Ruijie RG-WLAN Series User manual

RG-WLAN Series Access Point
Web-Based Configuration Guide, Release 11.1(5)B8

Copyright Statement
Ruijie Networks© 2016
Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification,
transmission, translation or commercial use of this document or any portion of this document, in any form or by any means,
without the prior written consent of Ruijie Networks is prohibited.
, , , , ,
, , , ,
, , are registered trademarks of Ruijie Networks.
Counterfeit is strictly prohibited.
Exemption Statement
This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain
the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will
not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

Preface
Thank you for using our products. This manual matches the RGOS Release 11.1(5)B8.
Audience
This manual is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Obtaining Technical Assistance
Ruijie Networks website: http://www.ruijienetworks.com/
Service Email: [email protected]
Technical Support: http://www.ruijienetworks.com/service.aspx
Technical Support Hotline: [phone]
Related Documents
Documents
Description
Command Reference
Describes the related configuration commands, including command modes,
parameter descriptions, usage guides, and related examples.
Hardware Installation and Reference
Guide
Describes the functional and physical features and provides the device
installation steps, hardware troubleshooting, module technical specifications,
and specifications and usage guidelines for cables and connectors.
Conventions
This manual uses the following conventions:
Convention
Description
boldface font
Commands, command options, and keywords are in boldface.
italic font
Arguments for which you supply values are in italics.

[ ]
Elements in square brackets are optional.
{ x | y | z }
Alternative keywords are grouped in braces and separated by vertical bars.
[ x | y | z ]
Optional alternative keywords are grouped in brackets and separated by
vertical bars.
Symbols
Means reader take note. Notes contain helpful suggestions or references.
Means reader be careful. In this situation, you might do something that could result in equipment damage or
loss of data.

Configuration Guide Web-based Configuration
Web-based Configuration
Overview
A user accesses the Web-based management system by using a browser (for example, IE browser) to manage the AP
device.
Web-based management involves two parts: Web server and Web client. A Web server is integrated onto a device to receive
and process requests sent from a client (for example, read a Web file or execute a command request) and returns the
processing result to the client. Generally, a Web client refers to a Web browser, for example, IE browser.
Currently, this file is applicable to only AP devices.
Application
Application
Description
Web-based Management
After finishing relevant configuration, a user can access the Web-based management
system through a browser.
Web-based Management
Scenario
As shown in the following figure, an administrator can access a device through a browser on a PC to manage the device.
Figure 1-1
Note
Web management system integrates configuration commands and sends them to the device through AJAX
request.
The device is enabled with the Web service to process the HTTP request to return the required data.
Function Deployment
Configuration Environment Requirements

Configuration Guide Web-based Configuration
Requirements for Client
An administrator logs in to the Web-based management system by using the Web browser on a client to manage the
device. Generally, a client refers to a PC. It may also be other mobile terminal devices, for example, a laptop.
Browser: IE7.0, IE8.0, IE9.0, IE10.0, IE11.0, Google chrome, Firefox, and some IE kernel-based browsers (for example,
Maxthon) are all supported. Exceptions such as messy code and format error may occur when other browsers are
used.
Resolution: It is recommended that the resolution be set to 1024 x 768, 1280 x 1024, or 1440 x 960. Exceptions such as
font alignment error and format error may occur when other resolutions are selected.
Requirements for server
The Web service must be enabled for the AP device.
Login authentication information for Web-based management must be configured for the AP device.
A management IP address must be configured for the AP device.
Default Configuration
The following table lists the default configuration of the Web management system.
Feature
Default Settings
Web service
Enabled
Management IP
192.168.110.1
Default Username/Password
Permission Description
admin/admin
Super administrator who possesses all permissions.
Login
You can type http://X.X.X.X (management IP address) in the address bar of a browser and press Enter to access the login
page, as shown in the following figure.
Figure 1-2 Login page

Configuration Guide Web-based Configuration
After typing the username and password, click Login.

Configuration Guide Web-based Configuration
Enter the username and password, click Login to access the Web management system.
Click Online Service for configuration help.
AP-Eweb Configuration
Quick Settings
Build a WiFi network for STAs to access and enjoy Internet services.

Configuration Guide Web-based Configuration
1) The Quick Settings page is displayed when you successfully logs in to the Web in the scenario that the device is in the
factory setting state, as shown in the preceding figure.
2) The Quick Settings page is also displayed when you click the Quick Settings link in the upper-right corner on the
homepage.
The device supporting NAT can work in AP access mode or wireless routing mode.

Configuration Guide Web-based Configuration

Configuration Guide Web-based Configuration
The device not supporting NAT can work only in AP access mode.

Configuration Guide Web-based Configuration
Configure the WiFi parameters, and click Finish to finish the configuration.
Favorites
System Homepage
The system homepage enables you to view the basic information of the AP device, including the device MAC address,
device model, system alarm information, flow trends of AP device ports, latest trends of all management APs, and STA
information corresponding to each management AP. In addition, it enables you to know the distribution condition of STA
signal strength in real time.

Configuration Guide Web-based Configuration
Click the Details link in the upper-right corner to view more system alarm information.
Click the Detail link in the upper-right corner of Top 10 Traffics or RSSI Distribution to view the STA information, for
example, the MAC address and RSSI.
User Information
STA information is displayed.
WiFi/WLAN
The WLAN allows wireless STAs to access the AP through WiFi to enjoy Internet services. You can add multiple WLANs.
You can also delete a WLAN.
The following figure shows the page for adding a WLAN.

Configuration Guide Web-based Configuration
Adding WiFi/WLAN
1) Click , a new panel for WiFi configuration is displayed.
2) Set the WiFi parameters.
3) Click Save to finish the configuration.
Editing the WLAN

Configuration Guide Web-based Configuration
1) Click the panel of WiFi you want to edit.
2) Edit the WiFi configuration.
3) Click Save. The Edit succeeded message is displayed.
Deleting WLANs
1) Click the panel of WiFi you want to delete.
2) Click Delete.
3) Click OK in the dialog box displayed to finish the deletion operation.
Wireless Channel Settings
Wireless channel settings are mainly about adjustment of the strength of the WiFi signal sent out by the device. You can set
channel parameters for the 2.4G and 5G networks.
Enabling the 2.4G network

Configuration Guide Web-based Configuration
1) You can click to enable or disable the 2.4G network.
1) You can click Enforce switch from 2.4GHz to 5GHz Network to switch the network type forcibly.
Enabling the 5G network

Configuration Guide Web-based Configuration
1) You can click to enable or disable the 5G network.
2) You can click Enforce switch from 5GHz to 2.4GHz Network to switch the network type to 2.4G network forcibly.
Restart
You can restart the system by a click, which is convenient and efficient.

Configuration Guide Web-based Configuration
Click Restart to restart the device.
Network
External Network Settings
External network settings are mainly about configuration of the communication mode between the AP and external network.
Two communication modes are available, that is, AP access mode and routing mode.
The AP used by you might not support this function, which is subject to the actual menu items.
You can select the AP working mode to determine the AP role and then conduct configuration based on the corresponding
working mode.

Configuration Guide Web-based Configuration
Set corresponding parameters and save the configuration.
Wireless Bridging
Multiple APs are connected to each other in wireless repeater or bridging mode to achieve the purpose of connecting
distributed networks and spreading wireless signals. An AP device can be regarded as a repeater. It spreads the front-end
network and elongates the WiFi transmission distance for association and connection of STAs far away. Wireless bridging
supports the 2.4G network and 5G network bridging.
Enable the 2.4G or 5G network bridging function as required, select the Central Base Station operating mode, and click
Save to finish configuration.
Advanced
VLAN
Adding a VLAN
Click Add VLAN. A dialog box is displayed, as shown in the preceding figure. Set corresponding parameters in the dialog
box and click Save. The newly added VLAN is displayed in the VLAN list after the Add succeeded message is displayed.

Configuration Guide Web-based Configuration
Deleting VLANs in batches
1) Select the VLAN to be deleted from the list.
2) Click Delete Selected VLAN to finish the deletion operation.
Editing a VLAN
Click the Edit button. A dialog box is displayed, as shown in the preceding figure. Click Save. The Save succeeded
message is displayed.
Deleting a VLAN
