Ruijie RG-MAP852-SF-S Installation and operating manual

Ruijie RG-MAP852-SF-S Access Point
Hardware Installation and Reference Guide
Document Version: V1.1
Date: August 16, 2023
Copyright © 2023 Ruijie
Networks

Copyright
Copyright © 2023 Ruijie Networks
All rights are reserved in this document and this statement.
Any reproduction, excerption, backup, modification, transmission, translation or
commercial use of this document or any portion of this document, in any form or by any
means, without the prior written consent of Ruijie Networks is prohibited.
Trademark and are owned by Ruijie
Networks.
All other trademarks or registered trademarks mentioned in this document are owned by
their respective owners.
Disclaimer
The products, services, or features you purchase are subject to commercial contracts and
terms. Some or all of the products, services or features described in this document may
not be within the scope of your purchase or use. Unless otherwise agreed in the contract,
Ruijie Networks does not make any express or implied statement or guarantee for the
content of this document.
Due to product version upgrades or other reasons, the content of this document will be
updated from time to time. Ruijie Networks reserves the right to modify the content of
the document without any notice or prompt.
This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy
and will not shoulder any responsibility for losses and damages caused due to content
omissions, inaccuracies or errors.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
Ruijie Networks Website: https://www.ruijienetworks.com/
Technical Support Website: https://ruijienetworks.com/support
Case Portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical Support Email: [e-mail]
Skype: [e-mail]
Conventions
1. Conversions
Convention
Description
Bold font
Commands, command options, and keywords are in
bold font.
Italic font
Arguments for which you supply values are in italic font.
[ ]
Elements in square brackets are optional.
{ x | y | z }
Alternative keywords are grouped in braces and
separated by vertical bars.
[ x | y | z ]
Optional alternative keywords are grouped in brackets
and separated by vertical bars.
&<1-n>
The argument before the sign (&) can be input for
consecutive 1- n times.

II
//
Double slashes at the beginning of a line of code
indicate a comment line.
2. Signs
The signs used in this document are described as follows:
Warning
An alert that calls attention to important rules and information that if not understood or
followed can result in data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed
can result in function failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or
followed will not lead to serious consequences.
Specification
An alert that contains a description of product or version support.
3. Note
The manual offers configuration information (including model, port type and command
line interface) for indicative purpose only. In case of any discrepancy or inconsistency
between the manual and the actual version, the actual version prevails.

i
Contents
Preface..................................................................................................................................................I
1 Product Introduction........................................................................................................................1
1.1 Product Overview.....................................................................................................................1
1.2 Product Appearance ................................................................................................................1
1.3 Package Contents.....................................................................................................................5
1.4 Technical Specifications...........................................................................................................6
1.4.1 Dimensions and Weight...............................................................................................6
1.4.2 RF Specifications...........................................................................................................7
1.4.3 Port Specifications........................................................................................................9
1.4.4 Power Supply and Consumption ................................................................................9
1.4.5 Environment and Reliability ......................................................................................10
1.5 Indicators and Buttons ..........................................................................................................10
2 Preparing for Installation...............................................................................................................12
2.1 Safety Precautions..................................................................................................................12
2.1.1 General Safety Precautions .......................................................................................12
2.1.2 Handling Safety ..........................................................................................................12
2.1.3 Electric Safety..............................................................................................................13
2.1.4 Storage Security .........................................................................................................13
2.2 Installation Environment Requirements..............................................................................13
2.2.1 Bearing Requirements...............................................................................................14

ii
2.2.2 Ventilation Requirements..........................................................................................14
2.2.3 Space Requirements ..................................................................................................14
2.2.4 Temperature/Humidity Requirements.....................................................................14
2.2.5 Cleanliness Requirements.........................................................................................15
2.2.6 Grounding Requirements..........................................................................................16
2.2.7 Anti-interference Requirements ...............................................................................16
2.2.8 Lightning Protection Requirements .........................................................................16
2.2.9 Inspection of the Installation Unit............................................................................17
2.3 Tools ........................................................................................................................................17
3 Installation ......................................................................................................................................18
3.1 Installation Procedure ...........................................................................................................18
3.2 Checking Before Installation.................................................................................................19
3.3 Precautions.............................................................................................................................19
3.4 Installing the Device...............................................................................................................20
3.4.1 Embedding in an 86-type Box ...................................................................................20
3.4.2 Removing the AP........................................................................................................24
3.5 Connecting Cables .................................................................................................................25
3.6 Bundling Cables......................................................................................................................25
3.6.1 Precautions .................................................................................................................25
3.6.2 Bundling Steps............................................................................................................26
3.7 Installation Verification..........................................................................................................26

iii
3.7.1 Checking the AP..........................................................................................................26
3.7.2 Checking Cable Connection.......................................................................................26
3.7.3 Checking the Power Supply.......................................................................................26
4 Debugging.......................................................................................................................................27
4.1 Establishing the Configuration Environment ......................................................................27
4.2 Powering on the AP................................................................................................................27
4.2.1 Checklist Before Power-on ........................................................................................27
4.2.2 Checking the Environment After Power-on .............................................................27
5 Monitoring and Maintenance........................................................................................................28
5.1 Monitoring ..............................................................................................................................28
5.1.1 Indicators ....................................................................................................................28
5.1.2 CLI Commands ...........................................................................................................28
5.2 Remote Maintenance.............................................................................................................28
5.3 Hardware Maintenance .........................................................................................................28
6 Troubleshooting .............................................................................................................................28
6.1 General Troubleshooting Procedure....................................................................................28
6.2 Common Troubleshooting Procedures................................................................................29
6.2.1 Ethernet Port Is Not Working After the Ethernet Cable Is Plugged In..................29
6.2.2 LED Is Off for a Long Time.........................................................................................29
6.2.3 LED Is Steady Red.......................................................................................................29
6.2.4 LED Is Steady Green...................................................................................................30

iv
6.2.5 No Wireless Signal Searched.....................................................................................30
7 Appendix .........................................................................................................................................31
7.1 Connectors and Media...........................................................................................................31
7.2 Cabling Recommendations ...................................................................................................32
7.3 Optical Modules and Specifications......................................................................................36
7.4 Power Adapter Specifications ...............................................................................................37

Hardware Installation and Reference Guide Product Introduction
1
1 Product Introduction
1.1 Product Overview
RG-MAP852-SF-S is a wireless access point (AP) for new-generation high-speed wireless
networks in scenarios with dense buildings, such as the campus dormitory network and
medical care ward network. It adopts the latest 802.11ax protocol and dual-radio
dual-band design. The 2.4 GHz radio frequency (RF) unit provides up to 574 Mbps access
rate, and the 5 GHz RF unit provides up to 1.201 Gbps access rate. The device provides up
to 1.775 Gbps wireless access rate. The ultra-fast wireless network makes performance
no longer a bottleneck.
1.2 Product Appearance
RG-MAP852-SF-S contains two wireless RF ports, one 10/100/1000Base-T adaptive
Ethernet port, one 1G optical port, one Console port, and one DC power supply port for
the external power adapter. Power can be supplied to RG-MAP852-SF-S through the DC
power adapter. The following figures show the product appearance.
Figure 1-1Front View

Hardware Installation and Reference Guide Product Introduction
2
Figure 1-2Rear View
Figure 1-3Installation View

Hardware Installation and Reference Guide Product Introduction
3
Figure 1-4Bottom View
Table 1-1 Port Description
No.
Item
Function Description
1
1000M LAN
port
Used to connect to the Ethernet communication port of the
STA.

Hardware Installation and Reference Guide Product Introduction
4
Figure 1-5Side View
Table 1-2 Side View Description
No.
Item
Function Description
1
Power supply
port
Used to supply power to the AP. The DC4805 power adapter
or photoelectric hybrid cable can be used for power supply.
2
Reset button
Used to restart the device or restore factory settings of the
device. For detailed reset operations, see section 1.5.
3
Management
port
Used to connect with a serial cable for device management.

Hardware Installation and Reference Guide Product Introduction
5
Figure 1-6Top View
Figure 1-7Button and Port
No.
Item
Function Description
1
Optical port
LC single-core fiber port used to connect with the uplink AM
host. The host needs to use the paired optical module.
2
Indicator
Used to display the AP working status. For details about the
indicator meaning, see section 1.5.
1.3 Package Contents
Table 1-3 Package Contents
No.
Item
Quantity
Remarks
1
RG-MAP852-SF-S
1
2
Mounting bracket
1
3
Hex socket screws M3 x 5 for
the kensington lock
1
4
Phillips pan head screws M4 x
2

Hardware Installation and Reference Guide Product Introduction
6
No.
Item
Quantity
Remarks
20
5
External optical module
1
6
Wire saddle
3
Pre-installed at the back of the
device
7
Warranty card and list of
hazardous substances
1
8
Quick start guide
1
9
Package Contents
1
Combined with the quick start
guide
1.4 Technical Specifications
1.4.1 Dimensions and Weight
Table 1-4 Dimensions and Weight
Dimensions and
Weight
RG-MAP852-SF-S
Dimensions (W × D × H)
86 mm ×160 mm × 30 mm (3.39 in x 6.30 in x 1.18 in)
Weight
AP: < 0.3 kg (0.66 lbs)
Mounting bracket: < 0.1 kg (0.22 lbs)
Installation Method
Embedded in the 86-type panel
Color
White
Anti-Theft Lock
Kensington lock
Mounting Bracket
Dimensions (W × D × H)
86 mm ×155 mm × 6 mm (3.39 in x 6.10 in x 0.24 in)

Hardware Installation and Reference Guide Product Introduction
7
Dimensions and
Weight
RG-MAP852-SF-S
Mounting Hole Pattern
60 mm (standard 86-type box hole diameter) (2.36 in)
Mounting Hole
Diameter
5.5 mm (standard 86 box hole diameter) (0.22 in)
1.4.2 RF Specifications
Table 1-5 RF Specifications
RF Specifications
RG-MAP852-SF-S
Radio Design
Bi-radio: two wireless RF ports, and four spatial streams per
device
Radio 1 (first channel): 2.4 GHz, 2 spatial streams: 2 × 2,
MU-MIMO
Radio 2 (second channel): 5 GHz, 2 spatial streams: 2 × 2,
MU-MIMO
Operating Band
Radio 1:
802.11b/g/n/ax, 2.400–2.4835 GHz, HE40
Radio 2:
802.11a/n/ac/ax, 5.150–5.350 GHz, HE80
802.11a/n/ac, 5.470–5.725 GHz, 5.725–5.850 GHz, HE80
Note: The operating band varies in different countries.
Transmission Rate
Radio 1: 2.4 GHz, 574 Mbps
Radio 2: 5 GHz, 1.201 Gbps
Maximum access rate of the AP
2.4 GHz+5 GHz, 1.775 Gbps
Antenna Type
Built-in omnidirectional antenna

Hardware Installation and Reference Guide Product Introduction
8
RF Specifications
RG-MAP852-SF-S
Antenna Gain
2.4 GHz: 3 dBi
5 GHz: 3 dBi
Max. Transmit Power
18 dBm
Note: The transmit power varies based on the regulations in
different countries and regions.
Transmit Power
Adjustment
Configurable in increments of 1 dBm
Modulation Modes
OFDM: BPSK@6/9 Mbps, QPSK@12/18 Mbps, 16-QAM@24
Mbps, 64-QAM@48/54 Mbps
DSSS: DBPSK@1 Mbps, DQPSK@2Mbps, and [email protected]/11
Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM and
1024QAM
OFDMA: 26, 52, 106, 242, 484, 996 Tone
Receiving Sensitivity
IEEE 802.11b: –96 dBm (1 Mbps), –93 dBm (5 Mbps), –89
dBm (11 Mbps)
802.11a/g: –91 dBm (6 Mbps), –85 dBm (24 Mbps), –80 dBm
(36 Mbps), –74 dBm (54 Mbps)
11n: –90 dBm @ MCS0, –70 dBm @ MCS7, –89 dBm @ MCS8,
–68 dBm @ MCS15
802.11ac: HT20: –88 dBm (MCS0), –63 dBm (MCS9)
802.11ac: HT40: –85 dBm (MCS0), –60 dBm (MCS9)
802.11ac: HT80: –82 dBm (MCS0), –57 dBm (MCS9)
802.11ax: HE80: –82 dBm (MCS0), –57 dBm (MCS9), –52 dBm
(MCS11)

Hardware Installation and Reference Guide Product Introduction
9
1.4.3 Port Specifications
Table 1-6 Port Specifications
Ports
RG-MAP852-SF-S
Fixed Service Ports
Uplink: 1 × 1000Base-X LC port
Downlink: 1 × 10/100/1000Base-T adaptive Ethernet electrical
port
Fixed Management
Ports
1 × Micro USB console port
Status Indicator
1 × system indicator
Button
One reset button
1.4.4 Power Supply and Consumption
Power Supply and
Consumption
RG-MAP852-SF-S
Power Supply
(1) Power supply using the power adapter (DC input voltage and
current: 48 V/0.5 A)
(2) Power supply using photoelectric hybrid cables (meet the
802.3af PoE power supply standard)
Power Supply to
External Devices
Not supported
Maximum Power
Consumption
< 11 W
Power Redundancy
Not supported
Caution
This product supports PoE power supply using photoelectric hybrid cables only when
it is connected with RG-AM5528-SF.

Hardware Installation and Reference Guide Product Introduction
10
The AP adopts a fan-free design. Therefore, maintain sufficient clearance around the
AP for air circulation.
When a laptop using a power adapter for power supply is used to manage a single
AP over a serial port, power on the AP before connecting the serial port of the laptop
to the AP. Otherwise, the AP cannot be powered on.
The power adapter is an optional component. For details about the specifications,
see 7.4 Power Adapter Specifications.
1.4.5 Environment and Reliability
Table 1-7 Standard Compliance
Environment and
Reliability
RG-MAP852-SF-S
Temperature
Operating temperature: –10°C to +40°C (14°F to 104°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
At a height between 3,000 m (9,842.52 ft.) and 5,000 m
(16,404.20 ft.) above the sea level, every time the altitude
increases by 166 m (546 ft.), the maximum temperature
decreases by 1°C.
Humidity
Operating humidity: 5% to 95% RH (non-condensing)
Storage humidity: 5% to 95% RH (non-condensing)
Regulatory
compliance
EN 55032, EN 55035, EN 61000-3-3, EN IEC 61000-3-2, EN 301
489-1, EN 301 489-3, EN 301 489-17, EN 300 328, EN 301 893, EN
300 440, FCC Part 15, EN IEC 62311, IEC 62368-1, and EN
62368-1
1.5 Indicators and Buttons
Table 1-8 System Indicator Status in Fit AP Mode
Indicator Status
Frequenc
y
Description
Off
N/A
The AP is not powered on. Alternatively, the AP is

Hardware Installation and Reference Guide Product Introduction
11
Indicator Status
Frequenc
y
Description
powered on, but the indicator is turned off using the
software function.
Steady green
N/A
The software system of the AP is being initialized.
Steady red
N/A
The system runs properly. However, the uplink
service port of the AP is in linkdown state.
Quick off after
blinking red
On for 3s
Off for 1s
The CAPWAP tunnel established between the AP and
AC is timed out.
Blinking green at
an interval of 0.2s
On for
0.2s
Off for
0.2s
The software system of the AP is being updated.
During this process, the AP cannot be powered off.
Off after blinking
green
On for 3s
Off for 1s
The software system runs properly, the AP works
properly, and the CAPWAP tunnel status is normal.
Blinking red at an
interval of 0.2s
On for
0.2s
Off for
0.2s
The AP enables the indicator locating function to
locate the specified AP.
Table 1-9 Reset Button
Button
Operation
Result
Reset
button
Press the button for less than 2s
Reboot the device.
Press and hold the button for longer than
5s
Restore to factory
settings.

Hardware Installation and Reference Guide Preparing for Installation
12
2 Preparing for Installation
2.1 Safety Precautions
Note
To avoid personal injury and device damage, carefully read the safety precautions
before you install the device.
The following safety precautions do not cover all possible dangers.
2.1.1 General Safety Precautions
Do not expose the AP to high temperature, dusts, or harmful gases. Do not install the
AP in an inflammable or explosive environment. Keep the AP away from EMI sources
such as large radar stations, radio stations, and substations. Do not subject the AP to
unstable voltage, vibration, and noises.
The installation site should be free from water flooding, seepage, dripping, or
condensation. The installation site should be selected according to network planning,
communications equipment features, and considerations such as climate, hydrology,
geology, earthquake, electrical power, and transportation.
The installation site should be dry. It is not recommended that the AP be installed in a
place near the sea. Keep the device at least 500 meters away from the ocean and do
not face it towards the sea breeze.
Do not place the device in walking areas.
During the installation and maintenance, do not wear loose clothes, ornaments, or any
other things that may be hooked by the chassis.
Keep tools and components away from walking areas.
2.1.2 Handling Safety
Prevent the AP from being frequently handled.
Cut off all the power supplies and unplug all power cords before moving or handling
the device.
