Ryobi BCL3660F User manual

BCL3660F
ORIGINAL INSTRUCTIONS
36 Volt
Lithium-ion
Battery Charger

Important!
The product is not intended to be used or cleaned by
persons with reduced physical, sensory or mental
capabilities, or lack of experience or knowledge, unless
they have been given instructions concerning the safe
use of the product by a person legally responsible for
their safety. They should be supervised while using the
product. Children shall not use, clean or play with this
product, which when not in use should be secured out of
their reach.

1 2 3 4
Fig.1
1
2
Fig.2
1
2
3
Fig.3
1

2
Safety, performance, and dependability have been given
top priority in the design of your battery charger.
INTENDED USE
This charger is only intended to charge BPL3626D,
BPL3626D2, BPL3640D, BPL3640D2, BPL3650D,
BPL3650D2, and BPL3660D battery packs listed in this
manual.
The product is only for use indoors in dry conditions.
The product is not intended to charge any other type of
battery or be used as a power supply. It should never be
used in explosive or inammable environments.
Do not use the product for any other purpose.
CHARGER SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
WARNING
Do not recharge primary cells (non-
rechargeable).
WARNING
Mains voltage must correspond with the voltage
specifications on the product.
■Before using the product, check that the charger
enclosure, cable, and plug are not damaged. If damage
is found, do not use the product and bring it to an
authorised service centre for repair.
■The product must not be damp and should never be
used in a damp environment.
■The product is for indoor use only.
■Do not use the product if it has suffered any heavy
shock or jolting, or is damaged in any other way.
■When charging, do not expose the product to sunlight
or other heat source. Recommended temperature
range at charging vicinity is 10° to 25°C.
■Due to the heat generated during charging, do not use
the product on a combustible surface.
■Do not use the product near flammable materials,
such as cloth, packaging materials, paint, spray paint
or aerosols, lubricants, thinners, petrol containers, gas
containers, or gas appliances.
■Do not cover any ventilation slots and provide adequate
ventilation during operation.
■Never modify, disassemble, or attempt to repair the
product yourself.
■Do not allow the charger or battery packs to become
contaminated with any material that could be
conductive, such as, metallic particles from grinding,
cutting, or machining processes.
■Remove the plug of the product from the power socket
when it is not in use or when cleaning it.
■Only use extension cable that is approved and in good
condition.
■Do not charge battery packs that show signs of leaks.
Dispose of them properly.
■Never charge a damaged battery pack. If damaged,
replace immediately.
■Before every use, examine the supply cord for damage.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING
To reduce the risk of re, personal injury, and product
damage due to a short circuit, never immerse your
tool, battery pack or charger in uid or allow a uid to
ow inside them. Corrosive or conductive uids, such
as seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a short
circuit.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of
disposing of as waste. The machine,
accessories and packaging should
be stored for environmentally friendly
recycling.
OPERATION
CHARGING THE BATTERY PACK
Battery packs are shipped in a low charge condition.
Therefore, you should charge them before rst use. If the
charger does not charge your battery pack under normal
circumstances, bring both the battery pack and charger to
an authorised service centre.
Make sure that the power supply is normal
household voltage, 220–240V, 50Hz, AC
only. Make sure that the battery pack latch clicks into
place and the battery pack is secured in the charger before
beginning operation.
NOTE: When the battery becomes fully charged, the green
LED remains on. The battery pack will become slightly
warm to touch while charging. This is normal and does not
indicate a problem.
Do not place the charger and battery pack in an area of
extreme heat or cold. They work best at normal room
temperature.
NOTE: The charger and battery pack should be placed in
a location where the temperature is more than 10°C but
less than 25°C.
CHARGING A COOL BATTERY PACK
1. Align the raised rib on the battery pack with the groove
in the product, and slide in the battery pack. Make sure
that the battery pack latch clicks into place.

3
2. Connect the product to a power supply.
See Fig.3
1. Disconnect the product from the power supply when the
battery pack becomes fully charged.
2. Press the battery pack latch to unlock the battery pack
from the product.
3. Slide the battery pack off the product.
CHARGING A HOT BATTERY PACK
When using a tool continuously, the cells in the battery
pack become hot. A hot battery pack should be allowed to
cool down for approximately 30 minutes before attempting
to recharge.
MAINTENANCE
■When not using or when cleaning the product,
disconnect it from the power supply and remove the
battery pack.
■Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to various types of commercial
solvents and may be damaged by their use. Use clean
cloth or soft brush to remove dirt and dust.
■Do not, at any time, let brake fluids, gasoline, petroleum-
based products, and penetrating oils come in contact
with plastic parts. They contain chemicals that can
damage, weaken, or destroy plastic.
■If you are experiencing any issues with this product
or any other RYOBI product, please contact RYOBI
Customer Service.
WARNING
Hazardous voltages are present within the product; do
not disassemble.
■If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
CLEANING THE CHARGER
WARNING
Unplug the charger power cord from power supply
before cleaning at any time to prevent serious personal
injury.
■Clean the charger surface (except labels) using a damp
cloth with a mild detergent.
■Do not use any strong detergents on the plastic housing.
They can be damaged by certain aromatic oils such as
pine and lemon, and by solvents such as kerosene.
■Moisture can cause a shock hazard. Wipe off any
moisture with a soft dry cloth.
STORAGE
Store your charger in a cool, dry place between 10°C and
38°C.

4
SPECIFICATIONS
Battery pack BPL3626D
BPL3626D2
BPL3640D
BPL3640D2
BPL3650D
BPL3650D2 BPL3660D
Type Lithium-ion
Voltage 36 V DC
Charger input 220 V–240 V,
50 Hz AC only
Charger input current 6 A
Battery pack capacity 2.6 Ah 4.0 Ah 5.0 Ah 6.0 Ah
No. of cell for battery 20 20 20 30
Maximum charging
time (BCL3660F)
62
minutes
90
minutes
115
minutes
138
minutes
Quick recharge 60%
32 minutes 50 minutes 60 minutes 74 minutes
KNOW YOUR PRODUCT
See fig.1
1. Battery port
2. LED indicator
3. Power cord
4. Key hole hanger
SYMBOLS ON THE PRODUCT
Some of the following symbols may be used on this product.
Study them and learn their meaning. Proper interpretation
of these symbols will allow you to operate the product
better and safer.
Precautions that involve your safety.
To reduce the risk of injury, user must
read and understand user’s manual
before using this product.
Regulatory Compliance Mark (RCM).
Product meets applicable regulatory
requirements.
Class II: Protection against electric
shock rely on double insulation or
reinforced insulation.
Time-lag type fuse
Indoor use only
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority or
retailer for recycling advice.
The following signal words and meanings are intended to
explain the levels of risk associated with this product.
DANGER
Indicates an imminently hazardous situation, which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION
(Without Safety Alert Symbol) Indicates a situation that
may result in property damage.
20191031v1

5
20191031v1
CHARGER LED FUNCTIONS
LED indicator Battery pack LED Action
Red Orange Green
Power on Without battery pack On Ready to charge battery pack.
Testing
Hot battery pack On When battery pack reaches cooled temperature, charger
begins fast charge mode.
Cold battery pack On When battery pack reaches warmed temperature, charger
begins fast charge mode.
Defective Defective Flashing Flashing Battery pack or charger could be defective.
●If the LED status shows defective, reset the charger or reinsert the battery.
●If the LED status repeats a second time, try charging a different battery.
●If a different battery charges normally, dispose of the defective pack (see maintenance section).See warranty sheet if the
battery is still within warranty.
●If a different battery also indicates "defective", the charger may be defective.
Charging
Fast charging Flashing —
Deeply discharged Flashing Charger pre-charges battery until normal voltage is
reached, then begins fast charge mode.
Ready — On Fast charging is complete; charger maintains charge
mode.

Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley, VIC 3149
Melbourne, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
Imported by:
960324021-01
RYOBI is a trademark of Ryobi Limited,
and is used under license.
© 2019 Techtronic Cordless GP. All rights reserved.
