Ruijie RG-S5300-E&5310-E Series Switches
Hardware Installation and Reference Guide
Document Version: V1.05
Date: 2023.10.08
Copyright © 2023 Ruijie Networks

Copyright
Copyright © 2023 Ruijie Networks
All rights are reserved in this document and this statement.
Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document
or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks
is prohibited.
Trademark and are owned by Ruijie Networks.
All other trademarks or registered trademarks mentioned in this document are owned by their respective owners.
Disclaimer
The products, services, or features you purchase are subject to commercial contracts and terms. Some or all of
the products, services or features described in this document may not be within the scope of your purchase or
use. Unless otherwise agreed in the contract, Ruijie Networks does not make any express or implied statement
or guarantee for the content of this document.
Due to product version upgrades or other reasons, the content of this document will be updated from time to
time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.
This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder
any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
Ruijie Networks Website: https://www.ruijienetworks.com/
Technical Support Website: https://ruijienetworks.com/support
Case Portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical Support Email: [email protected]
Skype: [email protected]
Conventions
1. Conversions
Convention
Description
Bold font
Commands, command options, and keywords are in bold font.
Italic font
Arguments for which you supply values are in italic font.
[ ]
Elements in square brackets are optional.
{ x | y | z }
Alternative keywords are grouped in braces and separated by
vertical bars.
[ x | y | z ]
Optional alternative keywords are grouped in brackets and
separated by vertical bars.
&<1-n>
The argument before the sign (&) can be input for consecutive 1- n
times.
//
Double slashes at the beginning of a line of code indicate a
comment line.
2. Signs
The signs used in this document are described as follows:

II
Warning
An alert that calls attention to important rules and information that if not understood or followed can result in
data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed can result in function
failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or followed will not lead to
serious consequences.
Specification
An alert that contains a description of product or version support.
3. Note
The manual offers configuration information (including model, port type and command line interface) for
indicative purpose only. In case of any discrepancy or inconsistency between the manual and the actual version,
the actual version prevails.

Hardware Installation and Reference Guide Product Overview
1
1Product Overview
The RG-S5300-E and RG-S5310-E series switches are new generation layer 3 switches, providing high performance, consolidated
security and multiple services. The switches are mainly applied to the access layer to provide line-rate switching and complete QoS
policies, prioritizing some traffic over others to ensure important data transmission without lantency. The switches also support a wide
variety of Ethernet interfaces with flexible media options for network construction.
There are 12 models available now.
Model
10/100/1000Base-T
Adaptive Ethernet
Port
GE SFP
Port
10GE
SFP+
Port
Management
Port
USB
Port
Console
Port
RPS
RG-S5310-24GT4XS-E
24
N/A
4
1
1
1
Dual
Power
Supplies
RG-S5300-24GT2SFP2XS-E
24
2
2
1
1
1
Fixed
Power
Supply
RG-S5300-24GT4XS-E
24
N/A
4
1
1
1
Fixed
Power
Supply
RG-S5310-48GT4XS-E
48
N/A
4
1
1
1
Dual
Power
Supplies
RG-S5300-48GT2SFP2XS-E
48
2
2
1
1
1
Fixed
Power
Supply
RG-S5300-48GT4XS-E
48
N/A
4
1
1
1
Fixed
Power
Supply
RG-S5310-24GT4XS-P-E
24 (PoE+ Capable)
N/A
4
1
1
1
Dual
Power
Supplies
RG-S5300-24GT2SFP2XS-P-
E
24 (PoE+ Capable)
2
2
1
1
1
Fixed
Power
Supply
RG-S5300-24GT4XS-P-E
24 (PoE+ Capable)
N/A
4
1
1
1
Fixed
Power
Supply
RG-S5310-24SFP4XS-E
N/A
24
4
1
1
1
Dual
Power
Supplies
RG-S5310-48SFP4XS-E
N/A
48
4
1
1
1
Dual
Power

Hardware Installation and Reference Guide Product Overview
2
Supplies
RG-S5310-48GT4XS-P-E
48 (PoE+ Capable)
N/A
4
1
1
1
Dual
Power
Supplies
This is a Class A product. In a domestic environment this product may cause radio interference. In this case, users are advised to
take proper measures against the interference.
An SFP+ port supports both 10GBase-R and 1000Base-X.
The PoE+ port is backward compatible with the PoE standard.
Management port: The management port is a 10/100/1000Base-T Ethernet port that uses an RJ-45 connector. This port is
connected to an Ethernet port of a PC with an Ethernet cable for program downloading. You can manage and maintain the switch
remotely by connecting the management port to the Ethernet port of a PC with an Ethernet cable.
USB port: The USB port is the interface into which you plug your USB storage device for online upgrade or log storage.
Console port: The console port is an RS-232 port that uses an RJ45 connector. The console port is used to connect a PC directly
to the management system for debugging, configuration, maintenance, management and program loading.
1.1 RG-S5310-24GT4XS-E
Specifications
Model
RG-S5310-24GT4XS-E
CPU
Dual-core CPU with the clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
SFP+ Port:
SFP Modules and SFP BIDI Modules
SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
See Chapter 7 for details.
The module types may update without prior notification. Please contact Ruijie Networks for
details.
Power Supply Module
Slots
2
Power Supply Module
Model: RG-PA70IB
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 2 A
Model: RG-PA150IB-F

Hardware Installation and Reference Guide Product Overview
3
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 3 A
Model: RG-PD150IB-F
DC Input
Rated Voltage Range: -48 V DC to -60 V DC
Rated Current Per Circuit: 5 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
Not Supported
Power Consumption
< 40 W
Operating Temperature
0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum
operating temperature decreases by 1°C (1.8°F) every time the altitude increases by 220 m (721.78
ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature Alarming
Supported
EMC Certification
GB/T 9254.1
Safety Regulation
Compliance
GB 4943.1
Dimensions
(W x D x H)
442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)
Weight
4 kg (8.82 lbs.)
Appearance
The front panel of the RG-S5310-24GT4XS-E switch provides 24 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports, one
management port, one Console port and one USB port. The back panel has two power supply module slots.
Figure 1-1 RG-S5310-24GT4XS-E Switch Appearance

Hardware Installation and Reference Guide Product Overview
4
Front Panel
Figure 1-2 Front Panel of RG-S5310-24GT4XS-E
1. System Status LED
2. MGMT Port LED
3. PWR1 Status LED
4. PWR2 Status LED
5. USB Port
6. Console Port
7. Management Port
8. 10/100/1000Base-T Ethernet Port
9. 10GE SFP+ Port
10. Port Status LED
Back Panel
Figure1-3 Back Panel of RG-S5310-24GT4XS-E
1. Grounding Stud
2. Power Supply Module Slot 1 (A filler panel is required if the
slot is vacant.)
3. Power Supply Module Slot 2 (A filler panel is required if the
slot is vacant.)
Power Supply Module
The RG-S5310-24GT4XS-E switch supports dual power supply modules. See Chapter 1.13 for details about the power supply modules.
The switch can be powered on by either one power supply module or dual power supply modules. If both power supply modules are
used, the switch works in the power redundancy mode.

Hardware Installation and Reference Guide Product Overview
5
Cooling
The RG-S5310-24GT4XS-E switch adopts a left-to-right and front-to-right airflow to ensure normal operation. Maintain a minimum
clearance of 100 mm (3.94 in.) around the device for air circulation.
Figure 1-4 Airflow Direction
LED
Function
Panel ID
Color
Status
System Status LED
Status
Off
System is not powered on.
Blinking Green
(3 Hz)
System is being initialized. Continuous blinking
indicates a fault.
Blinking Green
(10 Hz)
System is being located.
Solid Green
System is operating normally.
Solid Yellow
The temperature at the air intake and exhaust vents
exceeds the threshold.
Solid Red
1. The temperature at the air intake and exhaust vents
well exceeds the threshold.
2. The system is not functioning properly.
Power Supply Status LED
PWR1/PWR2
Off
The power supply module is not seated.
Solid Green
The power supply module is seated and providing
power to the switch.
Solid Yellow
The model of the power supply module is not
supported or cannot be read.
Solid Red
The redundant power supply module is not functioning
properly or not connected with the AC power cord.
Management Port LED
MGMT
Off
No link is detected for this port.
Solid Green
The port has made a successful 1000 Mbps link.
Blinking Green
The port is sending and receiving traffic at 1000 Mbps.
Solid Yellow
The port has made a successful 10/100 Mbps link.
Blinking Yellow
The port is sending and receiving traffic at 10/100
Mbps.
10GE SFP+ Port LED
25F to 28F
Off
No link is detected for this port.

Hardware Installation and Reference Guide Product Overview
6
Solid Green
The port has made a successful 1/10 Gbps link.
Blinking Green
The port is sending and receiving traffic at 1/10 Gbps.
10/100/1000Base-T Ethernet
Port LED
1F to 24F
Off
No link is detected for this port.
Solid Green
The port has made a successful 10/100/1000 Mbps
link.
Blinking Green
The port is sending and receiving traffic at
10/100/1000 Mbps.
1.2 RG-S5300-24GT2SFP2XS-E
Specifications
Model
RG-S5300-24GT2SFP2XS-E
CPU
Dual-core CPU with the clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP and SFP+ Module
Type
SFP Port:
SFP Modules and SFP BIDI Modules.
SFP+ Port:
SFP Modules and SFP BIDI Modules.
SFP+ Modules, SFP+ Cables and SFP BIDI Modules.
See Chapter 7 for details.
The module types may update without prior notification. Please contact Ruijie Networks for
details.
Built-in Power Supply
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 1.5 A
SFP Port
1000Base-X Capable
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
Not supported
Power Consumption
< 40 W
Operating Temperature
0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum
operating temperature decreases by 1°C (1.8°F) every time the altitude increases by 220 m (721.78
ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level

Hardware Installation and Reference Guide Product Overview
7
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature Alarming
Supported
EMC Certification
GB/T 9254.1
Safety Regulation
Compliance
GB 4943.1
Dimensions
(W x D x H)
442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.)
Weight
2.7 kg (5.95 lbs.)
Appearance
The front panel of the RG-S5300-24GT2SFP2XS-E switch provides 24 10/100/1000Base-T Ethernet ports, two GE SFP ports, two 10GE
SFP+ ports (The speed is 1000 Mbps by default and can be improved to 10 Gbps if you purchase a license. Without a license, the port
can make a successful link only when the peer end speed is 1000 Mpbs. If configured as a VSL port, the port supports a speed of 10
Gbps without the license), one management port, one Console port and one USB port. The back panel has an AC power plug.
Figure 1-5 RG-S5300-24GT2SFP2XS-E Switch Appearance
Front Panel
Figure 1-6 Front Panel of RG-S5300-24GT2SFP2XS-E

Hardware Installation and Reference Guide Product Overview
8
1. System Status LED
2. MGMT Port LED
3. USB Port
4. Console Port
5. Management Port
6. 10/100/1000Base-T Ethernet Port
7. GE SFP Port
8. GE SFP Port LED
9. 10GE SFP+ Port
10. 10GE SFP+ Port LED
Back Panel
Figure1-7 Back Panel of RG-S5300-24GT2SFP2XS-E
1. Grounding Stud
2. AC Power Plug
Power Supply
The RG-S5300-24GT2SFP2XS-E switch has a built-in power supply module. The back panel has an AC power plug.
Cooling
The RG-S5300-24GT2SFP2XS-E switch adopts a left-to-right and front-to-right airflow to ensure normal operation. Maintain a minimum
clearance of 100 mm (3.94 in.) around the device for air circulation.
Figure 1-8 Airflow Direction
LED
Function
Panel ID
Color
Status
System Status LED
Status
Off
System is not powered on.
Blinking Green (3
Hz)
System is being initialized. Continuous blinking
indicates a fault.
Blinking Green
(10 Hz)
System is being located.

Hardware Installation and Reference Guide Product Overview
9
Solid Green
System is operating normally.
Solid Yellow
The temperature at the air intake and exhaust vents
exceeds the threshold.
Solid Red
1. The temperature at the air intake and exhaust vents
well exceeds the threshold.
2. The system is not functioning properly.
MGMT Port LED
MGMT
Off
No link is detected for this port.
Solid Green
The port has made a successful 1000 Mbps link.
Blinking Green
The port has made a successful 1000 Mbps link.
Solid Yellow
The port has made a successful 10/100 Mbps link.
Blinking Yellow
The port is sending and receiving traffic at 10/100
Mbps.
10GE SFP+ Port LED
27F to 28F
Off
No link is detected for this port.
Solid Green
The port has made a successful 1/10 Gbps link.
Blinking Green
The port is sending and receiving traffic at 1/10 Gbps.
GE SFP Port LED
25F to 26F
Off
No link is detected for this port.
Solid Green
The port has made a successful 1000 Mbps link.
Blinking Green
The port is sending and receiving traffic at 1000 Mbps.
10/100/1000Base-T
Ethernet Port LED
1F to 24F
Off
No link is detected for this port.
Solid Green
The port has made a successful 10/100/1000 Mbps
link.
Blinking Green
The port is sending and receiving traffic at
10/100/1000 Mbps.
1.3 RG-S5300-24GT4XS-E
Specifications
Model
RG-S5300-24GT4XS-E
CPU
Dual-core CPU with the clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
SFP+ Port:
SFP Modules and SFP BIDI Modules
SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
See Chapter 7 for details.
The module types may update without prior notification. Please contact Ruijie Networks for
details.
Built-in Power Supply
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz

Hardware Installation and Reference Guide Product Overview
10
Rated Current Per Circuit: 1.5 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
Not supported
Power Consumption
< 40 W
Operating Temperature
0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum
operating temperature decreases by 1°C (1.8°F) every time the altitude increases by 220 m (721.78
ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature Alarming
Supported
EMC Certification
GB/T 9254.1
Safety Regulation
Compliance
GB 4943.1
Dimensions
(W x D x H)
442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.)
Weight
2.7 kg (5.95 lbs.)
Appearance
The front panel of the RG-S5300-24GT4XS-E switch provides 24 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports, one
management port, one Console port and one USB port. The back panel has an AC power plug.
Figure 1-9 RG-S5300-24GT4XS-E Switch Appearance
Front Panel

Hardware Installation and Reference Guide Product Overview
11
Figure 1-10 Front Panel of RG-S5300-24GT4XS-E
1. System Status LED
2. Management Port LED
3. USB Port
4. Console Port
5. Management Port
6. 10/100/1000Base-T Ethernet Port
7. 10GE SFP+ Port
8. Port LED
Back Panel
Figure1-11 Back Panel of RG-S5300-24GT4XS-E
1. Grounding Stud
2. AC Power Plug
Power Supply
The RG-S5300-24GT4XS-E switch has a built-in power supply module. The back panel has an an AC power plug.
Cooling
The RG-S5300-24GT4XS-E switch adopts a left-to-right and front-to-right airflow to ensure normal operation. Maintain a minimum
clearance of 100 mm (3.94 in.) around the device for air circulation.
Figure 1-12 Airflow Direction

Hardware Installation and Reference Guide Product Overview
12
LED
Function
Panel ID
Color
Status
System Status LED
Status
Off
System is not powered on.
Blinking Green (3
Hz)
System is being initialized. Continuous blinking
indicates a fault.
Blinking Green
(10 Hz)
System is being located.
Solid Green
System is operating normally.
Solid Yellow
The temperature at the air intake and exhaust vents
exceeds the threshold.
Solid Red
1. The temperature at the air intake and exhaust vents
well exceeds the threshold.
2. The system is not functioning properly.
Management Port LED
MGMT
Off
No link is detected for this port.
Solid Green
The port has made a successful 1000 Mbps link.
Blinking Green
The port is sending and receiving traffic at 1000 Mbps.
Solid Yellow
The port has made a successful 10/100 Mbps link.
Blinking Yellow
The port is sending and receiving traffic at 10/100
Mbps.
10GE SFP+ Port LED
25F to 28F
Off
No link is detected for this port.
Solid Green
The port has made a successful 1/10 Gbps link.
Blinking Green
The port is sending and receiving traffic at 1/10 Gbps.
10/100/1000Base-T
Ethernet Port LED
1F to 24F
Off
No link is detected for this port.
Solid Green
The port has made a successful 10/100/1000 Mbps
link.
Blinking Green
The port is sending and receiving traffic at
10/100/1000 Mbps.
1.4 RG-S5310-48GT4XS-E
Specifications
Model
RG-S5310-48GT4XS-E
CPU
Dual-core CPU with the clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
SFP+ Port:
SFP Modules and SFP BIDI Modules
SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
See Chapter 7 for details.

Hardware Installation and Reference Guide Product Overview
13
The module types may update without prior notification. Please contact Ruijie Networks for
details.
Power Supply Module
Slots
2
Power Supply Module
RG-PA70IB
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 2 A
RG-PA150IB-F
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 3 A
RG-PD150IB-F
DC Input
Rated Voltage Range: -48 V DC to -60 V DC
Rated Current Per Circuit: 5 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
Not supported
Power Consumption
< 55 W
Operating Temperature
0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum
operating temperature decreases by 1°C (1.8°F) every time the altitude increases by 220 m (721.78
ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature Alarming
Supported
EMC Certification
GB/T 9254.1
Safety Regulation
Compliance
GB 4943.1
Dimensions
(W x D x H)
442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)

Hardware Installation and Reference Guide Product Overview
14
Weight
4.3 kg (9.48 lbs.)
Appearance
The front panel of the RG-S5310-48GT4XS-E Ethernet switch provides 48 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports, one
management port, one Console port and one USB port. The back panel has two power supply module slots.
Figure 1-13 RG-S5310-48GT4XS-E Switch Appearance
Front Panel
Figure 1-14 Front Panel of RG-S5310-48GT4XS-E
1. System Status LED
2. Management Port LED
3. PWR1 Status LED
4. PWR2 Status LED
5. USB Port
6. Console Port
7. Management Port
8. 10/100/1000Base-T Ethernet Port
9. 10GE SFP+ Port
10. Port LED
Back Panel
Figure 1-15 Back Panel of RG-S5310-48GT4XS-E

Hardware Installation and Reference Guide Product Overview
15
1. Grounding Stud
2. Power Supply Module Slot 1 (A filler panel is required if the
slot is vacant.)
3. Power Supply Module Slot 2 (A filler panel is required if the
slot is vacant.)
Power Supply
The RG-S5310-48GT4XS-E switch supports dual power supply modules. See Chapter 1.13 for details about the power supply modules.
The switch can be powered on by either one power supply module or dual power supply modules. If both power supply modules are
used, the switch works in the power redundancy mode.
Cooling
The RG-S5310-48GT4XS-E switch adopts a left-to-right and front-to-right airflow to ensure normal operation. Maintain a minimum
clearance of 100 mm (3.94 in.) around the device for air circulation.
Figure 1-16 Airflow Direction
LED
Function
Panel ID
Color
Status
System Status LED
Status
Off
System is not powered on.
Blinking Green (3
Hz)
System is being initialized. Continuous blinking
indicates a fault.
Blinking Green
(10 Hz)
System is being located.
Solid Green
System is operating normally.
Solid Yellow
The temperature at the air intake and exhaust vents
exceeds the threshold.
Solid Red
1. The temperature at the air intake and exhaust vents
well exceeds the threshold.
2. The system is not functioning properly.
Power Supply Status LED
PWR1/PWR2
Off
The power supply module is not seated.
Solid Green
The power supply module is seated and providing
power to the switch.
Solid Yellow
The model of the power supply module is not

Hardware Installation and Reference Guide Product Overview
16
supported or cannot be identified.
Solid Red
The redundant power supply module is not functioning
properly or not connected with the AC power cord.
Management Port LED
MGMT
Off
No link is detected for this port.
Solid Green
The port has made a successful 1000 Mbps link.
Blinking Green
The port is sending and receiving traffic at 1000 Mbps.
Solid Yellow
The port has made a successful 10/100 Mbps link.
Blinking Yellow
The port is sending and receiving traffic at 10/100
Mbps.
10GE SFP+ Port LED
49F to 52F
Off
No link is detected for this port.
Solid Green
The port has made a successful 1/10 Gbps link.
Blinking Green
The port is sending and receiving traffic at 1/10 Gbps.
10/100/1000Base-T
Ethernet Port LED
1F to 48F
Off
No link is detected for this port.
Solid Green
The port has made a successful 10/100/1000 Mbps
link.
Blinking Green
The port is sending and receiving traffic at
10/100/1000 Mbps.
1.5 RG-S5300-48GT2SFP2XS-E
Specifications
Model
RG-S5300-48GT2SFP2XS-E
CPU
Dual-core CPU with the clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module
SFP Port:
SFP Modules and SFP BIDI Modules
SFP+ Port:
SFP Modules and SFP BIDI Modules
SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
See Chapter 7 for details.
The module types may update without prior notification. Please contact Ruijie Networks for
details.
Built-in Power Supply
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 2 A
SFP Port
1000Base-X Capable
