Saft STM 5-100 Owner's manual

Technical manual
installation, operation and maintenance
for Ni-Cd STM MR-MRE monoblocks type

Introduction 1
Important recommendations 2
1. Characteristics of STM MR-MRE monoblocks
1.1. General description 3
1.1.1. Operation principle of vented Ni-Cd cells 3
1.1.2. Description of STM MR-MRE Ni-Cd monoblocks 4
1.2. Mechanical characteristics 5
1.3. Electrical characteristics 5
1.4. Description of the centralized filling system 6
1.4.1. General description 6
1.4.2. Working principle of a centralized filling ramp 7
2. Precautions and practices
2.1. Transport, storage 8
2.2. Water and electrolyte 8
2.2.1. Water quality 8
2.2.2. Harm caused in using sulfuric acid or
acidic water 8
2.3. Electrical shocks and burns 9
2.4. Possible dangers of hydrogen 9
3. Installation
3.1. Assembly into batteries 10
3.2. Ventilation and cooling 11
3.3. Assembly of centralized water filling system 11
3.3.1. Precautions and recommendations 11
3.3.2. General instructions for assembly 12
Contents

4. Placing into service
4.1. Procedure before use 13
4.2. Commissioning cycle and water topping-up 13
5. Operation
5.1. Operating temperature 14
5.2. Two-level charge 14
5.2.1. Normal charge 14
5.2.2. Fast charge 14
5.2.3. Maintenance charge 14
5.2.4. Recommended charging method 15
5.3. Discharge 17
5.3.1. Discharge current 17
5.3.2. Voltage in discharge 17
6. Maintenance
6.1. Periodic maintenance 18
6.2. Topping-up operation 18
7. Repair and overhaul of batteries
7.1. Electrolyte specific density 19
7.2. Reconditioning 19
Appendix 1 STM 5-100 MR G RD equipped 20
Appendix 2 STM 5-100 MRE G RD equipped 21
Appendix 3 STM 5-140 MR G RD equipped 22
Appendix 4 STM 5-140 MR D RG equipped 23
Appendix 5 Accessories for the central filling system 24
Appendix 6 Basic specification for filling circuit hoses 25
Appendix 7 Basic specification for the cooling system hoses 26
Appendix 8 Basic specification for rigid connections 27
Appendix 9 Basic specification for distilled
or demineralized water 28

This manual is intended for users,
technical and maintenance
personnel.
It contains the main characteristics
of the low maintenance Saft Ni-Cd
STM MR-MRE monoblocks.
It provides guidelines for use
and maintenance to obtain the
best performance and a long
useful life.
The instructions are of general
validity for batteries in Electric
Vehicles.
Nevertheless, every vehicle will
have a specific battery that has
been adapted to its own
mechanical, electrical, thermal,
and other characteristics.
Depending on the referenced
model, specific instructions might
be added to this document.
For uses other than the ones
described in this manual,
contact Saft.
Introduction
1

!Install the battery such as to
ensure good ventilation.
!Never allow a flame or fire to
come near the battery.
!The electrolyte is harmful to
the skin and particularly to
the eyes. In the event of
contact with eyes, wash
immediately with running
water and/or with a 10 %
solution of boric acid.
!Wear base-resistant gloves
and goggles to manipulate
the electrolyte.
!Never use sulfuric acid or
acidified water to top-up
electrolyte, as acid, even in
traces, destroys the battery.
!Use tools with insulated handles.
!When batteries or vehicles
equipped with STM MR-MRE
batteries are operated in
closed premises, natural or
forced ventilation is necessary.
Always respect the applicable
safety codes and regulations
of the country of operation.
Important recommendations
2
