Ruijie Reyee RG-RAP6260 Installation and operating manual

Ruijie Reyee RG-RAP6260(G) Access Point
Hardware Installation and Reference Guide

·
Copyright statement
Ruijie Networks©2021
Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup,
modification, transmission, translation or commercial use of this document or any portion of this document,
in any form or by any means, without the prior written consent of Ruijie Networks is prohibited.
Exemption statement
This document is provided “as is”. The contents of this document are subject to change without any notice.
Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to
ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to
content omissions, inaccuracies or errors.

·
Preface
Thank you for using our products. This manual will guide you through the installation of the access point.
Scope
It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it
is assumed that the users are already familiar with the related terms and concepts.
Obtaining Technical Assistance
Ruijie Networks Website: https://www.ruijienetworks.com/
Technical Support Website: https://ruijienetworks.com/support
Case Portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical Support Email: [e-mail]
Skype: [e-mail]
Related Documents
Documents
Description
Configuration Guide
Describes network protocols and related mechanisms that supported by the
product, with configuration examples.
Command Reference
Describes the related configuration commands, including command modes,
parameter descriptions, usage guides, and related examples.
Documentation Conventions
The symbols used in this document are described as below:
This symbol brings your attention to some helpful suggestions and references.
This symbol means that you must be extremely careful not to do some things that may damage the device or cause
data loss.

·
1 Product Overview
RG-RAP6260(G) supports 802.11ax and provides dual-radio and dual-band performance speeding up to 575Mbps@2.4G
+ 1200Mbps@5G. The IP68 design adapts to inclement outdoor environments such as the cold and humidity. This
substantially simplifies installation and maintenance. RAP6260(G) supports PoE to take over challenges in a wide variety
of deployment scenarios, including large-scaled campuses, enterprises, hospitals and Wi-Fi hotspots.
1.1 Technical Specifications
Table 1-1 Technical Specifications of RG-RAP6260(G)
Hardware Specifications
RF
Dual-Band Dual-Stream
Transmission
Protocol
Support concurrent 802.11ax, 802.11ac wave2/wave1 and 802.11a/b/g/n
Operating Bands
802.11b/g/n/ax: 2.4 GHz to 2.4835 GHz
802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz, 5.725 GHz to 5.850 GHz
Antenna
Antenna array, 2.4G: 4dBi; 5G: 6dBi
Spatial Streams
2.4G: 2x2MIMO
5G: 2x2MIMO
Access Rates
2.4GHz: up to 575Mbps
5GHz: up to 1200Mbps
Modulation
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16QAM@24Mbps, and 64QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and [email protected]/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM , 64QAM, 256QAM and 1024QAM
OFDMA
Receive Sensitivity
11b: -96dBm(1Mbps), -93dBm(5Mbps), -89dBm(11Mbps)
11a/g: -91dBm(6Mbps), -85dBm(24Mbps), -80dBm(36Mbps), -74dBm(54Mbps)
11n: -90dBm(MCS0), -70dBm(MCS7), -89dBm(MCS8), -68dBm(MCS15)
11ac: 20MHz: -88dBm(MCS0), -63dBm(MCS9)
11ac: 40MHz: -85dBm(MCS0), -60dBm(MCS9)
11ac: 80MHz: -85dBm(MCS0), -60dBm(MCS9)
11ax: 80MHz: -82dBm(MCS0), -57dBm(MCS9), -52dBm(MCS11)
Maximum Transmit
Power
≤250mw (24dBm) (Country-specific)
Transmit Power
Adjustment
1dBm
Dimensions
(W x D x H)
298 mm×298 mm×65 mm (11.7in x 11.7in x 2.6in) (excluding bracket)
Weight
≤1.35kg
Service Ports
One 10/100/1000Base-T Ethernet port (Support PoE)
One 1000Base-X SFP port (optional)
Management Ports
N/A

·
LED
One LED (blue)
Power Supply
PoE: IEEE 802.3at (PoE+)
Warning：802.3af or non-standard POE adapter may cause unknown issues. Please use Ruijie
POE+ switch
Power Consumption
Maximum: 17W
Temperature
Operating: -40℃to 65℃(-40℉to 149℉)
Storage: -40℃to 85℃(-40℉to 185℉)
Humidity
Operating: 0% to 100% (non-condensing)
Storage: 0% to 100% (non-condensing/condensing)
Installation
Wall/Pole mount
Safety Standards
GB4943
IEC 60950-1
EMC Standards
GB9254
EN301 489
EN50155
EN50121
Vibration Standards
IEC61373
Radio
China Radio Transmission Equipment Type Approval Certificate
EN300 328
EN301 893
MTBF
>400,000H
The weight refers to the weight of host and bracket.
1.2 Product Image
The RG-RAP6260(G) provides one 10/100/1000Base-T Ethernet port (Support PoE) and one 1000Base-X SFP port
(optional).
Figure 1-1 Appearance of RG-RAP6260(G)

·
1.3 LED Indicators
State
Frequency
Meaning
Off
N/A
The AP is NOT receiving power.
Slow Blinking
0.5Hz
Normal operation, but the device is not connected to Ruijie Cloud.
Fast Blinking
10Hz
1. Restoring the factory settings.
2. Upgrading the firmware.
3. Restoring the image file.
4. Initializing the device.
Solid Blue
On
Normal operation.
Reset Button
Press for less than
Restart the device.

·
2s
Press for more
than 5s
Restore the factory settings.
Power Source
The RG-RAP6260(G) is powered through Power over Ethernet (PoE).
To use a PoE device, make sure it supports the IEEE 802.3at standard.
Reset
The RG-RAP6260(G) supports Cloud management. To reset the device, you can bring the device online and reset it on
Ruijie Cloud.
If the device can not access the Internet, power on the device, press the reset button with a thin rod (as shown in the
figure) for more than 5 seconds, and the device will restore the factory settings.
Figure 1-2 Reset the Device
Before pressing the reset button, please remove the waterproof joint first. Refer to the Chapter 3.5 Connecting
Cables for more information.
Cooling Solution
The AP adopts fanless design.
Leave sufficient space at the surrounding of the AP when place the AP to permit airflow for proper ventilation.

·
2 Preparing for Installation
To prevent device damage and bodily injury, please read carefully the safety recommendations described in this
chapter.
The recommendations do not cover all possible hazardous situations.
2.1 Installation
The AP must be installed indoors. To ensure its normal operation, the installation site must meet the following
requirements.
Install the AP in a well-ventilated environment. If it is installed in a closed room, make sure there is a good cooling
system.
Make sure the site is sturdy enough to support the AP and its accessories.
Make sure the site has enough space for installing the AP and leave sufficient room around the AP for ventilation.
Do not expose the AP to high temperature, dusts, or harmful gases.
Do not install the AP in an inflammable or explosive environment.
Keep the AP away from EMI sources such as large radar stations, radio stations, and substations.
Do not subject the AP to unstable voltage, vibration, and noises.
Keep the AP at least 500meters away from the seaside and do not face it toward the wind from the sea.
The installation site should be free from water flooding, seepage, dripping, or condensation.
The installation site shall be selected according to network planning and features of communications equipment, and
considerations such as climate, hydrology, geology, earthquake, electric power, and transportation.
Please follow the correct method described in the installation guide to install and remove the device.
2.2 Movement
Avoid moving the device frequently.
Turn off all power supplies and unplug all power cables before you move the device.
2.3 EMI
Please observe local regulations and specifications when performing electrical operations. Relevant operators must
be qualified.
Please carefully check for any potential danger in the working area, for example, damp/wet ground or floor.
Find out the location of the emergency power supply switch in the room before installation. First cut off the power
supply in case of an accident.
Be sure to make a careful check before you shut down the power supply.

·
Do not place the device in a damp/wet location. Do not let any liquid enter the chassis
Keep the AP far away from the grounding or lightning protection devices of power equipment.
Keep the AP away from radio stations, radar stations, high-frequency high-current devices, and microwave ovens.
Any nonstandard and inaccurate electrical operation can cause an accident such as fire or electric shock, thus
causing severe even fatal damages to human bodies and device.
Direct or indirect touch through a wet object on high voltage and power line can bring a fatal danger.
2.4 Ventilation
For proper ventilation, leave sufficient space around the AP.
2.5 Temperature and Humidity
To ensure normal operation and service life of the device, maintain appropriate temperature and humidity levels in your
equipment room. See Table 2-1. Improper room temperature and humidity can cause damages to the device.
Relatively high humidity may affect insulation materials, resulting in poor insulation and even electrical leakage, and
sometimes may lead to change of mechanical properties of materials and corrosion ofmetal parts.
Relatively low humidity may dryand shrink insulation sheets and cause static electricity that can damage the circuitry
inside the device.
High temperature greatly reduces reliability of the device and shortens its service life.
When the SFP module is used for data transmission, ensure its operating temperature matches the actual operating
environment.
Table 2-1 Required Temperature and Humidity for the RG-RAP6260(G)
Temperature
Relative Humidity
-40℃to 65℃(-40℉to 149℉)
0% to 100%
2.6 Waterproof
Use a seal plug to seal the unused ports.
Use a waterproof plug to connect cables to the AP. For details, see Chapter 3 “Installing the Access Point”.
2.7 Power Supply
PoE injector: IEEE 802.3at compliant
The input power should be greater than the power actually consumed by the system. The input power for the
RG-RAP6260(G) should be greater than 18W.
Please use Ruijie certified PoE injectors.

·
2.8 Installation Tools
Common Tools
Phillips screwdriver, related copper and fiber cables, bolts, diagonal pliers, cable ties
Special Tools
Wire stripper, crimping pliers, RJ-45 crimping pliers, punch down tool
Meter
Multimeter, bit error rate tester (BERT)
The listed tools are customer supplied.
2.9 Unpacking the Access Point
Package Contents
Items
Verify that all parts are installed and debugged.
Screws
Mounting brackets
Product quick installation guide
Packing list
The above listed items are for general situations, which may vary in the actual shipment. The purchase order shall
prevail in any case. Please check each item carefully according to the packing list or purchase order. If any item is
damaged or missing, notify the sales person.

·
3 nstalling the Access Point
Before installing the AP, make sure you have carefully read the requirements described in Chapter 2.
3.1 Installation Flowchart
3.2 Before You Begin
Before you install the AP, verify that:
The installation site provides sufficient ventilation for the AP.
The installation site meets temperature and humidity requirements.
The installation site is equipped with proper power supply.
Network cables are in place.
The installation site meets all described requirements.
The custom AP meets the customers’requirements.

·
3.3 Precautions
The device can be mounted on a wall or a pole (diameter: 50mm to 70 mm). If the diameter of the pole is out of the range,
the hose clamp is customer-supplied (thickness ≥ 2.5mm). The installation site can vary due to on-the-spot surveys
conducted by technical personnel.
Please make full preparations as described in Chapter 2 and observe the following precautions before installing the
device.
Do not power the device during installation.
Install the device in a well-ventilated location.
Do not subject the device to high temperatures.
Keep away from high voltage cables.
Do not expose the device in a thunderstorm or strong electric field.
Keep the device clean and dust-free.
Disconnect the device before cleaning it.
Do not wipe the device with a damp cloth.
Do not wash the device with liquid.
Do not open the enclosure when the AP is working.
Fasten the device tightly.
3.4 Installing the Access Point
Preparation before Installing
Adjust the angle of the access point to 0°, and fix the access point with M4x10 screws.
Figure 3-1 Adjust the Angle of Access Point
Wall mount

·
Use M8x60 expansion bolts to implement the wall mount.
a. Attach the bracket to the wall and mark the screw hole locations. Secure the mounting bracket on the wall using
M8x60 expansion bolts.
Figure 3-2 Installing the Bracket
b. Align the host with bracket and mounting plate to the bracket on the wall, and tighten the M8x20 screws to complete
installation.
Figure 3-3 Mounting the Bracket onWall
Pole mount (Vertical)
a. Attach the bracket to a pole with hose clamps and fasten the clamps with screws and nuts.
Figure 3-4 Mounting the Bracket on a Pole

·
b. Align the hostwith bracket and mounting plate to the bracket on the pole, and tighten the M8x20 screws to complete
installation.
Figure 3-5 Vertical Pole Mounting
Pole mount (Horizontal)
a. Attach the bracket to a pole with hose clamps and fasten the clamps with screws and nuts.
Figure 3-6 Mounting the Bracket on a Pole
b. Align the host with bracket and mounting plate to the bracket on the pole, and tighten the M8×20 screws to complete
installation.
Figure 3-7 Horizontal Pole Mounting

·
Angle Adjustment
a. To cover the specified area, adjust the angle (five stages from 0oto 60o).
Figure 3-8 Adjust the Angle
b. When the angle of the access point is properly adjusted, secure the access point with M4x10 screws in the position
shown in Note 1.
The device uses high-gain omnidirectional antenna. It is recommended to set the joint downward to be perpendicular
to the ground to obtain the maximum coverage radius.
After installation, verify that the AP is securely fastened.
3.5 Connecting Cables
Connecting to Network Port or Fiber (optional)
1. Screw off the waterproof joint, and the joint consists of four parts: A (main body), B (rubber plug), C (grab) and D
(tightening nut).

·
2. Run a network cable or fiber (optional) through the joint according to the order shown in the figure, and combine parts
B and C and place them in part A.
3. Screw part D, and wear the joint tightly with a waterproof tape.
Figure 3-9 Cable Connection
The waterproof materials are customer supplied.
Avoid bending the cable in a small radius close to the connector.
It is not recommended to use Ethernet cables with protective sleeves as they could make installation of Ethernet
cables more difficult. The Ethernet cable must have a diameter of 5.51mm, because any thicker or thinner cable
does not ensure waterproof performance.
As an optical module (optional) is enabled, the LC-LC fiber jumper cable must have a diameter of 3.00.2mm,
because any thicker or thinner cable does not ensure waterproof performance.
When the joint is removed, take down the parts in the order of D, B, C and A. That is, first screw off the tightening nut
(D), then remove the rubber plug (B) and the grab (C), and finally dismantle the cable connected to the AP device;
otherwise, the cable will be damaged.
3.6 Bundling Cables
Precautions
Make sure the cable bundles are neat and orderly.
Bend twisted pairs naturally or to a large radius close to the connector.
Do not over tighten cable bundle as it may reduce the cable life and performance.
Bundling Steps
1. Bundle the drop UTP/STP cables and route them to the ETH/PoE port.
2. Attach the cables in the cable tray of the rack.
3. Extend the cables under the AP and run in straight line.
3.7 Checking after Installation
Checking the Host
Make sure the external power supply matches the specifications of device.
Make sure the device and all cables are securely fastened and stable.

·
Checking Cable Connection
Make sure the UTP/STP cable matches the interface type.
Make sure cables are properly bundled.
Checking the Power Supply
Make sure all power cables are properly connected and safe.
Make sure the AP is operational after power-on.

·
4 System Debugging
4.1 Setting up a Debugging Environment
Power on the AP through PoE.
Setting up the Environment
Verify that the AP is properly connected to the power source.
When the AP is connected to a PC for debugging, verify that the PC and PoE switch are properly grounded.
4.2 Powering up the AP
Checking before power-up
Verify that the power supply is properly connected.
Verify that the input voltage matches the specification of the AP.
Checking after power-up (recommended)
After powering up, it is recommended that you check the following to ensure normal operation of the AP.
Check if the LED works normally.

·
5 Monitoring and Maintenance
5.1 Monitoring
LED
You can observe the LED to monitor the AP in operation.
5.2 Hardware Maintenance
If the hardware is faulty, please contact our Technical Assistance Center (TAC) for help.

·
6 Troubleshooting
6.1 Troubleshooting Flowchart
6.2 Troubleshooting
LED does not light up after the AP is powered on
Verify that the power source is IEEE 802.11at compliant, and then verify that the cable is connected properly.
Ethernet port is not working after the Ethernet port is connected
Verify that the device at the other end of the Ethernet cable is working properly. And then verify that the Ethernet cable is
capable of providing the required data rate and is properly connected.
Wireless client cannot find the AP
1. Check whether the power supply is normal.
2. Check the Ethernet port connection.
