Rugged Ridge 13510.10 User manual

Copyright © 2017 Omix-Ada®, Inc.
460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | [email protected]
Quick Release Bow Knuckle Kit
Page 1/3
Part # 13510.10
13510.11
13510.12
OMIX-ADA®TECHNICAL SUPPORT
PHONE: M-F 8am - 5pm EST 1-800-449-6649 | EMAIL: [email protected]
FOR WARRANTY INFORMATION VISIT: www.Omix-Ada.com
1. Small Bow Knuckle (2 - 13510.10)
(4 - 13510.12)
2. Large Bow Knuckle (2 - 13510.10)
(0 - 13510.12)
Components

Copyright © 2017 Omix-Ada®, Inc.
460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | [email protected]
Quick Release Bow Knuckle Kit
Page 2/3
3. Pull quick release knob and turn clockwise to lock
in open position.
2. Insert Quick Release Bow Knuckles in open ends
of soft top bows.
1. Lower soft top and detach factory bow knuckles
from soft top frame and sport bar by removing pivot
bolt and screw.
If installing kit #13510.10 ensure
quick release knob on Large Bow
Knuckles face outward and quick
release knob on Small Bow Knuckles
face inward.
Otherwise, ensure all quick release
knobs face inward.
NOTICE

Copyright © 2017 Omix-Ada®, Inc.
460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | [email protected]
Quick Release Bow Knuckle Kit
Page 3/3
5. Once all bow knuckles are attached to mounting
brackets, secure Quick Release Bow Knuckles to soft
top bows with factory self tapping screws.
4. Align bow knuckes with mounting bracket
and attach them by pulling quick release knob
slightly out and twisting counter-clockwise. Once in
main groove let go of quick release knob.
