1 Product Introduction
1.1 Product Overview
RG-MAP852-SF-M is a wireless access point (AP) for new-generation high-speed wireless
networks in scenarios with dense buildings, such as the campus network, dormitory
network, and medical care ward network.
It adopts the latest 802.11ax protocol and dual-radio design. The 2.4 GHz Radio
Frequency Processing Unit (RPU) provides a maximum access rate of 574 Mbps, and the 5
GHz RPU provides a maximum access rate of 2.402 Gbps. In this way, this AP can provide
a maximum access rate of 2.976 Gbps, which breaks through the bottleneck in wireless
performance. RG-MAP852-SF-M provides five wired ports, including four 1000 Mbps LAN
ports and one 1000 Mbps uplink SFP port, for high-performance wired access in
environments such as dormitory buildings.
Important factors such as the wireless network security, radio control, mobile access,
Quality of Service (QoS), and seamless roaming are fully taken into account for
RG-MAP852-SF-M. Therefore, this AP can be used together with Ruijie's access controllers
(ACs) to implement STA data forwarding, security, and access control.
1.2 Product Appearance
RG-MAP852-SF-M provides two RF ports, four Ethernet ports, one 2.5G SFP port, one
micro USB console port, and one DC port. The following figures show the product
appearance.

Hardware Installation and Reference Guide Product Introduction
2
Figure 1-1 Front View

Hardware Installation and Reference Guide Product Introduction
3
Figure 1-1Side View

Hardware Installation and Reference Guide Product Introduction
4
Figure 1-2Rear View
Table 1-1 Ports and Button on the Rear Side
No.
Item
Description
1
Power supply
port
Phoenix terminal powered port for power supply of the
device
2
SFP port
Uplink service port for data transmission
3
Reset button
Used to reboot the device or restore the device to factory
settings

Hardware Installation and Reference Guide Product Introduction
5
Figure 1-3Bottom View
Table 1-2 Port Description
No.
Port
Description
1
Indicator
Used to show the running status of the system (The
indicator is hidden and can be observed after the
decorative cover is disassembled.)
2
LAN 1 port
Downlink service port for data transmission
3
LAN 2 port
Downlink service port for data transmission
4
LAN 3 port
Downlink service port for data transmission
5
LAN 4 port
Downlink service port for data transmission

Hardware Installation and Reference Guide Product Introduction
6
Figure 1-4Right View
Table 1-3 Port Description
No.
Port
Description
1
Console port
Connected with a serial port cable for device
management
1.3 Package Contents
Table 1-4 Package Contents
No.
Item
Quantity
1
RG-MAP852-SF-M
1
2
Mounting bracket
1
3
Mounting bracket latch
1

Hardware Installation and Reference Guide Product Introduction
7
No.
Item
Quantity
4
Phillips pan head screws M4 x 20
2
5
External optical module
1
6
Wire saddle
3
7
Quick start guide
1
8
Warranty card and list of hazardous
substances
1
9
Package Contents
1
1.4 Technical Specifications
1.4.1 Dimensions and Weight
Table 1-5 Dimensions and Weight
Dimensions and
Weight
RG-MAP852-SF-M
Dimensions (W × D ×
H)
86 mm ×160 mm × 32.5 mm (3.39 in. x 6.30 in. x 1.28 in.)
Weight
AP: 0.30 kg (0.70 lbs)
Mounting bracket: 0.05 kg (0.11 lbs)
Installation Method
Embedding in an 86-type panel
Color
White
Anti-Theft Lock
Security screw
Mounting Bracket
Dimensions (W × D ×
H)
160.8 mm × 86 mm × 8 mm (6.33 in. x 3.39 in. x 0.31 in.)

Hardware Installation and Reference Guide Product Introduction
8
Dimensions and
Weight
RG-MAP852-SF-M
Mounting Hole
Pattern
60 mm (2.36 in.)
Mounting Hole
Diameter
5.1 mm (0.20 in.)
1.4.2 RF Specifications
Table 1-6 RF Specifications
RF Specifications
RG-MAP852-SF-M
Radio Design
Bi-radio
Up to four spatial streams
Radio 1: 2.4 GHz, 2 spatial streams: 2 × 2, MU-MIMO
Radio 2: 5 GHz, 2 spatial streams: 2 × 2, MU-MIMO
Operating Band
Radio 1:
802.11b/g/n/ax, 2.400–2.4835 GHz
Radio 2:
802.11a/n/ac/ax, 5.150–5.350 GHz
802.11a/n/ac, 5.470–5.725 GHz, 5.725–5.850 GHz
Note: The operating bands vary in different countries.
Transmission Rate
Radio 1: 2.4 GHz, 574 Mbps
Radio 2: 5 GHz, 2.402 Gbps
Maximum access rate of the AP:
2.4 GHz+5 GHz, 2.976 Gbps
Antenna Type
Built-in omnidirectional antenna

Hardware Installation and Reference Guide Product Introduction
9
RF Specifications
RG-MAP852-SF-M
Antenna Gain
2.4 GHz: 2.22 dBi
5 GHz: 6.45 dBi
Max. Transmit
Power
20 dBm
Note: The transmit power varies based on the regulations in
different countries and regions.
Transmit Power
Adjustment
Configurable in increments of 1 dBm
Modulation Modes
IEEE 802.11b: BPSK, QPSK, CCK
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
(dedicated extensibility)
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
(dedicated extensibility)
802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM,
4096-QAM (dedicated extensibility)
Receiving Sensitivity
802.11b: –91 dBm (1 Mbps), –90 dBm (5 Mbps), –87 dBm (11
Mbps)
802.11a/g: –89 dBm (6 Mbps), –82 dBm (24 Mbps), –78 dBm (36
Mbps), –72 dBm (54 Mbps)
802.11n: –85 dBm @ MCS0, –67 dBm @ MCS7
802.11ac HT20: –85 dBm (MCS0), –60 dBm (MCS9)
802.11ac HT40: –82 dBm (MCS0), –57 dBm (MCS9)
802.11ac HT80: –79 dBm (MCS0), –53 dBm (MCS9)
802.11ax HE80: –79 dBm (MCS0), –52 dBm (MCS11)
802.11ax HE160: –75 dBm (MCS0), –48 dBm (MCS11)

Hardware Installation and Reference Guide Product Introduction
10
1.4.3 Port Specifications
Table 1-7 Port Specifications
Ports
RG-MAP852-SF-M
Bluetooth
Bluetooth 5.1
USB Port
Not supported
Fixed Service Ports
Uplink: 1 × 2.5G SFP port, incompatibility with 1G SFP port
Downlink: 4 × 10/100/1000Base-T adaptive Ethernet ports
Fixed Management
Ports
1 × Micro USB console port
Status Indicator
1 × system indicator
Button
One reset button
1.4.4 Power Supply and Consumption
Power Supply
and
Consumption
RG-MAP852-SF-M
Power Supply
(1) Power supply using the power adapter (DC input voltage and
current: 48 V/0.5 A)
(2) Power supply using photoelectric hybrid cables (meet the 802.3af
PoE power supply standard)
Power Supply
to External
Devices
Not supported
Maximum
Power
Consumption
< 11 W

Hardware Installation and Reference Guide Product Introduction
11
Power Supply
and
Consumption
RG-MAP852-SF-M
Power
Redundancy
Not supported
Caution
To power the AP by using PoE, ensure that the device at the other end of the
Ethernet cable supports IEEE 802.3af power supply.
The AP adopts a fan-free design. Therefore, maintain sufficient clearance around the
AP for air circulation.
1.4.5 Environment and Reliability
Table 1-8 Standard Compliance
Environment and
Reliability
RG-MAP852-SF-M
Temperature
Operating temperature: –10°C to +40°C (14°F to 104°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
At a height between 3,000 m (9,842.52 ft.) and 5,000 m
(16,404.20 ft.) above the sea level, every time the altitude
increases by 166 m (546 ft.), the maximum temperature
decreases by 1°C.
Humidity
Operating humidity: 5% to 95% RH (non-condensing)
Storage humidity: 5% to 95% RH (non-condensing)
Regulatory
compliance
EN 55032, EN 55035, EN 61000-3-3, EN IEC 61000-3-2, EN 301
489-1, EN 301 489-3, EN 301 489-17, EN 300 328, EN 301 893, EN
300 440, FCC Part 15, EN IEC 62311, IEC 62368-1, and EN
62368-1

Hardware Installation and Reference Guide Product Introduction
12
1.5 Indicators and Buttons
Note
The LED description applies to both fit and fat modes unless otherwise specified.
Table 1-9 System Indicator Status
Indicator Status
Frequen
cy
Description
Off
N/A
The AP is not powered on.
The AP is powered on, but the indicator is manually
turned off.
Steady green
N/A
The software system of the AP is being initialized.
Steady red
N/A
The system is running properly, but the uplink
service port is linked down.
Quick off after
blinking red
On for 3s
Off for 1s
In fit mode, the setup of a CAPWAP tunnel between
the AP and AC timed out.
Blinking green at
an interval of 0.2s
On for
0.2s
Off for
0.2s
In fit or MACC mode, the software system of the AP
is being updated.
Quick off after
blinking green
On for 3s
Off for 1s
The system is running properly.
Blinking red at an
interval of 0.2s
On for
0.2s
Off for
0.2s
In fit mode, the AP is being located.
