Intended Use
This telephone system is intended to provide the user with voice communication be-
tween the system extensions and connection to the public switched telephone network
by digital or analogue links.
The telephone system may be provided with the ability to communicate with local com-
puter networks to provide CTI functions and features. In this case, it is capable of pass-
ing information to the computer network via a specified link.
The system is powered by mains voltage and can optionally be powered by batteries.
Details of all connections and power arrangements are provided in the instructions for
use. It should not be used in any other way.

SAMSUNG
DCS-816 Installation Manual
i
Table of Contents
PART 1. SITE REQUIREMENTS .....................................................................................1-1
PART 2. INSTALLING THE BASIC KSU …………………………………………………… 2-1
2.1 System Configuration and Capacity.................................................................................................... 2-1
2.2 Unpacking and Inspection................................................................................................................... 2-2
2.3 Mounting the KSU (Figure 2-1) ........................................................................................................... 2-2
2.4 Grounding the KSU (Figure 2-2) ......................................................................................................... 2-3
2.5 MDF Cabling (Figure 2-3).................................................................................................................... 2-3
2.6 External Battery Connection (Figure 2-4)............................................................................................ 2-6
2.7 Selecting Options on the Basic KSU (Figure 2-5)............................................................................... 2-7
PART 3. INSTALLING OPTION CARDS AND TRUNK CARDS ....................................3-1
3.1 SIO1 Option Card (Figure 3-2)............................................................................................................ 3-2
3.2 AA Option Card (Figure 3-2)................................................................................................................ 3-2
3.3 8TRK Card (Figure 3-3)....................................................................................................................... 3-3
3.4 2/4BRI Card (Figure 3-3)..................................................................................................................... 3-3
3.5 4TRK Card (Figure 3-4)....................................................................................................................... 3-4
PART 4. POWER-UP PROCEDURE ………………………………………………………..4-1
4.1 Connect Power to the System (Figures 4-1, 4-2)................................................................................ 4-1
4.2 Monitor LED Indication and Memory Backup Selection...................................................................... 4-3
4.3 PCB Verification................................................................................................................................... 4-3
4.4 Default Trunk and Station Numbering................................................................................................. 4-3
PART 5. CONNECTING PSTN CIRCUITS .………………………………………………….5-1
5.1 Safety Precautions .............................................................................................................................. 5-1
5.2 Loop-Start Lines (Figure 5-1) .............................................................................................................. 5-2
5.3 Off Premise Extension (OPX) (Figure 5-2).......................................................................................... 5-3
5.4 ISDN BRI Lines (Figure 5-3)................................................................................................................ 5-4
PART 6. CONNECTING STATION EQUIPMENT ………………………………………...6-1
6.1 Safety Precautions .............................................................................................................................. 6-1
6.2 Digital Keysets (Figure 6-1)................................................................................................................. 6-2
6.3 Single Line Telephones (Figure 6-2)................................................................................................... 6-3
6.4 Door Phone and Door Lock Release (Figure 6-3)............................................................................... 6-4
6.5 CTM - CTI Module (TAPI) (Figure 6-4)................................................................................................ 6-5
6.6 ISDN Terminal Equipment (ISDN Phone, G4 FAX, etc) (Figure 6-5) ................................................. 6-6
PART 7. CONNECTING OPTIONAL EQUIPMENT ……………………………………….7-1
7.1 Music-on-Hold/ Background Music (Figure 7-1).................................................................................. 7-1
7.2 External Paging (Figure 7-2) ............................................................................................................... 7-2
7.3 Common Bell (Figure 7-3)................................................................................................................... 7-3
7.4 Ring Over Page................................................................................................................................... 7-4
7.5 Station Message Detail Recording (SMDR) (Figure 7-4).................................................................... 7-4
7.6 PC Programming (Figure 7-5)............................................................................................................. 7-5
7.7 Remote Programming (Figure 7-6) ..................................................................................................... 7-6
7.8 Power Failure Transfer........................................................................................................................ 7-6
7.9 Voice Mail/ Auto Attendant (Figure 7-7).............................................................................................. 7-7
7.10 Information on DCS-816 Serial Interface (Figure 7-8) ......................................................................7-8
PART 8. CHANGING SOFTWARE .................................................................................8-1

SAMSUNG
DCS-816 Installation Manual
ii
Table Of Figures
2-1 ATTACHING MOUNTING BRACKET TO BACKBOARD
2-2 GROUNDING THE KSU
2-3 MDF CABLING
2-4 CONNECTING A SYSTEM BACKUP BATTERY
2-5 SELECTING OPTIONS ON THE BASIC KSU
3-1 INSTALLING OPTION CARDS AND A TRUNK CARD
3-2 SIO OPTION CARD AND AA OPTION CARD
3-3 8TRK CARD AND 2/4BRI CARD
3-4 4TRK CARD
4-1 CONNECTING POWER TO THE SYSTEM
4-2 REPLACING FUSES (POWER SUPPLY UNIT)
5-1 CONNECTING LOOP-START LINES
5-2 CONNECTING OPX LINES
5-3 CONNECTING BRI LINES
6-1 CONNECTING DIGITAL KEYSETS
6-2 CONNECTING SINGLE LINE TELEPHONES
6-3 CONNECTING A DOOR PHONE AND LOCK RELEASE
6-4 CONNECTING A CTM (TAPI)
6-5 CONNECTING ISDN TERMINAL EQUIPMENT
7-1 CONNECTING EXTERNAL MUSIC SOURCE
7-2 CONNECTING EXTERNAL PAGING EQUIPMENT
7-3 CONNECTING AN EXTERNAL LOUD BELL
7-4 PIN CONNECTIONS TO PRINTER
7-5 PIN CONNECTIONS TO PC
7-6 PIN CONNECTIONS TO MODEM
7-7 CONNECTING VM/AA
7-8 INFORMATION ON SERIAL INTERFACE
8-1 CHANGING SOFTWARE

SAMSUNG
DCS-816 Installation Manual
1-1
PART 1. SITE REQUIREMENTS
To install the DCS-816 system, choose a site that meets the following requirements.
9Select a location for the Key Service Unit (KSU) that has enough space for easy installation
and adequate lighting. (KSU dimensions [mm]: 465 (H) x 315 (W) x 120 (D))
9Select a location that minimises cable lengths. See the Cable Requirements table below.
9The equipment should not be exposed to direct sunlight, corrosive fumes, dust, constant vibra-
tion or strong magnetic fields such as those generated by motors and copying machines.
9A direct commercial AC power outlet is required. Do not use extension cords. Preferably, a
dedicated circuit should be used to minimise the risk of other electrical equipment being con-
nected that could adversely affect system operation.
9Ensure that all wires and cables going to and coming from the KSU are properly routed. Do
not cross fluorescent lights or run parallel with AC wires.
9The equipment must be located in an environment that will maintain a temperature range of
32°F ~ 104°F (0°C ~ 40°C) and a humidity range of 10% ~ 90% non-condensing.
9Allow at least 150 mm clearance on both sides and 150 mm clearance on top of the KSU to
ensure proper ventilation.
9Do not install within a 2-mile radius of broadcasting antenna or in close proximity to a fire
sprinkler head or other sources of water.
Meeting these requirements will help to ensure proper performance and greater life expectancy of
the system.
CABLE REQUIREMENTS
EQUIPMENT CABLE Gauge MAX FEET MAX METRES
DIGITAL KEYSETS 1 PR. TWISTED 0.5mm 1300 400
SINGLE LINE STATION 1 PR. TWISTED 0.5mm 3000 1 KM
DOOR PHONE 2 PR. TWISTED 0.5mm 330* 100
CTI INTERFACE MODULE 1 PR. TWISTED 0.5mm 1300 400
* This is the maximum distance a door phone can be from the Door Phone Interface Module
(DPIM). The DPIM can be a maximum of 250 cable metres from the KSU

SAMSUNG
DCS-816 Installation Manual
1-2
IMPORTANT !
Only qualified engineers or technicians should have access to the inside of the
system. In most countries, it is prohibited by law that non-qualified people
install or maintain systems.

SAMSUNG
DCS-816 Installation Manual
2-1
PART 2. INSTALLING THE BASIC KSU
2.1 System Configuration and Capacity
The DCS-816 system consists of the basic Key Service Unit (KSU), option cards, trunk interface
cards, interface modules and digital keysets. The KSU is a single metal cabinet, and in its basic
form has 16 station ports: twelve (12) keyset ports and four (4) SLT (single line telephone) ports.
Additionally, the KSU contains one (1) trunk expansion slot, two (2) option connectors and miscel-
laneous circuits: one (1) external page interface, one (1) general-purpose dry contact and one (1)
music interface selectable to internal built-in music (a melody chip) or external music.
Two types of telephones can be connected to the system: proprietary digital stations called "key-
sets" that connect to Digital Line Interface (DLI) ports and standard telephone sets, generally
called "single line telephones", that connect to Single Line Interface (SLI) ports.
The Trunk Expansion slot provides an option to select an analogue trunk card or a basic rate inter-
face (BRI) card.
The DCS-816 system also has some option cards to provide serial I/O ports or AA facilities.
The KSU starts with two (2) analogue trunk ports and 16 stations, and the trunk expansion slot
provides a maximum capacity of 10 trunk ports (analogue or digital) and 16 stations.
The maximum system capacity is as follows:
Stations 16 (12 keysets, 4 SLTs)
ISDN channels 8 (4 BRI ports)
Analogue C.O. lines 10
Music channel 1 (Internal or External)
External page 1
General-purpose Dry Contact 1
Serial I/O ports 2 (DB9 connectors)
Auto Attendant channels 4
CONFIGURATION NOTES
1. No KDbs (keyset daughterboards for additional DLI or SLI expansion) can be installed.
2. Only one (1) trunk expansion card can be installed.
3. Only one SIO option card and one AA option card can be installed.
4. The system cannot accommodate any cards from other Samsung DCS systems, except
for DCS Compact BRI cards.
5. Every analogue trunk interface contains an interface for MPD or PRS which is optional.
The MPD or PRS hybrid chips of the DCS system can be used.

SAMSUNG
DCS-816 Installation Manual
2-2
2.2 Unpacking and Inspection
After unpacking the KSU, inspect for any signs of physical damage. If any damage is detected, do
not attempt to install the KSU. Contact your dealer for advice.
Check to see that the Basic KSU carton includes the following items.
9Basic Key Service Unit (KSU)
9AC Power Cord
9Wall-mount bracket
9Spare fuses
9Cable ties and screws
9Battery connection cable
9SLT User Guide (for standard telephones)
2.3 Mounting the KSU (Figure 2-1)
The KSU can be wall-mounted on a plywood backboard at least 15 mm thick. Attach the wall-
mount bracket to the backboard with the screws supplied and hang the KSU on the bracket.
FIGURE 2-1
ATTACHING MOUNTING BRACKET TO BACKBOARD
