Rugged Ridge 13265.01 User manual

P/N: 13265.01
Installation instructions 13265.04
2007-08 Jeep® Wrangler JK - Neoprene Rear Seat Covers
13265.09
2-Door Rear Seats
13265.53
Parts included: (1) Rear top cover
(1) Rear bottom cover
(2) Head Rest Covers
NOTE: Please read instructions before installing
Instructions:
Step(1)
Step (1)
Remove rear headrest from
seat. The headrest can be
removed by pressing the
two buttons located on the top
of the seat.
Step (2)
Slip upper seat cover over
rear seat. Note location
of headrest mounting holes.
Slip lower Velcro strip
between the upper and
lower portions of the seat
and secure. Connect zipper
and close.
Step (2)
Step (3)
Push seat cover over headrest
mounting plates. Secure under
plastic caps as shown.
Step (4)
Adjust upper seat cover as
needed for proper fitment.
Step (5)
Slip lower cover over seat
bottom and slide back clips
and straps through the gap
between the top section and
the lower seat section.
Fold and touble the seat so
that front to rear straps can
Step (3)
be secured.
Step (6)
With seat folded forward
loosen staps and attach front
strap to back clip. Repeat for all
three locations.

Step (6)
Step (7)
With straps attached carefully
pull straps to thighten.
NOTE: DO NOT OVER TIGHTEN
Damage to seat cover may
result.
Step (8)
Slide side clips between
the seat and the fenderwell and
secure. Fold seat back down
and check fitment of cover
noting carseat attachment
Step (9)
Step (10)
slots.
Adjust as needed.
Step (9)
Slide supplied headrest covers
over headrest and secure velcro.
Adjust fitment as needed.
Step (10) Insert headrest back onto rear
seat.
Step (11)
Inspect seat cover and adjust
Step (11)
as needed. You may need
to fold and tumble the seat
several times and adjust to
get the final fitment.
Step (12)
