Ruijie RG-AP740-I Series Installation and operating manual

RG-AP740-I Series Access Point
Hardware Installation and Reference Guide V1.02

·
Copyright statement
Ruijie Networks©2017
Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup,
modification, transmission, translation or commercial use of this document or any portion of this document,
in any form or by any means, without the prior written consent of Ruijie Networks is prohibited.
Exemption statement
This document is provided “as is”. The contents of this document are subject to change without any notice.
Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to
ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to
content omissions, inaccuracies or errors.

·
Hardware Installation and Reference Guide Product Overview
Preface
Thank you for using our products. This manual will guide you through the installation of the access point.
Scope
It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it
is assumed that the users are already familiar with the related terms and concepts.
Obtaining Technical Assistance
Ruijie Networks Website: http://www.ruijienetworks.com/
Service Email: [email protected]
Technical Support: http://www.ruijienetworks.com/service.aspx
Technical Support Hotline: [phone]
Related Documents
Documents
Description
Configuration Guide
Describes network protocols and related mechanisms that supported by the
product, with configuration examples.
Command Reference
Describes the related configuration commands, including command modes,
parameter descriptions, usage guides, and related examples.
Documentation Conventions
The symbols used in this document are described as below:
This symbol brings your attention to some helpful suggestions and references.
This symbol means that you must be extremely careful not to do some things that may damage the device or cause
data loss.

·
Hardware Installation and Reference Guide Product Overview
1 Product Overview
The RG-AP740-I AP uses Ruijie’s highly acclaimed X-Sense Smart Antenna and tops the class by supporting 802.11ac
Wave 2. Featuring nine spatial streams and MU-MIMO, the AP implements a leading tri-radio, dual-band design. The
three main radios deliver up to 1,734Mbps+800Mbps+433Mbps access rates and the third offers frequency spectrum
scanning. The whole AP speeds performance up to 2,967Mbps. The market-leading X-Sense Smart Antenna provides
better coverage and ensures the best access for mobile terminals. All models in the X-Sense AP Series support security,
radio frequency (RF) control, mobile access, Quality of Service (QoS) and seamless roaming. Teamed up with the Ruijie
RG-WS Wireless Controller Series, wireless data forwarding, high performance security and access control can be
accomplished with ease.
In addition, the RG-AP740-I AP (with tri-band and dual-radio design) flexibly supports 2.4G+5G+2.4G or 2.4G+5G+5G
working modes and concurrently 802.11ac Wave 2, 802.11ac Wave 1 and 802.11n. The AP can be mounted on a ceiling
or wall or on a pole. The AP supports local power supply and PoE to meet challenges in a wide variety of deployment
scenarios, including large-scaled campuses, enterprises, hospitals and WiFi hotspots.
1.1 Technical Specifications
Table 1-1 RG-AP740-I Technical Specifications
Model
RG-AP740-I
RF
Tri-band, dual-radio
Transmission
Protocol
Three radio frequency cards support concurrent 802.11a/b/g/n, 802.11ac Wave 1 and 802.11ac
Wave 2.
Operating modes of 2.4G+5G+2.4G and 2.4G+5G+5G operating modes are supported.
Operating Bands
802.11b/g/n: 2.4GHz to 2.483GHz
802.11a/n/ac: 5.15GHz to 5.35GHz, 5.47GHz to 5.725GHz, 5.725GHz to 5.85GHz
(Country-Specific)
Antenna
Built-in X-Sense Smart Antenna array
Spatial Streams
9 streams: 4x4 SU-MIMO, 4x4 MU-MIMO, 1x1 SISO
Working Bandwidth
HT160(80+80), HT80, HT40, HT20
Max Throughput
802.11b/g/n: up to 800Mbps
802.11a/n/ac: up to 1,734Mbps and 433Mbps
Up to 2,967Mbps per AP
Modulation
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and [email protected]/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM , 64QAM and 256QAM
Receive Sensitivity
11a: -88dBm (6Mbps), -79dBm (24Mbps), -77dBm (36Mbps), -73dBm (54Mbps)
11b/g: -88dBm (6Mbps), -79dBm (24Mbps), -77dBm (36Mbps), -73dBm (54Mbps)
11n: -86dBm@MCS0, -68dBm@MCS7, -86dBm@MCS8, -68dBm@MCS15
11ac HT20: -83dBm (MCS0), -64dBm (MCS8)
11ac HT40: -80dBm (MCS0), -58dBm (MCS9)
11ac HT80: -77dBm (MCS0), -52dBm (MCS9)
11ac HT160(80+80): -74dBm (MCS0), -50dBm (MCS9)

·
Hardware Installation and Reference Guide Product Overview
Transmit Power
≤100mw (20dBm)
Transmit Power
Adjustment
1dBm
Dimensions
(W x D x H)
230mm x 230mm x 47mm (9.06in. x 9.06in. x 1.85in.)
Weight
1.3kg (2.87lbs)
Service Ports
Two 10/100/1000BASE-T Ethernet uplink ports (PoE-capable); one USB port
Management Ports
One Console port
Reset Button
Support
Anti-theft Locks
Support
LED
1 LED (red, green, blue and orange light for solid mode, flashing mode, or breathing flashing
mode, and the indicator can be switched off to silent mode)
Power Supply
Adapter: DC 48V (optional)
PoE: IEEE 802.3af/802.3at-compliant (compatible).
Dual PoE for power backup of the 802.3at or dual 802.3af power supplies
Note:
When power is supplied by dual 802.3at, USB is supported.
When power is supplied by single 802.3at, radio1 2.4G@1X4 and radio2 5G@3X4 modes are
supported.
Power Consumption
< 25.4W
Bluetooth
Bluetooth 4.0 (BLE) and Apple iBeacon protocol are supported. Bluetooth applications, such as
Shake and locating, can be extended.
Temperature
Operating: -10°C to 55°C (14°F to 131°F)
Storage: -40°C to 70°C (-40°F to 158°F)
Humidity
Operating: 5% to 95% (non-condensing)
Storage: 5% to 95% (non-condensing)
Installation
Ceiling/wall mount
IP Rating
IP41
Safety Standards
GB4943
EN/IEC 60950-1
EMC Standards
GB9254
EN301 489
Radio
China Radio Transmission Equipment Type Approval Certificate
EN300 328
EN301 893
Weight refers to the weight of host and bracket.
1.2 Product Image
The AP provides two 10/100/1000Base-T Ethernet ports (PoE-capable), one Console port, one power port for an external
power supply, one USB port and one reset button.
Figure 1-1 Appearance of the RG-AP740-I

·
Hardware Installation and Reference Guide Product Overview
Note
1. LED Indicator
2. Laptop lock
3. USB port
4. Reset button
5. LAN1/PoE Ethernet port
6. 48V DC power supply input port
7. Console port
8. LAN2/PoE Ethernet port
1.3 LED Indicators
Fit AP
State
Frequency
Meaning
Off
N/A
The AP is NOT receiving power in the Silent mode. This mode can be disabled
using software.
Blinking green
3Hz
Initialization is in progress. Continuously blinking green indicates abnormal
operation.
Blinking red
3Hz
Initialization is complete, but the Ethernet port is not connected.
Blinking blue
3Hz
Initialization is complete, and the AP is establishing a CAPWAP connection
with an AC.
Blinking orange
3Hz
Firmware upgrade in progress. Do not power off.
Solid blue
N/A
Normal operation, normal CAPWAP connection, but no wireless clients are
associated with the AP.
Breathing blue
Gradually fading
Normal operation, normal CAPWAP connection, at least one wireless client is
associated with the AP.
Solid red
N/A
Warnings (software defined )
Double blinking
red
3Hz (on and off for
2 cycles
alternately)
Locating AP
Fat AP
State
Frequency
Meaning

·
Hardware Installation and Reference Guide Product Overview
Off
N/A
The AP is NOT receiving power or in the Silent mode. This mode can be
disabled by software.
Blinking green
3Hz
Initialization is in progress. Continuously blinking green indicates abnormal
operation.
Blinking red
3Hz
Initialization is complete, but the Ethernet port is not connected.
Solid blue
N/A
Normal operation, but no wireless clients are associated with the AP.
Breathing blue
Gradually fading
Normal operation, at least one wireless client is associated with the AP.
Solid red
N/A
Warnings(defined by software)
Double blinking
red
3Hz (on and off for
2 cycles
alternately)
Locate AP.
1.4 Power Sources
The AP can be powered either with a power adapter or through Power over Ethernet (PoE).
To use a PoE device, make sure it supports the IEEE 802.3af/at PoE standard.
1.5 Cooling Solution
The AP adopts fanless design.
Leave sufficient space surrounding the AP when installing the AP to permit proper airflow for ventilation.
1.6 Radiation Pattern
The RG-AP740-I uses Ruijie’s patented X-Sense Smart Antenna. Regardless of the high mobility of smart devices, the AP
always provides the best signal path. Three radio patterns are shown in the following disgrams. The antennas focus gains
in front of the AP, so the signal strength in the front is stronger. It is preferable to install the AP towards the area that
requires the best wireless coverage.
When mounting the AP on a wall or ceiling, install the AP towards where you stand to avoid backward coverage.
Install the AP in a way that maximizes coverage.
When installing the AP indoors, it is better to mount it on the ceiling for greater coverage rather than on the wall.
Figure 1-2 and Figure 1-3 show the preferred wall-mount and ceiling-mount orientations of the AP operating in the 2.4
GHz and 5 GHz bands, respectively.
Figure 1-2 Preferred Ceiling-Mount and Wall-Mount Orientations of the RG-AP740-I (in the 2.4 GHz Band)

·
Hardware Installation and Reference Guide Product Overview
Figure 1-3 Preferred Ceiling-Mount and Wall-Mount Orientations of the RG-AP740-I (in the 5 GHz Band)

·
Hardware Installation and Reference Guide Preparing for Installation
2 Preparing for Installation
To prevent device damage and physical injury, please read the safety recommendations carefully as described in
this chapter.
Recommendations do not cover all possible hazardous situations.
2.1 Installation
The AP must be installed indoors. To ensure normal operation, the installation site must meet the following requirements.
Install the AP in a well-ventilated environment. If it is installed in a closed room, make sure there is a good cooling
system.
Make sure the site is sturdy enough to support the AP and its accessories.
Make sure the site has enough space for installing the AP and leave sufficient room around the AP for ventilation.
Do not expose the AP to high temperature, dust, or harmful gases.
Do not install the AP in an area prone to fire or explosions.
Keep the AP away from EMI sources such as large radar stations, radio stations, and substations.
Do not subject the AP to unstable voltage, vibration, and noises.
Keep the AP at least 500 meters away from the ocean and do not face it towards the sea breeze.
The installation site should be free from water including possible flooding, seepage, dripping, or condensation.
The installation site should be selected according to network planning and communications equipment features, and
considerations such as climate, hydrology, geology, earthquake, electrical power, and transportation.
Please follow the correct method described in the installation guide to install and remove the device.
2.2 Movement
Avoid frequently moving the device.
Turn off all power supplies and unplug all power cables before you remove the device.
2.3 EMI
Please observe local regulations and specifications when performing electrical operations. Relevant operators must
be qualified.
Carefully check for any potential hazards in the working area such as damp/wet ground or floors.
Find the location of the emergency power supply switch in the room before installation. Cut off the power supply first
in case of an accident.
Be sure to make a careful check before shutting down the power supply.

·
Hardware Installation and Reference Guide Preparing for Installation
Do not place the device in a damp/wet location. Do not let any liquid enter the chassis.
Keep the AP far away from grounding or lightning protection devices for power equipment.
Keep the AP away from radio stations, radar stations, high-frequency high-current devices, and microwave ovens.
Any nonstandard and inaccurate electrical operation can cause an accident such as fire or electric shock, thus
causing severe even fatal damages to humans and devices.
Direct or indirect contact with a wet object (or your finger) on the high voltage and power line can be fatal.
2.4 Ventilation
For proper ventilation, leave sufficient space around the AP.
2.5 Temperature and Humidity
To ensure the normal operation and equipment service life, maintain appropriate temperature and humidity levels in the
equipment room. See Table 2-1. Improper room temperature and humidity can cause damage to the device.
High relative humidity may affect insulation materials, resulting in poor insulation and even electrical leakage.
Sometimes it may lead to changes in the mechanical properties of materials and corrosion of metal parts.
Low relative humidity can dry and shrink insulation sheets and cause static electricity that can damage the circuitry.
High temperatures greatly reduce device reliability and shorten service life.
Table 2-1 Required Temperature and Humidity for the RG-AP740-I
Temperature
Relative Humidity
-10 to 55 ºC
5% to 95%
2.6 Cleanness
Dust poses a serious threat to device operation. Dust on the surface of the device can be absorbed onto metal contact
points by static electricity causing poor contact. Electrostatic absorption of dust occurs more easily when the relative
humidity is low, and might shorten the equipment service life and cause communication failures. Table 2-2 shows the
maximum concentration and diameter of dust allowed in the equipment room.
Table 2-2
Maximum diameter (μm)
0.5
1
3
5
Maximum concentration
(Particles/m3)
1.4 x 10
7 x 10
2.4 x 10
1.3 x 10
The amount of salt, acids and sulfides in the air are also strictly limited for the equipment room. These substances can
accelerate metal corrosion and aging of some parts. Table 2-3 describes the limits of some hazardous gases such as SO2,
H2S, NO2and Cl2 in the equipment room.
Table 2-3

·
Hardware Installation and Reference Guide Preparing for Installation
Gas
Average (mg/m3)
Maximum (mg/m3)
SO2
0.2
1.5
H2S
0.006
0.03
NO2
0.04
0.15
NH3
0.05
0.15
Cl2
0.01
0.3
2.7 Power Supply
DC power adapter: 42.5VDC to 57VDC (input voltage), 0.7A (minimum current), 30W (minimum power)
PoE injector: IEEE 802.3af/802.3at compliant
The DC input power should be greater than the power actually consumed by the system. The input power for the
RG-AP740-I should not be lower than 25.4W.
Please use Ruijie certified PoE injectors.
2.8 Installation Tools
Common Tools
Phillips (crosshead) screwdriver, related copper and fiber cables, bolts, diagonal pliers, cable
ties
Special Tools
Wire stripper, crimping pliers, RJ-45 crimping pliers, punch down tool
Meter
Multimeter, bit error rate tester (BERT)
The tools listed above are customer supplied.
2.9 Unpacking the Access Point
Package Contents

·
Hardware Installation and Reference Guide Preparing for Installation
Items
Verify that all parts are installed and debugged.
Screws
Mounting brackets
Product quick installation guide
Packing list
The above listed items are for general situations, and contents may vary in the actual shipment. The purchasing
order shall prevail in any case. Please check each item carefully according to the packing list or purchasing order. If
any item is damaged or missing, notify your sales representative.

·
Hardware Installation and Reference Guide Installing the Access Point
3 Installing the Access Point
The RG-AP740-I series must be fixed and installed indoors.
Before installing the AP, make sure you have carefully read the requirements described in Chapter 2.
3.1 Installation Flowchart
3.2 Before You Begin
Before installing the AP, verify that:
The installation site provides sufficient ventilation for the AP.
The installation site meets temperature and humidity requirements.
The installation site is equipped with a proper power supply.
Network cables are in place.
The installation site meets all described requirements.
The custom AP meets customer requirements.
3.3 Precautions
To avoid damage to the AP, observe the following safety precautions:
Do not power on the device during installation.
Install the device in a well-ventilated location.
Do not subject the device to high temperatures.
Keep away from high voltage cables.
Install the device indoors.
Do not expose the device in a thunderstorm or strong electric field.
Keep the device clean and dust-free.

·
Hardware Installation and Reference Guide Installing the Access Point
Disconnect the device before cleaning it.
Do not wipe the device with a damp cloth.
Do not wash the device with liquid.
Do not open the enclosure when the AP is working.
Fasten the device tightly.
3.4 Installing the Access Point
Ceiling Mount
1. Drill four 6 mm (0.24 in.) diameter holes in the ceiling, 53 mm (2.09 in.) apart. Tap wall anchors into the holes, and
drive screws through the mounting bracket into the anchors to fix the bracket. See Figure 3-1.
Figure 3-1 Attaching the Mounting Bracket on the Ceiling
2. Align the square feet (on the rear of the AP) over the mounting holes on the bracket. See Figure 3-2.
Figure 3-2 Aligning the Square Feet with the Mounting Holes
Install the Ethernet cables before mounting the AP on the bracket.

·
Hardware Installation and Reference Guide Installing the Access Point
3. Slide the AP onto the bracket in the reverse direction against the arrow on the mounting bracket until it clicks into
place. See Figure 3-3.
Figure 3-3 Mounting the AP on the Bracket
The AP can be installed in any of four directions on the mounting bracket depending on how you route the Ethernet
cable.
The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots.
After installation, verify that the AP is securely fastened.
Wall Mount
1. Drill four 6 mm (0.24 in.) diameter holes on the wall with the arrow on the mounting bracket facing up, 53 mm (2.09 in.)
apart. Tap wall anchors into the holes, and drive screws through the mounting bracket into the anchors to fix the
bracket. See Figure 3-4.
Figure 3-4 Attaching the Mounting Bracket on the Wall

·
Hardware Installation and Reference Guide Installing the Access Point
2. Align the square feet on the rear of the AP over the mounting holes on the bracket. See Figure 3-5.
Figure 3-5 Aligning the Square Feet with the Mounting Holes
Install the Ethernet cables before mounting the AP on the bracket.
3. Slide the AP into the holes in the reverse direction against the arrow on the mounting bracket until it clicks into place.
Note: keep the Ruijie logo pointed upwards. See Figure 3-6.
Figure 3-6 Mounting the AP on the Bracket
When mounting the AP on the wall, keep the Ruijie logo pointed upwards.
The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots.
After installation, verify that the AP is securely fastened.
3.5 (Optional) Securing the Access Point
1. Loosen the screw on the mounting bracket and enable the hidden lock.
Figure 3-1 Enabling the Hidden Lock

·
Hardware Installation and Reference Guide Installing the Access Point
2. Align the square feet on the rear of the AP over the mounting holes on the bracket, slide the AP in the reverse
direction against the arrow on the mounting bracket until it clicks into place.
Figure 3-2 Mounting the AP on the Bracket
Before mounting the AP on the bracket, you must first install the Ethernet cables.
3.6 Removing the Access Point
1. If the hidden lock is enabled, attach the front part of the key to the edge of the mounting bracket (keep the Ruijie key
logo towards the top panel of the AP). Slide the key along with the four edges of the mounting bracket, and attempt
to insert the key into the keyhole. It can only be inserted into one marked keyhole.
Figure 3-9 Inserting the Key for Unlocking
2. If the AP is installed on the wall, hold the AP in your hands and push it upward and away from the bracket in the LAN
port direction.

·
Hardware Installation and Reference Guide Installing the Access Point
Figure 3-10 Removing the Wall Mount AP
3. If the AP is installed on the ceiling, hold the AP in your hands and push it sideways. Attempt to push it in four
directions (the AP can be pushed out only in one direction).
Figure 3-11 Removing the Ceiling Mount AP
3.7 Connecting Cables
Connect the UTP/STP to the LAN1/PoE port on the AP. See Appendix A for the supported wiring for twisted pairs.
By default, the baud rate is set to 9600, data bit 8, parity none, stop bits 1 and flow control none on the AP console
port. The console port is used only when you want to configure the AP manually.
Avoid bending the cable in a small radius close to the connector.
Ruijie recommends that you do not use Ethernet cables with protective sleeves as they could make installation of
Ethernet cables more difficult.
3.8 Bundling Cables
Precautions

·
Hardware Installation and Reference Guide Installing the Access Point
Make sure the cable bundles are neat and orderly.
Bend twisted pairs naturally or in a large radius close to the connector.
Do not over tighten a cable bundle as it may reduce cable life and performance.
Bundling Steps
1. Bundle the drop UTP/STP cables and route them to the LAN1/PoE port.
2. Attach the cables in the cable tray of the rack.
3. Extend the cables under the AP and run in a straight line.
3.9 Checking after Installation
Checking the Cabinet
Make sure the external power supply matches the patch panel specifications for the cabinet.
After installation, make sure that the front and rear cabinet doors easily close.
Make sure the cabinet is stable and level.
Make sure the device and all cables are securely fastened in the rack.
Checking Cable Connection
Make sure the UTP/STP cable matches the interface type.
Make sure cables are properly bundled.
Checking the Power Supply
Make sure all power cables are properly connected and safe.
Make sure the AP is operational after powering on.

·
Hardware Installation and Reference Guide System Debugging
4 System Debugging
4.1 Setting up a Debugging Environment
Use a power adapter or PoE to power the AP.
Setting up the Environment
Verify that the AP is properly connected to the power source.
Connect the AP to an AC through a twisted pair cable.
When the AP is connected to a PC for debugging, verify that the PC and PoE switch are properly grounded.
4.2 Powering up the AP
4.2.1.1 Checking before power-up
Verify that the power supply is properly connected.
Verify that the input voltage matches the specification of the AP.
4.2.1.2 Checking after power-up (recommended)
After powering up, it is recommended that you check the following to ensure normal operation of the AP.
Check if any message is displayed on the Web-based configuration interface for the AC.
Check if the LED works normally.
4.3 Resetting the System
The reset button is placed in the hole beside the USB port. Insert into the hole an iron stick with a diameter less than 1mm.
After the button clicks, keep the stick in the same position for two more seconds before releasing it, and the system resets.
