Sanuvox P900-gx User manual

Instruction Manual

Photos illustrating products are non contractual.

P900-GX

PORTABLE UV AIR PURIFIER

Residential Model

IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE SAFETY INSTRUCTIONS BEFORE USING THIS PRODUCT.

Read and follow all instructions contained in

this manual before using the product. Failure

to comply with these instructions may result

in personal injuries or damage to the unit or

system.

1. Installation and servicing of air conditioning

and related equipment can be hazardous due

to systems pressure and electrical components.

Only trained and qualied service personnel

should install, repair or service equipment.

2. Untrained personnel can perform basic

maintenance functions such as replacing

lamp(s) and/or lter(s). All other operations

should be performed by trained service

personnel.

3. When working on the unit or system, observe

precautions in the literature, tags and labels

attached to the unit or system, and all other

safety precautions considered as best practices

in the HVAC industry.

4. When applicable, local regulation may

comprise more restrictive installation and/or

certication requirements. The afore mentioned

requirements prevail on those of this document

and the installer agrees to conform to these at

his own expense.

5. Follow all the safety instructions outlined in this

document and respect all local and national

codes applicable.

6. Never expose eyes or skin to ultraviolet light

from any source. Therefore, before installing

or performing maintenance on the unit or

system, TURN OFF AND DISCONNECT the

unit or system from all power sources (there

may be more than one switch to disconnect).

CAUTION: Electrical shock may cause

personal injuries or possibly death.

7. UV rays may destroy certain types of lters

(polymer or plastic); please keep the unit or

system light away from shining directly on

plastic.

8. When installing or performing maintenance on

the UV unit or system, it is recommended to

wear safety glasses and gloves. In order to

avoid reduced performance of lamp(s), do not

touch lamp glass without gloves.

9. UV lamps contain a small quantity of mercury:

if a lamp breaks, clean and dispose of with

care. UV lamps can be disposed/recycled after

use, as any other uorescent lamps. Contact

and follow your local and national authorities’

specic instructions.

10. Use only specied SANUVOX branded

replacement UV lamps with your unit or

system. Use of any other lamps will void your

warranty and can result in damage to the unit,

system and/or lamp(s).

11. Most UV units or systems are not waterproof.

DO NOT INSTALL OUTDOORS unless

specied otherwise.

SAVE THESE INSTRUCTIONS

Installation Date: _______________ Installed by: _________________

Installer Contact Info.: _________________________________________

YOUR WARRANTY

ONLINE AT

www.sanuvox.com

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS 1

TABLE OF CONTENTS 2

ABOUT THE PRODUCT 3

COMPONENTS 3

How it Works 3

SETUP & INSTALLATION 4

What you will need 4

What’s included 4

Step by Step Setup & Installation 4

Step by Step Stand Installation 5

Step by Step Handle Installation 5

OPERATION 6

How to Operate your Product 6

How to Read the Control Panel Display 6

Default Settings 6

How to Switch from Default to Timer Mode 6

Step by Step Adjust Fan Speed 7

MAINTENANCE 7

How to Replace Lamp(s) 7

Step by Step Lamp Replacement 7

How to Clean your Product 9

Step by Step Inlet Filter Cleaning 9

STORAGE 10

ULTRAVIOLETS: UVV & UVC 10

ELECTRICAL RATINGS, POWER CONSUMPTION & AVAILABLE VOLTAGE 10

TROUBLESHOOTING 10

What you will need 10

Problems & Solutions Table 10

A. Step by Step Verication of Motor Wire Connection 11

WARRANTY 12

CUSTOMER SERVICE 12

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

ABOUT THE PRODUCT

Congratulations on the purchase of your new Sanuvox ultraviolet air purier. Sanuvox UV air puriers are the most advanced

air purication systems available, having been proven to destroy up to 99.999% of biological and chemical contaminants that

circulate throughout your home or facility. Sanuvox systems have been tested by the EPA (Environmental Protection Agency),

the National Homeland Security Research Center, medical universities and independent third party laboratories.

The P900-GX is designed to purify up to 900 square feet, destroying chemical and biological contaminants.

The unit is designed for small homes and apartments, and can be used in commercial areas.

For information or recommendations on how to size your specic application, please call SANUVOX at 1-888-726-8869.

COMPONENTS

How it Works

Contaminated air enters the P900-GX parallel to the UV ‘J’ lamp, thus increasing contact time with the UV energy. First, the air

goes through an inlet lter that captures particles. After, the UVV oxidizing section of the lamp destroys chemicals and odors,

the UVC germicidal section of the lamp destroys biological contaminants. Finally, the purifed air circulates through the home.

A. Control Panel Display

B. Handle Notch (for wall-mounting)

C. Lamp Access Door

D. Stand

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

SETUP & INSTALLATION

What you will need

A utility knife to unpack all components and a Phillips No.2 screwdriver.

CAUTION: Handle your product with care to avoid breaking parts. Make sure you have a free and safe space to unpack,

install and setup your product. Conrm you have access to the necessary power source for the product requirements (see unit

or system label). If you have any questions regarding the installation instructions, call SANUVOX at 1-888-726-8869.

What’s included

The P900-GX with its UV lamp and a basic installation kit.

The installation kit includes: a UV caution decal, a maintenance decal, a stand and an handle with its screw (1).

Step by Step Setup & Installation

1. Prepare the P900-GX for installation. Remove unit from packaging.

Before plugging the P900-GX, turn it face down and place on soft

surface to protect top.

STEP 1

2. Install stand or handle.

See Stand and Handle Installation instructions on page 5.

3. Replace the P900-GX upright or on wall and plug the purier in a wall outlet.

You are now ready to power ON your new

P900-GX and enjoy great air quality

for you and your family.

STEP 3

STEP 2

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

Step by Step Stand Installation

Step by Step Handle Installation

1. Loosen the two bottom screws between the two rubber feet.

1. The handle ts into the wall/ handle notch just under the middle rubber

foot. Slide the handle in and tighten the screw.

2. Slide the stand through the two screws and tighten.

STEP 1

STEP 2

A B C

GED F

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

OPERATION

How to Operate your Product

The P900-GX is an automatic unit: once it’s installed and plugged in, simply press the power switch to turn it ON and enjoy clean

air in your home!

CAUTION: The suggested operating temperature range is 10 to 50°C (50 to 122°F). Operating the P900-GX outside this

range will result in decreased performance. For optimal performance, air temperature moving through the unit should be in the

range of 15 to 20°C (60 to 70°F).

How to Read the Control Panel Display

The P900-GX control panel display will give you real time status update about its fan speed and timer settings.

Default Settings

When the unit is plugged, all settings are OFF: push the power button to turn on unit.

Default fan speed is set to 3, which is considered the optimum performance.

Default run time is set to “C” (continuous operation).

The fan is always running when the lamp is on.

CAUTION: System is designed to control the TDCEF-05019A12-H-12-BAL 12 Volt brushless DC fan motor. Operation with

other types of fan may not be optimal and may void the warranty.

You can then select the P900-GX fan speed and operating time at any time to suit your individual preferences.

During operation, the LEDs and display toggle every 5 seconds between TIME and FAN setting display, showing time remaining

and fan speed.

Operation will resume at default time/speed whenever unit is turned off and on again.

How to Switch from Default to Timer Mode

1. While the P900-GX is powered ON, press the “Mode Button” to switch between settings. When “Timer Mode LED Indicator”

ashes, your unit is on “Timer Mode” settings and the numeric digit on the “LED Display Window” corresponds to the time

left before shutting down.

2. Use the up and down arrow buttons to select run time.

Run time can be set between 1 to 9 hours or to “C” (Continuous operation).

3. Wait for a short period without touching any buttons for P900-GX to register new settings. Your unit will then start working with

the timer mode activated.

After the set time has elapsed, lamp, fan and display will turn off.

A. Up Arrow Button

B. LED Display Window

C. Power ON/OFF Button

D. Down Arrow Button

E. Timer Mode LED Indicator

F. Fan Speed LED Indicator

G. Mode Button

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

How to Adjust Fan Speed

1. While the P900-GX is powered ON, press the “Mode Button” to switch between settings. When “Fan Speed LED Indicator”

ashes, numeric digits on the “LED Display Window” corresponds to the unit fan speed.

2. Use the up and down arrow buttons to select fan speed.

Variable fan speeds can be set between 1 to 9 (low-high).

MAINTENANCE

How to Replace Lamp(s)

Replacing lamp on the P900-GX is quick and easy. Simply turn off the power source, remove and dispose of old lamp, replace

with new Sanuvox branded UV lamp, turn power source back on. See below for detailed step by step instructions.

CAUTION: In order to avoid reduced performance of lamp(s), do not touch lamp glass without gloves.

Step by Step Lamp Replacement

1. Unplug P900-GX from wall outlet.

Turn face down and place on soft surface to protect top of unit.

CAUTION: Before installing or performing maintenance on the unit or

system, TURN OFF AND DISCONNECT the unit or system from all

power sources.

2. Remove the 4 screws from the lamp access door. Then remove lamp

access door.

NOTE: There is a micro switch / cut-off switch to cut power to the

P900-GX when the lamp access door is removed.

4. Press the lamp clamp to release the old lamp, and slowly remove the

old lamp.

3. Once the lamp access door is removed hold the old lamp by the ceramic

socket and remove the white plug from the old lamp.

STEP 1

STEP 2

STEP 4

STEP 3

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

STEP 5

STEP 6

STEP 7

STEP 8

STEP 9

5. Prepare the UV lamp for installation. Remove lamp from packaging.

Only after you have visually inspected the UV lamp should you break

the security seal on the underside of the cardboard sleeve.

6. Press the lamp clamp and insert the new lamp. Release lamp clamp to

secure lamp in place.

7. Holding the ceramic base, attach the plug to the new lamp. The plug

will t in one direction only. It may be necessary to rotate the plug 90° to

attach it.

8. Replace the lamp access door and secure it with its 4 screws.

9. Replace the P900-GX upright or on wall and plug the purier in a wall outlet.

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

How to Clean your Product

For optimal performance, the lamp(s) and lter(s) should be kept free of dust and residue deposit. Clean when necessary with

mild soap or alcohol. To clean the unit exterior, use a damp cloth with general purpose detergent. Always spot test the cleaner

to make sure it does not damage the surface.

CAUTION: Under no circumstance should water be sprayed or splashed onto the product.

1. Detach the two thumbscrews on the top of the lter frame with a

non-magnetic 5/16" nutdriver. Then, remove the lter frame.

3. Remove the aluminum lter and clean it.

NOTE: The lter can be washed in a mild detergent, soap and water.

5. Replace the plastic grill.

2. Remove the plastic inlet grill.

4. When lter is dry, reinstall it on the inlet posts.

6. Replace the lter frame. Reattach the thumbscrews: place them with

your nger and tighten them with the nutdriver.

STEP 1

STEP 3

STEP 5

STEP 2

STEP 4

STEP 6

Step by Step Inlet Filter Cleaning

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

ULTRAVIOLETS: UVV & UVC

The UVC (254 nm) and UVV (185 nm) light produced by Sanuvox UV units and systems are the same two UV wavelengths

produced by the Sun. The UVC wavelength attacks the micro-organisms on a molecular level deactivating and destroying the

contaminants, while the UVV wavelength degrades the chemicals and odors. Unlike conventional UV lamps on the market,

Sanuvox UV units and systems use a patented process designed to deliver the maximum UV dosage to the moving air-stream

or surface.

CAUTION: Never expose eyes or skin to ultraviolet light from any source.

STORAGE

The P900-GX does not require specic storage. It is a portable unit that works continuously when ON, or automatically when

selecting proper settings (fan speed and timer).

CAUTION: Keep away from unsupervised children. This unit is not a toy.

ELECTRICAL RATINGS, POWER CONSUMPTION & AVAILABLE VOLTAGE

The product is rated at 120V to 240V, and 50 Hz to 60 Hz.

See product label to conrm power consumption of your specic unit or system.

NOTE: IF YOU EXPERIENCE A PROBLEM, PLEASE CONTACT CUSTOMER SERVICE FIRST OR SEE YOUR WARRANTY.

DO NOT RETURN THE PRODUCT TO THE ORIGINAL PLACE OF PURCHASE. DO NOT ATTEMPT TO OPEN THE

PRODUCT OR TAMPER WITH ITS COMPONENTS WITHOUT CONTACTING CUSTOMER SERVICE FIRST. DOING SO

MAY VOID YOUR WARRANTY AND CAUSE PERSONAL INJURY OR DAMAGE TO THE PRODUCT.

Problem Possible Cause Solution

Unit doesn’t come ON. - There is no power to the electrical

outlet.

- Make sure the power outlet is working.

- Make sure the unit is plugged in to

120V outlet.

- The On/Off switch is not ON. - Push the ON button on the display.

- The power cord is damaged. - Replace power cord.

- The micro switch / cut-off switch is not

well engaged.

- Make sure the lamp door is well

closed.

- Make sure the lamp door pin pushes

on the micro switch / cut-off switch.

Unit comes ON, but lamp is OFF: its

“glow” isn’t visible throught the oulet

louver.

- Lamp and/or ballast are defective. - Get a genuine replacement lamp and/

or ballast.

- Replace lamp and/or ballast.

Unit comes ON and lamp is ON, but

the motor is not turning or is making

rattling noise.

- Motor is defective. - Replace motor.

- Motor wire connection is not properly

connected.

- Check motor wire connection.

See Verication of Motor Wire

Connection instructions on page 11 (A).

Contact your contractor for all your needs in terms of replacement parts:

power cord, control panel display, UV lamp, ballast, lter, grill, fan motor, stand, handle, etc.

TROUBLESHOOTING

If your product is not working properly, refer to the following.

What you will need

A Phillips No. 2 screwdriver, a non-magnetic 5/16" nutdriver and spare parts.

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

A. Step by Step Verication of Motor Wire Connection

1. Unplug P900-GX from wall outlet.

Turn face down and place on soft surface to protect top of unit.

CAUTION: Before installing or performing maintenance on the unit or

system, TURN OFF AND DISCONNECT the unit or system from all

power sources.

2. On the back of the P900-GX, unscrew the 8 screws along the sides

(4 on the left, and 4 on the right) to open the unit.

3. Once unscrewed, lift the cover to open the unit.

Look at the top to see if the motor connection is properly connected.

STEP 1

STEP 2

STEP 3

Instruction Manual for P900-GX

1-888-726-8869www.sanuvox.com

WARRANTY

You should rst read all instructions before attempting to use this product.

For this warranty to be valid, keep a copy of the proof of purchase.

UV lamp 3 years

Ballast 3 years

Electronic components 3 years

A. This limited warranty applies to repair or replacement of product found to be defective in material or workmanship. This warranty does not apply to

damage resulting from abusive, unreasonable use or supplemental damage. Defects that are the result of normal wear and tear will not be considered

manufacturing defects under this warranty.

SANUVOX IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE, ANY IMPLIED WARRANTY OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.

Some jurisdictions do not allow the exclusion or limitation of incidential or consequential damages or limitation on how long an implied warranty last, so

the above limitations or exclusions may not apply to you. This warranty gives specic legal rights, and you also may have other rights which vary from

jurisdiction to jurisdiction. This warranty applies only to the original purchaser of this product from the original date of purchase.

B. At its option, SANUVOX will repair or replace this product if it is found to be defective in material or workmanship.

C. This warranty does not cover damage resulting from any unauthorized attempts to repair or from any use not in accordance with the instruction manual.

D. This warranty does not cover the lters, pre-lters, UV bulbs or other accessories (if included) except for material or workmanship defects.

Call us toll-free at 1-888-726-8869 or email: [email protected]

Please be sure to specify product name.
