Ruijie RG-IF2920U-12GT1XS Series Installation and operating manual

RG-IF2920U-12GT1XS
Series Switch
Hardware Installation and Reference Guide
Document version: V2.0
Date: 2023-05-24
Copyright © 2023 Ruijie Networks

Copyright
Copyright © 2023 Ruijie Networks
All rights are reserved in this document and this statement.
Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document
or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks
is prohibited.
Trademark and are owned by Ruijie Networks.
All other trademarks or registered trademarks mentioned in this document are owned by their respective owners.
Disclaimer
The products, services, or features you purchase are subject to commercial contracts and terms, and some or
all of the products, services, or features described in this document may not be available for you to purchase or
use. Except for the agreement in the contract, Ruijie Networks makes no explicit or implicit statements or
warranties with respect to the content of this document.
Due to product version upgrades or other reasons, the content of this document will be updated from time to
time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.
This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder
any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
Ruijie Networks website: https://www.ruijienetworks.com/
Technical support website: https://ruijienetworks.com/support
Case portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical support email: s[email protected]
Live chat: https://www.ruijienetworks.com/rita
Conventions
1. Signs
The signs used in this document are described as follows:
Warning
An alert that calls attention to important rules and information that if not understood or followed can result in
data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed can result in function
failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or followed will not lead to
serious consequences.
Specification
An alert that contains a description of product or version support.
2. Note
The manual offers configuration information (including model, port type and command line interface) for indicative
purpose only. In case of any discrepancy or inconsistency between the manual and the actual version, the actual
version prevails.

Hardware Installation and Reference Guide Product Description
1
1 Product Description
The RG-IF2920U-12GT1XS is the simplified optical Ethernet (SOE) switch released by Ruijie Networks for all-
optical network scenarios. It uses the new hardware architecture, and silent and energy-saving design. It can
be flexibly installed and suitable for indoor scenarios. With Ruijie's modular OS, the RG-IF2920U-12GT1XS is
fit for the SOE solution, and implements lifecycle management, security control, plug and play, and intelligent
O&M through software-defined networking (SDN).
Table 1-1 Ports of the RG-IF2920U-12GT1XS
Model
10/100/1000M
Base-T Ethernet
Electrical Port
2.5G/1G
BASE-T
Ethernet
Electrical
Port
SFP
Port
2.5G SFP
Port
SFP+
Port
Console
Port
RG-IF2920U-
12GT1XS
12
N/A
N/A
N/A
1
N/A
Note
SFP+ ports are downward compatible with 1000Base-X ports.
1000Base-T ports are downward compatible with 100Base-T and 10Base-T ports.
Table 1-2 Configuration of the RG-IF2920U-12GT1XS
Model
Dimensions (W x D x H)
Cooling
RG-IF2920U-12GT1XS
240 mm x 86 mm x 38 mm (9.45 in.
x 3.39 in. x 1.50 in.)
Natural heat dissipation for fanless
design
1.2 RG-IF2920U-12GT1XS
1.2.1 Technical Specifications
Table 1-3 Technical Specifications of the RG-IF2920U-12GT1XS
Model
RG-IF2920U-12GT1XS
Supported Optical
Module
See Appendix B.
The supported optical module types may update without prior notification. Please
contact Ruijie Networks for any updates.
SFP+ Port
10GBase-X and 1000Base-X

Hardware Installation and Reference Guide Product Description
2
Power Supply
Adapter power supply:
Power adapter input
○Rated voltage range: 100 V to 240 V
○Maximum voltage range: 90 V to 264 V
○Rated frequency: 50/60 Hz
Power adapter output (DC)
○Rated voltage: 12 V
○Rated current: 1.0 A
Energy Efficient
Ethernet (EEE)
Supported
Maximum Power
Consumption
10 W
Operating
Temperature
Desktop deployment: 0ºC to 40ºC (32°F to 104°F) at the altitude between 0 m to
1,800 m (0 ft. to 5905.51 ft.)
Deployment under the desktop, wall-mounting, and pole-mounting: 0ºC to 45ºC
(32°F to 113°F) at the altitude between 0 m to 1,800 m (0 ft. to 5905.51 ft.)
At the altitude between 1,800 m (5905.51 ft.) and 5,000 m (16404.2 ft.), every
time the altitude increases by 220 m (721.79 ft.), the maximum temperature
decreases by 1°C (1.8°F).
Storage Temperature
–40°C to +70°C (–40°F to +158°F)
Operating Humidity
10% to 90% RH (non-condensing)
Storage Humidity
5% to 95% RH (non-condensing)
Fan Module
Natural heat dissipation for fanless design
Intelligent
Temperature Control
Temperature alarm and overheat protection
EMC Standard
GB/T 9254.1
Safety Standard
GB 4943.1
Dimensions (W x D x
H)
240 mm x 86 mm x 38 mm (9.45 in. x 3.39 in. x 1.50 in.)
Weight
0.86 kg (1.90 lbs) (including the package)
Warning
The RG-IF2920U-12GT1XS is a Class Aproduct. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.

Hardware Installation and Reference Guide Product Description
3
1.2.2 Product Appearance
The RG-IF2920U-12GT1XS provides 12 x 10/100/1000M Base-T Ethernet electrical ports and 1 x 10G SFP+
port.
Figure 1-2 Appearance of the RG-IF2920U-12GT1XS
1. Front Panel
Figure 1-3 Front Panel of the RG-IF2920U-12GT1XS
Note:
1. Console port (internal
debugging)
2. Switch status LED
3. Optical port LED

Hardware Installation and Reference Guide Product Description
4
2. Middle Frame Panel
Figure 1-4 Middle Frame Panel of the RG-IF2920U-12GT1XS
3. Top Cover
Note:
1. SFP+ port
2. Nameplate
4. Reset Button
The RG-IF2920U-12GT1XS provides one Reset button. When you press this button for more than 5s, the device
restores to factory defaults and restarts.
Note:
1. Power port 12 V/1 A
2. Reset button
3. 10/100/1000Base-T Ethernet port with auto-
negotiation
4. Ethernet port LED

Hardware Installation and Reference Guide Product Description
5
5. Heat Dissipation
The RG-IF2920U-12GT1XS adopts natural heat dissipation to ensure that it works properly in a specified
environment. For the RG-IF2920U-12GT1XS, maintain sufficient clearance on both sides of the chassis and
above the chassis for air circulation. Dust the device every three months to avoid blocking ventilation openings
on the housing.
6. LEDs
Table 1-4 LEDs
LED
Panel
Identification
Status
Description
Status LED
Status
Off
The switch is not powered on.
Blinking green
The switch is being initialized. If the
LED blinks continuously, a fault occurs.
Solid green
The switch works properly.
Solid yellow
A switch temperature alarm is
generated. Check the operating
environment of the switch.
Solid red
The switch fails.
Electrical port
LED
1–12
Off
The port is not connected.
Solid green
The port works at the rate of
10/100/1000 Mbps.
Blinking green
The port is sending or receiving data at
the rate of 10/100/1000 Mbps.
Optical port
LED
SFP+
Off
The port is not connected.
Solid green
The port is connected.
Blinking green
The port is sending or receiving data.
Solid red
An error occurs when the optical
module sends signals.
Solid yellow
An error occurs when the optical
module receives signals.

Hardware Installation and Reference Guide Preparing for Installation
6
2 Preparing for Installation
2.1 Safety Precautions
Warning
To avoid personal injury and device damage, carefully read the safety precautions before you install the
RG-IF2920U-12GT1XS.
The following safety precautions may not cover all possible dangers.
2.1.1 Mounting
Keep the chassis clean and dust-free.
Do not place the device in a walking area.
During installation and maintenance, do not wear loose clothes, ornaments, or any other things that may be
hooked by the chassis.
Cut off all the power supplies and unplug all power cords before handling the switch.
2.1.2 Handling
Avoid handling the device frequently.
Keep balance and prevent personal injuries when handling the device.
Cut off all the power supplies and unplug all power cords before moving or handling the switch. Avoid scalds
because the housing surface is hot.
2.1.3 Electricity
Observe local regulations and specifications during electric operations. Only qualified personnel can perform
such operations.
Before installing the device, check whether there are hidden risks in the operating environment of the device.
For example, check whether the power socket is grounded and whether the ground is wet.
Determine the location of the indoor emergency power supply switch before installing the device. When an
accident occurs, immediately cut off all power supplies.
Do not maintain the device by yourself when the device is powered on.
Make sure that the device is powered off when you cut off the power supply.
Do not place the switch in a wet position, and keep the switch away from liquid.
Warning
Improper or incorrect electric operations may cause a fire, electric shock, and other accidents, and lead
to severe and fatal personal injury and device damage.
Direct or indirect contact through wet objects with high voltage or mains power supply may be fatal.
When this device is running, the surface temperature of the top cover is high. Install and use it in the area
that can only be accessed by maintenance personnel or skilled technicians.

Hardware Installation and Reference Guide Preparing for Installation
7
2.1.4 ESD
To prevent damage caused by static electricity, pay attention to the following points:
Keep the indoor installation environment clean and dust-free.
Keep the indoor humidity within a certain range.
2.1.5 Laser
The RG-IF2920U-12GT1XS supports various types of optical transceivers available in the market, and these
optical transceiver are Class I laser products. Improper use of an optical transceiver may cause damage.
Therefore, pay attention to the following:
When a fiber transceiver works, ensure that the port has been connected with a fiber or covered by a dust cap
to keep out dust and prevent it from burning your eyes.
When an optical transceiver is working, do not look into its port after removing the optical fiber. Otherwise, your
eyes may be hurt.
Warning
Do not approach or look into any optical port under any circumstances. This may cause permanent damage to
your eyes.
2.1.6 Storage
To ensure proper working of the device, store the device in an environment based on the storage temperature or
humidity requirements in specifications.
Caution
If the device has been powered off for more than 18 months, power on the device and run it for consecutive 24
hours to activate the device.
2.2 Installation Site Requirements
The installation site must meet the following requirements to ensure the normal operation and prolonged service
life of the device.
2.2.1 Ventilation
For the RG-IF2920U-12GT1XS, maintain sufficient clearance on both sides of the chassis and above the chassis
for air circulation. After various cables are connected, bind the cables or place them in the cable management
bracket to avoid blocking air inlets. Dust the device every three months to avoid blocking the ventilation openings
on the housing.
The RG-IF2920U-12GT1XS uses natural heat dissipation, and the heat is primarily dissipated through the
housing. The surface temperature of the device is high. It is crucial to install the device in a restricted-access
area that offers sufficient ventilation.

Hardware Installation and Reference Guide Preparing for Installation
8
2.2.2 Temperature and Humidity
To ensure the normal operation and service life of the switch, maintain an appropriate temperature and humidity
in the environment where the switch is used.
Prolonged exposure of the switch to a high relative humidity environment can result in compromised insulation
of the insulating material, potentially leading to electrical leakage. Additionally, the mechanical properties of
materials may undergo alterations, and there is an increased risk of corrosion for metal components.
Extended storage of the switch in a low relative humidity environment can result in the shrinkage of insulating
strips, leading to the loosening of fastening screws. Additionally, the occurrence of static electricity becomes
more likely, which poses a risk of damaging internal circuits of the switch.
Extended exposure of the switch to a high ambient temperature environment can result in amplified damage.
The elevated temperature accelerates the aging process of insulating materials, significantly diminishing the
performance and reliability of the switch while severely impacting its service life.
Table 2-1 Ambient Temperature and Humidity Requirements of the RG-IF2920U-
12GT1XS
Operating Temperature
Relative Humidity
Desktop deployment: 0ºC to 40ºC (32°F to 104°F)
10% to 90%
Deployment under the desktop, wall-mounting, and
pole-mounting: 0ºC to 45ºC (32°F to 113°F)
2.2.3 Cleanliness
Dust poses a major threat to the device. The indoor dust takes on a positive or negative static electric charge
when falling on the switch, causing poor contact of the metallic joint. Such electrostatic adhesion may occur
more easily when the relative humidity is low, affecting the service life of the switch and causing communication
faults.
Table 2-2 Requirements for the Dust Content and Granularity in the Equipment Room
Dust
Unit
Maximum Quantity
Dust particles (diameter ≥ 0.5 μm)
Particles/m3
3.5 x 106
Dust particles (diameter ≥5 μm)
Particles/m3
3 x 104
Apart from dust, the salt, acid, and sulfide in the air of the equipment room must meet strict requirements. These
harmful substances will acceleratemetal corrosion and component aging. Therefore, the equipment room should
be properly protected against the intrusion of harmful gases, such as sulfur dioxide, hydrogen sulfide, nitrogen
dioxide, and chlorine gas.

Hardware Installation and Reference Guide Preparing for Installation
9
Table 2-3 Limit Values for Harmful Gases
Gas
Average (mg/m3)
Maximum (mg/m3)
Sulfur dioxide (SO2)
0.3
1.0
Hydrogen sulfide (H2S)
0.1
0.5
Nitrogen dioxide (NO2)
0.5
1.0
Chlorine (CI2)
0.1
0.3
Note
The average value refers to the average value of harmful gases measured in one week. The maximum value is
the upper limit of the harmful gas measured in one week for up to 30 minutes every day.
2.2.4 Anti-interference
The switch is susceptible to external interference by capacitive coupling, inductive coupling, electromagnetic
waves, common impedance (ground) coupling, or conduction over power lines, signal lines, and output lines.
Pay attention to the following points:
The switch should be located far away from the high-power radio launch pads, radar launch pads, and high-
frequency large-current devices.
Use electromagnetic interference (EMI) shielding such as shielded interface cables to minimize interference
when necessary.
Route interface cables only indoors to prevent signal ports from being damaged by overvoltage or overcurrent
caused by lightning strikes.
2.3 Tools
Common Tools
Phillips screwdriver, slotted screwdriver, copper and optical cables,
bolts, diagonal pliers, and cable ties
Special Tools
Anti-ESD tools
Meters
Multimeter
Note
The RG-IF2920U-12GT1XS is delivered without a tool kit. The tool kit is customer-supplied.

Hardware Installation and Reference Guide Installing the Switch
10
3 Installing the Switch
Caution
Before reading Chapter 3 Installing the Switch, ensure that you have read Chapter 2 Preparing for
Installation carefully.
Verify that requirements described in Chapter 2 Preparing for Installation have been met.
3.1 Installation Procedure
3.2 Before You Begin
Before installation, ensure that the following requirements are met:
The installation environment meets heat dissipation requirements.
The installation environment meets temperature and humidity requirements.
The power supply and required current are available at the installation site.
Ethernet cables have been deployed at the installation site.
3.3 Mounting the Switch
Pay attention to the following points:
Install switch correctly
Connect power supply
Connect cables
Bundle up cables
Check installation
End

Hardware Installation and Reference Guide Installing the Switch
11
Connect the power adapter to the DC interface of the device, ensuring that the interface of the power supply
cable makes good contact with the power interface of the device.
Do not place anything on the top of the RG-IF2920U-12GT1XS.
Maintain sufficient clearance around the device to ensure good air circulation. Do not stack the device.
Keep the RG-IF2920U-12GT1XS away from high-power radio launch pads, radar launch pads, and high-
frequency large-current devices. Take electromagnetic shielding measures to minimize interference when
necessary, for example, use shielded interface cables.
Manage Ethernet cables with a distance of 100 m (328.08 ft.) indoors. Take surge protection measures if
they need to be routed outdoors.
3.3.1 Mounting the Switch Against a Wall or on the Desktop
The RG-IF2920U-12GT1XS can be installed against a wall. Maintain sufficient space around the device for heat
dissipation. The installation requirements are as follows:
The device should be placed in a well-ventilated environment.
No obstacle is allowed within 90 mm (3.54 in.) in front of the switch.
Figure 3-1 Mounting the Switch Against the Wall Horizontally
The installation process is as follows:
(1) Place the mounting bracket on the wall and lock it with M4 x 18 mm countersunk screws, with the lateral
distance of 60 mm (2.36 in.).
(2) Install the optical module into the SFP+ port of the device, insert the optical fiber into the optical module, and
coil the external cable in the cable tray on the back of the device.
(3) Center the device on the mounting notch, place the device on the mounting bracket, and push the device to
the left.
(4) After the device is in place, lock it with the M3 x 8 mm screw of the spring washer and flat washer.

Hardware Installation and Reference Guide Installing the Switch
12
Figure 3-2 Mounting the Switch Against the Wall Vertically
The installation process is as follows:
(1) Place the mounting bracket on the wall and lock it with M4 x 18 mm countersunk screws, with the lateral
distance of 60 mm (2.36 in.).
(2) Install the optical module into the SFP+ port of the device, insert the optical fiber into the optical module, and
coil the external cable in the cable tray on the back of the device.
(3) Center the device on the mounting notch, place the device on the mounting bracket, and push the device
downward.
(4) Lock the device with screws of the spring washer and flat washer, and fix the device with M3 x 8 mm screws.
Caution
When mounting the device against a wall or on the desktop, ensure that it is installed exclusively on a concrete
or non-flammable surface.
3.3.2 Mounting the Switch Under the Desktop
The RG-IF2920U-12GT1XS can be secured under the desktop through the mounting bracket. The installation
requirements are as follows:
The device should be placed in a well-ventilated environment.

Hardware Installation and Reference Guide Installing the Switch
13
No obstacle is allowed within 90 mm (3.54 in.) in front of the switch.
Figure 3-3 Mounting the RG-IF2920U-12GT1XS Under the Desktop
The installation process is as follows:
(1) Place the mounting bracket under the workbench and lock it with M4 x 18 mm countersunk screws, with
screw holes at a distance of 60 mm (2.36 in.).
(2) Install the optical module into the SFP+ port of the device, insert the optical fiber into the optical module, and
coil the external cable in the cable tray on the back of the device.
(3) Center the device on the mounting notch, place the device on the mounting bracket, and push the device to
the right.
(4) After the device is in place, lock it with the M3 x 8 mm screw of the spring washer and flat washer.
Caution
The location where the switch is installed must be subject to movement restrictions.
3.3.3 Mounting the Switch on the Desktop
The RG-IF2920U-12GT1XS can be placed on the desktop. The installation process is as follows:
The device should be placed in a well-ventilated environment.
The device should be placed flat on the desktop, and no obstacle is allowed within 90 mm (3.54 in.) in front
of the switch.
3.3.4 Mounting the Switch Against a Pole
The RG-IF2920U-12GT1XS can be mounted against a pole.

Hardware Installation and Reference Guide Installing the Switch
14
Figure 3-4 Mounting the RG-IF2920U-12GT1XS Against a Pole
The installation process is as follows:
a Thread the cable tie through the hole in the mounting bracket and around the pole, strangling the rolled
tape.
b Install the optical module into the SFP+ port of the device, insert the optical fiber into the optical module,
and coil the external cable in the cable tray on the back of the device.
c Center the device on the mounting notch, place the device on the mounting bracket, and push the device
downward.
d After the device is in place, lock it with the M3 x 8 mm screw of the spring washer and flat washer.
3.4 Verifying the Installation
Caution
Turn off the power to avoid personal injury and damage to components caused by incorrect connections.

Hardware Installation and Reference Guide Installing the Switch
15
After the device is installed, check the following items:
Verify that the cables and power input cables are correctly connected.
Verify that the network cable of 100 m (328.08 ft.) is routed indoors. If it is routed outdoors, verify that the lightning
resistance socket and network interface lightning protector are connected.
Verify that there is adequate clearance around the device.

Hardware Installation and Reference Guide Verifying the Operating Status
16
4 Verifying the Operating Status
4.1 Setting Up the Debugging Environment
(1) Use a network cable to connect the first network port to a PC and keep other ports empty. Connect the device
to the serial port.
(2) Change the IPv4 address of the PC.
Choose Network & Internet > Ethernet > Change adapter options > Properties > Internet Protocol
Version 4 (TCP/IPv4), and set the IP address to any address (excluding the IP address of 192.168.1.200)
in the network segment 192.168.1.0/24.
(3) Power on the device and enter the IP address 192.168.1.200 of the device in the browser to access RG-INC.
The default username and password are both admin.

Hardware Installation and Reference Guide Verifying the Operating Status
17
4.2 Checking Device Startup
4.2.1 Checklist Before Power-on
The device is properly grounded.
The power cord is properly connected.
The power supply voltage meets the requirement of the switch.
Check that the control cable of the PC is correctly connected to the console port of the switch. Check whether
parameters are set correctly and whether RG-INC is enabled.
4.2.2 Checklist After Power-on (Recommended)
When the device is powered on, check the following items:
RG-INC is correctly connected.
LEDs of the switch are in normal state.
The main program is loaded properly.
Service ports can forward data properly.
