Rosslare AY-D09M Assembly instructions

AY-Dx9M Family
Indoor Multi-Format Readers
Installation and Programming Manual
Models:
AY-D09M
AY-D19M

Copyright © 2014 by Rosslare. All rights reserved.
This manual and the information contained herein are proprietary to ROSSLARE
ENTERPRISES LIMITED and/or its related companies and/or subsidiaries’
(hereafter: "ROSSLARE"). Only ROSSLARE and its customers have the right to
use the information.
No part of this manual may be re-produced or transmitted in any form or by any
means, electronic or mechanical, for any purpose, without the express written
permission of ROSSLARE.
ROSSLARE owns patents and patent applications, trademarks, copyrights, or
other intellectual property rights covering the subject matter in this manual.
TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN
THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS
AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND
TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION
MAY RESULT IN LEGAL PROCEEDINGS.
The furnishing of this manual to any party does not give that party or any third
party any license to these patents, trademarks, copyrights or other intellectual
property rights, except as expressly provided in any written agreement of
ROSSLARE.
ROSSLARE reserves the right to revise and change this document at any time,
without being obliged to announce such revisions or changes beforehand or
after the fact.

Table of Contents
AY-Dx9M Family Installation and Programming Manual iii
Table of Contents
1. Introduction ................................................................7
1.1 Reader/Controller Types........................................................... 7
1.2 Key Features ........................................................................... 7
1.3 Box Content ........................................................................... 8
1.4 Ancillary Equipment ................................................................ 8
2. Technical Specifications..............................................9
3. Installation ................................................................11
3.1 Mounting and Wiring the AY-Dx9M....................................... 11
4. Transmit Mode ..........................................................13
5. Programming the AY-Dx9M......................................14
5.1Entering Programming Mode................................................. 15
5.2 Exiting Programming Mode ................................................... 15
5.3 Selecting Keypad Transmission Format ................................... 16
5.3.1 Keypad Transmission Format Option Number ...............................17
5.4 Selecting Proximity Card Transmission Format (AY-D19M model
only)..................................................................................... 22
5.4.1 Wiegand Card + PIN Transmission Format ....................................22
5.5 Changing the Programming Code.......................................... 24
5.6 Changing the Facility Code.................................................... 24
5.7 Return to Factory Default Settings.......................................... 25
5.8 Replacing a lost Programming Code....................................... 26
A. Limited Warranty ......................................................27

List of Figures
iv AY-Dx9M Family Installation and Programming Manual
List of Figures
Figure 1: AY-Dx9M Layout ..............................................................................11
Figure 2: AY-Dx9M Wiring ..............................................................................12

List of Tables
AY-Dx9M Family Installation and Programming Manual v
List of Tables
Table 1: Programming Menus..........................................................................14
Table 2: Keypad Transmission Format..............................................................17

Notice and Disclaimer
vi AY-Dx9M Family Installation and Programming Manual
Notice and Disclaimer
This manual’s sole purpose is to assist installers and/or users in the safe and
efficient installation and usage of the system and/or product, and/or software
described herein.
BEFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM,THE INSTALLER AND THE
USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY
REQUIREMENTS AND OPERATING PROCEDURES.
The system must not be used for purposes other than those for which it
was designed.
The use of the software associated with the system and/or product, if
applicable, is subject to the terms of the license provided as part of the
purchase documents.
ROSSLARE exclusive warranty and liability is limited to the warranty and
liability statement provided in an appendix at the end of this document.
This manual describes the maximum configuration of the system with the
maximum number of functions, including future options. Therefore, not all
functions described in this manual may be available in the specific system
and/or product configuration you purchased.
Incorrect operation or installation, or failure of the user to effectively
maintain the system, relieves the manufacturer (and seller) from all or any
responsibility for consequent noncompliance, damage, or injury.
The text, images and graphics contained in the manual are for the purpose
of illustration and reference only.
All data contained herein subject to change without prior notice.
In no event shall manufacturer be liable for any special, direct, indirect,
incidental, consequential, exemplary or punitive damages (including,
without limitation, any and all damages from business interruption, loss of
profits or revenue, cost of capital or loss of use of any property or capital or
injury).
All graphics in this manual are for reference only, some deviation between
the image(s) and the actual product may occur.
All wiring diagrams are intended for reference only, the photograph or
graphic of the PCB(s) are intended for clearer illustration and
understanding of the product and may differ from the actual PCB(s).

Introduction
AY-Dx9M Family Installation and Programming Manual 7
1. Introduction
The AY-Dx9M series are programmable indoor readers that allow
entry via a personal identification number (PIN) and/or by presenting a
proximity card. The keypad can be programmed to output eight
different data formats. The AY-D19M supports multiple proximity
card formats to provide a high level of compatibility and connectivity
with host controllers.
1.1 Reader/Controller Types
The two types of units described in this manual are:
Keypad Type PIN Proximity
AY-D09M Standard 
AY-D19M Standard 
1.2 Key Features
Built-in proximity card reader (125 kHz ASK modulation) (AY-
D19M model only)
Programmable Proximity Card Transmission Format (AY-D19M
model only)
Clock & Data
Wiegand 26-Bit
Wiegand Card + PIN
Built-in keypad for PIN code entry
Programmable keypad transmission format
Built-in case and back tamper
Programmable Facility code
Two tri-colored LEDs
Internal buzzer provides audible interface feedback

Introduction
8 AY-Dx9M Family Installation and Programming Manual
Comes with mounting template for easier installation
Comes with installation kit that includes a security screw and a
security screw tool
1.3 Box Content
Before beginning, verify that all of the following is in the box. If
anything is missing, please report the discrepancy to your nearest
Rosslare office.
AY-Dx9M access control unit
Installation kit
Installation and operating instructions
1.4 Ancillary Equipment
Additional non-supplied equipment required:
Compatible host controller
Power supply – 5 to 16 VDC (from a regulated power supply)
Other Rosslare accessories can be found at Rosslare's website:
http://www.rosslaresecurity.com

Technical Specifications
AY-Dx9M Family Installation and Programming Manual 9
2. Technical Specifications
Electrical
Characteristics
AY-D09M AY-D19M
Power Supply Type Linear type (recommended)
Operating Voltage Range 5–16 VDC
Maximum Input Current
(not including attached
devices)
Standby: 55 mA
Max: 100 mA
Card Read Distance* N/A 80 mm (3.0 in.)
Proximity Card Modulation N/A •Wiegand 26-Bit, ASK
at 125 kHz
•Clock & Data, ASK at
125 kHz
Proximity Card Compatibility N/A All 26-Bit EM cards
Keypad Transmit Format •Single Key, Wiegand 6-Bit (Rosslare
Format)
•Single Key, Wiegand 6-Bit with Nibble
and Parity Bits
•Single Key, Wiegand 8-Bit, Nibbles
Complemented
•4 Keys Binary + Facility Code, Wiegand
26-Bit
•1 to 5 Keys + Facility Code, Wiegand
26-Bit
•6 Keys BCD and Parity Bits, Wiegand
26-Bit
•Single Key, 3x4 Matrix Keypad
•1 to 8 Keys BCD, Clock & Data
Tamper Only with Rosslare controllers AC-015, AC-
020, and AC-115
* Measured using a Rosslare proximity card or equivalent. Range also
depends on electrical environment and proximity to metal.

Technical Specifications
10 AY-Dx9M Family Installation and Programming Manual
Environmental Characteristics
Operating Temp. Range -31°C to 63°C (-24°F to 145°F)
Operating Humidity Range 0 to 95% (non-condensing)
Dimensions AY-D09M AY-D19M
Length x Width x Depth 122 x 75 x 24 mm (4.8 x 3.0 x 0.9 in.)
Weight 110 g (3.9 oz) 117 g (4.1 oz)

Installation
AY-Dx9M Family Installation and Programming Manual 11
3. Installation
Installation of an RFID reader adjacent to metallic surfaces
might alter the reader’s specifications. To diminish this
interference, use a plastic spacer when mounting the reader.
3.1 Mounting and Wiring the AY-Dx9M
The AY-Dx9M is designed to be easily mounted to a US Gang Box.
Before starting, select the location to mount the AY-Dx9M reader.
This location should be at shoulder height.
To mount and wire the unit:
1. Remove the Bezel screw (Figure 1).
Figure 1: AY-Dx9M Layout
2. Screw the reader onto a US Gang Box through the two mounting
holes provided (Figure 1).
LEDs
Bezel Screw
Mounting Hole
Mounting Hole

Installation
12 AY-Dx9M Family Installation and Programming Manual
3. Pass the wires through the exit/entry holes and attach them to
the reader’s terminal blocks (Figure 2).
Figure 2: AY-Dx9M Wiring
4. Replace the reader's bezel and replace the factory default screw
with the security screw that is provided in the installation kit. A
security screw tool is also provided in the installation kit.
To Controller
(+)
(-)
D0
D1

Transmit Mode
AY-Dx9M Family Installation and Programming Manual 13
4. Transmit Mode
When the AY-Dx9M is in Transmit mode, it is ready to receive data
from a presented proximity card (AY-D19M only) or an entered PIN
code.
When the reader is in Transmit mode, the
Mode LED is red and the Program LED is off.
When a proximity card or keyboard entry is being transmitted, the
Mode LED flashes green.
Keyboard data can be sent via one of eight different keypad
transmission formats (see Section 5.3).
For the AY-D19M model, proximity cards presented to the reader are
always sent in Wiegand 26-Bit, Clock & Data, or Wiegand Card + PIN
format formats (see Section 5.4).
Mode
Prog
Red

Programming the AY-Dx9M
14 AY-Dx9M Family Installation and Programming Manual
5. Programming the AY-Dx9M
Programming the AY-Dx9M is done solely via the unit's keypad driven
programming menu system. To reach the programming menu system,
the AY-Dx9M must first be placed into Programming mode (see
Section 5.1).
During the AY-Dx9M's manufacturing process, certain codes and
settings are pre-programmed. These settings are the called the default
factory settings.
Table 1 shows the names of all the AY-Dx9M menus.
Table 1: Programming Menus
Menu Description Menu Number
Selecting Keypad Transmission Format
Single Key, Wiegand 6-Bit (Rosslare format)
Single Key, Wiegand 6-Bit with Nibble + Parity Bits
Single Key, Wiegand 8-Bit, Nibbles Complemented
4 Keys Binary + Facility Code, Wiegand 26-Bit
1 to 5 Keys + Facility code, Wiegand 26-Bit
6 Keys BCD and Parity Bits, Wiegand 26-Bit
Single Key, 3x4 Matrix Keypad
1 to 8 Keys BCD, Clock & Data Single Key
1
Selecting Proximity Card Transmission Format (AY-
D19M model only)
Wiegand 26-Bit
Clock & Data
Wiegand Card + PIN
2
Changing the Programming Code 3
Changing the Facility Code 4
Return to Factory Default Settings 0

Programming the AY-Dx9M
AY-Dx9M Family Installation and Programming Manual 15
5.1 Entering Programming Mode
To enter Programming mode:
1. Press #for 2 seconds.
The Mode LED turns off and the
Program LED turns red.
2. Enter your 4-digit Programming code.
If the Programming code is valid, the
Program LED turns green and the AY-
Dx9M enters Programming mode.
•The factory default Programming code is 1234.
•If a Programming code is not entered within 30 seconds, the AY-
Dx9M returns to Transmit mode.
5.2 Exiting Programming Mode
To exit Programming mode at any time:
1. Press #.
You hear a beep.
The Program LED turns off and the
Mode LED turns red.
This indicates that the AY-Dx9M has returned to Transmit mode.
Wrong entries may reset the reader back to Transmit mode.
While in Programming mode, if no key is pressed for 30 seconds,
the AY-Dx9M exits Programming mode and returns to Transmit
mode.
Mode
Prog
Red
Mode
Prog
Green
Mode
Prog
Red

Programming the AY-Dx9M
16 AY-Dx9M Family Installation and Programming Manual
5.3 Selecting Keypad Transmission Format
The AY-Dx9M has eight different keypad transmission selectable
formats (see Section 5.3.1).
To select a keypad transmission format:
1. Enter Programming mode.
2. Press 1to enter Menu 1.
3. The Mode LED turns red.
Enter the appropriate option number
for the keypad transmission format that
you wish to select.
One beep is emitted on success.
The system returns to Transmit mode.
If an incorrect option number is entered, a long beep is sounded.
The reader returns
to Transmit mode and the keypad transmission
format remains unchanged.
•Only one keypad transmission format can be active at any one time
•When using the keypad transmission format “1 to 8 keys BCD,
Clock & Data" (Option 8), an additional input is required to specify
the number of keys in the PIN code.
Mode
Prog
Green
Mode
Prog
Red
Green
Mode
Prog
Red

Programming the AY-Dx9M
AY-Dx9M Family Installation and Programming Manual 17
5.3.1 Keypad Transmission Format Option Number
See Table 2 to determine the option number for the keypad
transmission format you wish to select.
Table 2: Keypad Transmission Format
Keypad Transmission Format Option Number
Single Key, Wiegand 6-Bit (Rosslare Format)
Single Key, Wiegand 6-Bit with Nibble + Parity Bits
Single Key, Wiegand 8-Bit, Nibbles Complemented
4 Keys Binary + Facility code, Wiegand 26-Bit
1 to 5 Keys + Facility code, Wiegand 26-Bit
6 Keys BCD and Parity Bits, Wiegand 26-Bit
Single Key, 3x4 Matrix Keypad
1 to 8 Keys BCD, Clock & Data Single Key
1*
2
3
4
5
6
7
8
* Option 1 is the default factory setting
More information on each of the different keypad transmission
formats is available below and on the following pages.
5.3.1.1 Single Key, Wiegand 6-Bit (Rosslare Format)
Each key press immediately sends 4 bits with 2 parity bits added; even
parity for the first 3 bits and odd parity for the last 3 bits.
0 = 1 1010 0 6 = 1 0110 0
1 = 0 0001 0 7 = 1 0111 1
2 = 0 0010 0 8 = 1 1000 1
3 = 0 0011 1 9 = 1 1001 0
4 = 1 0100 1 * = 1 1011 1 = "B" in Hexadecimal
5 = 1 0101 0 # = 0 1101 1 = "D" in Hexadecimal

Programming the AY-Dx9M
18 AY-Dx9M Family Installation and Programming Manual
5.3.1.2 Single Key, Wiegand 6-Bit, Nibble & Parities
Each key press immediately sends 4 bits with 2 parity bits added; even
parity for the first 3 bits and odd parity for the last 3 bits.
0 = 0 0000 1 6 = 1 0110 0
1 = 0 0001 0 7 = 1 0111 1
2 = 0 0010 0 8 = 1 1000 1
3 = 0 0011 1 9 = 1 1001 0
4 = 1 0100 1 * = 1 1010 0 = "B" in Hexadecimal
5 = 1 0101 0 # = 1 1011 1 = "C" in Hexadecimal
5.3.1.3 Single Key, Wiegand 8-Bit, Nibbles Complemented
This option inverts the most significant bits in the message leaving the
least 4 significant bits as Binary Coded Decimal (BCD) representation
of the key. The host system receives an 8-bit message.
0 = 11110000 6 = 10010110
1 = 11100001 7 = 10000111
2 = 11010010 8 = 01111000
3 = 11000011 9 = 01101001
4 = 10110100 *= 01011010 = "A" in Hexadecimal
5 = 10100101 # = 01001011 = "B" in Hexadecimal
5.3.1.4 4 Keys Binary + Facility Code, Wiegand 26-Bit
This option buffers 4 keys and outputs keypad data with a three-digit
Facility code like a standard 26-bit card output.
The Facility code is set in Programming Menu number four and can be
in the range 000 to 255. The factory default setting for the Facility
code is 000 (see Section 5.6).
The keypad PIN code must be 4 digits long and can range between
0000 and 9999. On the fourth key press of the 4-digit PIN code, the
data is sent across the Wiegand data lines as binary data in the same
format as a 26-bit card.
If *or #is pressed during PIN code entry, the keypad clears the PIN
code entry buffer, generates a beep and is ready to receive a new 4-
digit keypad PIN code.

Programming the AY-Dx9M
AY-Dx9M Family Installation and Programming Manual 19
If the entry of the 4-digit keypad PIN code is disrupted and no number
key is pressed within 5 seconds, the keypad clears the PIN code entry
buffer, generates a beep, and is ready to receive a new 4-digit keypad
PIN code.
(EP) FFFF FFFF AAAA AAAA AAAA AAAA (OP)
Where: EP = Even parity for first 12 bits
OP = Odd parity for last 12 bits
F = 8-bit Facility code
A = 24-bit code generated from keyboard
5.3.1.5 1 to 5 Keys + Facility Code, Wiegand 26-Bit
This option buffers up to 5 keys and outputs keypad data with a
Facility code like a 26-bit card output.
The Facility code is set in Programming Menu number four and can be
in the range 000 to 254. The factory default setting for the Facility
code is 000 (see Section 5.6).
The keypad PIN code can be one to five digits long and can range
between 1 and 65,535. When entering a keypad PIN code that is less
than 5 digits long, #must be pressed to signify the end of PIN code
entry. For keypad PIN codes that are 5 digits long, on the fifth key
press of the 5-digit PIN code, the data is sent across the Wiegand data
lines as binary data in the same format as a 26-bit card.
If *or #is pressed during PIN code entry or a PIN code greater than
65,535 is entered, the keypad clears the PIN code entry buffer,
generates a beep and is ready to receive a new 4-digit keypad PIN
code.
If the entry of the 1- to 5-digit keypad PIN code is disrupted and a
number key or #is not pressed within 5 seconds, the keypad clears
the PIN code entry buffer, generates a medium length beep and is
ready to receive a new 1 to 5-digit keypad PIN code.
(EP) FFFF FFFF AAAA AAAA AAAA AAAA (OP)

Programming the AY-Dx9M
20 AY-Dx9M Family Installation and Programming Manual
Where: EP = Even parity for first 12 bits
OP = Odd parity for last 12 bits
F = 8-bit Facility code
A = 24-bit code generated from keyboard
5.3.1.6 6 Keys BCD and Parity Bits, Wiegand 26-Bit
Sends buffer of 6 keys, adds parity and sends a 26-bit BCD message.
Each key is a four bit equivalent of the decimal number.
The keypad PIN code must be 6 key presses long. On the sixth key
press of the 6-digit PIN code, the data is sent across the Wiegand data
lines as a BCD message.
If the entry of the 6-digit keypad PIN code is disrupted and a number
key or #is not pressed within 5 seconds, the keypad clears the PIN
code entry buffer, generates a medium length beep and is ready to
receive a new 6-digit keypad PIN code.
(EP) AAAA BBBB CCCC DDDD EEEE FFFF (OP)
Where:
A = First key entered D = Fourth key entered
B = Second key entered E = Fifth key entered
C = Third key entered F = Sixth key entered
5.3.1.7 Single Key, 3x4 Matrix Keypad (MD-P64)
This unique mode is intended to let the host controller scan the AY-
Dx9M keypad while still keeping the proximity card readers Wiegand
26-Bit or Clock & Data formats active.
An optional interface board must be used between the AY-Dx9M and
the host system. Each key press is immediately sent on DATA0 as an
ASCII character at a baud rate of 9600 bits per second.
When a key is pressed, DATA1 is pulled "low" until the key is
released at which point DATA1 is set to "high". This allows the
controller to detect the duration of the key press.
