless otherwise noted, are envelope dimensions (not for mounting).
Consult ROSS for further information.
Port Threads
Ports of valves and bases described in this catalog have NPT (ANSI
B2.1) threads. Other thread types can be specified by putting an
appropriate prefix letter on the model or part number when ordering.
Flow Ratings
Flow ratings are expressed as CVwhere CV= 1 corresponds to a
steady state air flow of approximately 32 scfm under the following
conditions:
Inlet pressure = 100 psig (6.7 bar)
Pressure drop = 10 psi (0.69 bar)
Air temperature = 68°F (20°C)
Relative humidity = 36%
Note: Because widely differing test standards are used to measure CV
values, the figures given in this catalog should not be used to compare
ROSS valves with those of other makers. The CVratings given here
are intended only for use with performance charts published by ROSS.
The CVratings are averages for the various flow paths through the
valve and are for steady flow conditions.
Approvals and Certifications
ROSSproducts aredesigned to meeta numberof industrial standards,
including the Canadian Standards Association (C.S.A.) guidelines.
For more information on specific product approvals, contact your local
distributor or ROSS.
Solenoids
All ROSS standard solenoids are rated for continuous duty (unless
noted otherwise) and will operate the valve within the air pressure
range specified in this catalog.
Explosion-Proof Solenoid Pilot available, for more information
consult ROSS.
Voltage & Hertz
When ordering a solenoid valve, also specify the desired solenoid
voltage and hertz.
Recommended Solenoid Voltages: 100-110 volts AC, 50 Hz;
100-120 volts AC, 60 Hz; 24 volts DC; 110 volts DC.
In addition, the following voltages are available:
200, 220 volts AC, 50 Hz
200, 240, 480 volts AC, 60 Hz
24, 48, 220 volts AC, 50 Hz
240 volts AC, 60 Hz
200, 220 volts AC, 50 Hz
200, 240 volts AC, 60 Hz.
For example: Model 2773B5001, 120 volts AC, 60 Hz.
Model W6076B2401, 220 volts AC, 50 Hz.
Please note that not all congurations are available for all models.
For additional information or help with voltage configuration, please
contact your local distributor or ROSS.
Port Identification
Valve symbols in this catalog conform to the ISO 1219-1:1991
standard of the International Organization for Standardization (ISO)
and the SAE J2051 standard of the Society of Automotive Engineers
(SAE) respectively.
Information or Technical Assistance
For additional information or application assistance concerning ROSS
products, consult ROSS or your local ROSS distributor (see contact
information on the back cover).
Voltage Types by Model Suffix Letter
Voltage Suffix Letter
120 volts AC Z
220 volts AC Y
12 volts DC H
24 volts DC W
48 volts DC M
90 volts DC K
110 volts DC P
125 volts DC C

11
www.rosscontrols.com
Online Version
Rev. 11/14/16
CAUTIONS, WARNINGS and STANDARD WARRANTY
PRE-INSTALLATION or SERVICE
1. Before servicing a valve or other pneumatic component, be
sure that all sources of energy are turned off, the entire pneumatic
system is shut off and exhausted, and all power sources are locked
out (ref: OSHA 1910.147, EN 1037).
2. All ROSS products, including service kits and parts, should
be installed and/or serviced only by persons having training and
experience with pneumatic equipment. Because any installation
can be tampered with or need servicing after installation, persons
responsible for the safety of others or the care of equipment
must check every installation on a regular basis and perform all
necessary maintenance.
3. All applicable instructions should be read and complied with
before using any fluid power system in order to prevent harm to
persons or equipment. In addition, overhauled or serviced valves
must be functionally tested prior to installation and use. If you have
any questions, call your nearest ROSS location listed on the cover
of this document.
4. Each ROSS product should be used within its specification
limits. In addition, use only ROSS parts to repair ROSS products.
WARNING: Failure to follow these directions can adversely
affect the performance of the product or result
in the potential for human injury or damage to
property.
FILTRATION and LUBRICATION
5. Dirt, scale, moisture, etc. are present in virtually every air system.
Although some valves are more tolerant of these contaminants than
others, best performance will be realized if a filter is installed to
clean the air supply, thus preventing contaminants from interfering
with the proper performance of the equipment. ROSS recommends
a filter with a 5-micron rating for normal applications.
6. All standard ROSS filters and lubricators with polycarbonate
plastic bowls are designed for compressed air applications only.
Do not fail to use the metal bowl guard, where provided, to
minimize danger from high pressure fragmentation in the event of
bowl failure. Do not expose these products to certain fluids, such
as alcohol or liquefied petroleum gas, as they can cause bowls to
rupture, creating a combustible condition, hazardous leakage, and
the potential for human injury or damage to property. Immediately
replace a crazed, cracked, or deteriorated bowl. When bowl gets
dirty, replace it or wipe it with a clean dry cloth.
7. Only use lubricants which are compatible with materials
used in the valves and other components in the system.
Normally, compatible lubricants are petroleum based oils with
oxidation inhibitors, an aniline point between 180°F (82°C) and
220°F (104°C), and an ISO 32, or lighter, viscosity. Avoid oils
with phosphate type additives which can harm polyurethane
components, potentially leading to valve failure which risks human
injury, and/or damage to property.
AVOID INTAKE/EXHAUST RESTRICTION
8. Do not restrict the air flow in the supply line. To do so could
reduce the pressure of the supply air below the minimum
requirements for the valve and thereby cause erratic action.
9. Do not restrict a valve’s exhaust port as this can adversely
affect its operation. Exhaust silencers must be resistant to clogging
and must have flow capacities at least as great as the exhaust
capacities of the valves. Contamination of the silencer can result
in reduced flow and increased back pressure.
WARNING: ROSS expressly disclaims all warranties and
responsibility for any unsatisfactory performance
or injuries caused by the use of the wrong type,
wrong size, or an inadequately maintained silencer
installed with a ROSS product.
POWER PRESSES
10. Mechanical power presses and other potentially hazardous
machinery using a pneumatically controlled clutch and brake
mechanism must use a press control double valve with a monitoring
device. A double valve without a self-contained monitoring device
should be used only in conjunction with a control system which
assures monitoring of the valve. All double valve installations
involving hazardous applications should incorporate a monitoring
system which inhibits further operation of the valve and machine in
the event of a failure within the valve mechanism.
ENERGY ISOLATION/EMERGENCY STOP
11. Per specifications and regulations, ROSS L-O-X® and L-O-X®
with EEZ-ON® operation products are defined as energy isolation
devices, NOT AS EMERGENCY STOP DEVICES.
All products sold by ROSS CONTROLS are warranted for a one-year period
[withthe exception ofall Filters, Regulators andLubricators (“FRLs”)which are
warranted for a period of seven years] from the date of purchase to be free of
defects in material and workmanship. ROSS’obligation under this warranty is
limited to repair or replacement of the product or refund of the purchase price paid solely at the discretion of ROSS and provided
such product is returned to ROSS freight prepaid and upon examination by ROSS is found to be defective.This warranty becomes
void in the event that product has been subject to misuse, misapplication, improper maintenance, modification or tampering.
THE WARRANTY EXPRESSED ABOVE IS IN LIEU OF AND EXCLUSIVE OF ALL OTHER WARRANTIES AND ROSS EXPRESSLY
DISCLAIMS ALL OTHER WARRANTIES EITHER EXPRESSED OR IMPLIED WITH RESPECT TO MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. ROSS MAKES NO WARRANTY WITH RESPECT TO ITS PRODUCTS MEETING THE PROVISIONS
OF ANY GOVERNMENTAL OCCUPATIONAL SAFETY AND/OR HEALTH LAWS OR REGULATIONS.IN NO EVENT IS ROSS LIABLETO
PURCHASER, USER, THEIR EMPLOYEES OR OTHERS FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES WHICH MAY RESULT
FROM A BREACH OF THE WARRANTY DESCRIBED ABOVE OR THE USE OR MISUSE OF THE PRODUCTS. NO STATEMENT OF
ANY REPRESENTATIVE OR EMPLOYEE OF ROSS MAY EXTEND THE LIABILITY OF ROSS AS SET FORTH HEREIN.
STANDARD WARRANTY
