SANY SCM2000C-8S Guide

Quality Changes the World
Milling Machine
SCM2000C-8S
Safety, Operation & Maintenance Manual

Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-April 2020
SCM2000C-8S Milling Machine
Safety, Operation & Maintenance Manual
WARNING
Read and follow the safety precautions and instructions in this manual and on the machine
decals. Failure to do so can cause serious injury, death or property damage. Keep this manual
with the machine for reading and future reference.
SCM2000C-8S Milling Machine
Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-April 2020
SCM2000C-8S Milling Machine
SANY Group
SANY Automobile Manufacturing CO., LTD
Sany Industry Zone, Economic & Technical Development Zone, Changsha, Hunan,
China 410100
Tel:[phone]
E-mail:[e-mail]
Website:www.sanyglobal.com
Scan here to download the Service Cloud APP
Android iOS
© 2020 by Sany Group. All rights reserved. No part of this publication may be reproduced, used, distributed
or disclosed except during normal operation of the machine as described herein. All information included
within this publication was accurate at the time of publication. Product improvements, revisions, etc., may
result in differences between your machine and what is presented here. Sany Group assumes no liability.
For more information, contact Sany Group.
Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-April 2020 1
DELINEATION OF RESPONSIBILITY
SPECIFIC DECLARATION
A milling machine is an engineering vehicle used for the recycling of road pavements. The milling
machine can mill off the asphalt layer and the cement concrete layer whose thickness is below
3cm for express highways, first-grade highways, municipal roads, airports, goods yard and parking
lots; can solve problems of cracks, tracks, looseness, sinkage and defunctionalization of the sur-
face on asphalt road pavements.; can efficiently handle problems of crown, pot holes, pitting sur-
face and exposed aggregate on cement concrete road pavements. After having been properly
converted, the milling machine can be used for mining on open mines. Any other use or any opera-
tion beyond the specified working range is not authorized use. Sany expressly bears no liability for
any consequence due to any unauthorized use.
Information in this manual is used to guide qualified operators to operate and maintain milling ma-
chines correctly. Sany expressly bears no liability for any consequence due to any use not observ-
ing the information in this manual.
It is forbidden to convert the milling machine without authorization. Sany expressly bears no liabil-
ity for any consequence. When crack or electrical malfunction on the milling machine occurs,
please contact the supplier, and don’t conduct welding or make changes without permission, or
else, for any consequence due to such contravention, Sany shall not bear any liability.
Use genuine spare parts from Sany. Sany expressly bears no liability for any machine damage or
accident due to the use of untested or unauthorized spare parts or tools.
Operate and maintain parts (such as engine) on the milling machine, and observe related regula-
tions on Users' guide supplied from their manufacturer.
Sany expressly bears no liability for any machine failure or damage due to force majeure of natural
disasters (earthquake, typhoon) and wars.
Sany cannot predict every circumstance that might involve a potential hazard in operation or main-
tenance. Operators and owners should highly attach importance to safety. Local specific safety
rules of the countries may be stricter. If they differ from the regulations in this manual, observe the
stricter one.
Duty of Sany
•Be responsible for providing qualified products and correct documents.
•Fulfill their promises on after-sales service, and document all maintenance and repair working
done by after-sales service personnel.
•Train the operation and maintenance personnel based on their needs.
SCM2000C-8S Milling Machine
Find manuals at https://best-manuals.com

2Safety, Operation and Maintenance Manual-April 2020
Duty of Owners or Other Authorized Personnel
•Only after each person involved in the product’s operation, maintenance and repair is trained
and fully understands the Parts Book and Operation and Maintenance Manual, can they operate
and maintain the milling machine.
•Ensure the operation and maintenance personnel are qualified and know their related
responsibilities.
•Periodically check related personnel's safety consciousness during working.
•If any fault which will lead to unsafety occurs, stop the milling machine immediately.
•If necessary Sany service personnel have the right to check the milling machine for safety.
•Besides check items regulated by Sany, observe local laws and regulations to check the milling
machine.
•Ensure timely maintenance and repair on the milling machine.
•Carefully plan the use of the milling machine.
Duty of all Working Personnel
•If there is any abnormal symptom which may cause abnormal working of the milling machine or
potential hazard, report to your leader. If possible, correct fault in time.
•All personnel working around the milling machine must observe all warning signals and take
care of their own and others' safety.
•All personnel should know their working tasks and procedures.
•Watch something like high voltage wire, unrelated personnel and poor ground for potential dan-
ger, and report to the operators and signalmen.
Duty of Managers
•Ensure the operators are trained and fully understand the Operation and Maintenance Manual
supplied by Sany. Ensure they are in physical fitness and have the certification of operation. Oth-
erwise, it is forbidden to operate the milling machine.
•Ensure the operators have good judgement ability, teamwork consciousness and psychological
quality. Otherwise, it is forbidden to operate or repair the milling machine.
•Ensure the signalmen have good vision and acoustic judgement, master standard command sig-
nals. At the same time, they should have enough experience in recognizing danger factors cor-
rectly, and inform the operators of danger factors to avoid them in time.
•Ensure assistant workers can identify the model and working condition to choose a proper mill-
ing machine.
•Publicize safety consciousness to working personnel, and make them aware of safety precau-
tions and their related responsibilities.
SCM2000C-8S Milling Machine
Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-April 2020 I
Table of Contents
1 Introduction........................................................................................................................1-1
1.1 Overview.................................................................................................................................1-3
1.2 Your Documentation Package.............................................................................................1-4
1.2.1 Introduction....................................................................................................................1-4
1.2.2 Recommendations on the Use of Data .....................................................................1-4
1.2.3 Storage of Data ............................................................................................................1-4
1.2.4 Structure of this User’s Guide ....................................................................................1-4
1.3 Your Sany Equipment...........................................................................................................1-6
1.3.1 Breaking in a New Equipment ....................................................................................1-6
1.3.2 Equipment Information ................................................................................................1-7
1.3.3 Equipment Directions...................................................................................................1-8
1.3.4 Serial Number and Distributor Information ...............................................................1-9
1.4 Contact Information ........................................................................................................... 1-10
2 Safety.....................................................................................................................................2-1
2.1 General ...................................................................................................................................2-5
2.1.1 Introduction....................................................................................................................2-5
2.1.2 Applicable Range of the Machine ..............................................................................2-7
2.1.3 Qualification Required for Working with the Machine .............................................2-8
2.1.4 Conversions and Alterations to the Machine ...........................................................2-8
2.2 Safety Message.....................................................................................................................2-9
2.2.1 Introduction....................................................................................................................2-9
2.2.2 Safety Message Introduction ......................................................................................2-9
2.2.3 Safety Alerts ............................................................................................................... 2-10
2.2.4 An Example of Safety Alerts .....................................................................................2-11
2.2.5 Location of Safety Decals..........................................................................................2-11
2.2.6 Introductions of Decals ............................................................................................. 2-13
2.3 General Precautions.......................................................................................................... 2-22
2.3.1 Safety Rules ............................................................................................................... 2-22
2.3.2 Abnormal Case .......................................................................................................... 2-22
2.3.3 Safety Devices ........................................................................................................... 2-23
2.3.4 Protective Measures for Personal Safety .............................................................. 2-23
2.3.5 Precautions Against Emergency............................................................................. 2-24
2.4 Precautions During Operation.......................................................................................... 2-27
2.4.1 Safe Starting............................................................................................................... 2-27
2.4.2 Requirements on Worksite....................................................................................... 2-30
2.4.3 Before Operation ....................................................................................................... 2-32
SCM2000C-8S Milling Machine Table of Contents
Find manuals at https://best-manuals.com

II Safety, Operation and Maintenance Manual-April 2020
2.4.4 Safe Traveling ............................................................................................................ 2-32
2.4.5 Safe Parking............................................................................................................... 2-36
2.5 Precautions for Using the Milling Drum........................................................................... 2-37
2.5.1 Falling Speed of the Milling Drum ........................................................................... 2-37
2.5.2 Unintended Use ......................................................................................................... 2-37
2.6 Maintenance Precautions ................................................................................................. 2-38
2.6.1 Basic Rules................................................................................................................. 2-38
2.6.2 Lockout/Tagout Procedures..................................................................................... 2-38
2.6.3 Maintenance Area ..................................................................................................... 2-38
2.6.4 Washing the Machine ............................................................................................... 2-39
2.6.5 Self-preparation ......................................................................................................... 2-39
2.6.6 Using the Tool Properly............................................................................................. 2-39
2.6.7 Maintenance with Engine Running ......................................................................... 2-40
2.6.8 Maintaining under the Machine ............................................................................... 2-41
2.6.9 Maintaining in Noisy Environment........................................................................... 2-41
2.6.10 Removing Paint before Welding or Heating ........................................................ 2-41
2.6.11 Correct Welding ....................................................................................................... 2-42
2.6.12 No Heating beside Hydraulic Pipeline.................................................................. 2-43
2.6.13 No Heating the Pipes with Combustible Liquid................................................... 2-43
2.6.14 Correctly Operating the Hydraulic System .......................................................... 2-44
2.6.15 Be Care of High-pressure Liquid........................................................................... 2-45
2.6.16 Regularly Replacing the Rubber Hoses............................................................... 2-46
2.6.17 Avoiding Scald by High-temperature Liquid ........................................................ 2-46
2.6.18 Preventing Battery from Explosion ....................................................................... 2-47
2.6.19 Preventing Components from Flying Out ............................................................ 2-48
2.6.20 Safe Storage of Parts ............................................................................................. 2-48
2.6.21 Safe Treatment of Liquid ........................................................................................ 2-49
2.6.22 Safe Treatment of Chemicals ................................................................................ 2-49
2.6.23 Proper Disposal of Wastes .................................................................................... 2-49
2.7 Safe Transportation ........................................................................................................... 2-50
2.7.1 Load/Unload the Machine ........................................................................................ 2-50
2.7.2 Transporting the Machine......................................................................................... 2-50
2.8 Hoisting the Machine ......................................................................................................... 2-51
2.9 Towing the Machine Safely............................................................................................... 2-51
3 System Functions...........................................................................................................3-1
3.1 General ...................................................................................................................................3-3
3.2 Control Panel .........................................................................................................................3-3
3.2.1 Introduction....................................................................................................................3-3
3.2.2 Right Control Panel ......................................................................................................3-4
3.2.3 Left Control Panel...................................................................................................... 3-12
Table of Contents SCM2000C-8S Milling Machine
Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-April 2020 III
3.2.4 Middle Control Console ............................................................................................ 3-14
3.2.5 Left front Ground Control Box.................................................................................. 3-19
3.2.6 Right front Ground Control Box ............................................................................... 3-20
3.2.7 Left rear Ground Control Box................................................................................... 3-21
3.2.8 Right rear Ground Control Box ................................................................................ 3-22
3.3 Levelling Controller ............................................................................................................ 3-23
3.3.1 Introduction................................................................................................................. 3-23
3.3.2 LED.............................................................................................................................. 3-23
3.3.3 Keys............................................................................................................................. 3-24
3.3.4 Functional Indicators................................................................................................. 3-24
3.4 Display ................................................................................................................................. 3-25
3.4.1 Introduction................................................................................................................. 3-25
3.4.2 Main Interface ............................................................................................................ 3-25
3.4.3 User Information Inquiry ........................................................................................... 3-31
3.4.4 System Status Inquiry............................................................................................... 3-34
3.4.5 Levelling System ....................................................................................................... 3-36
3.4.6 Milling Expert System ............................................................................................... 3-38
3.4.7 Milling Mode Shift ...................................................................................................... 3-39
3.5 Other Functions.................................................................................................................. 3-40
3.5.1 Hoisting Points ........................................................................................................... 3-40
4 Operation.............................................................................................................................4-1
4.1 Check before Starting the Engine.......................................................................................4-5
4.1.1 Check(Walk-around) ....................................................................................................4-5
4.1.2 Check before Starting ..................................................................................................4-5
4.2 Adjustment Prior to Startup................................................................................................4-11
4.2.1 Handrail Adjustment...................................................................................................4-11
4.2.2 Control Panel Adjustment ........................................................................................ 4-12
4.3 Operation Prior to Startup ................................................................................................. 4-12
4.3.1 Introduction................................................................................................................. 4-12
4.3.2 Activate Control System ........................................................................................... 4-12
4.3.3 Check Fuel Level....................................................................................................... 4-14
4.3.4 Check Horn................................................................................................................. 4-15
4.4 Engine Start-up................................................................................................................... 4-15
4.4.1 Normal Start-up ......................................................................................................... 4-15
4.4.2 Engine Emergency Mode......................................................................................... 4-16
4.4.3 Jump-start................................................................................................................... 4-17
4.4.4 Engine Warm-up........................................................................................................ 4-18
4.4.5 Engine Shutdown ..................................................................................................... 4-19
4.5 Running in the Machine..................................................................................................... 4-19
4.6 Move the Machine.............................................................................................................. 4-20
SCM2000C-8S Milling Machine Table of Contents
Find manuals at https://best-manuals.com

IV Safety, Operation and Maintenance Manual-April 2020
4.6.1 Precautions for Moving the Machine ...................................................................... 4-20
4.6.2 Move Forwards .......................................................................................................... 4-21
4.6.3 Move Backwards ...................................................................................................... 4-21
4.6.4 Steering....................................................................................................................... 4-22
4.6.5 Antislipping Function................................................................................................. 4-24
4.7 Machine Operation............................................................................................................. 4-25
4.7.1 One-key Start ............................................................................................................. 4-25
4.7.2 Sprinkler ON/OFF...................................................................................................... 4-26
4.7.3 Conveyor .................................................................................................................... 4-26
4.7.4 Side Plate LIFT/LOWER .......................................................................................... 4-29
4.7.5 Drum Scraper............................................................................................................. 4-31
4.7.6 Machine LIFT/LOWER ............................................................................................. 4-33
4.7.7 Covering Parts OPEN/CLOSED ............................................................................. 4-34
4.7.8 Canopy FOLD/UNFOLD........................................................................................... 4-35
4.7.9 Levelling Operation .................................................................................................. 4-35
4.8 Parking the Machine .......................................................................................................... 4-42
4.8.1 Stopping the Machine ............................................................................................... 4-42
4.8.2 Leaving the Machine................................................................................................. 4-44
4.9 Check after Operation ....................................................................................................... 4-45
4.10 Machine Transportation .................................................................................................. 4-45
4.10.1 Preparation before Loading ................................................................................... 4-45
4.10.2 Check before Loading ........................................................................................... 4-45
4.10.3 Loading ..................................................................................................................... 4-46
4.10.4 Transportation.......................................................................................................... 4-47
4.10.5 Unloading ................................................................................................................. 4-47
5 Maintenance.......................................................................................................................5-1
5.1 Maintenance Information .....................................................................................................5-5
5.1.1 Introduction....................................................................................................................5-5
5.1.2 Precautions on Engine Performance.........................................................................5-5
5.1.3 Precautions on Fuel System.......................................................................................5-5
5.1.4 Precautions on Hydraulic System ..............................................................................5-6
5.2 Fluid.........................................................................................................................................5-6
5.2.1 Engine Oil ......................................................................................................................5-6
5.2.2 Fuel.................................................................................................................................5-7
5.2.3 Hydraulic Oil ..................................................................................................................5-8
5.2.4 Lubricant ........................................................................................................................5-8
5.2.5 Grease ...........................................................................................................................5-8
5.2.6 Coolant...........................................................................................................................5-8
5.2.7 Filling Amount of Fuel/ Lubrication.......................................................................... 5-12
5.3 Maintenance ....................................................................................................................... 5-13
Table of Contents SCM2000C-8S Milling Machine
Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-April 2020 V
5.3.1 Introduction................................................................................................................. 5-13
5.3.2 Routine Maintenance................................................................................................ 5-13
5.3.3 Clean ........................................................................................................................... 5-14
5.3.4 Check .......................................................................................................................... 5-16
5.4 Initial 50h Maintenance ..................................................................................................... 5-39
5.4.1 Introduction................................................................................................................. 5-39
5.4.2 Milling Drum Gearbox ............................................................................................... 5-40
5.4.3 Fixation Points ........................................................................................................... 5-41
5.4.4 Milling Drum Bearing................................................................................................. 5-42
5.4.5 Engine Oil ................................................................................................................... 5-43
5.4.6 Engine Oil Filter Element.......................................................................................... 5-43
5.4.7 Fuel Filter.................................................................................................................... 5-44
5.4.8 Oil Water Separator................................................................................................... 5-45
5.4.9 Hydraulic Oil Filter .................................................................................................... 5-46
5.4.10 Transfer Case .......................................................................................................... 5-46
5.4.11 Drive Belt Tension.................................................................................................... 5-48
5.4.12 Advance Drive Gearbox ........................................................................................ 5-51
5.5 Every 100h Maintenance .................................................................................................. 5-52
5.6 Every 250h Maintenance .................................................................................................. 5-52
5.7 Every 500h Maintenance .................................................................................................. 5-52
5.7.1 Introduction................................................................................................................. 5-52
5.7.2 Battery......................................................................................................................... 5-53
5.8 Every 1000h Maintenance ................................................................................................ 5-54
5.8.1 Introduction................................................................................................................. 5-54
5.8.2 Hydraulic Oil ............................................................................................................... 5-54
5.8.3 Hydraulic Oil Filter Element ..................................................................................... 5-56
5.9 Every Year Maintenance ................................................................................................... 5-56
5.10 Maintenance for Long Time Storage............................................................................. 5-56
6 Troubleshooting ..............................................................................................................6-1
6.1 Mechanical System...............................................................................................................6-3
6.1.1 Diesel Engine ................................................................................................................6-3
6.1.2 Sealing Elements..........................................................................................................6-8
6.2 Hydraulic System ..................................................................................................................6-9
6.2.1 Axial Plunger Pump......................................................................................................6-9
6.2.2 Axial Plunger Motor................................................................................................... 6-12
6.2.3 Reducer ...................................................................................................................... 6-14
6.2.4 Change Valve............................................................................................................. 6-16
6.2.5 Relief Valve................................................................................................................. 6-17
6.2.6 Cylinder....................................................................................................................... 6-21
6.2.7 Oil Filter....................................................................................................................... 6-26
SCM2000C-8S Milling Machine Table of Contents

VI Safety, Operation and Maintenance Manual-April 2020
6.2.8 Accumulator ............................................................................................................... 6-27
6.2.9 Cooler.......................................................................................................................... 6-27
6.2.10 Other Faults ............................................................................................................. 6-27
6.3 Electrical System................................................................................................................ 6-33
6.3.1 Engine and Battery.................................................................................................... 6-33
6.3.2 Advance Drive System ............................................................................................. 6-33
6.3.3 Steering System ........................................................................................................ 6-34
6.3.4 Working Mechanism Control System ..................................................................... 6-34
6.3.5 Lights, Alarms and Auxiliary System ...................................................................... 6-35
6.4 Water System ..................................................................................................................... 6-35
7 Technical Specifications.............................................................................................7-1
7.1 Dimension of the Machine ...................................................................................................7-3
7.2 Technical Parameters...........................................................................................................7-4
Table of Contents SCM2000C-8S Milling Machine

Safety, Operation and Maintenance Manual-April 2020 1-1
Introduction
1 Introduction........................................................................................................................1-1
1.1 Overview.................................................................................................................................1-3
1.2 Your Documentation Package.............................................................................................1-4
1.2.1 Introduction ..................................................................................................................1-4
1.2.2 Recommendations on the Use of Data ....................................................................1-4
1.2.3 Storage of Data ..........................................................................................................1-4
1.2.4 Structure of this User’s Guide ..................................................................................1-4
1.3 Your Sany Equipment...........................................................................................................1-6
1.3.1 Breaking in a New Equipment ...................................................................................1-6
1.3.2 Equipment Information ...............................................................................................1-7
1.3.3 Equipment Directions .................................................................................................1-8
1.3.4 Serial Number and Distributor Information..............................................................1-9
1.4 Contact Information ........................................................................................................... 1-10
SCM2000C-8S Milling Machine Introduction

1-2 Safety, Operation and Maintenance Manual-April 2020
WARNING
Read and understand all safety precautions and instructions in this manual before reading any
other manuals provided with this machine and before operation or maintaining it.Failure to do
this could result in death or serious injury.
Introduction SCM2000C-8S Milling Machine

Safety, Operation and Maintenance Manual-April 2020 1-3
1.Introduction
1.1 Overview
•Sany-built equipment offers high-quality
performance and excellent after-sales serv-
ice support.
Fig.1-1
•Sany-built equipment is widely used
throughout the industry for various types of
applications.
•Sany is a leading manufacturer of heavy
construction equipment worldwide.
This operator's manual provides safety, oper-
ation, maintenance, troubleshooting and tech-
nical specifications. In order to properly use
your equipment, it is important to read this
manual carefully before beginning any
operations.
Items addressed in this manual are designed
to help you:
•Understand the structure and performance
of your machine.
•Reduce improper operation and point out
possible hazardous situations when using
equipment.
•Increase equipment efficiency during
operation.
•Prolong the service life of your equipment.
•Reduce maintenance costs.
Always keep this manual nearby and have all
personnel involved with any work operations
read it periodically.
If you sell the equipment, be sure to give this
manual to the new owner.
Continuing improvements in the design can
lead to changes in detail which may not be re-
flected in this manual. Always consult your
Sany distributor for the latest available infor-
mation on your equipment or if you have
SCM2000C-8S Milling Machine Introduction

1-4 Safety, Operation and Maintenance Manual-April 2020
questions regarding information in this
manual.
1.2 Your Documentation Package
1.2.1 Introduction
The attached data includes:
•User’s Guide;
•Spare Parts Drawing Volume: including the
Parts List and the drawings needed when
ordering parts. If the Spare Parts Drawing
Volume is not attached with the equipment,
contact Sany.
1.2.2 Recommendations on the Use of
Data
•The documents only apply to the equipment
herein.
•Ensure the documents are complete and
are the latest editions.
•Put all data in a folder (if including leaflets)
and print and replace the lost, damaged
and blotted documents.
•Add the latest Sany data in time and de-
stroy the inapplicable old documents.
1.2.3 Storage of Data
•Put this User’s Guide and the Load Table in
the equipment operation room;
•You’d better put the Spare Parts Drawing
Volume in the maintenance area or office to
enable the maintenance personnel to find it
at any time.
1.2.4 Structure of this User’s Guide
This User’s Guide covers use and mainte-
nance of your equipment. Get familiar with it
before performing any operations. Put this
Introduction SCM2000C-8S Milling Machine

Safety, Operation and Maintenance Manual-April 2020 1-5
manual within easy reach for your reference.
Replace it if it is lost or damaged. Due to im-
provement and updating of products, some in-
formation may differ from your equipment. If
you have any question on your equipment,
contact your Sany distributor before operating
or maintaining the equipment.
1. Introduction
This section provides an overview of what is
covered in the rest of this manual, including
machine label information and Sany contact
information.
2. Safety
This section covers basic safety information
relating to this equipment. Make sure you fully
understand all the precautions described in
this manual and the safety labels on the ma-
chine before operating or maintaining this ma-
chine. Failure to do so may result in serious
injury or death.
3. System Functions
This section provides an overview of all the
controls and prompt & operating systems on
your equipment. Only when you are familiar
with all systems, can you operate and main-
tain the equipment safely.
4. Operation
This section provides the basic operating pro-
cedures for the job. It is important to study
and become familiar with all procedures be-
fore performing any operations with the
equipment.
5. Maintenance
This section provides all general maintenance
and repair procedures. It is important to study
and become familiar with all the maintenance
and repair procedures before performing any
SCM2000C-8S Milling Machine Introduction

1-6 Safety, Operation and Maintenance Manual-April 2020
maintenance or repair operations on the
equipment.
6. Troubleshooting
This section outlines common malfunctions
and fault diagnostic procedures for the operat-
ing system. Basic mechanical, hydraulic and
electrical system troubleshooting is included.
7. Technical Specifications
This section provides the basic performance
parameters of this equipment.
Some information may change as design
modification.
1.3 Your Sany Equipment
1.3.1 Breaking in a New Equipment
Your equipment has been well adjusted and
tested before delivery, but the initial operation
on the machine in severe conditions will seri-
ously affect the performance or reduce the
service life of the machine. Thus Sany recom-
mends you to perform 100-hour test run be-
fore putting the equipment into production
use.
During the test run:
•Preheat the equipment before performing
any operations.
•Avoid operating or running the equipment at
a high speed in overload working
conditions.
•Avoid sudden starting, rapid movement or
abrupt stop of the equipment.
•Cool down the equipment system at the
end of every working day.
Introduction SCM2000C-8S Milling Machine

Safety, Operation and Maintenance Manual-April 2020 1-7
1.3.2 Equipment Information
The factory numbers (serial numbers) and
models on the data plate are important num-
bers required for ordering replacement parts
or requiring assistance for your equipment.
So please write down the related information
in this manual for further use (see: “Serial
Number and Distributor Information” on page
1-9).
The data plate is riveted on the left side of the
front frame.
Fig.1-2
SCM2000C-8S Milling Machine Introduction

1-8 Safety, Operation and Maintenance Manual-April 2020
1.3.3 Equipment Directions
Fig.1-3
1. Front
2. Back
3. Left
4. Right
1
2
3
4
Introduction SCM2000C-8S Milling Machine
