SANY SSR200C-8H Guide

Quality Changes the World
Single Drum Roller
SSR200C-8H
SSR220C-8H
Safety, Operation and Maintenance Manual

Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-Jan. 2019
SSR200/220 Series Single Drum
Roller
Safety, Operation and Maintenance Manual
WARNING
Read and follow the safety precautions and instructions in this manual and on the machine
decals. Failure to do can cause serious injury, death or property damage. Keep this manual with
the machine for reading and future reference.
SSR200/220 Series Single Drum Roller
Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-Jan. 2019
SSR200/220 Series Single Drum Roller
Sany Group
SANY Automobile Manufacturing CO.,LTD
Sany Industry Zone
Economic & Technical Development Zone
Changsha, Hunan, China 410100
http://www.sanygroup.com
Tel: [phone]
Scan here to download the Service Cloud APP
Android iOS
©2019 by Sany Group. All rights reserved. No part of this publication may be reproduced, used, distributed
or disclosed except during normal operation of the machine as described herein. All information included
within this publication was accurate at the time of publication. Product improvements, revisions, etc., may
result in differences between your machine and what is presented here. Sany Group assumes no liability.
For more information, contact Sany Group.
Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-Jan. 2019 1
RESPONSIBILITY
SPECIFIC DECLARATION
The single drum roller is used to compact sand soil and sand gravel in the construction of roads
and foundations, which are suitable for most types of road construction, airfields, dam construction
and harbor projects. Any other use or any operation beyond the specified working range is not au-
thorized use. Sany expressly bears no liability for any consequence due to any unauthorized use.
Information on this manual is used to guide qualified operators to operate and maintain rollers cor-
rectly. Sany expressly bears no liability for any consequence due to any use not observing the in-
formation on this manual.
It is forbidden to convert the roller without authorization. Sany expressly bears no liability for any
consequence. When crack or electrical malfunction on the roller occurs, please contact the suppli-
er, and don’t conduct welding or make changes without permission, or else, for any consequence
due to such contravention, Sany shall not bear any liability.
Use genuine spare parts from Sany. Sany expressly bears no liability for any machine damage or
accident due to the use of untested or unauthorized spare parts or tools.
Operate and maintain parts (such as engine, a/c) on the roller, and observe related regulations on
Users' guide supplied from their manufacturer.
Sany expressly bears no liability for any machine failure or damage due to force majeure of natural
disasters (earthquake, typhoon) and wars.
Sany can not predict every circumstance that might involve a potential hazard in operation or main-
tenance. Operators and owners should highly attach importance to safety. Local specific safety
rules of the countries may be stricter. If they differ from the regulations in this manual, observe the
stricter one.
Duty of Sany
•Be responsible for providing qualified products and correct documents.
•Fulfill their promises on after-sales service, and document all maintenance and repair working
done by after-sales service personnel.
•Train the operation and maintenance personnel based on their needs.
Duty of owners or other authorized personnel
•Only after each person involved in the product’s operation, maintenance and repair is trained
and fully understands the Parts Book and Operation and Maintenance Manual, can they operate
and maintain the roller.
SSR200/220 Series Single Drum Roller
Find manuals at https://best-manuals.com

2Safety, Operation and Maintenance Manual-Jan. 2019
•Ensure the operation and maintenance personnel are qualified and know their related
responsibilities.
•Periodically check related personnel's safety consciousness during working.
•If any fault which will lead to unsafe situation occurs, stop the roller immediately
•If necessary Sany service personnel have the right to check the roller for safety.
•Besides check items regulated by Sany, observe local laws and regulations to check the roller.
•Ensure timely maintenance and repair on the roller.
•Carefully plan the use of the roller.
Duty of All Working Personnel
•If there is any abnormal symptom which may cause abnormal working of the roller or potential
hazard, report to your leader. If possible, correct fault in time.
•All personnel working around the roller must observe all warning signals and take care of their
own and others' safety.
•All personnel should know their working tasks and procedures.
•Watch something like high voltage wire, unrelated personnel and poor ground for potential
danger, and report to the operators and signalmen.
Duty of Managers
•Ensure the operators are trained and fully understand the Safety, Operation and Maintenance
Manual supplied by Sany. Ensure they are in physical fitness and have the certification of
operation. Otherwise, it is forbidden to operate the roller.
•Ensure the operators have good judgement, teamwork consciousness and psychological
quality. Otherwise, it is forbidden to operate or repair the roller.
•Ensure the signalmen have good vision and acoustic judgement, master standard command
signals. At the same time, they should have enough experience in recognizing danger factors
correctly, and inform the operators of danger factors to avoid them in time.
•Ensure assistant workers can identify the model and working condition to choose a proper roller.
•Publicize safety consciousness to working personnel, and make them aware of safety
precautions and their related responsibilities.
SSR200/220 Series Single Drum Roller
Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-Jan. 2019 I
Table of Contents
1 Introduction........................................................................................................................1-1
1.1 Overview.................................................................................................................................1-3
1.2 Your Documentation Package.............................................................................................1-4
1.2.1 Introduction....................................................................................................................1-4
1.2.2 Recommendations on Using the Documentation ....................................................1-4
1.2.3 Documentation Storage...............................................................................................1-4
1.2.4 Organization of this Manual ........................................................................................1-4
1.3 Your SANY Equipment .........................................................................................................1-6
1.3.1 Equipment Directions...................................................................................................1-6
1.3.2 Breaking in a New Equipment ....................................................................................1-7
1.3.3 Equipment Information ................................................................................................1-8
1.3.4 Serial Number and Distributor Information ...............................................................1-9
1.4 Contact Information ........................................................................................................... 1-10
2 Safety.....................................................................................................................................2-1
2.1 General...................................................................................................................................2-5
2.1.1 Introduction....................................................................................................................2-5
2.1.2 Intended Use.................................................................................................................2-7
2.1.3 Unintended Use ............................................................................................................2-7
2.1.4 Qualifications of Operators and Maintainers ............................................................2-8
2.1.5 Unauthorized Modification ..........................................................................................2-8
2.2 Safety Message.....................................................................................................................2-9
2.2.1 Introduction....................................................................................................................2-9
2.2.2 Safety Message Introduction ......................................................................................2-9
2.2.3 Safety Message Locations....................................................................................... 2-10
2.2.4 Signal Words...............................................................................................................2-11
2.2.5 An Example of Signal Words ................................................................................... 2-12
2.2.6 Safety Decals ............................................................................................................. 2-12
2.3 General Precautions.......................................................................................................... 2-17
2.3.1 Safety Rules ............................................................................................................... 2-17
2.3.2 Abnormal Case .......................................................................................................... 2-18
2.3.3 Safety Devices ........................................................................................................... 2-18
2.3.4 Protective Measures for Personal Safety .............................................................. 2-18
2.3.5 Precautions Against Emergency............................................................................. 2-20
2.4 Precautions During Operation.......................................................................................... 2-23
2.4.1 Safe Starting............................................................................................................... 2-23
2.4.2 Safe Operation........................................................................................................... 2-27
SSR200/220 Series Single Drum Roller Table of Contents
Find manuals at https://best-manuals.com

II Safety, Operation and Maintenance Manual-Jan. 2019
2.4.3 Safe Parking............................................................................................................... 2-34
2.5 Maintenance Precautions ................................................................................................. 2-35
2.5.1 Basic Rules................................................................................................................. 2-35
2.5.2 Lockout/Tagout Procedures..................................................................................... 2-35
2.5.3 Working Area Preparation........................................................................................ 2-36
2.5.4 Washing the Equipment ........................................................................................... 2-37
2.5.5 Self-preparation ......................................................................................................... 2-37
2.5.6 Proper Tool ................................................................................................................. 2-38
2.5.7 Maintenance with Engine Running ......................................................................... 2-38
2.5.8 Working under the Roller.......................................................................................... 2-39
2.5.9 Working in Noisy Environment ................................................................................ 2-40
2.5.10 Removing Paint before Welding or Heating ........................................................ 2-40
2.5.11 Correct Welding ....................................................................................................... 2-41
2.5.12 No Heating beside Hydraulic Pipeline.................................................................. 2-42
2.5.13 No Heating the Pipes with Combustible Liquid................................................... 2-42
2.5.14 Correctly Operating the Hydraulic System .......................................................... 2-43
2.5.15 Being Aware of High-pressure Liquid................................................................... 2-44
2.5.16 Regularly Replacing the Rubber Hoses............................................................... 2-45
2.5.17 Avoiding Scald by High-temperature Liquid ........................................................ 2-45
2.5.18 Preventing Battery from Explosion ....................................................................... 2-46
2.5.19 Preventing Components from Flying Out ............................................................ 2-47
2.5.20 Safe Storage of Parts ............................................................................................. 2-47
2.5.21 Safe Treatment of Liquid ........................................................................................ 2-48
2.5.22 Safe Treatment of Chemicals ................................................................................ 2-48
2.5.23 Proper Disposal of Wastes .................................................................................... 2-48
2.6 Safe Transportation ........................................................................................................... 2-49
2.6.1 Load/Unload the Roller............................................................................................. 2-49
2.6.2 Transport the Roller................................................................................................... 2-50
2.6.3 Lift the Roller .............................................................................................................. 2-51
3 System functions ............................................................................................................3-1
3.1 Exterior Components............................................................................................................3-3
3.2 Control Console and Display...............................................................................................3-4
4 Operation.............................................................................................................................4-1
4.1 Check before Starting the Engine.......................................................................................4-5
4.1.1 Inspection (walk-around).............................................................................................4-5
4.1.2 Inspection before Starting ...........................................................................................4-6
4.2 Adjustments Prior to Startup............................................................................................. 4-13
4.2.1 Seat Adjustment ........................................................................................................ 4-13
4.2.2 Rearview Mirror Adjustment .................................................................................... 4-13
Table of Contents SSR200/220 Series Single Drum Roller
Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-Jan. 2019 III
4.3 Equipment Check Prior to Startup ................................................................................... 4-14
4.3.1 Introduction................................................................................................................. 4-14
4.3.2 Power on the Control System .................................................................................. 4-14
4.3.3 Check the Fuel Level ................................................................................................ 4-16
4.3.4 Check the Propel Control Lever .............................................................................. 4-17
4.3.5 Check the Emergency Stop Switch ........................................................................ 4-17
4.3.6 Check the Park Brake Switch .................................................................................. 4-18
4.3.7 Check other Switches (if any) .................................................................................. 4-18
4.4 Engine Starting ................................................................................................................... 4-19
4.4.1 Introduction................................................................................................................. 4-19
4.4.2 Normal Start ............................................................................................................... 4-19
4.4.3 Jump-start................................................................................................................... 4-19
4.4.4 Engine Start in Cold Weather (optional)................................................................. 4-20
4.5 After Engine Starting.......................................................................................................... 4-20
4.6 Test Running....................................................................................................................... 4-21
4.7 Travel Operation................................................................................................................. 4-22
4.7.1 Travel Forward........................................................................................................... 4-22
4.7.2 Travel Backward ........................................................................................................ 4-22
4.8 Vibration Operation............................................................................................................ 4-22
4.9 Parking Operation .............................................................................................................. 4-23
4.9.1 Service Brake............................................................................................................. 4-23
4.9.2 Park Brake.................................................................................................................. 4-24
4.9.3 Emergency Brake...................................................................................................... 4-25
4.10 Correct Driving According to the Road Condition ....................................................... 4-26
4.10.1 Working near Ditch Edge and Road Shoulder.................................................... 4-26
4.10.2 Working near Buildings Vulnerable to Vibration ................................................. 4-26
4.10.3 Working on the Slope ............................................................................................. 4-27
4.11 Check after Each Work Day ........................................................................................... 4-28
4.12 Transportation .................................................................................................................. 4-28
4.12.1 Transport Vehicle .................................................................................................... 4-28
4.12.2 Using a Slope........................................................................................................... 4-29
4.12.3 Shipping.................................................................................................................... 4-30
5 Maintenance.......................................................................................................................5-1
5.1 Maintenance Information .....................................................................................................5-5
5.1.1 Introduction....................................................................................................................5-5
5.1.2 Checks before Maintenance .......................................................................................5-5
5.1.3 Checks after Maintenance or Repairs .......................................................................5-7
5.1.4 Hour Meter Reading.....................................................................................................5-8
5.1.5 Genuine SANY Replacement Parts...........................................................................5-8
5.1.6 SANY Approved Lubricants ........................................................................................5-8
SSR200/220 Series Single Drum Roller Table of Contents
Find manuals at https://best-manuals.com

IV Safety, Operation and Maintenance Manual-Jan. 2019
5.1.7 Windshield Washer Fluid.............................................................................................5-8
5.1.8 Grease ...........................................................................................................................5-8
5.1.9 Oil and Filter Inspection...............................................................................................5-9
5.1.10 Welding on the Machine............................................................................................5-9
5.1.11 Inventory Your Tools and Parts.............................................................................. 5-10
5.1.12 Cleaning Parts of the Machine .............................................................................. 5-10
5.1.13 Adverse Work Site Conditions............................................................................... 5-10
5.1.14 Covers and Locks.....................................................................................................5-11
5.1.15 Hydraulic Hoses, Lines or Components ...............................................................5-11
5.1.16 Torque Values ...........................................................................................................5-11
5.1.17 Notes on Maintenance............................................................................................ 5-13
5.1.18 Notes on Fuel System ............................................................................................ 5-14
5.1.19 Notes on Engine Performance .............................................................................. 5-14
5.1.20 Notes on Hydraulic System ................................................................................... 5-15
5.2 Requirements on use of oil & fluid ................................................................................... 5-16
5.2.1 Introduction of Functional Oil & Fluids.................................................................... 5-16
5.2.2 Oil & Fluids Selection................................................................................................ 5-19
5.2.3 Filling Capacities ....................................................................................................... 5-27
5.3 Test Run Instructions ......................................................................................................... 5-28
5.4 Maintenance ....................................................................................................................... 5-29
5.5 Roller Maintenance Locations.......................................................................................... 5-30
5.6 Daily Maintenance ............................................................................................................. 5-31
5.6.1 Introduction................................................................................................................. 5-31
5.6.2 Secure the Machine for Maintenance..................................................................... 5-31
5.6.3 Clean ........................................................................................................................... 5-33
5.6.4 Check .......................................................................................................................... 5-35
5.6.5 Drain-Oil Water Separator........................................................................................ 5-53
5.6.6 Fill-Windshield Washer Fluid ................................................................................... 5-54
5.7 Initial 50 Hour Maintenance.............................................................................................. 5-54
5.7.1 Introduction................................................................................................................. 5-54
5.7.2 Secure the Machine for Maintenance..................................................................... 5-55
5.7.3 Change........................................................................................................................ 5-56
5.7.4 Check .......................................................................................................................... 5-65
5.8 Initial 250 Hour Maintenance............................................................................................ 5-66
5.8.1 Introduction................................................................................................................. 5-66
5.8.2 Replace-lubricant for Drum ...................................................................................... 5-66
5.9 Every 250 Hour Maintenance........................................................................................... 5-66
5.9.1 Introduction................................................................................................................. 5-66
5.9.2 Secure the Machine for Maintenance..................................................................... 5-66
5.9.3 Replace-engine Oil.................................................................................................... 5-67
5.9.4 Replace-engine Oil Filter Element .......................................................................... 5-67
Table of Contents SSR200/220 Series Single Drum Roller
Find manuals at https://best-manuals.com

Safety, Operation and Maintenance Manual-Jan. 2019 V
5.9.5 Replace-fuel Filter ..................................................................................................... 5-68
5.9.6 Replace-oil Water Separator ................................................................................... 5-68
5.10 Every 500 Hour Maintenance......................................................................................... 5-69
5.10.1 Introduction .............................................................................................................. 5-69
5.10.2 Secure the Machine ................................................................................................ 5-69
5.10.3 Fill .............................................................................................................................. 5-71
5.10.4 Replace..................................................................................................................... 5-72
5.10.5 Check ........................................................................................................................ 5-73
5.11 Every 1000 Hour Maintenance....................................................................................... 5-74
5.11.1 Introduction............................................................................................................... 5-74
5.11.2 Secure the Machine for Maintenance................................................................... 5-74
5.11.3 Check/Maintain-A/C (If Equipped) ........................................................................ 5-75
5.11.4 Replace..................................................................................................................... 5-82
5.12 Others ................................................................................................................................ 5-89
5.12.1 Introduction .............................................................................................................. 5-89
5.12.2 Clean-fuel Tank........................................................................................................ 5-89
5.12.3 Clean-fuel Radiator ................................................................................................. 5-90
5.13 Maintenance for long-time storage................................................................................ 5-92
5.13.1 Engine....................................................................................................................... 5-92
5.13.2 Complete Machine .................................................................................................. 5-93
5.14 Antifreezing Maintenance ............................................................................................... 5-94
5.15 Check after Maintenance................................................................................................ 5-94
6 Troubleshooting ..............................................................................................................6-1
6.1 Mechanical Parts...................................................................................................................6-3
6.1.1 Engine ............................................................................................................................6-3
6.1.2 Vibratory Drum..............................................................................................................6-6
6.1.3 Propel System...............................................................................................................6-8
6.1.4 Brake ..............................................................................................................................6-9
6.2 Typical Hydraulic Elements .................................................................................................6-9
6.2.1 Introduction....................................................................................................................6-9
6.2.2 Axial Plunger Pump................................................................................................... 6-10
6.2.3 Axial Plunger Motor................................................................................................... 6-13
6.2.4 Change Valve............................................................................................................. 6-15
6.2.5 Overflow Valve ........................................................................................................... 6-19
6.2.6 Steering Cylinder ....................................................................................................... 6-22
6.2.7 Oil Filter....................................................................................................................... 6-27
6.2.8 Sealing Elements....................................................................................................... 6-28
6.2.9 Hydraulic Steering Gear ........................................................................................... 6-30
6.3 Electrical Parts.................................................................................................................... 6-32
6.3.1 Basic Electrical System ............................................................................................ 6-32
SSR200/220 Series Single Drum Roller Table of Contents

VI Safety, Operation and Maintenance Manual-Jan. 2019
6.3.2 Electrical System of Working Devices.................................................................... 6-34
6.3.3 Fuses........................................................................................................................... 6-35
6.3.4 Radio ........................................................................................................................... 6-36
6.4 Air Conditioning System.................................................................................................... 6-37
6.4.1 Introduction................................................................................................................. 6-37
6.4.2 System with Poor Cooling ........................................................................................ 6-38
6.4.3 Insufficient System Cooling...................................................................................... 6-39
6.4.4 Abnormal Noise Caused by Cooling System ........................................................ 6-42
6.4.5 Air Heating Device Fault........................................................................................... 6-43
6.4.6 Other Faults................................................................................................................ 6-43
6.5 Troubleshooting Examples ............................................................................................... 6-46
7 Specifications ...................................................................................................................7-1
7.1 Dimension of the Equipment ...............................................................................................7-3
7.2 Specifications of the Equipment..........................................................................................7-4
Table of Contents SSR200/220 Series Single Drum Roller

Safety, Operation and Maintenance Manual-Jan. 2019 1-1
Introduction
1 Introduction........................................................................................................................1-1
1.1 Overview.................................................................................................................................1-3
1.2 Your Documentation Package.............................................................................................1-4
1.2.1 Introduction ..................................................................................................................1-4
1.2.2 Recommendations on Using the Documentation...................................................1-4
1.2.3 Documentation Storage .............................................................................................1-4
1.2.4 Organization of this Manual.......................................................................................1-4
1.3 Your SANY Equipment .........................................................................................................1-6
1.3.1 Equipment Directions .................................................................................................1-6
1.3.2 Breaking in a New Equipment ...................................................................................1-7
1.3.3 Equipment Information ...............................................................................................1-8
1.3.4 Serial Number and Distributor Information..............................................................1-9
1.4 Contact Information ........................................................................................................... 1-10
SSR200/220 Series Single Drum Roller Introduction

1-2 Safety, Operation and Maintenance Manual-Jan. 2019
WARNING
Read and understand all safety precautions and instructions in this manual before reading any
other manuals provided with this machine and before operation or maintaining it.Failure to do
this could result in death or serious injury.
Introduction SSR200/220 Series Single Drum Roller

Safety, Operation and Maintenance Manual-Jan. 2019 1-3
1.Introduction
1.1 Overview
Fig.1-1
•SANY-built equipment offers high-quality
performance and excellent after-sales
service support.
•Sany-built equipment is widely used
throughout the industry for various types of
applications.
•Sany is a leading manufacturer of heavy
construction machine worldwide.
This operator’s manual provides safety, oper-
ation, maintenance, troubleshooting and
specifications. In order to properly use your
equipment, it is important to read and under-
stand this manual before using the
equipment.
Items addressed in this manual are designed
to help you:
•Understand the structure and performance
of your equipment.
•Reduce improper operation and point out
possible hazardous situations when using
equipment.
•Increase equipment efficiency during
operation.
•Prolong the service life of your equipment.
•Reduce maintenance costs.
Always keep this manual nearby and have all
personnel involved with any work operations
read it periodically. If this manual becomes
damaged or lost and cannot be read, it is ad-
vised to request a replacement copy from
your SANY distributor as soon as possible. If
you sell the equipment, be sure to give this
manual to the new owner. Continuingimprove-
ments in the design can lead to changes in
details which may not be reflecte in this man-
ual. Always consult your SANY distributor for
the latest available information on your
SSR200/220 Series Single Drum Roller Introduction

1-4 Safety, Operation and Maintenance Manual-Jan. 2019
equipment or if you have questions regarding
information in this manual.
1.2 Your Documentation Package
1.2.1 Introduction
The documentation includes:
•Safety,Operation and Maintenance Manual.
•Parts Book–including the Parts List and the
Drawings needed when ordering parts. If
the Parts Book is not attached with the
equipment, contact SANY.
1.2.2 Recommendations on Using the
Documentation
•The documents only apply to the equipment
and should not be used with any other
equipments.
•Ensure that documents are complete and
up to date.
•Put all data in a folder (if including leaflets).
•Print and replace the lost, damaged and
blotted pages.
•Add the latest SANY data in time and
destroy the inapplicable old documents.
1.2.3 Documentation Storage
Always keep the operator manual with the
equipment in the operator cabin. The Parts
Book is best left either shelved in the work-
shop area or office. It should always be avail-
able to the maintenance and service
personnel as required.
1.2.4 Organization of this Manual
This operator's manual covers operation and
maintenance of your equipment. Get familiar
with it before performing any operations. Put
this manual within easy reach for your
Introduction SSR200/220 Series Single Drum Roller

Safety, Operation and Maintenance Manual-Jan. 2019 1-5
reference and replace it if it is lost or dam-
aged. Due to improvement and updating of
products, some information may differ from
your equipment. If you have any question on
the use and maintenance of your equipment,
contact your SANY distributor.
1. Introduction
This section provides an overview of what is
covered in the rest of this manual, including
equipment label information and SANY con-
tact information.
2. Safety
This section covers basic safety information
relating to this equipment. Make sure you fully
understand all the precautions described in
this manual and the safety decals on the
equipment before operating or maintaining
this equipment. Failure to do so may result in
serious injury or death.
3. System functions
This section provides an overview of all the
controls and prompt & operating systems on
your equipment. Only when you are familiar
with all systems, can you operate and main-
tain the equipment safely.
4. Operation
This section provides the basic operating pro-
cedures for the equipment. It is important to
study and become familiar with all procedures
before performing any operations with the
equipment.
5. Maintenance
This section provides all general maintenance
and repair procedures. It is important to study
and become familiar with all the maintenance
and repair procedures before performing any
maintenance or repair operations on the
equipment.
SSR200/220 Series Single Drum Roller Introduction

1-6 Safety, Operation and Maintenance Manual-Jan. 2019
6. Troubleshooting
This section includes common malfunctions
and fault diagnostic procedures for the operat-
ing system of this single drum roller. The basic
troubleshooting methods for mechanical, hy-
draulic and electrical systems are included.
7. Specifications
This section provides the general information
about this equipment. Some information may
change as design modification.
1.3 Your SANY Equipment
1.3.1 Equipment Directions
Fig.1-2
(A) Front
(B) Back
(C) Left
(D) Right
A
B
CD
Introduction SSR200/220 Series Single Drum Roller

Safety, Operation and Maintenance Manual-Jan. 2019 1-7
1.3.2 Breaking in a New Equipment
Your equipment has been well adjusted and
tested before delivery. However, initial opera-
tion on the equipment in severe conditions will
seriously affect the performance or reduce the
service life of the equipment. Thus SANY rec-
ommends you to perform 100- hour test run
before putting the equipment into production
use.
During the break-in period:
•Let the equipment warm up prior to any
operation.
•Avoid operating or running the equipment at
a high speed in overload working
conditions.
•Avoid sudden starting, rapid movement or
abrupt stop of the equipment.
•Cool down the equipment system at the
end of every working day.
SSR200/220 Series Single Drum Roller Introduction

1-8 Safety, Operation and Maintenance Manual-Jan. 2019
1.3.3 Equipment Information
The serial numbers and model numbers on
the components are the only numbers that
your SANY distributor will need when ordering
replacement parts or requiring assistance for
your equipment. You can find the related infor-
mation on the data plate. It is a good idea to
record this information in this manual for fu-
ture use.
Product identification plate is riveted on the
left side of the rear frame(See below figure).
Fig.1-3

Pro

duc

tTy


p
S
e
A

NY

Sin

gle

Dr

um

Ro

ller
●
G

ro


ssM

as


skg

Rat

ed

Pow

erkW

Dat

eo

fPr

oduction
Number
/MadeinChina
Introduction SSR200/220 Series Single Drum Roller
