Ruijie RG-S6510-32CQ Installation and operating manual

Ruijie RG-S6510-32CQ Switch
Hardware Installation and Reference Guide
Document Version: V2.0
Date: November 16, 2023
Copyright © 2023 Ruijie Networks

Copyright
Copyright © 2023 Ruijie Networks
All rights are reserved in this document and this statement.
Without the prior written consent of Ruijie Networks, no organization or individual is permitted to reproduce,
extract, back up, modify, or distribute the content of this document in any manner or form. It is also prohibited to
translate the document into other languages or use any or all parts of it for commercial purposes.
and trademarks are owned by Ruijie Networks.
All other trademarks or registered trademarks mentioned in this document are owned by their respective owners.
Disclaimer
The products, services, or features that you purchase are subject to commercial contracts and terms. It is
possible that some or all of the products, services, or features described in this document may not be available
for purchase or use. Unless agreed upon otherwise in the contract, Ruijie Networks does not provide any explicit
or implicit statements or warranties regarding the content of this document.
The content of this document is subject to constant change due to product version upgrades or other reasons.
Thus, Ruijie Networks reserves the right to modify the content of the document without prior notice or prompt.
This manual serves solely as a user guide. While Ruijie Networks endeavors to ensure the accuracy and
reliability of the content when compiling this manual, it does not guarantee that the content of the manual is free
of errors or omissions. All information contained in this manual does not constitute any explicit or implicit
warranties.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
Ruijie Networks website: https://www.ruijienetworks.com/
Online support center: https://ruijienetworks.com/support
Case portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Email support: [email protected]
Live chat: https://www.ruijienetworks.com/rita
Conventions
1. Signs
The signs used in this document are described as follows:
Danger
An alert that contains important safety instructions. Before you work on any equipment, be aware of the
hazards involved and be familiar with standard practices in case of preventing accidents.
Warning
An alert that calls attention to important rules and information that if not understood or followed can result in
data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed can result in function
failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or followed will not lead to
serious consequences.
Specification
An alert that contains a description of product or version support.

II
2. Notes
The manual provides configuration information, including models, port types, and command line interfaces, for
reference purposes only. In the event of any discrepancy or inconsistency between the manual and the actual
version, the actual version shall take precedence.

I
Contents
Preface.................................................................................................................................................. I
1 Overview ........................................................................................................................................... 1
1.1 About the RG-S6510-32CQ.......................................................................................................1
1.2 Component Modules..................................................................................................................1
1.3 Chassis ......................................................................................................................................1
1.3.1 Appearance....................................................................................................................2
1.3.2 LEDs ..............................................................................................................................4
1.3.3 Ports...............................................................................................................................5
1.3.4 Cooling...........................................................................................................................5
1.3.5 Technical Specifications.................................................................................................6
1.3.6 Asset Tag........................................................................................................................9
1.4 Power Module............................................................................................................................9
1.4.1 RG-PA550I-F................................................................................................................10
1.4.2 RG-PD800I-F...............................................................................................................12
1.5 Fan Module..............................................................................................................................14
1.5.1 M1HFAN I-F.................................................................................................................14
1.6 Cables......................................................................................................................................16
1.6.1 Console Cable .............................................................................................................16
1.6.2 Ethernet Cable.............................................................................................................17
1.6.3 Power Cord..................................................................................................................17
1.6.4 Grounding Wire............................................................................................................19
1.7 Pluggable Modules..................................................................................................................20
2 Preparing for Installation................................................................................................................. 21

II
2.1 Safety Guidelines.....................................................................................................................21
2.1.1 General Precautions....................................................................................................21
2.1.2 Chassis-Lifting Guidelines...........................................................................................21
2.1.3 Electricity Safety ..........................................................................................................21
2.1.4 Preventing ESD Damage.............................................................................................22
2.1.5 Laser Safety.................................................................................................................22
2.1.6 Storage Guidelines ......................................................................................................22
2.2 Site Requirements ...................................................................................................................23
2.2.1 Floor Loading...............................................................................................................23
2.2.2 Airflow...........................................................................................................................23
2.2.3 Space...........................................................................................................................23
2.2.4 Temperature.................................................................................................................23
2.2.5 Humidity.......................................................................................................................23
2.2.6 Cleanliness...................................................................................................................24
2.2.7 System Grounding.......................................................................................................25
2.2.8 Preventing Electromagnetic Interference ....................................................................26
2.2.9 Surge Protection..........................................................................................................26
2.3 Rack-Mounting Guidelines.......................................................................................................26
2.4 Tools ........................................................................................................................................27
2.5 Unpacking the Switch..............................................................................................................28
2.5.1 Verifying the Shipped Content.....................................................................................28
2.5.2 Unpacking the Container.............................................................................................28
3 Installing the Switch ........................................................................................................................ 30
3.1 Installation Procedure..............................................................................................................31

III
3.2 Installing the Rack....................................................................................................................32
3.2.1 Installation Guidelines..................................................................................................32
3.2.2 Procedure.....................................................................................................................32
3.3 Installing the Chassis...............................................................................................................32
3.3.1 Installation Guidelines..................................................................................................32
3.3.2 Mounting the Brackets.................................................................................................33
3.3.3 Mounting the Chassis on the Rack..............................................................................33
3.3.4 Mounting the Chassis on the Workbench....................................................................34
3.4 Installing the Protective Grounding Wire.................................................................................35
3.4.1 Installation Guidelines..................................................................................................35
3.4.2 Procedure.....................................................................................................................35
3.5 Installing and Removing the Fan Module................................................................................36
3.5.1 Installing the Fan Module.............................................................................................36
3.5.2 Removing the Fan Module...........................................................................................36
3.6 Installing and Removing the Power Module............................................................................37
3.6.1 Installing the RG-PA550I-F..........................................................................................37
3.6.2 Installing the RG-PD800I-F..........................................................................................39
3.6.3 Removing the Power Module.......................................................................................41
3.7 Installing and Removing the Pluggable Module......................................................................42
3.8 Verifying Installation.................................................................................................................42
3.9 Connecting the Power Cord.....................................................................................................43
4 Commissioning................................................................................................................................ 43
4.1 Setting Up the Configuration Environment..............................................................................43
4.2 Powering on the Device...........................................................................................................45

IV
4.2.1 Checklist Before Power-on..........................................................................................45
4.2.2 Power-on......................................................................................................................45
4.2.3 ChecklistAfter Power-on .............................................................................................45
5 Monitoring and Maintenance........................................................................................................... 46
5.1 Monitoring................................................................................................................................46
5.1.1 Monitoring the LEDs ....................................................................................................46
5.1.2 Running the CLI Commands .......................................................................................46
5.2 Maintenance ............................................................................................................................46
5.2.1 Replacing the Power Module.......................................................................................46
5.2.2 Replacing the Fan Module...........................................................................................47
5.2.3 Replacing the Lithium Battery......................................................................................47
5.2.4 Replacing the Fuse......................................................................................................47
6 Troubleshooting............................................................................................................................... 48
6.1 Flowchart..................................................................................................................................48
6.2 Common Issues.......................................................................................................................49
6.2.1 Forgetting Login Password..........................................................................................49
6.2.2 AC Power Module Failure............................................................................................49
6.2.3 Fan Module Not Rotating.............................................................................................49
6.2.4 No Output on the Console...........................................................................................49
6.2.5 Garbled Output on the Console...................................................................................49
6.2.6 Optical Port Linkdown..................................................................................................50
7 Appendix.......................................................................................................................................... 50
7.1 Labeling Process .....................................................................................................................50
7.1.1 Hand Writing on Labels................................................................................................50

V
7.1.2 Pasting Labels .............................................................................................................50
7.1.3 Label Contents.............................................................................................................51
7.2 Connectors and Media.............................................................................................................52
7.2.1 1000BASE-T Port ........................................................................................................52
7.2.2 100BASE-TX/10BASE-T Port......................................................................................53
7.3 Surge Protection......................................................................................................................54
7.3.1 Installing an AC Power Arrester...................................................................................54
7.3.2 Installing an Ethernet PortArrester..............................................................................55
7.4 Site Selection...........................................................................................................................56
7.5 Recommended Cabling...........................................................................................................57

Hardware Installation and Reference Guide Overview
1
1 Overview
1.1 About the RG-S6510-32CQ
The RG-S6510-32CQ switch is a next-generation 100GE switch featuring high-performance, high-density, and
low-latency launched by Ruijie Networks for data centers and high-end campuses. The RG-S6510-32CQ switch
provides high-density 25GE/50GE/100GE access and diverse data center features. It can be used with Ruijie’s
RG-N18000-X and RG-S6920-4C switches for a high-performance and high-reliability data center network.
Table 1-1 RG-S6510-32CQ Overview
Chassis
100GE Ports
Expansion
Module Slots
Power
Redundancy
Fan Redundancy
RG-S6510-32CQ
32
N/A
1 + 1
4 + 1
Note
The product images involved in this manual are for indicative purpose only. The appearance is subject to the
actual equipment.
1.2 Component Modules
The RG-S6510-32CQ adopts the modular design. Compliant with industry standards, the design differentiates
modules and integrates module interfaces to ensure an integrated system with independent function modules.
Table 1-2 Component Modules
Chassis
Power Module
Fan Module
RG-S6510-32CQ
RG-PA550I-F
M1HFAN I-F
RG-PD800I-F
Caution
Different power modules are interchangeable. That is, the switch allows concurrent AC and DC input. For
example, input 1 uses mains electricity (AC power) and input 2 use Uninterrupted Power Supply (UPS) DC
power.
1.3 Chassis
The RG-S6510-32CQ hardware system consists of a chassis, a power supply system, and a cooling system.
Power supply system: provides two power module slots and supports 1 + 1 power redundancy.

Hardware Installation and Reference Guide Overview
2
Cooling system: provides five fan module slots and supports 4 +1fan redundancy.
1.3.1 Appearance
1. Appearance
Figure 1-1 Front View of the RG-S6510-32CQ
Figure 1-2 Rear View of the RG-S6510-32CQ
2. Structure
Figure 1-3 Front Panel Structure

Hardware Installation and Reference Guide Overview
3
Table 1-3 Front Panel Components
No.
Component
1
USB 2.0 port
2
Console port
3
Management port
4
QSFP28 port LED
5
QSFP28 port
6
System status LED
7
Power status LED
8
Fan status LED
9
Asset tag
Figure 1-4 Rear Panel Structure
Table 1-4 Rear Panel Components
No.
Component
1
Power module slot
2
Fan module slot
3
Grounding stud
4
Ground for ESD-preventive wrist strap

Hardware Installation and Reference Guide Overview
4
1.3.2 LEDs
Table 1-5 LEDs
Silkscreen
Label
LED
Description
SYS
System
status LED
Solid green: The system is operating normally.
Blinking green: The system is starting up.
Solid yellow:
○The system (including all modules) is not functioning properly.
○The number of fan modules is less than 4.
○The temperature exceeds the limit and the switching service resets.
Off: The system is not receiving power or not operating even after
receiving power.
PSU
Power status
LED
Solid green: The power module is operating normally.
Solid yellow: The power module is not functioning properly.
Off: The power module is not receiving power or not operating even after
receiving power.
FAN
Fan status
LED
Solid green: The fan module is operating normally.
Blinking green: The fan module is not functioning properly.
Off: The system is not receiving power or not operating even after
receiving power.
1F to 32F
QSFP28 port
LED
LED for the 100GE/40GE port:
○Solid green: The port has made a successful 100 Gbps link.
○Solid yellow: The port has made a successful 40 Gbps link.
○Blinking green: The port is sending and receiving traffic at 100 Gbps.
○Blinking yellow: The port is sending and receiving traffic at 40 Gbps.
○Off: No link is detected for the port.
LED for the two 50GE ports split from a 100GE port:
○Solid green: Both 50GE ports have made successful links.
○Solid yellow: Only one 50GE port has made a successful link.
○Blinking green: Both 50GE ports are sending and receiving traffic.
○Blinking yellow: Only one 50GE port is sending and receiving traffic.
○Off: No link is detected for the port.
LINK/ACT
Management
port LED
Solid yellow: The port has made a successful 10/100 Mbps link.
Blinking yellow: The port is sending and receiving traffic at 10/100 Mbps.
Solid green: The port has made a successful 1,000 Mbps link.
Blinking green: The port is sending and receiving traffic at 1,000 Mbps.
Off: No link is detected for the port.

Hardware Installation and Reference Guide Overview
5
1.3.3 Ports
Table 1-6 Ports
Port
Connector Type
Description
Accessory
100GE QSFP28 port
Subject to the optical
module
The 100GE QSFP28 port can be
split into four 25GE ports or two
50GE ports. It is backward
compatible with 40GE and can be
split into four 10GE ports for
downlink data transmission.
Standards compliance:
IEEE802.3ba
Working mode: Full-duplex
Optical attributes: Subject to
the module or cable
40GE optical module
100GE optical module
AOC
Management port
RJ45
The management port is used to
set up the local or remote
configuration environment.
Standards compliance:
IEEE802.3ab
Working mode: 10/100/1000
Mbps with auto-negotiation
and full-duplex
CAT5 or higher cable
USB port
USB
The USB port is connected with a
USB flash drive for configuration
backup and firmware upgrade.
USB 2.0
FAT32 file format
USB 2.0 flash drive
Console port
RJ45
The console port is connected to a
console for local configuration.
Standards compliance: RS-
232
Working mode: Duplex
Universal Asynchronous
Receiver/Transmitter (UART)
Baud rate:
○Range: 9,600 bits/s to
115,200 bits/s
○Default value: 115,200
bits/s
Console cable
1.3.4 Cooling
1. Overview
The RG-S6510-32CQ adopts the front-to-rear airflow. Air flows in through the ports and out through the power
module, as shown in Figure 1-5.

Hardware Installation and Reference Guide Overview
6
Caution
Maintain a minimum clearance of 200 mm (7.87 in.) around the equipment for air circulation.
At least three fan modules are required. If any slot is unoccupied, install a filler panel to enable proper
airflow and to keep dust out of the chassis.
Dust the equipment every three months to avoid blocking the ventilation openings on the housing.
2. Airflow
Figure 1-5 Front-to-Rear Airflow
1.3.5 Technical Specifications
Table 1-7 Technical Specifications
Class
Item
Specification
Technical
indicators
CPU
2.2 GHz quad-core
Memory
4 GB, DDR4 SODIMM (up to two SODIMM with 32 GB)
Flash memory
NOR flash: 16 MB (for BootROM)
SSD
240 GB
Physical
characteristics
Dimensions
(W x D x H)
Without packing materials: 442 mm x 560 mm x 44 mm (17.40
in. x 22.05 in. x 1.73 in.,1 RU)
With packing materials: 835 mm x 606 mm x 277 mm (32.87
in. x 23.86 in. x 10.91 in.)

Hardware Installation and Reference Guide Overview
7
Class
Item
Specification
Weight
Chassis and modules (five fan modules and two power
modules) without packing materials: 11.43 kg (25.20 lbs.)
Chassis and modules (five fan modules and two power
modules) with packing materials: 16.10 kg (35.49 lbs.)
Structure
Integrated chassis without expansion module slots
Two power module slots
Five fan module slots
Ports
Service port
32 x 100GE QSFP28 ports, backward compatible with 40GE, each
port splittable into four 10GE or 25GE ports, or two 50GE ports
Console port
1 x RJ45 port
USB port
1 x UBS 2.0 port
Management port
1 x Gigabit RJ45 port supporting backward compatibility
Environment
Altitude
Operating altitude: 0–5,000 m (0–16,404.20 ft.)
Storage altitude: 0–5,000 m (0–16,404.20 ft.)
Temperature
Operating temperature: 0°C to 40°C (32°F to 104°F) at an
altitude in the range of 0–2,000 m (0–6,561.68 ft.)
Note
At an altitude in the range of 2,000–5,000 m (6,561.68–
16,404.20 ft.), every time the altitude increases by 200 m
(656.17 ft.), the maximum temperature decreases by 1°C
(1.8°F).
Storage temperature: –40°C to +70°C (–40°F to +158°F)
Humidity
Operating humidly: 10% RH to 90% RH (non-condensing)
Storage humidity: 5% RH to 95% RH (non-condensing)
Noise
Sound pressure level at 27°C (80.6°F): < 78 dB
Surge protection
AC power protection
Common mode: 2 kV
Differential mode: 1 kV
Power supply
mode
AC
DC
High-voltage DC (HVDC)
Power connector
Three-pin connector, subject to the power module

Hardware Installation and Reference Guide Overview
8
Class
Item
Specification
Power supply
Power
consumption
Max: 450 W
Typical: 270 W
Static: 150 W
Voltage
AC: 100 V AC to 240 V AC, 50 Hz to 60 Hz
DC: –36 V DC to –72 V DC
HVDC: 180 V DC to 310 V DC
AC input
RG-PA550I-F:
○Rated voltage: 110 V AC/220 V AC
○Rated voltage range: 100 V AC to 240 V AC (50 Hz to 60 Hz)
○Max. voltage range: 90 V AC to 264 V AC (47 Hz to 63 Hz)
○Max. current range: 7.2 A to 3.5A
DC input
RG-PA550I-F:
○HVDC range: 180 V DC to 310 V DC
○Rated voltage: 240 V DC
○Max. current: 3.6 A
RG-PD800I-F:
○Rated voltage range: –36 V DC to –72 V DC
○Rated voltage: –48 V DC
○Rated input current: 23 A
Max. output
power
consumption
RG-PA550I-F: 550 W
RG-PD800I-F:
○600 W (–36 V DC to –41 V DC)
○800 W (–42 V DC to –72 V DC)
Airflow direction
RG-PA550I-F: Front-to-rear airflow (air exhaust on power
module panel)
RG-PD800I-F: Front-to-rear airflow (air exhaust on power
module panel)
Cooling
Cooling mode
Fan cooling
Fan type
Swappable fan
Reliability
Mean Time to
Recovery (MTTR)
0.5 hours
Power
redundancy
1 + 1
Fan redundancy
4 + 1
Hot swapping
Hot swappable power and fan modules
Certification
EMC
GB/T 9254.1
Safety standard
GB 4943.1
Environment
protection
Environment protection regulation

Hardware Installation and Reference Guide Overview
9
Warning
Operation of this equipment in a residential environment could cause radio interference.
This equipment is not suitable for use in locations where children are likely to be present.
This equipment should be installed in the equipment room. Only a skilled person should be allowed to
install, replace, or service this equipment. Do not open the enclosure when the equipment is running. Cut
off the power supply before opening the enclosure in case of an electric shock.
1.3.6 Asset Tag
The asset tag is in the lower left corner of the front panel. The tag can be pulled out of the panel. You can add
your own asset tracking label without interfering with the intended air flow.
Figure 1-6 Asset Tag
1.4 Power Module
The smart power module for the RG-S6510-32CQ support power consumption management and hot swapping.
It can obtain the output power, output current, and operating temperature in real time.
Caution
To improve system stability and availability, you are advised to configure 1 + 1 power redundancy. The
chassis configured with power redundancy works in current-sharing mode.
At least one power module is required. If any slot is unoccupied, install a filler panel to enable proper
airflow and to keep dust out of the chassis.
Unplug the power cord before installing or removing the power module.

Hardware Installation and Reference Guide Overview
10
1.4.1 RG-PA550I-F
1. Appearance
Figure 1-7 Appearance
Figure 1-8 Structure
Table 1-8 Components
No.
Component
Description
1
Handle
Handle of the power module
2
Fan
Forward fan
3
Power connector
Three-pin connector
4
LED
Power status LED
5
Latch
Latch of the power module

Hardware Installation and Reference Guide Overview
11
2. LED
Table 1-9 LED
Silkscreen
Label
LED
Description
N/A
Power status
LED
Solid green: The power module is outputting power normally.
Blinking green at 1 Hz:
○The power module is in PS OFF state with only 12 V standby output.
○The power module is in the cold standby status and not outputting
power.
Solid red:
○The power module is not functioning properly (overcurrent,
overvoltage, or fan failure).
○The power module in redundancy mode is removed.
Blinking red at 1 Hz: The power module is operating but with alarms,
such as high power, high current, high temperature, and low fan
rotation speed.
Off: The power module is not receiving power or not operating even
after receiving power.
3. Technical Specifications
Table 1-10 Technical Specifications
Item
Specification
Dimensions (W x D x H)
Without packing materials: 73.5 mm x 185 mm x 40 mm (2.89 in. x
7.28 in. x 1.57 in.)
With packing materials: 462 mm x 195 mm x 232 mm (18.19 in. x
7.68 in. x 9.13 in.)
Weight
Without packing materials: 0.9 kg (1.98 lbs.)
With packing materials: 1.5 kg (3.31 lbs.)
Power connector
C14 connector for connection with AC/HVDC power cord
Rated input voltage range
AC: 100 V AC to 240 V AC, 50 Hz to 60 Hz
HVDC: 240 V DC
Max. input voltage range
AC: 90 V AC to 264 V AC, 47 Hz to 63 Hz
HVDC: 180 V DC to 310 V DC
Rated input current range
7.2 A to 3.5 A (100 V AC to 240 V AC)
3.6 A (240 V DC)
Rated output current
45 A
Rated output voltage
12 V DC
Rated output power consumption
550 W
Hot swapping
Supported
Cooling
Front-to-rear airflow (air exhaust on power module panel)
