Rugged Ridge 11561.12 User manual

11561.12
Jeep®JK Wrangler Stubby Tube Front Bumper with Winch Plate
Contents:
1. Tube Bumper (1)
2. Winch Plate (1)
3. Nut Plate (2)
4. M10 Washer (2)
5. M10 Bolt (2)
6. M12 Lock Nut (8)
7. M12 Washer (8)
8. M3 Lock Nut (8)
1. Disconnect fog lights. Remove 4 nuts per frame horn that hold the original front bumper to the vehicle.
Remove original bumper.
2. Install the original fog lights into the Center Section from the back (Figure 2a). Use the (8) M3 lock
nuts to secure them (Figure 2b).
Page 1 of 3
1
8
4
3
5
2
6
7

3. Remove the grille from the Jeep®. This is done by removing the 6 plastic fasteners from across the
top of the grille, removing the blinker bulbs from their housings by untwisting them, and then pulling
the grill away from the vehicle from the bottom, which will release the push fasteners.
Page 2 of 3
4. With the winch plate angled down (Figure 4a), manuever it down on the frame rails such that the
front holes go behind the mounting plates on the front of the frame rails, and the winch mounting
portion lays on the frame rails. Once in position, insert the Nut plates into the end of the frame rail,
using needle nose pliers to hold them, and install the 10mm bolts and washers (Figure 4b).
5. Install grille. Installation is the reverse of removal.
Figure 4a Figure 4b
6. If winch is being used, install per manufacturer's instructions.
7. Position Tube Bumper with the 12mm studs facing the vehicle. These studs go through the 8 holes
on the front of the frame rails. Place bumper onto vehicle and install 12mm washers and locknuts.

3. Tighten all hardware. Reconnect Fog Lights. Installation of the Bumper is now complete!
