Samsung OFFICESERV 100 Series User manual

GABD-000100
Ed. 00
OfficeServ 100
Installation Manual
10. 2004.

COPYRIGHT
This manual is proprietary to SAMSUNG Electronics Co., Ltd. and is protected by copyright.
No information contained herein may be copied, translated, transcribed or duplicated for any commercial
purposes or disclosed to third parties in any form without the prior written consent of SAMSUNG Electronics
Co., Ltd.


TRADEMARKS
is the trademark of SAMSUNG Electronics Co., Ltd.
Product names mentioned in this document may be trademarks and/or registered trademarks of their
respective companies.
This manual should be read before the installation and operation, and the operator should correctly install
and operate the product by using this manual.

This manual may be changed for the system improvement, standardization and other technical reasons without prior
notice. 
For further information on the updated manual or have a question for the content of manual, contact the address or
homepage below.
Address: Document Center 2nd Floor IT Center. Dong-Suwon P.O. Box 105, 416, Maetan-3dong Yeongtong-gu,
Suwon-si, Gyeonggi-do, Korea 442-600
Homepage: http://www.samsungdocs.com
©2004 SAMSUNG Electronics Co., Ltd. All rights reserved.

OfficeServ 100 Installation Manual
© SAMSUNG Electronics Co., Ltd. I
INTRODUCTION
Purpose
OfficeServ 100, Enterprise IP Solutions System, is a digital telephone system designed for
small to medium-sized businesses.
This manual provides the information about installation of the Samsung OfficeServ 100,
including information about connecting the equipments. When there are questions about
OfficeServ 100 system or damage to the phone, please call your Authorized Samsung
Reseller.
Document Content and Organization
This manual is composed of 10 Chapters and 1 Annex. Each chapter is introduced as follows:
CHAPTER 1. Site Requirement
This chapter describes site requirements for OfficeServ 100 system installation.
CHAPTER 2. Installing Basic KSU and Expansion Cabinet
This chapter describes how to install the OfficeServ 100 Key System Unit and expansion
cabinet.
CHAPTER 3. Installing Printed Circuit Cards
This chapter describes how to install each card of OfficeServ 100 system.
CHAPTER 4. Power Up Procedures
This chapter describes power up procedures of OfficeServ 100 system.
CHAPTER 5. Connecting Trunk Line Circuit
This chapter describes how to connect CO(Trunk Line) circuit.
CHAPTER 6. Connecting Station Equipment
This chapter describes how to connect station equipments to the OfficeServ 100 system.
CHAPTER 7. Connecting Optional Equipment
This chapter describes how to connect optional equipments to the OfficeServ 100 system.

INTRODUCTION
II © SAMSUNG Electronics Co., Ltd.
CHAPTER 8. Installing KDB (Keyset Daughter Board)
This chapter describes how to install the KDB(Keyset Daughter Board) to the phone.
CHAPTER 9. Changing Software
This chapter describes how to change software of OfficeServ 100 system.
CHAPTER 10 Networking Description and Programming Procedure
This chapter describes networking description and programming procedure of OfficeServ
100 system.
ANNEX A. Abbreviation
Acronyms frequently used in this manual are described.
Conventions
The following special paragraphs are used in this document to point out information that
must be read. This information may be set-off from the surrounding text, but is always
preceded by a bold title in capital letters.
WARNING
Provides information or instructions that the reader should follow in order to avoid
personal injury or fatality.
CAUTION
Provides information or instructions that the reader should follow in order to avoid
a service failure or damage to the system.
NOTE
Indicates additional information as a reference.
OPERATION PROCEDURES
Indicates the operational procedures that should be executed in sequence.

OfficeServ 100 Installation Manual/Ed.00
© SAMSUNG Electronics Co., Ltd. III
Reference
OfficeServ 100 Programming Manual
Introduces programming method for the OfficeServ 100 system users. Users can configure
the system using the MMC(Man Machine Communication) program at the digital
telephone. This manual describes how to use the MMC program.
OfficeServ 100 General Description Guide
Introduces the hardware configuration, specifications, and functions of the OfficeServ 100
system.
OfficeServ 100 Service Manual
Introduces circuit configuration of each section in OfficeServ 100 system, main functions,
parts list, troubleshooting, and disassembly diagram of main device.
Revision History
EDITION DATE OF ISSUE REMARKS
00 10. 2004. First Edition

INTRODUCTION
IV © SAMSUNG Electronics Co., Ltd.
This page is intentionally left blank.

OfficeServ 100 Installation Manual
© SAMSUNG Electronics Co., Ltd. V
SAFETY CONCERNS
For product safety and correct operation, the following information must be given to the
operator/user and shall be read before the installation and operation.
Symbols
Caution
Indication of a general caution
Restriction
Indication for prohibiting an action for a product
Instruction
Indication for commanding a specifically required action

SAFETY CONCERNS
VI © SAMSUNG Electronics Co., Ltd.
Warning
When installing or modifying telephone lines.
To limit the risk of personal injury, always follow these precautions before
connecting CO circuit.
- Never install telephone wiring during a lightning storm.
- Never install telephone jacks in a wet location unless the jack is specially
designed for wet location.
- Never touch non-insulated telephone wires or terminals unless the telephone
line has been disconnected at the network interface
Before connecting the ground
Unplug the power cord from the AC outlet before attempting to connect the
ground. Hazardous voltage may cause death or injury. Observe extreme caution
when working with AC power. Remove champ connectors.
WARNING

OfficeServ 100 Installation Manual/Ed.00
© SAMSUNG Electronics Co., Ltd. VII
Caution
When installing appropriate batteries
Be sure the polarity is observed. Equipment damage will result if polarity is
reversed. Do not connect external AC/ DC power to the OfficeServ 100 system if
the system is damaged by electrical power.
Before installing OfficeServ 100
Unpack and inspect each card before installing. Check for signs of physical
damage. If any damage is detected, do not attempt to install. Contact Samsung
Technical Support immediately.
When using extension cords(A direct commercial AC power outlet)
A direct commercial AC power outlet is required. Do not use extension cords.
Preferably, a dedicated circuit must be used to minimize the risk of other electrical
equipment being connected that could adversely affect system operation.
When installing OfficeServ 100
Ensure that all wires and cable going to and coming from the OfficeServ 100 are
properly routed. Do not cross fluorescent lights or connect lines parallel to the AC
power line.
Connecting equipment
Do not attempt to connect commercial AC power to the contacts on the DPIM,
External Paging, and Common Bell. It may cause damage to your equipment.
CAUTION

SAFETY CONCERNS
VIII © SAMSUNG Electronics Co., Ltd.
Before installing OfficeServ 100
Do not install the OfficeServ 100 system in close proximity to a fire sprinkler head
or other sources of water.
When installing OfficeServ 100
OfficeServ 100 system must not be exposed to direct sunlight, corrosive fumes,
dust, constant vibration or strong magnetic fields such as those generated by
motors and copy machines.
When using long line Extension
Using long line Extensions(over 1 Km) on a 8SLI or KDB SLI may cause damage
to your equipment.
