RYOBI
18 Volt Jig Saw
Model No. P521
Repair Sheet

RYOBI 18 VOLT JIG SAW – MODEL NUMBER P521
2
1
2
3
4
5
6
7
911
10
10
53
46
54
52
55
56
12
12
13
14
15
17
18
19
20
21
24 25
26
28
27
29
30
31
32
3334
35
36
37
38
39
40
41
42
43
44
45
16
47
48
49
50
51
22
23
8

RYOBI 18 VOLT JIG SAW – MODEL NUMBER P521
3
KEY PART
NO. NUMBER DESCRIPTION QTY.
PARTS LIST
1 660302002 Screw (10-24 x 1/2 in.)..................2
2 630847003 Clamp Plate ..................................1
3 550432001 Rubber Tube .................................1
4 631737001 Base..............................................1
5 660302001 Screw (10-24 x 3/8 in.)..................1
6 550424002 Detent Button ...............................1
7 680909001 Spring ...........................................1
8 514042001 Orbital Knob .................................1
9 680910004 Rod ...............................................1
10 200202473 Housing Assembly........................1
11 514047001 Blade Door....................................1
12 660439002 Screw (M4 x 8 mm).......................2
13 680906003 Pin.................................................1
14 300577025 Blade Guide Assembly .................1
15 630848002 Strip Nut .......................................1
16 660944001 Laser Adjust Nut...........................1
17 671363001 Spring For Adjust Laser................2
18 660126001 Nut (M4 x 2.3 Mm, Square) ..........1
19 570653002 Rubber Cover ...............................1
20 760270004 Switch (For Laser Control) ............1
21 300549056 Laser Assembly ............................1
22 513433001 Laser Holder .................................1
23 681046002 Metal Wire (Blade Guard)..............1
24 630849001 Return Spring ...............................1
25 630845003 Slide Guide Plate..........................1
26 301007004 Quick Clamp Blade Assembly......1
27 300019002 Bushing Assembly w/Bearing.......1
28 220016102 Gear Assembly ............................1
29 630843002 Drive Plate ....................................1
30 630844001 Washer..........................................1
The model number will be found on a label attached to the motor housing. Always mention the model
number in all correspondence regarding your JIG SAW or when ordering repair parts.
31 671112001 Sleeve ...........................................1
32 300477004 Bearing Block
Assembly w/Bearing.....................1
33 660212001 Screw (M4 x 6 mm).......................2
34 6703001 Spring Washer ..............................2
35 630193002 Mounting Plate .............................1
36 610377002 Pinion............................................1
37 740527001 Motor ............................................1
38 570263001 Rubber Cushion............................1
39 570264001 Rubber Cushion............................1
40 270001122 Switch Assembly ..........................1
41 6620805 Screw (M4 x 16 mm)...................11
42 660203004 Screw (M3 x 16 mm).....................1
43 300306017 Heat Sink Assembly .....................1
44 514045001 Safety Button................................1
45 670998004 Spring ...........................................1
46 940230135 Laser Warning Label (Spanish).....1
47 680907001 Hex Key (1/8 in.) ...........................1
48 681070001 Hex Key (5/64 in.) .........................1
49 690227036 Cut-Metal Blade ...........................1
50 690227035 Cut-Wood Blade ...........................1
51 200292003 Plug In Lanyard.............................1
52 940054127 Logo Label....................................1
53 940055122 Data Label ....................................1
54 940214110 Laser Data Label...........................1
55 940230134 Laser Warning Label (English) ......1
56 940230133 Laser Warning Label (French).......1
983000935 Operator’s Manual (960001247)
6-7-12
(REV:01)
KEY PART
NO. NUMBER DESCRIPTION QTY.

RYOBI 18 VOLT JIG SAW – MODEL NUMBER P521
4
SWITCH
MOTOR
RED
LEAD
YELLOW
LEAD
BLUE LEAD
BLACK LEAD
WIRING DIAGRAM
BLACK LEAD
RED LEAD BLACK
LEAD
BLACK LEAD
BLACK
LEAD
RED LEAD
RED
LEAD
LASER
CONTACT
PLATE HOLDER
RED LEAD
