SANY STR30C-8 Guide

STR30C-8
Quality Changes the World
Tandem Roller
Safety, Operation & Maintenance Manual

Find manuals at https://best-manuals.com

STR30C-8 Tandem Roller
Safe, Operation and Maintenance Manual
STR30C-8 Tandem Roller
Read and follow the safety precautions and instructions in this manual and on the machine
decals. Failure to do can cause serious injury, death or property damage. Keep this
manual with the machine for reading and future reference.
WARNING
Safety, Operation & Maintenance Manual - October 2019
Find manuals at https://best-manuals.com

Safety, Operation & Maintenance Manual - October 2019
SANY GROUP
SANY AUTOMOBILE MANUFACTURING CO., LTD.
SANY Industry Town,
Economic and Technological Development Zone,
Changsha, Hunan China 410100
http://www.sanygroup.com
Tel: [phone]
Fax: [phone]
Service E-mail: [e-mail]
Service Hotline : [phone]
WARNING
CALIFORNIA PROPOSITION 65 WARNING
Diesel engine exhaust and some of its constituents are known to the State of
California to cause cancer, birth defects, and other reproductive harm.
WARNING
CALIFORNIA PROPOSITION 65 WARNING
The battery posts, terminals, and related accessories contains chemical lead and
lead compounds, chemicals known to the State of California to cause cancer,
birth defects or other reproductive harm. Wash hands after handling.
©2019 by SANY Group. All rights reserved. No part of this publication may be
reproduced,used, distributed or disclosed except during normal operation of the
machine as described herein. All information included within this publication was
accurate at the time of publication. Product improvements, revisions, etc., may result in
differences between your machine and what is presented here. SANY Group assumes
no liability. For more information,contact SANY Group.
STR30C-8 Tandem Roller
Scan here to download the Service Cloud APP
Android iOS
Find manuals at https://best-manuals.com

Responsibility
Safety, Operation & Maintenance Manual - October 2019
STR30C-8 Tandem Roller
DELINEATION OF RESPONSIBILITY
SPECIFIC DECLARATION
Tandem roller is used to compact sand soil and sand gravel in the construction of roads and
foundations, which are suitable for most types of road construction, airfi lds, dam construction
and harbor projects. Any other use or any operation beyond the specified working range is not
authorized use. Sany expressly bears no liability for any consequence due to any unauthorized
use.
Information on this manual is used to guide qualified operators to operate and maintain rollers
correctly. Sany expressly bears no liability for any consequence due to any use not observing the
information on this manual.
It is forbidden to convert the roller without authorization.Sany expressly bears no liability
for any consequence. When crack or electrical malfunction on the roller occurs, please contact
the supplier, and don’t conduct welding or make changes without permission, or else, for any
consequence due to such contravention, Sany shall not bear any liability.
Use genuine spare parts from Sany. Sany expressly bears no liability for any machine
damage or accident due to the use of untested or unauthorized spare parts or tools.
Operate and maintain parts (such as engine, a/c) on the roller, and observe related
regulations on Users' guide supplied from their manufacturer.
Sany expressly bears no liability for any machine failure or damage due to force majeure of
natural disasters (earthquake, typhoon) and wars.
Sany cannot predict every circumstance that might involve a potential hazard in operation
or maintenance. Operators and owners should highly attach importance to safety. Local specific
safety rules of the countries may be stricter. If they differ from the regulations on this manual,
observe the stricter one.
Duty of Sany
• Be responsible for providing qualified products and correct documents
• Fulfill their promises on after-sales service, and document all maintenance and repair working
done by after-sales service personnel.
• Train the operation and maintenance personnel based on their needs.
Duty of owners or other anthorized personnel
•Only after each person involved in the product’s operation, maintenance and repair is trained
and fully understands the Parts Book and Operation and Maintenance Manual, can they
operate and maintain the roller.
•Ensure the operation and maintenance personnel are qualified and know their related
responsibilities.
Find manuals at https://best-manuals.com

STR30C-8 Tandem Roller
Responsibility
Safety, Operation & Maintenance Maunal - October 2019
• Periodically check related personnel's safety consciousness during working.
• If any fault which will lead to unsafety occurs, stop the roller immediately.
• If necessary Sany service personnel have the right to check the roller for safety.
•Besides check items regulated by Sany, observe local laws and regulations to check the
roller.
• Ensure timely maintenance and repair on the roller.
• Carefully plan the use of the roller.
Duty of all working personnel
• If there is any abnormal symptom which may cause abnormal working of the roller or potential
hazard, report to your leader. If possible, correct fault in time.
•All personnel working around the roller must observe all warning signals and take care of their
own and others' safety.
• All personnel should know their working tasks and procedures.
•Watch something like high voltage wire, unrelated personnel and poor ground for potential
danger, and report to the operators and signalmen.
Duty of managers
•Ensure the operators are trained and fully understand the Operation and Maintenance Manual
supplied by Sany. Ensure they are in physical fitness and have the certification of operation.
Otherwise, it is forbidden to operate the roller.
•Ensure the operators have good judgement ability, teamwork consciousness and
psychological quality. Otherwise, it is forbidden to operate or repair the roller.
•Ensure the signalmen have good vision and acoustic judgement, master standard command
signals. At the same time, they should have enough experience in recognizing danger factors
correctly, and inform the operators of danger factors to avoid them in time.
•Ensure assistant workers can identify the model and working condition to choose a proper
roller.
•Publicize safety consciousness to working personnel, and make them aware of safety
precations and their related responsibilities.
Find manuals at https://best-manuals.com
