Ryobi RC18240 User manual

FRONT PAGE
RC18240

IMPORTANT!
It is essential that you read the instructions in this manual
before assembling, operating, and maintaining the product.
Subject to technical modications.
Safety, performance, and dependability have been given top
priority in the design of your charger.
INTENDED USE
This charger is only intended to charge RYOBI ONE+
Lithium-Ion battery packs listed in this manual.
The product is only for use indoors in dry conditions.
The product is not intended to charge any other type of
battery, to be used as a power supply, or for any other
purpose. It should never be used in explosive or inammable
environments.
CHARGER SAFETY WARNINGS
Please read and observe these instructions before using the
product. Failure to follow these instructions and warnings
increases the risk of electric shock, fire and explosion.
WARNING! Do not charge non-rechargeable batteries
with the charger.
WARNING! Mains voltage must correspond with the
voltage specications on the product.
■This appliance is not intended to be used or cleaned
by persons with reduced physical, sensory or mental
capabilities, or lack of experience or knowledge, unless
they have been given instructions concerning the safe
use of the appliance by a person legally responsible for
their safety. They should be supervised whilst using the
appliance. Children shall not use, clean or play with this
appliance, which when not in use should be secured out
of their reach.
■Before using the product, check that the product
enclosure, cable and adaptor plug are not damaged. If
damage is found, do not use and follow instruction in the
maintenance section of this manual.
■The product must not be damp, and should never be
used in a damp environment.
■The product is for indoor use only.
■Do not use the product if it has suffered any heavy shock
or jolting, or is damaged in any other way.
■Do not conduct charging in a position which may become
exposed to sunlight or other heat source.
■Due to the heat generated during charging, the product
should not be operated on a combustible surface.
■Do not conduct charging operations in the vicinity
of flammable materials. Example: Cloth, packaging
materials, paint, spray paint or aerosols, lubricant,
thinners, petrol containers, gas containers or gas
appliances.
■Do not cover any ventilating slots and provide adequate
ventilation during operation.
■Never modify, disassemble or attempt to repair the
product yourself.
■Do not allow the charger or batteries to become
contaminated with any material which is conductive.
Example: Metal particles from grinding, cutting or
machining processes.
■Remove the plug of the product from the power socket
when it is not in use or during cleaning.
■Only use extension cable that is approved and in good
condition.
■Protect battery contacts to avoid a short circuit caused
by metallic objects which could cause a fire or explosion!
■Do not charge batteries which show signs they have
leaked electrolyte. Dispose of them properly.
■Never charge a damaged battery pack. If damaged,
replace immediately.
■If the battery is not going to be used for a while, remove
the charger plug from the power socket and take the
battery off the product.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING! To reduce the risk of re, personal injury,
and product damage due to a short circuit, never immerse
your tool, battery pack or charger in uid or allow a uid
to ow inside them. Corrosive or conductive uids, such
as seawater, certain industrial chemicals, and bleach or
bleach-containing products, etc., can cause a short circuit.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling
when transporting batteries by a third party. Ensure that
no batteries can come in contact with other batteries
or conductive materials while in transport by protecting
exposed connectors with insulating, non-conductive caps or
tape. Do not transport batteries that are cracked or leaking.
Check with the forwarding company for further advice.
OPERATION
CHARGING THE BATTERY PACK
Battery packs are shipped in a low charge condition to
prevent possible problems. Therefore, you should charge
them before rst use. If the charger does not charge your
battery pack under normal circumstances, return both the
battery pack and charger to your nearest authorised service
center for electrical check.
Do not charge nickel cadmium (NiCd) battery packs.
Make sure the power supply is normal household voltage,
220 V – 240 V, 50 Hz 105 W, AC only.
NOTE: When two battery packs are connected to the
charger, they are charged at the same time. The charging
current is equally distributed to the charging ports.
NOTE: After charging is complete, the green LED will
remain on until the battery pack is removed from the charger
or charger is disconnected from the power supply.
The battery pack will become slightly warm to the touch while
charging. This is normal and does not indicate a problem.
Do not place the charger and battery pack in an area of
extreme heat or cold. They will work best at normal room
temperature.
NOTE: The charger and battery pack should be placed in a
location where the temperature is more than 10°C but less
than 38°C.
NOTE: Remove the batteries from the charger and
disconnect the charger once charging is complete.
Do not place the charger near moist or damp areas.
CHARGING A HOT BATTERY PACK
When using a tool continuously, the batteries in the battery
pack will become hot. You should let a hot battery pack cool
down for approximately 30 minutes before attempting to
recharge it.
2
Original Instructions

CHARGE STATUS
To display the amount of charge left in the battery, press the
Charge level indicator button.
Charge level indicator
0 - 10%
0 - 25%
25 - 50%
50 - 75%
75 - 100%
MAINTENANCE
■If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
■Remove the plug of the product from the power socket
when it is not in use or when cleaning it.
■Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to various types of commercial
solvents and may be damaged by their use. Use clean
cloth or soft brush to remove dirt, dust, etc.
■Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. They contain chemicals that can
damage, weaken or destroy plastic.
WARNING! Hazardous voltages are present within this
product; do not disassemble.
■There are no user service or replacement parts inside
this product. In case of damage or failure please return
to your authorised RYOBI service centre for professional
repair.
STORAGE
■Store your charger in a cool dry place between 10 and
25°C.
■It is not recommended to leave the product in a vehicle
during hot or cold conditions. Ensure no metal filings or
swarf can fall into the vents during storage, as this may
cause serious injury when the product is next used.
SYMBOLS ON THE PRODUCT
V Volts
Direct current
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Class II equipment
Please read the instructions carefully before
starting the machine.
For indoor use only.
Time-lag fuse 3.15A
Do not dispose of waste electrical and
electronic equipment as unsorted municipal
waste.
Waste electrical and electronic equipment
must be collected separately.
Waste light sources have to be removed
from the equipment.
Check with your local authority or retailer for
recycling advice and collection point.
According to local regulations, retailers
may have an obligation to take back waste
electrical and electronic equipment free of
charge.
Your contribution to the reuse and recycling
of waste electrical and electronic equipment
helps to reduce the demand of raw materials.
Waste electrical and electronic equipment
contain valuable and recyclable materials,
which can adversely impact the environment
and the human health if not disposed of in an
environmentally compatible manner.
Delete personal data from waste equipment,
if any.
SYMBOLS IN THIS MANUAL
Safety alert
Note
Parts or accessories sold separately
Connect to the power supply.
Disconnect to the power supply.
3
Original Instructions

CHARGER LED FUNCTIONS
LED indicator Battery pack
status Red LED Green LED Action
Evaluate Hot battery pack Flashing OFF When battery pack reaches cooled temperature,
charger begins fast charge mode.
Evaluate Cold battery pack Flashing OFF When battery pack reaches warmed
temperature, charger begins fast charge mode.
Defective Defective Flashing Flashing Battery pack or charger is defective.
• If defective, try to repeat the conditions a second time by removing and reinstalling the battery pack. If the
LED status repeats a second time, try charging a different battery.
• If a different battery charges normally, dispose of the defective pack (see Maintenance section).
• If a different battery also indicates “Defective,” the charger may be defective.
Charging Fast charging OFF Flashing Battery pack is being charged.
Charging Taper charging OFF Fading Battery pack is being charged at lower rate.
Full Fully charged OFF ON Charging is complete.
COMPATIBLE BATTERY PACKS
Battery Pack Voltage Charger Input Battery type Battery Capacity Number of Cell for
Battery
RB18L15
18 V 220 - 240V
50 Hz Lithium-Ion
1.5 Ah 5
RB18L15A 1.5 Ah 5
RB18L15B 1.5 Ah 5
RB18L20 2.0 Ah 5
RB18L20A 2.0 Ah 5
RB18L25 2.5 Ah 5
RB18L25A 2.5 Ah 5
RB18L40 4.0 Ah 10
RB18L40A 4.0 Ah 10
RB18L50 5.0 Ah 10
RB18L50A 5.0 Ah 10
RB18L60A 6.0 Ah 10
RB1860X 6.0 Ah 10
RB18L90A 9.0 Ah 15
4
Original Instructions

Operator's manual
Battery port
Battery pack
Key hole hanger
114 mm
Green LED
Red LED
5
Know your product

20220622v1
21
6
Getting started

114 mm 5mm
1
2
7
Maintenance

PRODUCT SPECIFICATIONS
Charger
Model RC18240
Charger
Input 220 - 240V 50 Hz
Output 18 V
Input power 105 W max.
Charger output current 4 A max.
Weight - excluding battery pack 0.83 kg
Battery Pack
Voltage 18 V
Battery type Lithium-Ion
Operating temperature 5°C - 40°C




BACK PAGE
961014510-01
Imported by:
Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley, VIC 3149
Melbourne, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
RYOBI is a trade mark of Ryobi Limited, and is used under license.
Other manuals for RC18240
2
This manual suits for next models
1
Table of contents
Other Ryobi Batteries Charger manuals

Ryobi
Ryobi RC18627 User manual

Ryobi
Ryobi C120N User manual

Ryobi
Ryobi P131 User manual

Ryobi
Ryobi Tek4 AP4800 User manual

Ryobi
Ryobi AP4500 User manual

Ryobi
Ryobi R36CHR3P User manual

Ryobi
Ryobi PCG004 User manual

Ryobi
Ryobi BCS618 Assembly instructions

Ryobi
Ryobi BCL-1800 Operation manual

Ryobi
Ryobi RC18115 User manual

Ryobi
Ryobi BCS618 User manual

Ryobi
Ryobi EVERCHARGE P180TH User manual

Ryobi
Ryobi RC18150-250 User manual

Ryobi
Ryobi RC18150 User manual

Ryobi
Ryobi C121D User manual

Ryobi
Ryobi 260111130 Operation manual

Ryobi
Ryobi OP407 User manual

Ryobi
Ryobi AM00180 User manual

Ryobi
Ryobi C123L User manual

Ryobi
Ryobi RC18115 User manual
