Sanyipace WP9603 User manual

Sewer Pipeline Drain Inspection Camera
User Manual
---------------------------------------------------------------------------------------
Please contact us the first time if you got any issues with the
product
[email protected]

-1-
Attentions
1. Please read the manual carefully before using it.
2. Handle it carefully during operation, avoid throwing down or
pressing it heavily.
3. If the users disassemble or deliberately damage the machine,
it will beyond the warranty.
4. Please keep distance when charging
5. Turn off the device and unplug all the cables after using .
6. If your device is not in accordance with some content on the
manual, it may because device is upgraded, please refer to the
device itself.
Product Highlights
1. 9 inch color TFT LCD Screen.
2. High resolution camera lens, up to 1080P clear picture.
3. With 12 adjustable LED beads on the camera lens to brighten
the dark environment.
4. High tenacity fibreglass cable, waterproof and anti-corrosion /
cold / tensile.
5. With length scale on the cable
6. Rechargeable 6000mah lithium battery.
7. Range of Application: Water-supply pipe blocking/leakage
inspection; Air-conditioner pipe, pipeline vacuum system,
plumbing pipe inspection; Buildings, Road sunken, Municipal
engineering inspection

-2-
Product Specification
Item
Parameter
Charger
AC 100-240V DC12.6V
Battery
Lithium battery 12V
Continuous use time for battery
Approximate 6h-8h
Investigation depth
20M/30M/50M optional
Cable Material
High tenacity fibreglass
Camera light source
high white light
Camera material
Stainless steel
Menu languages
Multi-language
Camera picture
Color
Monitor Screen Type
9” Color TFT LCD
Monitor Resolution
1080 x 720 pixels
Details Information of the Parts
(1) Camera
①metal contact chip ②spring ③highlight white LED
④camera lens

-3-
Item
Parameter
Camera diameter
0.9in/23mm
With the tube protective shell
>25MM
Camera light source
12pcs LED with high while
light(adjustable)
Camera working voltage
5V
Lights working voltage
12V
Waterproof level
IP68
Camera material
stainless steel
Camera protective cover size
1.1in*1.6in/29mm*40mm
Camera pulley size
1.6in3.5in/40mm*90mm
(2) Monitor

-4-
(3) Charger

-5-
(4) Cable Coil
System Installation
1. Important tips: please make sure the device was turned off
before connecting the camera and the monitor
2. Connect camera - coil -monitor.
3. Turn on the power switch on the side of the screen, the
indicator light on the monitor bright up means device is turned on.
4. Install the protective shell slightly according to your need and
put it into the pipe, rotate coil to release the cable, push camera
lens moving in the pipe
5. Adjust LED light brightness according to your need.

-6-
6. After use, pull the cable back carefully and rotate the coil to reel
the cable, turn off the power switch, take out the camera lens, use
a clean, soft and dry cloth to clear it up and put it back in the
aluminium case.
Functions of Buttons on the Screen

-7-
1. REC/-: press to start recording videos/ capturing pictures, or
press it to confirm
2. PLAY/+: switch video recording and picture capturing mode, or
back to home page
3. MENU/EXIT: Press it to select setting options, or exit
4. “>” and “<”: press it to choose sub-options; zoom +/- when
video recording
5. Power: turn on/off the screen
6. TF Card slot: press to pop out the memory card (max support
32GB memory card)
How to record a video?
(switch to video record mode) Press “PLAY/+” until the left upper
corner of screen shows the video recording icon , press REC/- to
start and stop recording.
Or press “Menu” to find out the “record”, press “REC/-” to start
video recording
(audio recording is turned on by default when the device is in
video recording mode.Below are the steps to turn off audio

-8-
record: press "Menu" repeatedly until you find "Video Playback",
press "<" button skip to the "Record Audio", press "REC/-" to go
on, press ">" to choose "off" and press "REC/-" to confirm.)
How to take photos?
(switch to take snapshot mode) Press “PLAY/+” until the left upper
corner shows the take photo icon , press REC/- to take photo.
Or press “Menu” find out the “snapshot”, press “REC/-” to take
Product Components and Accessories

-9-
Recharging
When the battery power is low, it needs charging, and the method
is as below:
1. take out the charger cable, plug it into the charger port, another
end plug into an AC100V-240V AC socket
2. The indicator on the charger is a red light that means on
charging, it turns green light when fully charged. Usually, the
charging time is 4-5 hours.
Note:
1. Charging the device as soon as possible when it is going to be
out of power, because the battery may be damaged easily for
overuse.
2. Do not use the device when charging, and don't overcharge
----Contact Us----
Go to our website to download the user manual or view more
products:
https://www.sanyipace.com
Website After-sale: [email protected]
Amazon After-sale: [email protected]
Facebook: Sanyipace
WhatsApp: [phone]
