Samson 3731-5 Service manual

Translation of original instructions
EB 8387-5 EN
Firmware version 1.63
Edition November 2018
Type3731-5 Electropneumatic Ex d Positioner
With FOUNDATION™ eldbus communication
EB + CD

Note on these mounting and operating instructions
These mounting and operating instructions assist you in mounting and operating the device
safely. The instructions are binding for handling SAMSON devices.
ÎFor the safe and proper use of these instructions, read them carefully and keep them for
later reference.
ÎIf you have any questions about these instructions, contact SAMSON‘s After-sales Service
Department (aftersalesser[email protected]).
The mounting and operating instructions for the devices are included in
the scope of delivery. The latest documentation is available on our website
at www.samson.de > Service & Support > Downloads > Documentation.
Denition of signal words
Hazardous situations which, if not avoided,
will result in death or serious injury
Hazardous situations which, if not avoided,
could result in death or serious injury
Property damage message or malfunction
Additional information
Recommended action
DANGER
!
WARNING
!
NOTICE
!
Note
Tip
2 EB 8387-5 EN

Contents
EB 8387-5 EN 3
1 Safety instructions and measures ...................................................................6
1.1 Notes on possible severe personal injury .........................................................9
1.2 Notes on possible personal injury ...................................................................9
1.3 Notes on possible property damage..............................................................10
2 Markings on the device ...............................................................................11
2.1 Nameplate..................................................................................................11
2.2 Article code.................................................................................................12
2.3 Firmware versions........................................................................................13
3 Design and principle of operation ................................................................14
3.1 Additional equipment...................................................................................16
3.2 Communication ...........................................................................................16
3.2.1 Conguration using the TROVIS-VIEW software .............................................16
3.3 Accessories .................................................................................................17
3.4 Travel tables ................................................................................................20
3.5 Technical data .............................................................................................21
3.6 Dimensions in mm........................................................................................25
3.7 Fixing levels according to VDI/VDE3845 (September 2010) ..........................26
4 Measures for preparation............................................................................27
4.1 Unpacking ..................................................................................................27
4.2 Transporting ................................................................................................27
4.3 Storage.......................................................................................................27
5 Mounting and start-up.................................................................................28
5.1 Mounting position........................................................................................28
5.2 Lever and pin position..................................................................................28
5.3 Type 3277-5 Actuator..................................................................................30
5.4 Type 3277 Actuator .....................................................................................32
5.5 Attachment according to IEC 60534-6 (NAMUR) ...........................................34
5.6 Attachment to Type3510 Micro-ow Valve....................................................36
5.7 Attachment to rotary actuators ......................................................................38
5.8 Reversing amplier for double-acting actuators ..............................................40
5.8.1 Reversing amplier (1079-1118 or 1079-1119)............................................42
5.9 Pneumatic connections..................................................................................43
5.10 Connecting the supply air.............................................................................43
5.10.1 Signal pressure connection ...........................................................................43
5.10.2 Signal pressure gauges ................................................................................44
5.10.3 Supply pressure ...........................................................................................44
5.10.4 Signal pressure (output)................................................................................44

Contents
4 EB 8387-5 EN
5.11 Electrical connections ...................................................................................45
5.11.1 Connect the electrical power.........................................................................46
5.11.2 Establishing communication..........................................................................47
6 Operating controls and readings..................................................................49
6.1 Rotary pushbutton........................................................................................49
6.2 Serial interface ............................................................................................49
6.3 Reading ......................................................................................................50
7 Operating the positioner..............................................................................52
7.1 Adapting the display direction ......................................................................52
7.2 Limiting the signal pressure...........................................................................53
7.3 Checking the operating range of the positioner ..............................................54
7.4 Determining the fail-safe position ..................................................................55
7.5 Initializing the positioner ..............................................................................56
7.5.1 Initialization based on maximum range (MAX)...............................................58
7.5.2 Initialization based on nominal range (NOM) ................................................59
7.5.3 Initialization based on a manually selected range (MAN)................................61
7.5.4 Substitute calibration (SUB)...........................................................................63
7.6 Zero calibration ...........................................................................................68
7.7 Reset to default settings.................................................................................70
8 Operation...................................................................................................72
8.1 Enabling and selecting parameters................................................................72
8.2 Operating modes.........................................................................................73
8.2.1 Automatic (AUTO) and manual (MAN) modes ...............................................73
8.2.2 Fail-safe position (SAFE)...............................................................................75
8.3 Fault/malfunction.........................................................................................75
8.3.1 Conrming error messages...........................................................................77
9 Servicing.....................................................................................................78
9.1 Preparation for return shipment.....................................................................78
10 Malfunctions ...............................................................................................79
10.1 Emergency action ........................................................................................79
11 Decommissioning and removal ....................................................................79
11.1 Decommissioning.........................................................................................79
11.2 Removing the positioner ...............................................................................80
11.3 Disposal......................................................................................................80

Contents
EB 8387-5 EN 5
12 Appendix....................................................................................................80
12.1 After-sales service........................................................................................80
12.2 Certicates ..................................................................................................80
12.3 Code list......................................................................................................81
12.4 Error codes..................................................................................................93
12.5 Select characteristic....................................................................................100
The functions of the EXPERTplus Valve Diagnostics are described in the Operating
Instructions uEB8389. EB8389 is included on the enclosed CD-ROM and is available
on our website.
Note

6 EB 8387-5 EN
Safety instructions and measures
1 Safety instructions and measures
Intended use
SAMSON's Type3731-5 Positioner is mounted on pneumatic control valves and is used to
assign the valve position to the control signal. The device is designed to operate under exact-
ly dened conditions (e.g. operating pressure, temperature). Therefore, operators must en-
sure that the positioner is only used in applications where the operating conditions corre-
spond to the technical data. In case operators intend to use the positioner in other applica-
tions or conditions than specied, contact SAMSON.
SAMSON does not assume any liability for damage resulting from the failure to use the de-
vice for its intended purpose or for damage caused by external forces or any other external
factors.
ÎRefer to the technical data for limits and elds of application as well as possible uses.
Reasonably foreseeable misuse
The Type3731-5 Positioner is not suitable for the following applications:
−Use outside the limits dened during sizing and by the technical data
Furthermore, the following activities do not comply with the intended use:
−Use of non-original spare parts
−Performing maintenance activities not specied by SAMSON
Qualications of operating personnel
The positioner must be mounted, started up and serviced by fully trained and qualied per-
sonnel only; the accepted industry codes and practices are to be observed. According to
these mounting and operating instructions, trained personnel refers to individuals who are
able to judge the work they are assigned to and recognize possible hazards due to their spe-
cialized training, their knowledge and experience as well as their knowledge of the applica-
ble standards.
The explosion-protected versions of the Type3731-5 Positioner are to be handles only by
personnel who has undergone special training or instructions or who is authorized to work
on explosion-protected devices in hazardous areas.

EB 8387-5 EN 7
Safety instructions and measures
Personal protective equipment
No personal protective equipment is required for the direct handling of the positioner. Work
on the control valve may be necessary when mounting or removing the device.
ÎObserve the requirements for personal protective equipment specied in the valve docu-
mentation.
ÎCheck with the plant operator for details on further protective equipment.
Revisions and other modications
Revisions, conversions or other modications of the product are not authorized by SAMSON.
They are performed at the user's own risk and may lead to safety hazards, for example. Fur-
thermore, the product may no longer meet the requirements for its intended use.
Safety features
Upon failure of the air supply, the positioner vents the actuator, causing the valve to move to
the fail-safe position determined by the actuator.
Warning against residual hazards
The positioner has direct inuence on the control valve. To avoid personal injury or property
damage, plant operators and operating personnel must prevent hazards that could be
caused in the control valve by the process medium, the operating pressure, the signal pres-
sure or by moving parts by taking appropriate precautions. They must observe all hazard
statements, warning and caution notes in these mounting and operating instructions, espe-
cially for installation, start-up and service work.
If inadmissible motions or forces are produced in the pneumatic actuator as a result of the
supply pressure, it must be restricted using a suitable supply pressure reducing station.
Responsibilities of the operator
The operator is responsible for proper operation and compliance with the safety regulations.
Operators are obliged to provide these mounting and operating instructions to the operating
personnel and to instruct them in proper operation. Furthermore, the operator must ensure
that operating personnel or third persons are not exposed to any danger.
Responsibilities of operating personnel
Operating personnel must read and understand these mounting and operating instructions as
well as the specied hazard statements, warning and caution notes. Furthermore, the operat-
ing personnel must be familiar with the applicable health, safety and accident prevention
regulations and comply with them.

8 EB 8387-5 EN
Safety instructions and measures
Servicing explosion-protected devices
If a part of the device on which the explosion protection is based needs to be serviced, the
device must not be put back into operation until a qualied inspector has assessed it accord-
ing to explosion protection requirements, has issued an inspection certicate or given the de-
vice a mark of conformity. Inspection by a qualied inspector is not required if the manufac-
turer performs a routine test on the device before putting it back into operation. Document
the passing of the routine test by attaching a mark of conformity to the device.
Referenced standards and regulations
The device with a CE marking fullls the requirements of the Directives 2014/30/EU and
2011/65/EU as well as 2014/34/EU depending on the version (Type3731-521). The dec-
larations of conformity are included at the end of these instructions.
Referenced documentation
The following documents apply in addition to these mounting and operating instructions:
−Operating instructions of EXPERTplus Valve Diagnostics uEB 8389
−The mounting and operating instructions of the components on which the positioner is
mounted (valve, actuator, valve accessories etc.).

EB 8387-5 EN 9
Safety instructions and measures
1.1 Notes on possible severe personal injury
DANGER
!
Risk of fatal injury due to the formation of an explosive atmosphere.
Incorrect installation, operation or maintenance of the positioner in potentially explosive
atmospheres may lead to ignition of the atmosphere and cause death.
ÎThe following regulations apply to installation in hazardous areas: EN60079-14
(VDE0165, Part1).
ÎInstallation, operation or maintenance of the positioner must only performed by per-
sonnel who has undergone special training or instructions or who is authorized to
work on explosion-protected devices in hazardous areas.
1.2 Notes on possible personal injury
WARNING
!
Risk of personal injury due to moving parts on the valve.
During initialization of the positioner and during operation, the actuator stem moves
through its entire travel range. Injury to hands or ngers is possible if they are inserted
into the valve.
ÎDuring initialization, do not insert hands or ngers into the valve yoke and do not
touch any moving valve parts.

10 EB 8387-5 EN
Safety instructions and measures
1.3 Notes on possible property damage
NOTICE
!
Risk of damage to the positioner due to incorrect mounting position.
ÎDo not mount the positioner with the back of the device facing upward.
ÎDo not seal or restrict the vent opening when the device is installed on site.
Risk of malfunction due to incorrect sequence during start-up.
The positioner can only work properly if the mounting and start-up are performed in the
prescribed sequence.
ÎPerform mounting and start-up as described in section5.
An incorrect electric signal will damage the positioner.
The positioner is powered over the bus line.
ÎOnly use a current source and never a voltage source.
Incorrect assignment of the terminals will damage the positioner and will lead to mal-
function.
For the positioner to function properly, the prescribed terminal assignment must be ob-
served.
ÎConnect the electrical wiring according to the prescribed terminal assignment.
Malfunction due to initialization not yet completed.
The initialization causes the positioner to be adapted to the mounting situation. After ini-
tialization is completed, the positioner is ready to use.
ÎInitialize the positioner on the rst start-up.
ÎRe-initialize positioner after changing the mounting position.
Risk of positioner damage due to incorrect grounding of the electric welding
equipment.
ÎDo not ground electric welding equipment near to the positioner.

EB 8387-5 EN 11
Markings on the device
2 Markings on the device
2.1 Nameplate
* See technical data and explosion-protection certificate for
permissible ambient temperature and maximum values.
4
SAMSON 3731- 5
FOUNDATION ™ Fieldbus Positioner
SAMSON AG D-60314 Frankfur
tM
ade in Germany
56
Firmware
Var.-ID
10
Serial no.
9
1
Communication Profile Class:
Physical Layer Class:
Supply max.
Fieldbus *
0044
Option:
Output -NPT- Supply
A -
B -
C -
2
3
6
6
7
Model 3731-5 8
6
1Communication prole
2Physical layer
3Max. supply pressure
4Type of protection
5Optional additional equipment
6Details on the electrical connection for
optional additional equipment
7 Firmware version
8Model no.
9Conguration ID
10 Serial number
The nameplate layout may vary depending on the certication.
Note

12 EB 8387-5 EN
Safety instructions and measures
2.2 Article code
Positioner Type3731- 5x x x x x x 0 0 0 x 1 x 0 0 0
With LCD and autotune, FOUNDATIONTM
eldbus
Explosion protection
ATEX:
II 2G Ex db IIC T6 Gb, II 2G Ex db eb IIC T6 Gb;
II 2G Ex db [ia Ga] IIC T6 Gb;
II 2G Ex ia IIC T6 Ga;
II 2D Ex tb IIIC T80°C DB IP66
2 1
FM/CSA:
Class I, Div. 1+2, Groups B, C, D;
Class I, Zone 1, Groups IIB+H2;
Class I, Div. 1+2 Groups E, F, G; Class III/
Class I, Zone 1, Group IIB+H2 T4...T6;
Class I, Div. 1+2, Groups B, C, D T4...T6;
Class II, Div. 1, Groups E, F, G
2 3
JIS: Exd IIC T6 2 7
Option (additional equipment)
Without 0 0
Binary input 0 3
Forced venting 0 5
Diagnostics
EXPERTplus for control valves 4
Electrical threaded connections
2x M20x1.5 1
2x ½ NPT 2
Explosion protection certicate
As specied in Table11 0
IECEx:
Exd IIC T6, T5, T4 Gb;
Exd e IIC T6, T5, T4 Gb;
Ex tb IIIC T80°C Db IP66
2 1
2
GOST:
1Exd IIC T6/T5/T4 Gb X;
1Exd e IIC T6/T5/T4 Gb X;
Ex tb IIIC T80°C Db X
2 1 3

EB 8387-5 EN 13
Safety instructions and measures
Special applications
Without 0
Version compatible with paint (IP41/NEMA1) 1
Special version
Without 000
2.3 Firmware versions
Communication
Firmware Revisions
K 3.01 • Certied according to ITK6.2.0
• Diagnostics specication according to FF-912
• Additional function blocks: AI (Analog Input), 2x DO (Digital Output)
K 3.04 • Optimized readout of PST and PST graphics over the FF communication network
• Stabilized transmission of the initialization status
Control
Firmware Revisions
R 1.62 The positioner moves more quickly to closed-loop operation due to an improved start-
up routine.
R 1.63 Adapted to the new communication rmware K3.04

14 EB 8387-5 EN
Design and principle of operation
3 Design and principle of oper-
ation
ÎRefer to Fig.1
The electropneumatic Exd positioner is
mounted on pneumatic control valves and is
used to assign the valve position (controlled
variable x) to the control signal (set point w).
The positioner compares the electric control
signal of a control system to the travel or ro-
tational angle of the control valve and issues
a signal pressure (output variabley) for the
pneumatic actuator.
The positioner consists of an electric travel
sensor system (2), an analog i/p converter
(6) with a downstream air capacity booster
(7) and the electronics with microcontroller
(5).
When a set point deviation occurs, the
actuator is either vented or lled with air. The
signal pressure supplied to the actuator can
be limited by software or on site to 1.4, 2.4
or 3.7bar. The xed ow regulator (9)
ensures a constant air ow to the
atmosphere, which is used to ush the inside
of the positioner housing and to optimize the
air capacity booster (7). The i/p converter
(6) is supplied with a constant upstream
pressure by the pressure regulator (8) to
compensate for any uctuations in the supply
pressure.
All parts are enclosed in an Exd enclosure.
The electrical connection is established over
a separate terminal compartment also with
Exd protection.
The extended EXPERTplus diagnostics are
integrated into the positioner. They provide
information on the positioner and generate
diagnostic and status messages, which allow
faults to be pinpointed quickly.
The positioner is suitable for the following
types of attachment using the corresponding
accessories:
−Direct attachment to SAMSON
Type3277-5 Actuator:
ÎSee section 5.3
−Direct attachment to SAMSON
Type3277 Actuator:
ÎSee section 5.4
−Attachment to actuators according to
IEC60534-6 (NAMUR):
ÎSee section 5.5
−Attachment to Type3510 Micro-ow
Valve:
ÎSee section 5.6
−Attachment to rotary actuators according
to VDI/VDE3845:
ÎSee section 5.7

EB 8387-5 EN 15
Design and principle of operation
%
S
mm
%
mm
w
x
G
PD
Serial
Interface 16
22
20 23
2
4
17
519
3
6
7
81
9
x
y
Ex d enclosure
1Control valve
2Travel sensor
3PD controller
4Interface module (IEC-61158-2)
5Microcontroller
6i/p converter
7Air capacity booster
8Pressure regulator
9Flow regulator
16 Display
17 Actuation of forced venting (optional)
19 D/A converter
20 Serial interface (SSP)
22 Rotary pushbutton
23 Binary input (optional)
FOUNDATION™eldbus
IEC 61158-2
Fig.1: Circuit diagram of Type3731-3 Ex d Positioner

16 EB 8387-5 EN
Design and principle of operation
3.1 Additional equipment
Forced venting
The i/p converter is de-energized when no
operating voltage is applied to the corre-
sponding terminals. The positioner can no
longer operate and the control valve moves
to the fail-safe position (SAFE) determined
by the actuator, regardless of the set point.
Binary input
Positioners can be optionally tted with a bi-
nary input.
−Connection to terminals A-B:
The binary input for DC voltage signals
allows process information to be ex-
changed over the FOUNDATION™ eld-
bus network.
−Connection to terminals B-C:
Input to connect a oating contact pow-
ered by the positioner. The switching
state of the binary input can be indicated
over the FOUNDATION™eldbus net-
work.
3.2 Communication
The positioner is controlled completely by
digital signal transmission according to
FOUNDATION™ eldbus specication.
Data are transmitted over the bus using digi-
tal, bit-synchronous Manchester coding at a
Baud rate of 31.25kbit/s over twisted-pair
wires according to IEC61158-2.
3.2.1 Conguration using the
TROVIS-VIEW software
The positioner can be congured with
SAMSON's TROVIS-VIEW Software. For this
purpose, the positioner has a digital
interface (SSP) to allow the USB port of a
computer to be connected to it using an
adapter cable. The TROVIS-VIEW software
enables the user to easily congure the
positioner as well as view process
parameters online.
TROVIS-VIEW can be downloaded free of
charge from our website at uwww.samson.
de > SERVICE & SUPPORT > Downloads >
TROVIS-VIEW.
Note

EB 8387-5 EN 17
Design and principle of operation
3.3 Accessories
Table1: Direct attachment to Type3277-5 (section5.3)
Mounting parts Order no.
Standard version for actuators 120cm² or smaller 1400-7452
Version compatible with paint for actuators 120cm² or smaller 1402-0940
Accessories for actuator Order no.
Old switchover plate for Type 3277-5xxxxxx.00 Actuator (old) 1400-6819
New switchover plate for Type 3277-5xxxxxx.01 Actuator (new) 1) 1400-6822
New connecting plate for Type3277-5xxxxxx.01 Actuator (new) 1) G
1
/
8
and
1
/
8
NPT 1400-6823
Old connecting plate for Type 3277-5xxxxxx.00 Actuator (old) G
1
/
8
1400-6820
Old connecting plate for Type 3277-5xxxxxx.00 Actuator (old)
1
/
8
NPT 1400-6821
Accessories for positioner Order no.
Connecting plate (6) G¼1400-7461
Pressure gauge bracket (7) G¼1400-7458
¼NPT 1400-7459
Pressure gauge mounting kit (8) up to max. 6 bar (output/supply) Stainless steel/brass 1402-0938
Stainless steel/stainless steel 1402-0939
1) Only new switchover and connecting plates can be used with new actuators (Index 01). Old and new plates are not
interchangeable.
Table2: Direct attachment to Type3277 (section5.4)
Mounting parts Order no.
Standard version for actuators 175, 240, 350, 355, 700, 750cm² 1400-7453
Connection block with seals and screw G¼ 1400-8819
¼NPT 1402-0901
Pressure gauge mounting kit up to max. 6 bar (output/supply) Stainless steel/brass 1402-0938
Stainless steel/stainless steel 1402-0939
Piping with screw ttings1) Order no.
Actuator (175cm²), steel G¼/G
3
/
8
1402-0970
¼NPT/
3
/
8
NPT 1402-0976
Actuator (175cm²), stainless steel G¼/G
3
/
8
1402-0971
¼NPT/
3
/
8
NPT 1402-0978
Actuator (240cm²), steel G¼/G
3
/
8
1400-6444
¼NPT/
3
/
8
NPT 1402-0911
Actuator (240cm²), stainless steel G¼/G
3
/
8
1400-6445
¼NPT/
3
/
8
NPT 1402-0912

18 EB 8387-5 EN
Design and principle of operation
Actuator (350cm²), steel G¼/G
3
/
8
1400-6446
¼NPT/
3
/
8
NPT 1402-0913
Actuator (350cm²), stainless steel G¼/G
3
/
8
1400-6447
¼NPT/
3
/
8
NPT 1402-0914
Actuator (355cm²), steel G¼/G
3
/
8
1402-0972
¼NPT/
3
/
8
NPT 1402-0979
Actuator (355cm²), stainless steel G¼/G
3
/
8
1402-0973
¼NPT/
3
/
8
NPT 1402-0980
Actuator (700cm²), steel G¼/G
3
/
8
1400-6448
¼NPT/
3
/
8
NPT 1402-0915
Actuator (700cm²), stainless steel G¼/G
3
/
8
1400-6449
¼NPT/
3
/
8
NPT 1402-0916
Actuator (750cm²), steel G¼/G
3
/
8
1402-0974
¼NPT/
3
/
8
NPT 1402-0981
Actuator (750cm²), stainless steel G¼/G
3
/
8
1402-0975
¼NPT/
3
/
8
NPT 1402-0982
1) For "actuator stem retracts" direction of action;
with air purging of the top diaphragm chamber;
air purging of the diaphragm chamber for "actuator stem extends" direction of action
Table3: Attachment according to IEC60534-6 1) (see section5.5)
Travel in
mm Lever For actuator Order no.
7.5 S Type 3271-5 with 60/120 cm² on Type3510 Micro-ow Valve 1402-0478
5 to 50 M1) Actuators from other manufacturers and Type3271 (120 to 700 cm² areas) 1400-7454
14 to 100 L Actuators from other manufacturers and Type 3271 (1000 and 1400-60cm²) 1400-7455
30 or 60 L
Type3271, 1400-120 and 2800cm² versions with 30/60mm travel 1400-7466
Mounting brackets for Emerson and Masoneilan linear actuators (in addition, a
mounting kit according to IEC60534-6 is required depending on the travel). See
rows above.
1400-6771
Valtek Type25/50 1400-9554
40 to 200 XL Actuators from other manufacturers and Type 3271 with 1400-120 and
2800cm² and with 120mm travel 1400-7456
Accessories Order no.
Connecting plate G¼1400-7461
Pressure gauge bracket G¼1400-7458
¼NPT 1400-7459
Pressure gauge mounting kit up to max. 6 bar (output/supply) Stainless steel/brass 1402-0938
Stainless steel/stainless steel 1402-0939
1) M lever is mounted on basic device (included in the scope of delivery)

EB 8387-5 EN 19
Design and principle of operation
Table4: Attachment to rotary actuators (section 5.7)
Mounting parts/accessories Order no.
Attachment acc. to VDI/VDE 3845 (September 2010), see section3.7 for details
Size AA1 to AA4, heavy-duty version 1400-9244
Size AA5, heavy-duty version (e.g. Air Torque 10 000) 1400-9542
Bracket surface corresponds to xing level 2, heavy-duty version 1400-9526
Attachment to SAMSON Type3278 with 160cm² and to VETEC TypeS160, Type R and Type M,
heavy-duty version 1400-9245
Attachment to SAMSON Type3278 with 320cm² and to VETEC TypeS320, heavy-duty version 1400-5891
and
1400-9526
Attachment to Camex II 1400-9120
Accessories
Connecting plate G¼1400-7461
Pressure gauge bracket G¼1400-7458
¼NPT 1400-7459
Pressure gauge mounting kit up to max. 6 bar (output/
supply)
Stainless steel/brass 1402-0938
Stainless steel/stainless steel 1402-0939
Table5: General accessories
Designation Order no.
Reversing amplier for double-acting actuators Type3710
Signal pressure restrictions (screw restriction (item no.0390-1424) and s restriction (item no.0390-
1423)) 1400-6964
Serial interface adapter (SAMSON SSP interface to RS-232 port on a computer) 1400-7700
Isolated USB interface adapter (SAMSON SSP interface to USB port on a computer) in-
cluding TROVIS-VIEW CD-ROM 1400-9740
Table6: Accessories for electrical connection
Mounting parts Order no.
Plastic cable gland M20x1.5, black (Exe) 8808-0178
Blanking plug, Exde, stainless steel
(certication CENELEC, CSA, GOST, IECEx)
M20x1.5 8323-1203
½NPT 8323-1204
Cable entry for non-armored cable (Exe, Exd, ExtD A21)
(certication CENELEC, IECEx)
M20x1.5 8808-0200
½NPT 8808-2010

20 EB 8387-5 EN
Design and principle of operation
3.4 Travel tables
The Mlever is included in the scope of delivery.
S, L, XL levers for attachment according to IEC60534-6 (NAMUR) are available as
accessories (see 18 on pageTable3).
Table7: Direct attachment to Type3277 Actuator (see section5.4)
Actuator size Rated travel Adjustment range at positioner 1) Required
lever
Assigned pin
position[cm²] [mm] Travel [mm]
120 7.5 5.0 to 25.0 M25
120/175/240/350 15 7.0 to 35.0 M35
355/700/750 30 10.0 to 50.0 M50
Table8: Attachment according to IEC60534-6 (see section5.5)
SAMSON valves with Type3271
Actuator
Adjustment range at positioner 1)
Other control valves
Required
lever
Assigned pin
position
Actuator size Rated travel Min. travel Max. travel
[cm²] [mm] [mm] [mm]
120 7.5 5.0 25.0 M25
120/175/240/350 15 7.0 35.0 M35
355/700/750 7.5
355/700/750 15 and 30 10.0 50.0 M50
1000/1400/2800 30 14.0 70.0 L 70
60 20.0 100.0 L 100
1400/2800 120 40.0 200.0 XL 200
See manufacturer's
specications 200 See manufacturer's specications 300
Table9: Attachment to rotary actuators (section 5.7)
Opening angle Required lever Assigned pin position
24 to 100° M90°
1) Values are based on NOM initialization
Note
