Hardware Installation and Reference Guide Product Overview
1
1 Product Overview
Launched by Ruijie independently, RG-CS88-08 series next generation core switches adopt the Crossbar/FullMesh/Clos
architecture and support dual supervisor modules and power supply redundancy.
Specifications
Model
RG-CS88-08
Module Slot
two supervisor module slots and six service module slots
Supervisor Module
CM88-CM
Supervisor Module
Redundancy
Supported
Service Module
CM88-CM supports the following 4 modules:
CM88-48GT-H
CM88-48SFP-H
CM88-48XS-H
CM88-8CQ-H
Hot Swapping
Supported
Power Supply
Module
RG-PA600I-F: 90-180 V~ power: 600 W;
180-264 V~ power: 600 W
RG-PA1600I-F: 90-180 V~ power: 1200 W;
180-264 V~ power: 1600 W
Power Supply
Redundancy
The power supply redundancy of the same model is supported
Fan Module
M08-FAN
EMC Standards
GB/T 9254.1
Safety Standards
GB 4943.1
Altitude
Long term operation height: 3000m at 50℃. The temperature decreases by 1℃as the altitude
ranging from 3000m to 5000m increases by 200 m.
Operation height: 5000 m max
Storage height: 5000 m max
Operating
Temperature
0°C to 50°C
Storage
Temperature
-40°C to 70°C
Operating Humidity
10% to 90% RH (non-condensing)
MTBF
216,000 hours
Noise
70 dB at normal temperature
Max Noise: 77dB
Weight
Net weight: 35.6 kg
Dimensions
(W x D x H)
442 mm x 465 mm x 441.7 mm (without cable management brackets), 10U
The weight only includes that of the empty chassis and fans. The whole device's weight is subject to that of the
modules selected.
RG-CS88-08 switch is a class A product. In a domestic environment, this product may cause radio interference in
which case the user may be required to take adequate measures.
Product Appearance
The hardware system of the RG-CS88-08 switch is composed of the chassis, the power system, modules and the cooling
system.
The power system provides four power supply slots and supports N+N power redundancy.
The RG-CS88-08 switch provides two supervisor module slots and six service module slots. The supervisor modules
support 1+1 redundancy. Users are recommended to configure redundancy for the supervisor modules. Users may
choose different service modules as needed.

Hardware Installation and Reference Guide Product Overview
2
The cooling system is composed of the fan trays and air filters. Fan trays are at the back of the chassis. The air filters
are on the right side of the chassis.
Figure 1-1 Appearance of the RG-CS88-08 Switch
Front Panel
The front panel of the RG-CS88-08 switch is shown in Figure 1-2.
Figure 1-2 Front Panel of the RG-CS88-08 Switch
Note:
1. Supervisor module slots
2. Service module slots
3. Cable management bracket
4. Slot for system power supply module
5. Anti-static wrist strap socket
Ensure the supervisor module, service module, and power supply module are removed from the chassis before you
move or transport the RG-CS88-08 chassis.
Back Panel

Hardware Installation and Reference Guide Product Overview
3
The back panel of the RG-CS88-08 switch is shown in Figure 1-3.
Figure 1-3 Back Panel of the RG-CS88-08 Switch
Note:
1. PoE power supply slots
2. Direction sign for installing air filter
3. Captive screw of the air filter
4. Air filter module
5. Fan Tray
6. Handle of the fan tray
7. Captive screws of the fan tray
Power supply
The RG-CS88-08 switch adopts both AC power supply input.
AC power supply input: The RG-PA1600I-F and the RG-PA600I-F power supply modules are supported. The two
types of power supply modules support power management. The supervisor module of the RG-CS88-08 switch can
read the power supply information and implement flexible and intelligent power management.
The RG-CS88-08 switch supports N+N power supply redundancy to improve the system stability and reliability. We
recommend users to configure N+M redundancy for power supply modules.
Heat Dissipation System
The operating environment temperature of the RG-CS88-08 switch ranges between 0 and 50°C . The thermal design must
satisfy the requirement on the device's reliability in the temperature range while ensuring the device's safety and
maintainability. According to the thermal design of the RG-CS88-08 switch, fans are used to draw air for forced convection
cooling in order to ensure that the device works properly in the specified environment.
Figure 1-4 Ventilation and Heat Dissipation System of the RG-CS88-08 Switch (Air Intakes)

Hardware Installation and Reference Guide Product Overview
4
Note:
1. Air intakes for PoE power modules
2. Air intakes for service and supervisor modules
3. Air intakes for system power modules
Figure 1-5 Ventilation and Heat Dissipation System of the RG-CS88-08 Switch (Exhaust Vents)
Note:
1. Exhaust vents for PoE power modules
2. Exhaust vents for service and supervisor
modules
3. Exhaust vents for system power modules
For the PoE power supply modules, air flows across the chassis from the back intakes to the front vents.
For the supervisor and service modules, air flows across the chassis from the right intakes to the back vents.
For the power supply modules, air flows in from the front intakes and out from the back vents.
The chassis should be mounted in a place with sufficient space for air circulation. Maintain a minimum clearance of
10cm around the chassis.

Hardware Installation and Reference Guide Module
5
If any module slot is unoccupied, install a filler panel to ensure proper airflow.
2 Module
The RG-CS88-08 switch adopts the module-based design. Compliant with industry standards, the design divides modules
and integrates module interfaces to ensure the switch system's functioning and independence of various function modules.
The modules of the RG-CS88-08 switch provide 10/100/1000M auto-sensing Ethernet copper ports, 1000 Mbps/100 Mbps
SFP (single-mode/multi-mode) optical fiber interfaces and 10G/40G optical fiber interfaces.
2.1 RGOS12.X Modules
2.1.1 RGOS12.X Supervisor Modules
2.1.1.1 CM88-CM
CM88-CM is the supervisor module of the RG-CS88-08 series switches and is designed with management and switching
functions.
Module Appearance
Figure 2-11 Appearance of the CM88-CM Module
External Port
The CM88-CM module provides three external ports:
Universal Serial Bus (USB) port: By connecting to the USB port, the USB storage devices can store logs, host version,
alarms and other diagnosis information, facilitating online upgrade of switch software and storage of logs.
To secure data and prevent damage to the device, it is recommended to use high-quality flash disks produced by
reliable manufacturers. The USB port is compatible with most USB controllers but may be unable to identify some
USB disk models.
Console port: As a serial communications port, it uses the RS-232 interface level and standard RJ-45 connector. This
port is used to connect the device to serial ports of background terminal computers to perform tasks including system
commissioning, configuration, maintenance, management, and host software loading.
10/100/1000M MGMT port: As the 10/100/1000BASE-T Ethernet port, it uses the RJ-45 connector. This port can be
used to connect the device to the Ethernet port of the background computer to load programs. Use the standard cable
to connect the device to the Ethernet port of the background computer.
Button
The CM88-CM module provides a FUNC button, which is used to reset the system. If the button is held for less than five
seconds, it is a short press; if the button is held for five seconds or longer, it is a long press.
In case of a short press, the Status LED flashes in green, and the device resets within five seconds after the press.
In case of a long press, the Status LED flashes in green and then flashes in red; the device resets within five seconds
after the press.
Press the button, and the system starts to collect information, during which the device will not restart. After the
collection is complete, the device restarts automatically. Hold the button for a while and release it, the device restarts
automatically in five seconds.
LED
LED
Identification
on the panel
Status
Meaning
System LED
Status
Off
The module is powered off.
Solid red
The module is faulty.
Blinking green
Initialization is in progress. Continuous blinking indicates
errors.

Hardware Installation and Reference Guide Module
6
Solid green
The module is operational.
Active/standby supervisor
module LED
Primary
Off
The module acts as the standby supervisor module.
Solid green
The module acts as the primary supervisor module.
Alarm LED
Alarm
Off
No fault
Solid red
The whole system or a module fails to work. The device
may be damaged if it continues operating.
Solid yellow
The temperature exceeds the threshold but the system
continues operating.
Fan status LED
FAN
Solid green
The fan is operational.
Solid yellow
The fan is NOT in the position.
Solid red
The fan is faulty.
Power status LED
PWR
Off
The power supply module is NOT in the position.
Solid green
The power supply module is operational.
Solid red
The power supply module is faulty.
MGMT port LED
MGMT
Off
The MGMT port is NOT connected.
Green
The MGMT port is connected at 1000Mbps.
Yellow
The MGMT port is connected at 10/100Mbps.
Blinking
The MGMT port is transmitting or receiving data.
Specifications
Model
CM88-CM
CPU
Quad-core CPU, each core with the clock speed of 1.5G
BOOTROM
16 MB
Flash Memory
8 GB
SDRAM
DDR4 4GB
External Port
One Console port
One 10/100/1000M MGMT port
Two USB ports
Button
FUNC button
Power Consumption
< 50 W
Hot Swapping
Supported
Management
Redundancy
Supported
EMC Standards
GB9254-2008 CLASS A
Safety Standards
GB4943-2011
Operating
Temperature
0°C to 50°C
Storage
Temperature
-40°C to 70°C
Operating Humidity
10% to 90% RH (non-condensing)
MTBF
960,000 hours
Weight
Net weight: 2.1 kg
Dimensions
(W x D x H)
438.5 mm x 309.0 mm x 40.1 mm
The CM88-CM adopts the CR2032 lithium battery. The device may explode if a wrong battery model is used. Used
batteries should be properly disposed of.
2.1.2 RGOS12.X Service Modules
2.1.2.1 CM88-48GT-H
Module Appearance
Figure 2-22 Appearance of the CM88-48GT-H

Hardware Installation and Reference Guide Module
7
External Port
CM88-48GT-H provides 48 10/100/1000BASE-T RJ45 ports.The RJ45 ports support 10/100/1000Mbps auto-negotiation.
LED
LED
Identification on
the panel
Status
Meaning
System LED
Status
Off
The module is powered off.
Solid red
The module is faulty.
Blinking green
Initialization is in progress. Continuous blinking
indicates errors.
Solid green
The module is operational.
RJ45 port LED
Link/ACT
Off
The port link is NOT connected.
Solid green
The port is connected at 1000Mbps.
Solid yellow
The port is connected at 10Mbps or 100Mbps.
Blinking
The port is transmitting and receiving data.
Specifications
Model
CM88-48GT-H
CPU
Quad-core CPU, each core with the clock speed of 1.5G
BOOTROM
16 MB
Flash Memory
8 GB
SDRAM
DDR4 2GB
Port Type
48 10/100/1000BASE-T RJ45 ports
Transmission
Medium
10/100/1000BASE-TCat-5 UTP
LED
Status, Link/ACT
Hot Swapping
Supported
Power
Consumption
< 75 W
EMC Standards
GB9254-2008 CLASS A
Safety
Standards
GB4943-2011
Operating
Temperature
0°C to 50°C
Storage
Temperature
-40°C to 70°C
Operating
Humidity
5% to 95% RH (non-condensing)
MTBF
334,000 hours
Weight
Net weight: 3.1 kg
Dimensions
(W x D x H)
412 mm x 390 mm x 40.16 mm
2.1.2.2 CM88-48SFP-H
Module Appearance
Figure 2-23 Appearance of the CM88-48SFP-H

Hardware Installation and Reference Guide Module
8
External Port
CM88-48SFP-H provides 48 SFP ports.The SFP ports support 100/1000Mbps auto-negotiation.
LED
LED
Identification on
the panel
Status
Meaning
System LED
Status
Off
The module is powered off.
Solid red
The module is faulty.
Blinking green
Initialization is in progress. Continuous blinking
indicates errors.
Solid green
The module is operational.
SFP port LED
Link/ACT
Off
The port link is NOT connected.
Solid green
The port is connected at 1000Mbps.
Solid yellow
The port is connected at 100Mbps.
Blinking
The port is transmitting and receiving data.
Specifications
Model
CM88-48SFP-H
CPU
Quad-core CPU, each core with the clock speed of 1.5G
BOOTROM
16 MB
Flash Memory
8 GB
SDRAM
DDR4 2GB
Port Type
48 SFP ports
Transmission
Medium
1000BASE-SX (850nm) Multi-mode optical fiber
1000BASE-LX (1310nm) Single-mode optical fiber
1000BASE-LH (1310nm) Single-mode optical fiber
1000BASE-ZX (1550nm) Single-mode optical fiber
100BASE-LX (1310nm) Single-mode optical fiber
100BASE-LH (1310nm, 1550nm) Single-mode optical fiber
LED
Status, Link/ACT
Hot Swapping
Supported
Power
Consumption
< 95 W
EMC Standards
GB9254-2008 CLASS A
Safety
Standards
GB4943-2011
Operating
Temperature
0°C to 50°C
Storage
Temperature
-40°C to 70°C
Operating
Humidity
5% to 95% RH (non-condensing)
MTBF
329,000 hours
Weight
Net weight: 3.2 kg
Dimensions
(W x D x H)
412 mm x 390 mm x 40.16 mm
2.1.2.3 CM88-48XS-H
Module Appearance
Figure 2-24 Appearance of the CM88-48XS-H

Hardware Installation and Reference Guide Module
9
External Port
CM88-48XS-H provides 48 SFP+ ports.The SFP+ ports support 10G SFP+ modules, Gigabit SFP modules and hot
swapping.
The CM88-48XS-H module supports 10G SFP+ module and Gigabit SFP module. 10G SFP+ module cannot be used
as a Gigabit SFP module. If the Gigabit SFP module is used, force the interface to run at the specified speed, duplex
mode and flow control.
LED
LED
Identification on
the panel
Status
Meaning
System LED
Status
Off
The module is powered off.
Solid red
The module is faulty.
Blinking green
Initialization is in progress. Continuous blinking
indicates errors.
Solid green
The module is operational.
SFP port LED
Link/ACT
Off
The port link is NOT connected.
Solid green
The port is connected at 1000Mbps.
Solid yellow
The port is connected at 100Mbps.
Blinking
The port is transmitting and receiving data.
SFP+ port LED
Link/ACT
Off
The port link is NOT connected.
Solid green
The port is connected.
Blinking
The port is transmitting and receiving data.
Specifications
Model
CM88-48XS-H
CPU
Quad-core CPU, each core with the clock speed of 1.5G
BOOTROM
16 MB
Flash Memory
8 GB
SDRAM
DDR4 2GB
Port Type
48 SFP+ ports
Transmission
Medium
1000BASE-SX (850nm) Multi-mode optical fiber
1000BASE-LX (1310nm) Single-mode optical fiber
1000BASE-LH (1310nm) Single-mode optical fiber
1000BASE-ZX (1550nm) Single-mode optical fiber
10GBASE-SR (850nm) Multi-mode optical fiber
10GBASE-LR (1310nm) Single-mode optical fiber
10GBASE-ER (1550nm) Single-mode optical fiber
10GBASE-ZR (1550nm) Single-mode optical fiber
XG-SFP-AOC1M 1m SFP+ active optical cable
XG-SFP-AOC3M 3m SFP+ active optical cable
XG-SFP-AOC5M 5m SFP+ active optical cable
LED
Status, Link/ACT
Hot Swapping
Supported
Power
Consumption
< 160 W
EMC Standards
GB9254-2008 CLASS A
Safety
Standards
GB4943-2011
Operating
Temperature
0°C to 50°C

Hardware Installation and Reference Guide Module
10
Storage
Temperature
-40°C to 70°C
Operating
Humidity
5% to 95% RH (non-condensing)
MTBF
305,000 hours
Weight
Net weight: 3.85 kg
Dimensions
(W x D x H)
412 mm x 390 mm x 40.16 mm
2.1.2.4 CM88-8CQ-H
Module Appearance
Figure 2-26 Appearance of the CM88-8CQ-H
External Port
CM88-48XS-H provides eight QSFP28 ports.The QSFP28 ports support 100G QSFP28 modules, 40G SFP28 modules
and hot swapping.
LED
LED
Identification on
the panel
Status
Meaning
System LED
Status
Off
The module is powered off.
Solid red
The module is faulty.
Blinking green
Initialization is in progress. Continuous blinking
indicates errors.
Solid green
The module is operational.
QSFP28 port LED
Link/ACT
Off
The port link is NOT connected.
Solid green
The port is connected.
Blinking
The port is transmitting and receiving data.
Specifications
Model
CM88-8CQ-H
CPU
Quad-core CPU, each core with the clock speed of 1.5G
BOOTROM
16 MB
Flash Memory
8 GB
SDRAM
DDR4 2GB
Port Type
8 QSFP ports. The QSFP28 port cannot be split into four 25G ports or four 10G ports.
Transmission
Medium
100G-QSFP-SR Multi-mode optical fiber
100G-QSFP-LR4 Single-mode optical fiber
100G-QSFP-eSR Multi-mode optical fiber
100G-AOC-10M 10m Multi-mode cable
40GBASE-SR4 Multi-mode optical fiber
40GBASE-LR4 Single-mode optical fiber
40G-QSFP-STACK3M 3m QSFP+ copper cable
LED
Status, Link/ACT
Hot Swapping
Supported
Power
Consumption
< 130 W
EMC Standards
GB9254-2008 CLASS A
Safety
Standards
GB4943-2011

Hardware Installation and Reference Guide Module
11
Operating
Temperature
0°C to 50°C
Storage
Temperature
-40°C to 70°C
Operating
Humidity
5% to 95% RH (non-condensing)
MTBF
335,000 hours
Weight
Net weight: 3.2 kg
Dimensions
(W x D x H)
412 mm x 390 mm x 40.16 mm
2.1.3 RGOS12.X Switch Fabric Modules
The RG-CS88-08 series switches do not support independent RGOS12.X switch fabric modules.
2.2 Power Supply Modules
2.2.1 AC Power Supply Modules
2.2.1.1 RG-PA600I-F
Module Appearance
Figure 2-31 Appearance of the RG-PA600I-F Module
External Port
The RG-PA600I-F module provides 12 VAC input to the overall system of the RG-CS88-08 switch. The front panel of the
power supply module provides a 3-pin plug, which can be connected to a standard 10A power cord.
LED
LED
Meaning
AC
DC/FLT
Solid green
Solid green
The module is operational
Off
Solid red
There is no power input or input undervoltage.
Solid green
Solid red
Overvoltage
Solid green
Solid red
Overcurrent
Solid green
Solid orange
Temperature alarm
Solid green
Solid red
Over-temperature fault

Hardware Installation and Reference Guide Module
12
Solid green
Solid red
PSR on/off
Specifications
Module Model
RG-PA600I-F
Rated Voltage
Range
100 to 120 VAC, 200 to 240 VAC; 50/60 Hz
Max Voltage
Range
90 to 264 VAC; 47 to 63 Hz
Max Power
Output
90 to180 VAC Power: 600 W
180 to 264 VAC Power: 600 W
High Current DC
Parameter
192 to 290VDC Power: 600 W
Input
Leakage
Current
≤0.85 mA
Weight
Net weight: 1.64 kg
Power Cord
Requirement
10 A power cord
When you plug the power cable into the power supply, pull down the retention clip over the plug on the power cable.
Operation Altitude: 5000m max. Storage Altitude: 5000m max.
2.2.1.2 RG-PA1600I-F
Module Appearance
Figure 2-32 Appearance of the RG-PA1600I-F Module
External port
The RG-PA1600I-F module provides 12 VAC input to the overall system of the RG-CS88-08 switch. The front panel of the
power supply module provides a 3-pin plug, which can be connected to standard 16A power cord.
LED
LED
Meaning
AC
DC/FLT
Solid green
Solid green
The module is operational
Off
Solid red
There is no power input or input undervoltage.
Solid green
Solid red
Overvoltage.
Solid green
Solid red
Overcurrent.
Solid green
Solid orange
Temperature alarm

Hardware Installation and Reference Guide Module
13
Solid green
Solid red
Over-temperature fault
Solid green
Solid red
PSR on/off
Specifications
Module Model
RG-PA1600I-F
Rated Voltage
Range
100 to 120 VAC, 200 to 240 VAC; 50/60 Hz
Max Voltage
Range
90 to 264 VAC; 47 to 63 Hz
Max Power
Output
90 to 180 VAC Power: 1200 W
180 to 264 VAC Power: 1600 W
High Current DC
Parameter
192 to 290 VDC Power: 1600 W
Input Leakage
Current
≤3 mA
Weight
Net weight: 2.04 kg
Power Cord
Requirement
16 A power cord
When you plug the power cable into the power supply, pull down the retention clip over the plug on the power cable.
Operation Altitude: 5000m max. Storage Altitude: 5000m max.
2.3 Fan Modules
2.3.1 M08-FAN
Module Appearance
Figure 2-43 Appearance of the M08-FAN Module
Note:
1. Fan status LED
2. Captive screws of fan tray
3. Fan handle
Composition
The M08-FAN is the fan for service modules and supervisor modules on the RG-CS88-08. There is one M08-FAN tray with
two fans and one fan control board. The M08-FAN draws air out to form convection for heat dissipation.
Specifications
Fan Model
M08-FAN
Dimension
(W x D x H)
167.5 mm x 132 mm x 133 mm
LED

Hardware Installation and Reference Guide Preparation before Installation
14
LED
Status
Meaning
Status
Off
The fan is not powered on.
Solid green
The fan is operational.
Features
Function
Meaning
Status Monitoring
Rotational speed monitoring, failure alarm
Automatic Speed-
adjustment
Speed-adjustment controlled by temperature
Hot Swapping
Hot swapping is supported by the fan tray.
3 Preparation before Installation
3.1 Safety Suggestions
To avoid body injury and equipment damage, please carefully read the safety suggestions before you install RG-
CS88-08.
The following safety suggestions do not cover all possible dangers.
3.1.1 General Suggestions
Take security measures (such as wearing an anti-static wrist strap) to ensure safety.
Keep the chassis clean, free from any dust. Please do not place the switch at a damp place to prevent the moisture
from entering the switch.
Make sure the installation site is dry and flat. Take skid-proof measures.
Do not place the equipment in a walking area.
Do not wear loose clothes or any other things that may be caught by the chassis during installation and maintenance.
Moving or lifting the switch and its components requires team work. Be careful not to get hurt.
3.1.2 Safety Precautions for Removal
RG-CS88-08 is large and heavy. When you handle them, please pay attention to the following requirements:
Avoid moving the equipment frequently.
Turn off all power supplies and unplug all power cables before you remove the equipment.
At least four people are needed to move the equipment. Do not attempt to move the equipment by one people only.
Keep balance when moving the equipment, and avoid injuring your leg and feet or spraining your waist.
Do not move the equipment by grasping the panel, power supply handle, ventilation holes of the chassis, as they are
not designed to bear the weight of the entire equipment. This may cause damage or even injure you.
Remove all supervisor modules, service modules and power modules before you move the device, to reduce the
chassis weight.
The device must be installed and used in the restricted access location.
3.1.3 Electrical Safety
Please observe local regulations and specifications when performing electrical operations. Relevant operators must
be qualified.
Please carefully check for any potential danger in the working area, for example, ungrounded power supply, unreliable
grounding of the power supply and damp/wet ground or floor.
Find out the location of the emergency power supply switch in the room before installation. First cut off the power
supply in case of an accident.
Be sure to make a careful check before you shut down the power supply.
Do not place the equipment in a damp/wet location. Do not let any liquid enter the chassis
Any nonstandard and inaccurate electrical operation can cause an accident such as fire or electrical attack, thus
causing severe even fatal damages to human bodies and equipment.

Hardware Installation and Reference Guide Preparation before Installation
15
Direct or indirect touch through a wet object on high-voltage and mains supply can bring a fatal danger.
3.1.4 Static Discharge Damage Prevention
Although much has been done in RG-CS88-08 to prevent static electricity, great damage may be caused to the circuitry
and equipment when the static electricity exceeds a certain limit. In the communication network of the RG-CS88-08,
electrostatic induction may come from the following sources: External electric field produced by the high-voltage supply
cable, lightning, etc; internal systems such as the indoor floor and the entire structure.
To prevent damage from static electricity, you must pay attention to the following:
Properly ground the equipment.
Take dust prevention measures in the room.
Maintain an appropriate humidity.
Always wear an anti-static wrist strap when you touch any circuit board.
Try to hold a circuit board by its edges. Do not touch any components or the PCB.
Use an anti-static shielding bag to properly store the board.
Do not let any clothes touch a circuit board. An antistatic wrist strap can only prevent human static electricity from
damaging the circuit board, but cannot prevent any static electricity on clothes.
The CS88-08 series switches are equipped with an anti-static wrist strap. Please refer to Figure 2-1 for the position
of the jack for the wrist strap.
The CS88-08 series switches are equipped with an anti-static wrist strap. To protect electronic components against static
electricity, wear an anti-static wrist strap close to your skin and keep it properly grounded while installing swappable
modules.
Use an anti-static wrist strap as follows:
Ensure that the switch is properly grounded.
Put your hand in the anti-static wrist strap.
Tighten the buckle till the trap is closely attached to your skin.
For safety, use a multimeter to measure the resistance between yourself and the ground, which should be within the
range from 1 to 10 Ω.
Make sure that the switch is properly grounded when the anti-static wrist strap is connected to the ground through
the chassis jack.
Figure 3-1 Preventing EMI on RG-CS88-08
3.1.5 Laser Safety
Among the modules supportedby RG-CS88-08, there are a great number ofoptical modules that are Class I laser products.

Hardware Installation and Reference Guide Preparation before Installation
16
Precautions:
When a fiber transceiver works, ensure that the port has been connected with a fiber or is covered with a dust cap so
as to keep out dust and avoid burning your eyes.
Do not stare into any fiber port.
Do not stare into any fiber port under any circumstances, as this may cause permanent damage to your eyes.
3.2 Installation Site Requirements
RG-CS88-08 must be used in the room. To ensure normal operation and a prolonged useful life of the equipment, the
installation site must meet the following requirements.
3.2.1 Load Bearing Requirements
Evaluate the load bearing requirements for the ground according to the weight of the switch and its components (such as
the cabinet, chassis, single board and power supply). Make sure the installation site meet the requirements.
3.2.2 Space Requirements
It is recommended that the width of the machine room corridor be greater than 0.8m to ensure enough space for
moving of chassis and plugging and removing of modules.
Please do not install the switch against the wall. Instead, please leave some space around the switch for heat
dissipation and switch maintenance.
3.2.3 Ventilation Requirements
See Product Overview for heat dissipation and ventilation. Maintain a minimum clearance of 10 cm around the air intakes
and exhaust vents for ventilation. After connecting various cables, you should bundle the cables or place them in the cable
management bracket to avoid blocking air intakes.
Remove all foam packaging materials and protective plastics before you power on the switch.
3.2.4 Temperature Requirements
To ensure the normal operation and a prolonged useful life of the RG-CS88-08, you must maintain an appropriate
temperature in the equipment room. Too high or low temperature for a long period of time may damage the equipment.
In an environment with high temperature, the equipment is subjected to even greater harm, as its performance may
degrade significantly and its useful life may be shortened in the case of long-term exposure that expedites the aging
process.
Temperature Requirements of the RG-CS88-08
Operating Temperature
Storage Temperature
0ºC to 50ºC
-40ºC to 70ºC
The ambient temperature is measured at the point that is 1.5m above the floor and 0.4m before the equipment when
there is no protective plate in front or back of the equipment rack.
RG-CS88-08 Dusting Cycle Suggestions:
1. Clean the air filters every three months.
2. Dust the air intakes and exhaust vents of all modules every three months.
3. Dust the modules every one or two years.
4. Dust the fan shelves yearly.
5. Dust the chassis, including the backplane, every one or two years.
Dust the equipment more often if the equipment room does not have enough dust-proof measures.
3.2.5 Humidity Requirements
To ensure the normal operation and a prolonged use life of the RG-CS88-08, you must maintain an appropriate humidity
in the equipment room. Too high or low humidity for a long period of time may damage the equipment.
In an environment with high relative humidity, the insulating material may have bad insulation or even leak electricity,
and sometimes the materials may suffer from mechanical performance change and metallic parts may get rusted.
