Samsung OFFICESERV 100 Series Operating and maintenance instructions

OfficeServ 100
General
Description
Enterprise IP Solutions

Publication Information
Samsung Business Communications reserves the right without prior notice to revise information
in this publication for any reason.
Samsung Business Communications also reserves the right without prior notice to make
changes in design or components of equipment as engineering and manufacturing may warrant.
Disclaimer
Samsung Business Communications is not responsible for errors or problems arising from
customers not installing, programming or operating their Samsung systems as described in this
manual.
Copyright 2004
Samsung Business Communications
All rights reserved. No part of this manual may be reproduced in any form or by any means –
graphic, electronic or mechanical, including recording, taping, photocopy or information retrieval
system – without express written permission of the publisher of this material.
2004/12/OS100(GD)Version 1.0

EU Declaration ofConformity(RTTE)
Samsung Electronics Co., Ltd.
259 Gongdan-Dong, Gumi-CityKyungbuk,Korea,730-030
(factoryname,address)
declareunderoursoleresponsibilitythattheproduct
DigitalKeyphoneSystem"OfficeServ 100"
towhichthisdeclarationrelates isinconformitywith
RTTEDirective 1999/5/EC(AnnexII)
LowVoltageDirective73/23/EEC:93/68/EEC
EMC Directive 89/336/EEC:92/31/EEC
By applicationof thefollowingstandards
EN55022 :1998 + A1:2000 + A2:2003, EN55024 : 1998 + A1:2001 + A2:2003
EN61000-3-2:2000, EN61000-3-3 : 1995 + A1:2001
EN61000-4-2:1995 +A1:1998 + A2:2001,EN61000-4-3:2002
EN61000-4-4:1995 + A1:2001 + A2:2001,EN61000-4-5:1995
EN61000-4-6:1996 + A1:2001, EN61000-4-11:1994 + A1:2001
EN60950-1: 2001(1st Edition) and/or EN60950-1: 2001
(Manufacturer)
SamsungElectronics Co., Ltd
259,Gongdan-Dong,Gumi-City
Kyungbuk,Korea, 730-030
Tae-eok Jang/ GeneralManager
................................................. .................................................................................
(placeanddateofissue)(nameand signatureofauthorizedperson)
(Representative intheEU)
SamsungElectronics EuroQALab.
BlackbusheBusiness Park
SaxonyWay,Yateley,Hampshire
GU46 6GG, UKPeter Park /Manager
................................................. ...............................................................................
(place and date ofissue) (name andsignature ofauthorized person)
TEJang
2004-12-04
Peter Park
2004-12-04

EU Declaration ofConformity(RTTE)
Samsung Electronics Co., Ltd.
259 Gongdan-Dong, Gumi-CityKyungbuk,Korea,730-030
(factoryname,address)
declareunderoursoleresponsibilitythattheproduct
DigitalKeyphoneSystem"iDCS 100"
towhichthisdeclarationrelates isinconformitywith
RTTEDirective 1999/5/EC(AnnexII)
LowVoltageDirective73/23/EEC:93/68/EEC
EMC Directive 89/336/EEC:92/31/EEC
By applicationof thefollowingstandards
EN55022 :1998 + A1:2000 + A2:2003, EN55024 : 1998 + A1:2001 + A2:2003
EN61000-3-2:2000, EN61000-3-3 : 1995 + A1:2001
EN61000-4-2:1995 +A1:1998 + A2:2001,EN61000-4-3:2002
EN61000-4-4:1995 + A1:2001 + A2:2001,EN61000-4-5:1995
EN61000-4-6:1996 + A1:2001, EN61000-4-11:1994 + A1:2001
EN60950-1: 2001 (1st Edition) and/or EN60950-1: 2001
(Manufacturer)
SamsungElectronics Co., Ltd
259,Gongdan-Dong,Gumi-City
Kyungbuk,Korea, 730-030
Tae-eok Jang/ GeneralManager
................................................. .................................................................................
(placeanddateofissue)(nameand signatureofauthorizedperson)
(Representative intheEU)
SamsungElectronics EuroQALab.
BlackbusheBusiness Park
SaxonyWay,Yateley,Hampshire
GU46 6GG, UKPeter Park /Manager
................................................. ...............................................................................
(placeanddateofissue)(nameand signatureofauthorizedperson)
TEJang
2004-12-04
Peter Park
2004-12-04

Intended Use
This telephone system is intended to provide the user with voice communication between the system extensions
and connection to the public switched telephone network by digital or analogue links.
The telephone system may be provided with the ability to communicate with local computer networks to provide
CTI functions and features. In this case, it is capable of passing information to the computer network via a specified
link.
The system is powered by mains voltage and can optionally be powered by batteries. Details of all connections and
power arrangements are provided in the instructions for use. It should not be used in any other way.

OfficeServ100 General System Diagram
External paging zones
Computer
SVMi-4/8
voice mail &
auto attendant
Loud Bells
Door phones
Voice mail/auto
attendant systems
48VDC Battery
Backup
Printer or call accounting system
SMDR
External music sources
iDCS 64B AOMiDCS 14B AOMiDCS 8D Keyset
iDCS 28D Keyset iDCS 18D Keyset
Single Line Telephone6B LCD (Euro) KeysetDS-2100B Keyset
48-Button AOM
64B AOM
LCD 12B/24B (Euro) Keyset
Telephone Lines
Loop starttrunk
VoIP
Wireless
ISDN PRI/BRI
110/220V AC
System programming
Remote programming
Computer telephonyintegration
DS-5007S (7B, 2-Line LCD) DS-5014S (14B, 2-Line LCD)
DS-5038S (38B, 2-Line LCD)
iDCS Series and DCS EuroKeysets 5000 Series Digital Keysets and IP Phones
DS-5021D (21B, 2-Line LCD)
ITP-5021D (21B, 2-Line LCD)
DS-5014D (14B, 2-Line LCD) ITP-5014D (14B, 2-Line LCD)
DS-5012L (12B, Large LCD) ITP-5012L (12B, Large LCD)
WBS24

i
Preface
About This Guide
The OfficeServ 100 Digital Communications System is designed for small to medium–sized
businesses. This guide provides a comprehensive overview of the system including configu-
ration, hardware descriptions and available features.
The Guide comprises the following chapters.
yChapter 1: Introduction to the OfficeServ 100
Information on capacities, possible configurations, the technology employed and default programming.
yChapter 2: Hardware Descriptions
Describes the components of the Basic Key Service Unit and Expansion cabinets, including interface
cards (such as TRK, BRI, DLI), and the station equipment available.
yChapter 3: Specifications
Electrical, physical, and environmental specifications, including system tones and keyset LED indica-
tions.
yChapter 4: Business Features Package
All the system, station and display features available on the OfficeServ 100 to enhance your business
procedures, including example reports and printouts.
Supporting Documents
This guide is supported by the following OfficeServ 100 system guides which are available
from Samsung:
yOfficeServ 100 Installation Guide
Provides full instructions for installing the OfficeServ 100 system including interface cards, station
equipment (telephones) and optional devices such as printers and paging equipment.
yOfficeServ 100 & 500 System Administration Guide
A useful guide to system administrators for programming the most commonly used features of the
telephone system.
yOfficeServ 100 Programming Guide
Provides complete instructions for programming your system using MMC programs at a digital keyset.
yKeyset and Phone User Guides
Guides are available for using a variety of Samsung keysets, standard telephones and mobile phones
with your OfficeServ 100.

ii
Contents
CHAPTER 1 INTRODUCTION TO THE OFFICESERV 100 ........................................................................................... 1-1
GENERAL DESCRIPTION........................................................................................................................................................... 1-1
SIZE AND CONFIGURATION ...................................................................................................................................................... 1-2
TECHNOLOGY.......................................................................................................................................................................... 1-6
PROGRAMMING ....................................................................................................................................................................... 1-6
CHAPTER 2 HARDWARE DESCRIPTIONS................................................................................................................... 2-1
KEY SERVICE UNIT (KSU)....................................................................................................................................................... 2-1
EXPANSION CABINET............................................................................................................................................................... 2-2
INTERFACE CARDS................................................................................................................................................................... 2-2
INTERFACE CARDS................................................................................................................................................................... 2-3
STATION EQUIPMENT............................................................................................................................................................... 2-7
CHAPTER 3 OFFICESERV 100 SPECIFICATIONS....................................................................................................... 3-1
ELECTRICAL SPECIFICATIONS .................................................................................................................................................. 3-1
DIMENSIONS AND WEIGHTS..................................................................................................................................................... 3-1
ENVIRONMENTAL LIMITS......................................................................................................................................................... 3-2
CABLE REQUIREMENTS ........................................................................................................................................................... 3-2
POWER SUPPLY........................................................................................................................................................................ 3-2
SYSTEM TONES........................................................................................................................................................................ 3-3
KEYSET LED INDICATIONS...................................................................................................................................................... 3-4
CHAPTER 4 BUSINESS FEATURES PACKAGE............................................................................................................ 4-1
SYSTEM FEATURES .................................................................................................................................................................. 4-1
STATION FEATURES................................................................................................................................................................ 4-27
DISPLAY FEATURES................................................................................................................................................................ 4-35
SAMPLE KEYSET DISPLAYS ................................................................................................................................................... 4-39
SAMPLE CALLER ID DISPLAYS .............................................................................................................................................. 4-40
SAMPLE UCD DISPLAYS........................................................................................................................................................ 4-41
SAMPLE SMDR PRINTOUT .................................................................................................................................................... 4-42
SAMPLE UCD REPORT........................................................................................................................................................... 4-43
SAMPLE TRAFFIC REPORT...................................................................................................................................................... 4-46
TRAFFIC REPORT OVERVIEW ................................................................................................................................................. 4-47
SAMPLE ALARM REPORT ....................................................................................................................................................... 4-53

1-1
Chapter 1 Introduction to the
OfficeServ 100
This chapter contains the following sections.
yGeneral Description
ySize and Configuration
yTechnology
yProgramming
General Description
The Samsung OfficeServ 100 (Digital Communications System) is a digital telephone system
designed for small- to medium-sized businesses. It can operate with the functionality of a key
system, PABX or a combination of both (hybrid). The system employs DSP (Digital Signal
Processor) digital technology.
The OfficeServ 100 offers a variety of interface cards that allow connection to the public tele-
phone network or to private networks. These are generally referred to as trunk cards. Three
types of telephone can be connected to the system: proprietary digital phones called “key-
sets” connect to digital line interface cards (DLI), standard telephones (generally called single
line telephones, or SLTs) connect to single line interface cards (SLI), and IP (internet)
phones use the Media Gateway Interface (MGI) card.
In addition, DLI station ports are used to connect peripheral devices such as door phones
and add-on modules. Miscellaneous circuits are provided to allow such optional features as
external paging, music-on-hold, background music, common audible devices, alarms and
emergency power failure telephones.
Voice Over IP (VoIP)
The OfficeServ 100 system supports calls over an IP network connection using industry-
standard protocols, allowing the transfer of voice, data and images quickly and efficiently.
Samsung Keysets
All keysets have a single PCB with surface-mounted components assuring the highest
product quality and long life. Samsung’s customary large, easy-to-read displays and key
LEDs make them much easier to use. In many instances, sophisticated features are made
simple through the use of friendly display prompts or programmable feature keys.

1-2 Chapter 1
Introduction to the OfficeServ100
Size and Configuration
The OfficeServ 100 comprises a Basic Key Service Unit (KSU, Figure 1–1), Expansion cabi-
net, interface cards and electronic keysets. The simplest KSU has eight (8) keyset ports, but
this is expandable to 18 analogue C.O. line ports, or 24 BRI lines, or 32 stations. In addition,
up to eight keyset daughterboards may be added to the system along with the optional 2SLI
card.
Two types of Expansion cabinet are available: Expansion A and Expansion B. Expansion A
has three universal slots and one dedicated slot for a TEPRI or Voice Mail card. This pro-
vides the maximum configuration of 66 ports with analogue trunk lines or 96 ports with digital
trunk lines. Expansion B has two universal slots and two dedicated slots: the first dedicated
slot is for a Voice Mail card; the second dedicated slot supports a TEPRI card. This provides
the maximum configuration of 66 ports with analogue trunk lines or 96 ports with digital trunk
lines.
The system also has an optional MISC card which provides Music-On-Hold, external paging
and other useful facilities.
NOTE: For a full description of each card discussed in this section, refer to Chapter 2,
Hardware Descriptions.
The charts shown in Figures 1-2 to 1-5 describe possible configurations using the Basic
KSU, Expansion Cabinet and interface cards. However, by using the system’s unique keyset
daughterboards (KDBs), which are installed in the base of a digital keyset, the capacity of the
system can be increased by one station per KDB. Installing a KDB-DLI adds another digital
port while a KDB-SLI adds a single line port. You can mix and match these two types of KDB
to get up to a total of eight KDBs in the system. Using this method allows the system to ex-
pand to a maximum of 64 stations. Adding the optional 2SLI card to the KSU provides a fur-
ther two SLI ports. The combination of the Basic KSU plus three expansion cards in the KSU,
plus three expansion cards and one TEPRI card in the Expansion A cabinet, plus eight
KDBs, plus a 2SLI card provides a maximum configuration of 96 ports plus a MISC card.
Important Points to Remember:
Only one 2SLI card can be installed in the system.
Only one MISC card can be installed in the system.
Only three expansion cards can be installed in the KSU.
An additional three expansion cards and a card such as a TEPRI or SVMi-8 card can be
installed in an Expansion A cabinet; OR an additional two expansion cards and a TEPRI
and Voice Mail card can be installed in an Expansion B cabinet.
A PLL card is required if ISDN cards (TEPRI, BRI) are installed
Only eight KDBs can be installed in the keysets connected to the Basic KSU.
The system can have up to 48 digital keysets, but this is reduced to up to 40 digital key-
sets if an SVMi-8 card or MGI3 card is installed.
The number of stations allowed is reduced by four for each WBS24 installed (up to 16 if
the 4WLI card supports the maximum four base stations).
Large LCD keysets consume three times as much power as other stations.

OfficeServ100
1-3
Figure 1–1 OfficeServ 100 Basic Key Service Unit

1-4 Chapter 1
Introduction to the OfficeServ100
Trunk Lines
Figure 1–2 Configuration Matrix Table (With Analogue Trunks) (Expansion Type A)
Trunk Lines
Figure 1–3 Configuration Matrix Table (With Digital Trunks) (Expansion Type A)
36
30
24
18
12
6
0
Two Cabinets
KSU
78
48
40
32
24
16
8
0
KSU
Two Cabinets
8 16 18 26 34 42 50 58 66
Station Lines
8 16 18 26 34 42 50 58 66
Station Lines

1-5
Trunk Lines
Figure 1–4 Configuration Matrix Table (With Analogue Trunks) (Expansion Type B)
Trunk Lines
Figure 1–5 Configuration Matrix Table (With Digital Trunks) (Expansion Type B)
30
24
18
12
6
0
70
40
32
24
16
8
0
8 16 18 26 34 42 50 58
Station Lines
8 16 18 26 34 42 50 58
Station Lines
Two Cabinets
KSU
KSU
Two Cabinets

1-6 Chapter 1
Introduction to the OfficeServ100
Technology
Memory
All specific customer data is stored in Random Access Memory (RAM) which is protected
against the loss of AC power to the system by an onboard battery back-up system.
The OfficeServ 100 program is stored in 16 Mb NAND flash memory on the Main Control
Processor (MCP1) card. The system boots from a 512 K boot ROM and downloads the op-
erating program into 32 Mb of SDRAM on the MCP1 card. The customer database is stored
in 1 Mb of non-volatile SRAM.
Microprocessors
OfficeServ 100 uses distributed processing. The primary processor is a 32–bit Motorola®
MPC855 on the MCP1 card operating at a clock speed of 50 MHz. Secondary processing is
carried out in some special cards, such as BRI, and also in keysets. Secondary processing
on the base board is done via an MC68EC000 processor running at 16 MHz to provide local
control of cards. Digital keysets use a Hitachi H8 processor for data communication.
Switching
The system provides 256 switchable digital channels. Each of the 256 digital channels is
automatically assigned to carry voice or data as required by system operation in a PCM for-
mat.
In addition to these channels, the system uses Digital Signal Processors (DSPs). Each DSP
may be configured by the switching control program as a DTMF sender, a DTMF receiver or
as a C.O. tone detector on a per–call basis. Four DSP channels are provided by default.
Four additional DSPs are added when a MISC card is installed. This means that the system
contains a total of eight DSP channels when fully expanded. The DSP channels are fully
shared throughout the system as a common resource.
Programming
OfficeServ 100 is a self-configuring system. This means that immediately after applying
power, the system reads the types and locations of all installed interface cards and keysets
and assigns default data to them. All trunks and stations are assigned numbers according to
the default numbering plan. This numbering plan is flexible and may be changed to suit cus-
tomer requirements.
The system can be programmed from any LCD display keyset without interrupting system
operation. There are three levels of programming: technician (or system), customer and sta-
tion. The technician level has access to all programs and can allow the customer access to
system programs as needed. Technician and Customer access levels are controlled by dif-

1-7
ferent security passcodes and access procedures. Refer to the Samsung OfficeServ 100
Programming Guide for more information.
The system also allows the use of a proprietary computer program called OfficeServ Man-
ager. This permits a technician to program the system using a personal computer. OfficeServ
Manager can be used on-site to modify the customer database or to download (save) the en-
tire customer database to a file. This file can then be saved as a backup and be uploaded
when required to restore the database.
Using a modem or Wide Area Network (WAN) connection, OfficeServ Manager can access
the system remotely (off-site) to make changes to the customer database or to perform up-
loads or downloads of the database as if the technician were on-site.

2-1
Chapter 2 Hardware Descriptions
This chapter describes the hardware for the OfficeServ 100 system as follows.
Key Service Unit
Interface Cards
Station Equipment
Key Service Unit (KSU)
The OfficeServ 100 KSU (see Figure 1–1 in Chapter 1) is a single metal cabinet containing
the following:
Power supply unit
Processing and switching technology
Eight 2B+D digital keyset interfaces
Main Control Processor card (MCP1)
One Internal Music source or an External Music interface for Music–On–Hold and Back-
ground Music
One External Page interface
One general–purpose dry contact
Three universal expansion slots, a MEM card slot (for MCP1), a 2SLI card slot and a
MISC card slot.
Two Champ connectors for external connections, and other connectors for the Expansion
cabinet and the Ring Generator Unit.
MCP1 CARD
The main control card for the system, the MCP1 is mounted in the MEM slot of the main
KSU. It provides:
16 Mbyte NAND flash memory
512K boot flash memory
32 Mb SDRAM memory
2 Mb SRAM data memory (with SP program and data memory)
2K DPRAM for inter-processor communication
a real-time clock
monitoring and LAN status LEDs
a memory clear switch
a 10/100 base T RJ-45 LAN interface
9-pin serial I/O interface.

2-2 Chapter 2
Hardware Descriptions
Ring Generator Unit (RGU1 or RGU2)
Two kinds of sinusoidal–waveform Ring Generator Units are available: RGU1 provides 3W
ring signals; RGU2 provides 20W ring signals. RGU2 is required when a large number of sin-
gle line telephones are connected to the system.
Expansion Cabinet
One metal Expansion cabinet can be attached to the KSU. There are two types available.
Expansion “A” type (Figure 2–1) comprises three Universal expansion slots and one dedi-
cated card slot for a TEPRI or SVMi-8 card. Expansion “B” type (Figure 2–2) consists of
two universal expansion slots and two dedicated card slots. The Expansion cabinet connects
to the KSU via a 64-pin ribbon cable, two 2-wire power connections and an F-GND connec-
tion. It contains a 50-pin Champ connector for external connections.
When installing an SVMi-8 card, the plastic case should first be removed.
Figure2−1Expansion‘A’Type Figure2−2Expansion‘B’Type
Dedicated slot (TEPRI or SVMi-8 card) Dedicated slot (SVMi-8 card)
Dedicated slot (TEPRI card)

2-3
Interface Cards
These cards provide the interface connections for telephone lines and stations to the KSU
and Expansion cabinet. They fit into the card slots to configure the system as required. Refer
to the Samsung OfficeServ 100 Installation Guide for information on how to recognise and
install interface cards.
1. Trunk Cards
AC15
Contains three 4-wire tielines. Signalling frequency is 2280 Hz.
3TRK
Provides three loop-start C.O. interface circuits. The first two circuits are equipped with
power failure transfer (PFT) relays. Each circuit contains a Polarity Reversal Signal (PRS) in-
terface. (The optional PRS hybrid chips for a Samsung DCS system can be used.)
6TRK
Provides six loop-start C.O. interface circuits. The first two C.O. circuits are equipped with
PFT relays. Each circuit contains a Polarity Reversal Signal (PRS) interface. (The optional
PRS hybrid chips for a Samsung DCS system can be used.).
2BRI
Contains two Basic Rate access ports, i.e. four ISDN channels. Protocol is compatible with
Euro–ISDN BRI. For S0 applications, power feeding to ports is selectable by programming.
(See also PLL, below.)
4BRI
Contains four Basic Rate access ports, i.e. eight ISDN channels. Protocol is compatible with
Euro–ISDN BRI. For S0applications, power feeding to ports is selectable by programming.
(See also PLL, below.)
PLL
Any ISDN card (i.e. BRI or PRI) requires that a PLL card be installed in the dedicated PLL
slot on the KSU motherboard.
TEPRI
Can be configured as a T1/E1 card or PRI card. If configured as T1/E1 it provides up to 30
trunk circuits in any combination of the following:
yLoop-start lines
yDID (Direct Inward Dialing)
yE & M tie lines or two-way DID calling
yQSIG

2-4 Chapter 2
Hardware Descriptions
If configured as PRI, it contains 30 ISDN channels. Protocol is compatible with Euro-ISDN
PRI. (See also PLL, above.)
Media Gateway Interface (MGI3)
Provides a Voice over Internet Protocol (VoIP) gateway between IP and non-IP parts of the
telephone system, as well as Codec conversion. The main features of the MGI3 card are:
yOn-board Flash memory and data memory
yEcho cancellation function supported
ySilence suppression function supported, preventing data transfer on the network for the
brief silent intervals between words during calls
Provides an 8-channel interface (expandable to 16 by the addition of a daughterboard) using
the G.711, G.723 and G.729 Codecs for speech compression and T.38 protocol for fax or IP
communication. It also supports proprietary SPnet IP networking.
MGI3 acts as a universal gateway for generic types of VoIP handsets. A maximum of three
cards can be installed in the KSU.
All power to run the system comes from the power supply. Each power supply is rated ac-
cording to the number of stations it will support. When the MGI3 card is installed, it counts as
eight (8) stations of the PSU rating.
3BSI
Provides interface circuits for up to three base stations for DECT 8000. When the 3BSI card
is installed, it counts as twelve (12) stations of the PSU rating; therefore a maximum of 36
keysets can be connected. Only one card can be installed in the KSU.
2. Station Cards
2SLI
The 2SLI card is installed in the dedicated SLI slot on the KSU motherboard. The card pro-
vides two single line telephone interfaces equipped with Long Line protection and the ability
to provide a loop-disconnect signal.
8SLI
The 8SLI card provides eight SLI ports for industry–standard single line telephones and the
ability to provide a loop-disconnect signal. This card does not provide Long Line protection.
8DLI
Provides eight DLI ports for digital stations.

2-5
6MWSLI
100V pulse for message waiting LED working. Provides six SLI ports for industry–standard
single line telephones and the ability to provide a loop-disconnect signal and a message-
waiting signal. This card does not provide Long Line protection.
Keyset Daughterboards
A variety of keyset daughterboards (KDB) are available. If installed in a digital keyset con-
nected to the Basic KSU, a KDB provides a second DLI or SLI port. (See Station Equipment,
below, for full details.)
3. Other Cards
MISC 3 or MISC 4
MISC 3 provides a DTMF receiver (4 channels), background music, paging, three general-
purpose relays, and an optional Modem. MISC 4 provides all the MISC 3 card functions and
also provides a 4-port AA function.
NOTE: In future releases, the MISC card will also support the FSK (Frequency Shift Keying) Caller ID
feature supporting CLIP information for SLT phones (a maximum of 16 channels for CID Tx & Rx
ports).
It is strongly recommended that a MISC card be used in situations requiring heavy single line
telephone use.
MODEM
This card is a built–in modem and is installed on a MISC card.
SVMi-4
The SVMi-4 is a self-contained Voice Mail and Auto Attendant system on a single card. It is
designed to meet the demands of the sophisticated voice mail user without sacrificing sim-
plicity. The SVMi-4 may act as an Auto Attendant system only, a Voice Mail system only, or
both.
By default, the SVMi-4 can handle two calls simultaneously. It can be easily upgraded to
handle up to four calls simultaneously. No external line or power connections are necessary.
The standard memory capacity is about 5 hours using a 64MB memory card. (Higher capac-
ity Flash memory cards are available from Samsung.)
SVMi-8
The SVMi-8 Voice Mail system is a fully integrated Auto Attendant/Voice Mail/Fax system on
a single card. This optional card provides four or eight communication channels. Only one
card is permitted per system and it should be installed in a dedicated slot in the Expansion
cabinet. (This should be the first dedicated slot in an Expansion type B cabinet.)
