RS PRO RS-5322 User manual

Instruction Manual
RS-5322
174-9558
PM2.5 AIR QUALITY MONITOR

PM2.5AIRQUALITYMONITOR / EN
05/24/18 Version No. 00
CONTENTS
Title Page
1. SAFETY INFORMATION......................................................................1
2. INTRODUCTION ..................................................................................2
2-1 Features..........................................................................................3
2-2 Applications.....................................................................................4
3. SPECIFICATIONS................................................................................4
4. PARTS & CONTROLS .........................................................................6
4-1 Description of Parts & Control keys.................................................6
4-2 Description of Display .....................................................................9
5. BEFORE OPERATION.......................................................................12
5-1 Power Supply................................................................................12
5-2 Install the Batteries .......................................................................12
5-3 AC Adaptor...................................................................................12
5-4 Air Sampling Port..........................................................................12
6. OPERATING INSTRUCTIONS ...........................................................13
6-1 Selecting Temperature Unit ℃or ℉.............................................13
6-2 Selecting VOCs unit ppm or mg/m
3
...............................................13
6-3 Taking Measurements ..................................................................13
6-4 Setting the TWA Average Time ....................................................14
6-5 Setting the Real-Time...................................................................14
6-6 Taking Maximum (MAX) and Minimum (MIN) Recorder
Measurements..............................................................................14
6-7 Taking Alarm Operation................................................................16
6-8 Clearing Memorized data..............................................................19
6-9 Manual data Memory and Read Mode ..........................................19
6-10 Auto data record .........................................................................20
6-11 User Friendly Calibration Procedure ...........................................21
7. MAINTENANCE..................................................................................23
8. SOFTWARE INSTALLATION AND OPERATION...............................23
9. AIR POLLUTION REGULATION........................................................24

PM2.5AIRQUALITYMONITOR / EN
05/24/18 Version No. 00 1
1. SAFETY INFORMATION
Read and keep the instruction manual.
Follow all warnings and instructions.
To avoid any adhesive particle like oil, etc. to gets into the meter.
Do not install or operate the meter close to noise generator, such as
electric dust collector, fluorescent lighting, etc.
To avoid the meter under mechanical vibration.
To avoid the meter is moisturized.
Do not use the meter near water, such as a sink, wash basin, or bathtub.
Do not spill any liquids onto or into the meter.
Do not push any objects into the openings of the meter.
Do not use any liquid or spray cleaners on the meter. Clean only with
dry cloth.
Do not install or operate near any source of heat.
Do not use the meter in direct sunlight or other bright light source.
Air sampling port shall not be covered when in use.
Place the meter in a flat and safe surface to prevent it from dropping.
Health Disclaimer
While the meter can detect levels of airborne particulates it
cannot determine the health impact for any given individual.
Respiratory ailments and allergic symptoms are caused by a
variety of factor. The meter is not meant to be used in the
treatment or mitigation of any medical condition.
Protected by:
Taiwan: D170348
U.S.A.: US D741,204
China: ZL 2014 3 0428394.1

PM2.5AIRQUALITYMONITOR / EN
2 05/24/18 Version No. 00
2. INTRODUCTION
Particle pollution comes from many different type of sources. Fine
particle (2.5 micrometers in diameter and smaller) include power plants,
industrial processes, vehicle tailpipes, wood stoves, and wildfires.
Coarse particles (between 2.5 and 10 micrometers) come from
crushing and grinding operations, road dust, and some agricultural
operations.
Particle pollution is linked a number of health problems, including
coughing, wheezing, reduced lung function, asthma attacks, heart
attacks and strokes. It also is linked to early death.
Some people may be at greater risk from particle pollution. They
include:
People with cardiovascular disease (diseases of the heart and blood
vessels).
People with lung disease, including asthma and COPD.
Children and teenagers.
Older adults.
Research indicates that obesity or diabetes may increase risk.
New or expectant mothers may want to take precaution to protect the
health of their babies.
Volatile organic compounds (VOCs) definitions: A VOCs is any organic
compound having an initial boiling point less than or equal to 250℃
(480℉) measured at a standard atmospheric pressure of 101.3 kPa.
VOCs play an important role in indoor and outdoor air pollutants.
Vehicular and industrial emissions are the major sources of outdoor VOCs.
Indoor sources are quite numerous including combustion product, cooking,
construction materials, furnishings, paints, varnishes and solvents,
adhesives and caulks, office equipment and consumer products.
Concentrations of many VOCs are consistently higher indoors (up to ten
times higher) than outdoors.

PM2.5AIRQUALITYMONITOR / EN
05/24/18 Version No. 00 3
VOCs include a variety of chemicals that can cause eye, nose and throat
irritation, shortness of breath, headaches, fatigue, nausea, dizziness, and
skin problems. Higher concentrations may cause irritation of the lungs, as
well as damage to the liver, kidney, or central nervous system.
Some VOCs are suspected to cause cancer in humans and have been
shown to cause cancer in animals. The health effects caused by VOCs
depend on the concentration and length of exposure to the chemicals.
The meter is a real-time air quality monitor instrument used to monitor
the concentration of PM2.5, VOCs, humidity and temperature in the
indoor environment.
The meter convert the concentration of PM2.5 and VOCs in the air into
visual data, and evaluate the air quality comprehensively. Visual and audio
alarm will be actived when the air quality reached a critical or alarm limit
values.
2-1 Features
Fine particulate matter (PM2.5) measurement
Volatile organic compounds (VOCs) measurement
Temperature and Humidity measurements
Health index (0 ~ 9) detection and alarm
PM2.5 time weighted average reading
VOCs time weighted average reading
Data hold and MAX/MIN with time stamp function
Six-color LED indication Air Quality Index Category
Preset warning point of buzzer alarm, LED and alarm output
Manual data memory and read function
Auto data record and USB interface to PC

PM2.5AIRQUALITYMONITOR / EN
4 05/24/18 Version No. 00
2-2 Applications
Sensitive individuals can monitor their personal space at home and
work.
Evaluate effectiveness and placement of air filtration devices.
Investigate the effectiveness of different strategies to reduce particulates.
Correlate health related issues to changes in particulate levels.
Indoor air quality investigations.
Evaluate effectiveness of air filtration.
Continuous monitoring of building conditions (continuous
commissioning)
Troubleshooting/optimization of filtration methods.
Sales tool for understanding filtration needs.
3. SPECIFICATIONS
Measurement range:
PM2.5: 0 to 500µg/m
3
VOCs: 0 to 50ppm
Humidity: 1% to 99%R.H.
Temperature: -20℃to +60℃(-4℉to +140℉)
Resolution: 1µg/m
3
, 1ppm, 0.1% R.H., 0.1℃, 0.1℉
Accuracy:
PM2.5: ≦50µg: ±5µg
>50µg: ±10% of reading
VOCs: ±10% of reading ±1ppm
Temperature: ±0.8℃, ±1.5℉
Humidity: ±3%RH (at 25℃, 30 to 80% RH).
±5%RH (at 25℃, 0 to 20% RH and 80 to 100% RH).

PM2.5AIRQUALITYMONITOR / EN
05/24/18 Version No. 00 5
Response time:
PM2.5: ≦1min
VOCs: ≦10min
Humidity: 45% R.H. to 95% R.H. ≦1min
95% R.H. to 45%R.H. ≦3min
Temperature : 10℃/2sec.
Sampling rate: 1 sample/second.
Memory data memory capacity: 39 sets. (Direct reading from LCD
display)
Auto data record capacity: Internal micro SD CARD 4GB.
Max. 99 blocks can be split.
Alarm Output: Open-collect output. Input impedance: 490Ω
Maximum applied Voltage: 24V DC
Maximum drive current: 50mA DC
Operating temperature and humidity: 0℃to 60℃, below 95% R.H.
Storage temperature and humidity: -10℃to 60℃,below 70% R.H.
Power supply:Four 1.5V LR-6/AA size batteries, AC adapter
Battery life:Approx. 5.5 hour (LCD backlight ON and DC FAN ON)
Dimensions: 165mm(L)×93mm(W)×75mm(T), (6.5”L×3.7”W×3”T)
Weight:Approx. 380g (13.4oz)
Accessories: Instruction manual, Battery, PC software, USB
connecting cable, AC adaptor DC6V 1000mA.

PM2.5AIRQUALITYMONITOR / EN
6 05/24/18 Version No. 00
4. PARTS & CONTROLS
4-1 Description of Parts & Control keys:
MODE MEM
MAX
ALM
Health Index

PM2.5AIRQUALITYMONITOR / EN
05/24/18 Version No. 00 7
1. PM2.5 LED Air quality indicator
LED
Color
Air Quality
Index Who Needs to Be Concerned ? PM2.5 (µg/m
3
)
24-hour average
Green
Good
(0 – 50) No one. Air quality is good for everyone. 0.0 – 12.0
Yellow
Moderate
(51 – 100)
Some people may be
unusually sensitive to particle
pollution and may need to take
precautions.
12.1 – 35.4
Aqua
Unhealthy
for Sensitive
Groups
(101 – 150)
Sensitive groups include
people with heart or lung
disease, older adults, children
and teenagers.
35.5 – 55.4
Red Unhealthy
(151~200) Everyone can be affected. 55.5 – 150.4
Purple
Very Unhealthy
(201 – 300) Everyone 150.5 – 250.4
Blue Hazardous
(301 – 500) Everyone 250.5 – 500
2. LCD display.
3. Power and DC FAN control key:
Press this key to turn on the meter.
Press this key again to turn on or off the DC FAN.
When the DC FAN is off, the “PM2.5- - - -” mark is displayed.
Press this key for 3 seconds to turn off the meter.
4. MODE S key:
MODE key: Press this key to circulate the Measurement, PM2.5 VOCs
TWA (Time-Weighted Average) and Current Date reading.
Skey: Press this key for 3 seconds to enter the Setting Mode.
Press ↵key to exit this mode.
SET dAtE: Real-time setting mode.
SET bEEP: Alarm sound on/off setting mode.
SET ALM: Alarm function on/off setting mode.
SET UNit: Temperature unit ℃/℉setting mode.

PM2.5AIRQUALITYMONITOR / EN
8 05/24/18 Version No. 00
SET PM2.5 TWA: PM2.5 TWA average time setting mode.
SET UNit VOCs: VOCs unit ppm or mg/m
3
setting mode.
SET cA: User calibration setting mode.
SET A M Int- : Auto data record interval time setting mode.
SET A M StAt: Auto data record start time setting mode.
SET ALM: Alarm limit values setting mode.
5. MAX ↵key:
↵key: In the setting mode, press this key to store the setting data
and exit.
MAX key:
a). Press this key to enter the MAX (maximum) / MIN (minimum)
Recording Mode.
b). Press this key to circulate the MAX and MIN reading.
c). Press this key for 3 seconds to exit this mode and store one
set recorded datas to memory.
6. MEM key:
key: In the setting mode, press this key to move cursor to the
desired position.
MEM key:
a). Memory function: Press this key one time to store a
measuring data.
b). Clear the stored data: Press and hold this key, then turn
on the meter again. There shows “rEC CLr no” mark on
LCD. Press key to select “YES” or “no” to erase the
memory data.
7. R key:
R key: Press this key for 3 seconds to enter the READ mode, then
press this key again to select the desired stored number of
data to read. Press ↵ key to exit.
key: Press this key to turn on or off the LCD backlight.
key: In the setting mode, press this key to increase the parameter.
8. Air sampling inlet port.

PM2.5AIRQUALITYMONITOR / EN
05/24/18 Version No. 00 9
9. Air sampling outlet port.
10. Mocro-USB: USB input/output connector for input of control signals
and output of measurement data.
11. Alarm output jack: Allow output of a alarm signal is available this
jack.
12. AC adaptor power jack (DC 6V, 1000mA).
13. Battery compartment.
4-2 Description of Display:
ALM
MAX MIN
SET HOLD
Health Index
Month Date
min sec hour
Year
SET : Setting mode indication.
HOLD : In the user calibration setting mode, the measuring data hold
indication for calibration.
MAX: In the MAX/MIN recording mode, maximum value indication.
MIN: In the MAX/MIN recording mode, minimum value indication.

PM2.5AIRQUALITYMONITOR / EN
10 05/24/18 Version No. 00
MAX MIN: In the MAX/MIN recording mode, current value indication.
: Battery capacity indication.
: Low battery indication.
PM2.5: Fine particulate matter (PM2.5) measurement value indication.
PM2.5 TWA: Fine particulate matter (PM2.5) measurement TWA value
indication.
PM2.5- - - -: DC FAN off indication.
µg/m
3
: PM2.5 measurement unit.
: PM2.5 measurement value.
: Disable alarm sound indication.
: Enable alarm sound indication.
ALM: Enable the alarm function indication.
: Measurement value upper to the high limit value or setting the high
limit value indication.
: Measurement value below to the low limit value or setting the low
limit value indication.
VOCs: volatile organic compounds measurement value indication.
VOCs TWA: VOCs measurement TWA value indication.
ppm, mg/m
3
: VOCs measurement units.
: VOCs countdow 600 seconds display.
: VOCs measurement value.
: PM2.5 air particle pollution or VOCs air pollution is based on a scale
from 0 – 9 indication.
0: Very good, 1: Good, 2 – 4: Moderate, 5 – 8: Poor, 9: Very poor.

PM2.5AIRQUALITYMONITOR / EN
05/24/18 Version No. 00 11
: Temperature measurement value.
A: Auto memory indication.
M: Disappeared one time store one sets data into the memory.
M 39: Manual memory address number indication.
R : Read mode indication.
R 39: Recall manual memory address number indication.
Hour 24: PM2.5 or VOCs TWA average time indication or setting.
: Relative humidity measurement value.
Year Month Date hour min sec: Real-time or MAX/MIN recorded stamp
time indication.

PM2.5AIRQUALITYMONITOR / EN
12 05/24/18 Version No. 00
5. BEFORE OPERATION
5-1 Power Supply
The meter can be powered by two ways: Four AA-size alkaline
batteries or the AC adaptor.
5-2 Install the Batteries
Insert 4 AA-size batteries as indicated by the diagram located on the
inside of the battery compartment.
The meter is disigned to operate only with alkaline batteries.
When the battery voltage drop below the operating voltage, the
“ ” mark will be blink displayed, it indicates the batteries need
to be changed.
5-3 AC Adaptor
The AC adaptor allows you to power the meter from a wall outlet.
When using the AC adaptor, the batteries (if installed) will be by
passed. The AC adaptor is not a battery charger.
5-4 Air Sampling Port
Always ensures that the meter air sampling inlet and outlet port are
not blocked and open to the atmosphere.

PM2.5AIRQUALITYMONITOR / EN
05/24/18 Version No. 00 13
6. OPERATING INSTRUCTIONS
6-1 Selecting Temperature Unit ℃or ℉
1. Press key to turn on the meter.
2. Press Skey for 3 seconds to enter the setting mode, the “SET” and
“dAtE” marks are displayed.
3. Press Skey 3 times to enter the temperature unit ℃/℉setting mode,
the “Unit” mark is displayed.
4. Press key to select “℃” or “℉” unit now blink on the display.
5. Press ↵key to store the desired measure unit.
6-2 Selecting VOCs unit ppm or mg/m
3
1. Press key to turn on the meter.
2. Press Skey for 3 seconds to enter the setting mode, the “SET” and
“dAtE” marks are displayed.
3. Press Skey 5 times to enter the VOCs unit ppm or mg/m
3
setting
mode, the “Unit” mark is displayed.
4. Press key to select “ppm” or “mg/m
3
” unit now blink on the display.
5. Press ↵key to store the desired measure unit.
6-3 Taking Measurements
1. Press key to turn on the meter (The VOCs need waiting 600
seconds countdown then display the measured values).
2. The display will shows the PM2.5 reading (PM2.5 µg/m
3
), VOCs reading
(ppm or mg/m
3
), temperature reading (℃or ℉), Humidity reading
(%RH), PM2.5 or VOCs air particle pollution (Health Index 0 – 9 ). The
Health Index 5 – 9 will be blink display for warning.
3. The LED air quality indicator in a color format, the Red, Purple and
Blue colors will be blink.
4. Press MODE key to circulate the Measurement, PM2.5 TWA, VOCs
TWA and Real-time display. If the measurement time arrive ahead of
the TWA average setting time, the “hour - -:” will be displayed.
5. Press key again to turn on or off the DC FAN.
6. Press key for 3 seconds to turn off the meter.

PM2.5AIRQUALITYMONITOR / EN
14 05/24/18 Version No. 00
6-4 Setting the TWA Average Time
1. Press key to turn on the meter.
2. Press Skey for 3 seconds to enter the setting mode, the “SET” mark
is displayed.
3. Press Skey 4 times to enter the PM2.5 TWA average time setting
mode, the “SET PM2.5 TWA hour” mark is displayed.
4. Press key to select the desired average time from 1 to 24 hours.
5. Press ↵key to store the setting value and to enter the VOCs TWA
average time setting mode, the “SET TWA VOCs hour” mark is displayed.
6. Press key to select the desired average time from 1 to 24 hours.
7. Press ↵key to store the setting value and to enter the sampling time
setting mode, the “SET TWA St min sec” mark is displayed.
8. Press key to select the desired sampling time 1 minute, 5 minutes or
10 minutes.
9. Press ↵key to store the setting value and exit this mode.
6-5 Setting the Real-Time
The meter internal clock is used in the display and for time-stamping
recorded measurements.
1. Press key to turn on the meter.
2. Press Skey for 3 seconds to enter the real-time setting mode, the
“SET dAtE” mark is displayed.
3. Using key to position the cursor on the date or time element to adjust.
4. Press key to change the selected date or time element value.
5. Press ↵key to complete the action.
6-6 Taking Maximum (MAX) and Minimum (MIN) Recorder
Measurements
1. Press key to turn on the meter.
2. Press MAX key to enter the read previous recorded data mode, the
“rEAd OLd dAtA” mark is displayed.

PM2.5AIRQUALITYMONITOR / EN
05/24/18 Version No. 00 15
3. If you will read previously recorded data, press Rkey to circulate
display the recorded data, then press MAX key for 3 seconds to exit
this mode. Otherwise press MAX key again to enter the recorder mode
and auto clear the previous recorded data.
4. Press MAX key to cycle through the
a). Current measurement reading, the “MAX MIN” mark is displayed.
b). MAX. reading for PM2.5, VOCs, temperature and humidity, the
“MAX” mark is displayed.
c). MAX. reading for PM2.5 TWA, VOCs TWA, temperature and
humidity, the “MAX TWA” mark is displayed.
d). MIN. reading for PM2.5, VOCs, temperature and humidity, the
“MIN” mark is displayed.
e). MIN. reading for PM2.5 TWA, VOCs TWA, temperature and
humidity, the “MIN TWA” mark is displayed.
f). MAX. PM2.5 reading with its VOCs, temperature and humidity
reading, the “PM2.5” mark is blinks.
g). MIN. PM2.5 reading with its VOCs, temperature and humidity
reading, the “PM2.5” mark is blinks.
h). MAX. VOCs reading with its PM2.5, temperature and humidity
reading, the “VOCs” mark is blink.
i). MIN. VOCs reading with its PM2.5, temperature and humidity
reading, the “VOCs” mark is blink.
j). MAX. temperature reading with its PM2.5, VOCs and humidity
reading, the “℃or ℉” mark is blink.
k). MIN. temperature reading with its PM2.5, VOCs and humidity
reading, the “℃or ℉” mark is blink.
l). MAX. humidity reading with its PM2.5, VOCs and temperature
reading, the “%RH” mark is blink.
m). MIN. humidity reading with its PM2.5, VOCs and temperature
reading, the “%RH” mark is blink.
Under fto msteps, users also can get its occurred time by press
MODE key to display the occurred time, press MODE key again to exit
time display.
Under bto msteps, the “R” mark is displayed.

PM2.5AIRQUALITYMONITOR / EN
16 05/24/18 Version No. 00
5. Press MAX key for 3 seconds to exit this mode and store the recorded
data to memory.
6-7 Taking Alarm Operation
1. Quantity for alarm operation
Alarm setpoints:
A alarm monitors the quantity chosen for the alarm operation. When
the measured value is in between the “high” and “low” limit values,
the alarm is OFF. When choosing low value as “high” value and
higher value as “low” value, the alarm is OFF when the measured
value is not between the setpoints. You can also set only one
setpoints.
The figure for illustrative examples of the different measurement-
based alarm operation modes.
Hysteresis function is to prevent the alarm operation back and forth
when the measured value is near to the setpoint values. Hysteresis
value should be smaller than difference of the setpoints.
The following figure for illustrative examples of the different
measurement-based alarm output modes.
Mode 1: Only “high” setpoint set. MODE 2: Only “low” setpoint set.
measured
value
A
A-h
measured
value
time
B+h
B
Alarm is ON when value is
above the setpoint.
Alarm is ON when value
is below the setpoint.

PM2.5AIRQUALITYMONITOR / EN
05/24/18 Version No. 00 17
Mode 3: Both setpoints set
“high” > “low”.
measured
value
time
A
A-h
B+h
B
measured
value
time
B
B-h
A+h
A
Alarm is ON when value is
outside the setpoints.
Legend
A: “high” setpoint value Alarm is ON
B: “low” setpoint value •Alarm is ON
h: Hysteresis value

Alarm is OFF
2. Setting the alarm limit values
a). Press key to turn on the meter.
b). Press Skey for 3 seconds to enter the setting mode, the “SET”
mark is displayed.
c). Press Skey 9 times to enter the PM2.5 alarm mode select, the
“PM2.5 ALM” and “no-x” marks are displayed.
d). Press key to select the desired alarm mode from 1 to 4, then
press ↵key to select and to enter the alarm limit values setting mode.
e). The “ALM” mark indication setting the low limit value,
the “ALM” mark indication setting the high limit value, and
the “ALM” mark indication setting the hysteresis value.
Press key to set the desired value, the key can be held down to
increase the speed.
Mode 4: Both setpoints set
“high” < “low”.
Alarm is OFF when value
is outside the setpoints.

PM2.5AIRQUALITYMONITOR / EN
18 05/24/18 Version No. 00
Press ↵key to move to the next setting value or to enter the VOCs
alarm mode select, the “VOCs ALM” and “no-x” marks are displayed.
f). Repeat step and above to complete the VOCs limit value
setting, and to enter the temperature alarm mode select, the “℃or
℉ALM” and “no-x” marks are displayed.
g). Repeat step and above to complete the temperature limit value
setting, and to enter the humidity alarm mode select, the “%RH,
ALM” and “no-x”marks are displayed.
h). Repeat step and above to complete the humidity limit value
setting, and exit the alarm limit values setting mode.
3. Setting the alarm sound ON/OFF
a). Press key to turn on the meter.
b). Press Skey for 3 seconds to enter the setting mode, the “SET”
mark is displayed.
c). Press Skey 1 times to enter this mode, the “bEEP” and “ ”
marks are displayed.
d). Press key to select “ ” for disable the alarm sound or select
“ ” for enable the alarm sound.
e). Press ↵key to exit this mode.
4. Setting the alarm function ON/OFF
a). Press key to turn on the meter.
b). Press Skey for 3 seconds to enter the setting mode, the “SET”
mark is displayed.
c). Press Skey 2 times to enter this mode, the “ALM on” or “ALM OFF”
mark is displayed.
d). Press key to select “on” or “OFF”.
e). Press ↵key to exit this mode.
