Rutland County Rutland Box Lean-to Pergola User manual

Assembly Instructions
Rutland Box Lean-to Pergola
1
Before you commence the assembly process, we recommend that you read these instructions thoroughly beforehand to
familiarise yourself with the assembly process and to also check that you have the correct components. If for any reason you
need assistance, you can find our contact details on the final page of these instructions.
We highly recommend that any assembly is carried out on an open flat, level surface if possible, with sufficient space. You
will also require the assistance of 2 adults to complete assembly safely.
Please note: 1) For a free-standing pergola you can remove up to 600mm from the bottom of each post prior to commencing
construction.
2) Wall fixings are not included.
Package contents
Tools required
2 x Posts
1 x Runner
1 x Wall plate
2 x Edge rafters
4 x Rafters
6 x 75mm screws
8 x 100mm Coach Screws
8 x 120mm Coach Screws
10mm socket drive or spanner
#2 Pozidriv screwdriver
Platform or Step ladder
Spirit level or laser level
The Rutland Box Lean-to Pergola

Rutland Box Lean-to Pergola
Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows,
Aslackby, Sleaford, Lincs, NG34 0HZ.
Company No: 7670072 VAT No: 151744027
2
Step 1
Step 2
Check that you have the correct components as
shown in the package contents, including any fixings.
Your pergola can be shorter than standard by
removing the appropriate amount from the bottom
of each post. Remember to subtract the same
amount from the dimension shown in Step 2.
Take the wall plate and place it horizontally using a
level (batten toward the bottom) on the wall where
you would like the pergola located. Mark the hole
positions for your wall fixings then drill and fix in
place. Note: The distance from the underside of the
wall plate to the floor is 242cm.
Step 3
Step 4
Lay the runner down (part with timber batten
attached) with the batten uppermost. Position one of
the posts as shown, so that it is butted against the
batten and the top face of the post is flush with the
top edge of the runner. Now fix the post in place
using 2 of the 100mm coach screws and repeat for
remaining post.
Using your assistants, position the frame assembly
(post side facing the wall) vertically as shown,
approximately a rafter's length from the wall.

Rutland Box Lean-to Pergola
Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows,
Aslackby, Sleaford, Lincs, NG34 0HZ.
Company No: 7670072 VAT No: 151744027
3
Step 5
Step 6
Using a platform or step ladder (and an assistant if
necessary) lift one of the plain Edge rafters into
position so that both ends are butted up to the inner
edge of the rafter and flush with its top and bottom
edges as shown...
...before using 2 100mm coach screws to fix it to the
post.
Step 7
Step 8
Adjust the other end so that it fits snugly against the
wall...
...and is vertically aligned with the wall plate as
shown before securing in place...

Rutland Box Lean-to Pergola
Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows,
Aslackby, Sleaford, Lincs, NG34 0HZ.
Company No: 7670072 VAT No: 151744027
4
Step 9
Step 10
...with 3 x 75mm screws.
Add the other Edge rafter in the same fashion.
Step 11
Step 12
Now lower the first rafter into place using the pencil
markings on the wall plate and runners to align it...
...and secure the wall end in place with a 120mm
coach screw driven in from above at the wall plate
end...

Rutland Box Lean-to Pergola
Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows,
Aslackby, Sleaford, Lincs, NG34 0HZ.
Company No: 7670072 VAT No: 151744027
5
Step 13
Step 14
...and a second 120mm coach screw at the runner
end. Add the remaining rafters in the same fashion.
Your Rutland Box Lean-to Pergola is now complete.
We hope that you found your product quick and easy to assemble but if not and you require any further assistance or have any questions
you can contact us by telephone on: 01778 440803
Email: [email protected]
www.rutlandcountygardenfurniture.co.uk
