Ruijie Reyee RG-NBS6002 Installation and operating manual

Ruijie Reyee
RG-NBS6002 Switch
Hardware Installation and Reference Guide
DocumentVersion:V1.0
Date: 2023.02.09
Copyright © 2023RuijieNetworks

Copyright
Copyright © 2023RuijieNetworks
All rights arereservedin this documentand this statement.
Anyreproduction,excerption,backup,modification,transmission,translationorcommercialuseofthisdocument
oranyportion ofthis document,inanyform orbyanymeans,withoutthepriorwrittenconsentofRuijieNetworks
is prohibited.
Trademarks including , are ownedby RuijieNetworks.
Allothertrademarks orregisteredtrademarks mentionedinthis document are ownedbytheirrespectiveowners.
Disclaimer
The products,services,orfeatures youpurchasearesubjectto commercialcontracts and terms,andsomeor
all ofthe products,services, orfeatures describedinthis documentmaynotbe available foryou topurchase or
use. Except for the agreement in the contract, Ruijie Networks makes no explicit or implicit statements or
warranties with respecttothe contentof this document.
Thecontentofthis documentwillbeupdatedfrom timetotimeduetoproductversionupgrades orotherreasons,
RuijieNetworks reserves therightto modifythe contentof the documentwithoutanynoticeor prompt.
This manualis designed merelyas a userguide.RuijieNetworks has tried its besttoensuretheaccuracyand
reliabilityofthe content whencompiling this manual, butitdoes not guaranteethatthe content ofthe manual is
completelyfreeoferrors oromissions,and all theinformationin this manualdoes not constituteanyexplicitor
implicitwarranties.

I
Preface
IntendedAudience
This documentis intendedfor:
Networkengineers
Technicalsupportand servicing engineers
Networkadministrators
Technical Support
The officialwebsiteof Ruijie Reyee:https://www.ruijienetworks.com/products/reyee
Conventions
1. Signs
This documentalso uses signs toindicatesomeimportantpoints during theoperation.Themeanings ofthese
signs areas follows:
Caution
An alert that calls attentionto safety instruction thatif not understood orfollowedcanresultin personalinjury.
Warning
An alert that calls attention to importantrules and information thatif not understoodorfollowedcanresultin
data loss orequipmentdamage.
Note
An alert that calls attentionto essentialinformation thatifnot understoodorfollowed can resultin function
failureor performancedegradation.
Instruction
An alert that contains additionalorsupplementaryinformation thatifnot understoodorfollowed willnotlead to
serious consequences.
Specification
An alert that contains adescriptionofproductor version support.
2. Note
This manual provides installation steps, troubleshooting, technical specifications, and usage guidelines for
cables and connectors.Itis intendedforusers who wanttounderstandthe above andhave extensive experience
in networkdeploymentandmanagement,andassumethatusers arefamiliar withrelatedterms andconcepts.

Hardware Installation and Reference Guide Product Overview
1
1 Product Overview
RG-NBS6002 switchis 1U swappable box-typenetwork switchindependentlydevelopedbyRuijie Networks. It
provides two line card slots for four types of line cards and two power supply module slots for 1+1 power
redundancy.The followingtabledescribescomponentsofanRG-NBS6002switch.
Item
Model
Remarks
Chassis(independently
purchasedanddelivered)
RG-NBS6002
The chassiscontains thebackplane.
Service module (independently
purchasedanddelivered)
M6000-24GT2XS
One or two servicemodules canbe configured.
M6000-24SFP2XS
M6000-16GT8SFP2XS
M6000-16SFP8GT2XS
Powersupplymodule
(independentlypurchased and
delivered)
RG-PA150I-FS
1+1 redundancyis supported.

Hardware Installation and Reference Guide Product Overview
2
1.1 RG-NBS6002Switch
1.1.1 Package Contents
Table 1-1 PackageContents
Item
Quantity
Chassis
1
Powersupplymodule fillerpanel
1
Service module fillerpanel
1
M4 x 10 mm screw
1
M4 x 8 mm screw
8
Foot pad
4
Mounting bracket
2
Yellow/greenground cable
1
Warranty Card
1
UserManual
1
Product managementsoftware ofRuijieNetworks
1
Instruction
●The preceding tablelists itemsdeliveredinnormalcases.Theactuallydelivereditems mayvary with the
contract. Carefullycheck your goods againstthe package contents orcontract. Contact the sellerif you
have any questions orfind anyerrors.
1.1.2 Product Appearance
The hardware ofanRG-NBS6002switch consists ofthechassis,power supplysystem,system modules,and
heat dissipation system.
Power supply system: Provides two power supply module slots and supports 1+1 power redundancy. It is
recommendedtoconfigure powerredundancy.
System modules:Provides two servicemoduleslots.Allservicemodules can beconfiguredin eitherofthe two
slots.You can selectdifferent servicemodules based onactualapplicationrequirements.
Figure 1-1 RG-NBS6002 Switch Appearance (Service Module Combination of M6000-24GT2XS and
M6000-24SFP2XS)
Front View

Hardware Installation and Reference Guide Product Overview
3
RearView
1.1.3 Ports - Front Panel
Figure 1-2shows thefrontpanel ofanRG-NBS6002 switch.For thedetailedmeanings ofnumbers 1 to7,see
the followingtable.
Figure 1-2 Front Panel of an RG-NBS6002 Series Switch (Service Module Combination of M6000-
16GT8SFP2XS and M6000-16SFP8GT2XS)

Hardware Installation and Reference Guide Product Overview
4
Item
Description
Linecard status
indicator
Linecard status indicator.Thestatuses areas follows:
●
Solidgreen:The service moduleworks properly.
●
Blinkinggreen:The service moduleis startingup.
●
Blinkingyellow:Hot swappingorconfiguration conflictoccurs.
Off: The system is notpoweredon or the system is receivingpowerbut is not
functioningproperly.
RJ-45copper
port
10/100/1000Base-TadaptiveEthernetport that supports auto-negotiation.The
copperport uses an RJ45connector.
RJ-45copper
port indicator
Status indicatorof a 10/100/1000Base-Tadaptive Ethernetport. The statuses
are as follows:
●
Solidgreen:The port has made asuccessful1000 Mbps link.
●
Blinkinggreen:The port is sending orreceiving traffic at 1000Mpbs.
Off: No linkis detectedfor the port.
SFP port
SFP port. For details aboutapplicable transceivermodules,see
TransceiverModules.
SFP port
indicator
SFP port indicator. The statuses areas follows:
●
Solidgreen:The port has madeasuccessful link.
●
Blinkinggreen:The port is sending orreceiving traffic.
Off: No linkis detected for the port.
SFP+ port
SFP+ port. For details aboutapplicable transceivermodules,see
TransceiverModules
SFP+ port
indicator
SFP+ port indicator.The statuses areas follows:
●
Solidgreen:The port has madeasuccessful link.
●
Blinkinggreen:The port is sending orreceiving traffic.
Off: No linkis detectedfor the port.
Nameplate
Nameplateonthe bottom of the device
Warning
●Before handlingortransportingthechassis ofaRG-NBS6002switch,removethe servicemodules and
powersupplymodules from thechassis.Pleasedonothandleortransportthe chassisofanRG-
NBS6002 switchwiththe servicemodules or powersupplymodulesinstalled.
1.1.4 Ports - Rear Panel
Figure 1-3shows therear panelof anRG-NBS6002 switch.For detailedmeanings ofnumbers 1to 7,seethe
followingtable.

Hardware Installation and Reference Guide Product Overview
5
Figure 1-3 Rear Panel of an RG-NBS6002 Switch
Item
Description
Groundingpost
Used to fastenthe groundcable.
MGMT port
10/100/1000Base-Tadaptive Ethernetport. The port uses anRJ-45
connector. The managementportis used for configuration andsoftware
upgrade.
System indicator
(SYS)
●
Solidgreen:The system is initialized.
●
Blinkinggreen(rapidly):The system is startingup.
●
Blinkingyellow:The temperaturereaches thewarningvalueor you are
unableto read the temperature.Aservice moduleis insertedinhot
swappingmode.
●
Blinkingred:Adevice fault occurs, whichcauses system ormodule failure
or causes devicedamageifthe system continues to run.
The powersupplymoduleis faultyor inserted withoutacable.
Off: The switchis not powered on.
Managementport
indicator
10/100/1000Base-Tadaptive Ethernetport status indicator.The statuses are
as follows:
●
Solidgreen:The port has madeasuccessful 1000Mbps link.
●
Blinkinggreen:The port is sending orreceiving traffic at 1000Mpbs.
Off: No linkis detectedfor the port.
Resetbutton
After the resetbuttonis pressed,thesystem is resetand restarts basedonthe
originalsoftwareversion(Note).
Fan module
Three fan modulesareused forheat dissipation.
Powersupply
module
Two powersupplymodule slots PWR1 andPWR2 areavailable.
Insertpowersupplymodules andthenconnectAC powercords.
1+1 powerredundancyis supported.
Powersupply
module indicator
Powersupplymodule status indicator(PWR1 andPWR2). The statuses are
as follows:
●
Solidgreen:Power supplyis normal.
●
Solidred: Powersupplyis abnormal.

Hardware Installation and Reference Guide Product Overview
6
Off: The system is not powered on.
Note
●Resetbutton:Whenyou press andholdthe resetbutton for less than2 seconds,all modulesarereset.
When you press andholdthe resetbuttonfor morethan5 seconds,all modulesarereset,the initial
passwordis restored,thesupervisormoduleis restoredto factory settings,and theconfigurationbackup
file is saved.If you login to the web-basedmanagementsystem aftera restart,you can selectDelete
Backup or Restore Backup (the password is the defaultpassword).If you do not login, factory settings
are usedforthe supervisormodule.Whenyou press andholdtheresetbuttonfor 2s to 5s, no operation
is performed.Thepreceding events are executed after you releasetheresetbutton.
1.1.5 Technical Specifications
Table 1-2 Technical Specifications of an RG-NBS6002 Switch
Product
Model
RG-NBS6002
CPU
EmbeddedCPU,single-core processor,and clockspeed of 1 GHz
Flash
Memory
256MB
SDRAM
DDRIII 1 GB
Module Slot
Two service moduleslots
Service
Module
M6000-24GT2XS
M6000-24SFP2XS
M6000-16GT8SFP2XS
M6000-16SFP8GT2XS
Hot Swapping
Powersupplymodules supporthotswapping,whileservicemodules donot.
PowerSupply
Module
RG-PA150I-FS: 100V to 240V; Power:150 W
Power Supply
Redundancy
Supported(Powersupplymodules ofthe samemodelmustbeused.)
Fan Module
Fixed fans
Certificate
CE
Altitude
At 3000m (3.11 miles)above sealevel,the maximum operating temperatureis 50°C
(122°F). Every timethe altitudeincreases by220 m (721.78 ft.), the maximum
operatingtemperatureis decreaseby1°C (1.8°F).
Operating altitude:up to 5000 m above sealevel (3.11 miles)
Storagealtitude: upto 5000m above sealevel (3.11 miles)

Hardware Installation and Reference Guide Product Overview
7
Operating
Temperature
0°C to 50°C (32°F to 122°F)
Storage
Temperature
–40°Cto 70°C (-40°F to 158°F)
Operating
Humidity
10%to 90%RH (non-condensing)
MTBF
> 200,000hours
Noise
In an ambienttemperatureof25°C(77°F),the device noiseis 60 dB or less.
Weight
(Without
Service
Modules)
5.4 kg (11.90 lbs.)
Dimensions
(Chassis) (H x
W x D)
44 mm x442 mm x460 mm (1.73in. x 17.40 in. x 18.11 in.), 1U
Instruction
●The weightin the preceding tableindicates onlythe weightof the emptychassis.The entiredevice weight
is calculated based ondifferentservicemodules.
Caution
●Operation of this equipmentina residential environmentcouldcause radio interference.
●This equipmentis notsuitableforuse inlocations wherechildrenare likelyto be present.
1.2 RG-PA150I-FSPower SupplyModule
Powersupplyfor anRG-NBS6002switch:
AC input: The RG-PA150I-FS powersupplymodule is supported.
Note
●RG-NBS6002 switchsupports 1+1 redundancyof the powersupplymodules.Toimprovethe stabilityand
reliabilityof the entire system,itis recommended to configurepowerredundancy.

Hardware Installation and Reference Guide Product Overview
8
1.2.1 Power Supply Appearance
Figure 1-4 Appearance of an RG-PA150I-FS Power Supply Module
RG-PA150I-FS is anAC powermodule withAC powerinputand provides 12 V voltage to the entire
RG-NBS6002 system.Thefront panelof the power supplyprovides athree-pinpowersocket, whichis
connectedwitha standard10Apowercord.
1.2.2 Technical Specifications
Table 1-3 RG-PA150I-FS Technical Specifications
Module Model
RG-PA150I-FS
Rated Voltage
Range
100V to 240 V; 50/60Hz
Maximum
Voltage Range
90 V to 264 V; 47 to 63 Hz
Maximum
Output Power
100V to 240 V; Power: 150 W
Input Current
Parameter
< 3 A@ 90 to 264V AC @ fullload
Leakage
Current
Parameter
< 3.5 mA@ 110V AC and 220V AC/50 Hz and60 Hz
Weight
Net weight:about 0.55 kg
Power Cord
Requirements
10 A powercord

Hardware Installation and Reference Guide Product Overview
9
Note
●When connecting a powercord, pushup on the cable-retention clipthatsecures theinputpowercord to
the powersupply.
●Connectthe powercords to a groundedoutputsocket.
●The maximum operating andstorage altitudes ofthe power supplymoduleare5000m (3.11 miles).
1.3 Service Module
1.3.1 Package Contents
Table 1-4 Service Module Package Contents
Item
Quantity
Service module
1
Warranty Card
1
Instruction
●The package contents tableapplies toallservicemodules.
●The preceding tablelists itemsdeliveredinnormalcases.Theactuallydelivereditems mayvary with the
contract. Carefullycheck your goods againstthe packing listorcontract. Contactthe sellerif you have
any questionsorfindany errors.
1.3.2 M6000-24GT2XS Service Module
1. Product Appearance
Figure 1-5 Appearance of M6000-24GT2XS

Hardware Installation and Reference Guide Product Overview
10
2. Front Panel
Figure 1-6 Front Panel of M6000-24GT2XS
Item
Description
Linecard status
indicator
Linecard status indicator.Thestatuses are as follows:
●
Solidgreen:The service moduleworks properly.
●
Blinkinggreen:The service moduleis startingup.
●
Blinkingyellow:Hot swappingorconfiguration conflictoccurs.
Off: The system is not poweredonor the system is receiving powerbut is not
functioningproperly.
RJ-45copper
port
24 10/100/1000Base-Tadaptive Ethernetports that supportauto-negotiation.
The copperport uses an RJ45connector.
RJ-45copper
port indicator
24 10/100/1000Base-Tadaptive Ethernetport status indicator.The statuses
are as follows:
●
Solidgreen:The port has madeasuccessful 1000Mbps link.
●
Blinkinggreen:The port is sending orreceiving traffic at 1000Mpbs.
Off: No linkis detectedfor the port.
SFP+ port
Two SFP+ ports.For details aboutapplicable transceivermodules,see
TransceiverModules.
SFP+ port
indicator
Two SFP+ portindicators.The statuses areas follows:
●
Solidgreen:The port has madea successful link.
●
Blinkinggreen:The port is sendingorreceiving traffic.
Off: No linkis detectedfor the port.

Hardware Installation and Reference Guide Product Overview
11
3. Technical Specifications
Table 1-5 M6000-24GT2XS Technical Specifications
Product Model
M6000-24GT2XS
Port Type
24 10/100/1000BASE-TRJ-45copperports and two SFP+ ports
Supported
Transceiver
Modules and
Cable Types
For details,see
TransceiverModules.Coppercables are notsupported.
Supportedmodels maybe updatedanytime. For details,consultRuijieNetworks Co.,Ltd.
Indicator
Status and Link/ACT indicators
Hot Swapping
Unsupported
Power
Consumption
< 20.6 W
Certificate
CE
Operating
Temperature
0°C to 50°C (32°F to 122°F)
Storage
Temperature
–40°Cto 70°C (-40°F to 158°F)
Operating
Humidity
10%to 90%RH (non-condensing)
MTBF
> 200,000hours
Weight
Net weight:0.9 kg (1.98 lbs.)
Dimensions
(H x W x D)
40.3 mm x227 mm x210 mm (1.59in. x 8.94 in. x 8.27 in.)

Hardware Installation and Reference Guide Product Overview
12
1.3.3 M6000-24SFP2XS Service Module
1. Product Appearance
Figure 1-7 Appearance of M6000-24SFP2XS
2. Front Panel
Figure 1-8 Front Panel of M6000-24SFP2XS
Item
Description
Linecard status
indicator
Line card status indicator.Thestatuses areas follows:
●
Solidgreen:The service moduleworks properly.
●
Blinkinggreen:The service moduleis startingup.
●
Blinkingyellow:Hot swappingorconfiguration conflictoccurs.
Off: The system is not poweredonor the system is receiving powerbut is not
functioningproperly.
SFP port
24 SFP ports. For details aboutapplicable transceivermodules,see
TransceiverModules.
SFP port
indicator
24 SFP port indicators.Thestatuses areas follows:
●
Solidgreen:The port has madea successful link.

Hardware Installation and Reference Guide Product Overview
13
3. Technical Specifications
Table 1-6 M6000-24SFP2XS Technical Specifications
Product Model
M6000-24SFP2XS
Port Type
24 SFP ports and two SFP+ ports
Supported
Transceiver
Modules and
Cable Types
For details,see
TransceiverModules.Coppercables are notsupported.
Supportedmodels maybe updatedanytime.For details,consultRuijieNetworks Co.,Ltd.
Indicator
Status and Link/ACT indicators
Hot Swapping
Unsupported
Power
Consumption
< 44.4 W
Certificate
CE
Operating
Temperature
0°C to 50°C (32°F to 122°F)
Storage
Temperature
–40°Cto 70°C (-40°F to 158°F)
Operating
Humidity
10%to 90%RH (non-condensing)
MTBF
> 200,000hours
Weight
Net weight:about 0.95 kg (2.09 lbs.)
Dimensions (H
x W x D)
40.3 mm x227 mm x210 mm (1.59in. x 8.94 in. x 8.27 in.)
●
Blinkinggreen:The port is sending orreceiving traffic.
Off: No linkis detectedfor the port.
SFP+ port
Two SFP+ ports.For details aboutapplicable transceivermodules,see
TransceiverModules.
SFP+ port
indicator
Two SFP+ portindicators.The statuses areas follows:
●
Solidgreen:The port has madea successful link.
●
Blinkinggreen:The port is sendingorreceivingtraffic.
Off: No linkis detectedfor the port.

Hardware Installation and Reference Guide Product Overview
14
1.3.4 M6000-16GT8SFP2XS Service Module
1. Product Appearance
Figure 1-9 Appearance of M6000-16GT8SFP2XS
2. Front Panel
Figure 1-10 Front Panel of M6000-16GT8SFP2XS
Item
Description
Linecard status
indicator
Linecard status indicator.Thestatuses areas follows:
●
Solidgreen:The service moduleworks properly.
●
Blinkinggreen:The service moduleis startingup.
●
Blinkingyellow:Hot swappingorconfiguration conflictoccurs.
Off: The system is not powered on or the system is receivingpowerbut is not
functioningproperly.
RJ-45copper
port
16 10/100/1000Base-Tadaptive Ethernetports that supportauto-negotiation.
The copperport uses an RJ45connector.
RJ-45copper
16 10/100/1000Base-Tadaptive Ethernetport status indicators.Thestatuses

Hardware Installation and Reference Guide Product Overview
15
port indicator
are as follows:
●
Solidgreen:The port has madeasuccessful 1000Mbps link.
●
Blinkinggreen:The port is sending orreceiving traffic at 1000Mpbs.
Off: No linkis detectedfor the port.
SFP port
Eight SFP ports. For details aboutapplicable transceivermodules,see
TransceiverModules.
SFP port
indicator
Eight SFP port indicators.The statuses areas follows:
●
Solidgreen:The port has madea successful link.
●
Blinkinggreen:The port is sending orreceiving traffic.
Off: No linkis detectedfor the port.
SFP+ port
Two SFP+ ports.For details aboutapplicable transceivermodules,see
TransceiverModules.
SFP+ port
indicator
Two SFP+ portindicators.The statuses areas follows:
●
Solidgreen:The port has madea successful link.
●
Blinkinggreen:The port is sending orreceiving traffic.
Off: No linkis detectedfor the port.

Hardware Installation and Reference Guide Product Overview
16
3. Technical Specifications
Table 1-7 M6000-16GT8SFP2XS Technical Specifications
Product Model
M6000-16GT8SFP2XS
Port Type
16 10/100/1000BASE-TRJ-45copperports, eightSFP ports,and two SFP+ ports
Supported
Transceiver
Modules and
Cable Types
For details,see
TransceiverModules.Coppercables are notsupported.
Supportedmodels maybe updatedanytime.For details,consultRuijieNetworks Co.,Ltd.
Indicator
Status and Link/ACT indicators
Hot Swapping
Unsupported
Power
Consumption
< 28.5 W
Certificate
CE
Operating
Temperature
0°C to 50°C (32°F to 122°F)
Storage
Temperature
–40°Cto 70°C (-40°F to 158°F)
Operating
Humidity
10%to 90%RH (non-condensing)
MTBF
> 200,000hours
Weight
Net weight:0.9 kg (1.98 lbs.)
Dimensions
(H x W x D)
40.3 mm x227 mm x210 mm (1.59in. x 8.94 in. x 8.27 in.)

Hardware Installation and Reference Guide Product Overview
17
1.3.5 M6000-16SFP8GT2XS Service Module
1. Product Appearance
Figure 1-11 Appearance of M6000-16SFP8GT2XS
2. Front Panel
Figure 1-12 Front Panel of M6000-16SFP8GT2XS
Item
Description
Linecard status
indicator
Linecard status indicator.Thestatuses areas follows:
●
Solidgreen:The service moduleworks properly.
●
Blinkinggreen:The service moduleis startingup.
●
Blinkingyellow:Hot swappingorconfiguration conflictoccurs.
Off: The system is not poweredonor the system is receiving powerbut is not
functioningproperly.
SFP port
16 SFP ports. For details aboutapplicable transceivermodules,see
TransceiverModules.
SFP port
16 SFP port indicators.Thestatuses areas follows:
