SATO PV3 Instruction manual

Wireless LAN Connection Manual
BARCODE PRITNER
Rev. 1.00
PV3

Rev. 1.00 - 2 -
Wireless LAN Connection Manua
l
■Table of Contents
1. Manual Information........................................................................................................3
2. Precautions ....................................................................................................................3
3. How to Connect .............................................................................................................4
3-1 Android Soft AP mode (default) ..................................................................................6
3-2 iOS Soft AP mode (default) ........................................................................................7
3-3 How to change infrastructure mode............................................................................8
4. Factory Reset ...............................................................................................................10

Rev. 1.00 - 3 -
Wireless LAN Connection Manua
l
1. Manual Information
This Wireless LAN manual provides information on the connection of a wireless network
with the mobile printer.
We at SATO maintain ongoing efforts to enhance and upgrade the functions and
quality of all our products. The following product specifications and/or user manual
content may be changed without prior notice.
2. Precautions
2-2If a device (such as a microwave oven, Wireless LAN, etc.) that uses the same
frequency is present, transmission may be interrupted. Separate the printer and
Bluetooth-enabled device from such interrupting devices by a distance of at least 5m.
2-1 The printer has to be within 100m (Outdoors) from AP (Access point) to connect to a
Wireless LAN. Although up to 35m is possible to communicate indoors, Wireless LAN
performance could be affected by the environmental conditions, such as cement walls,
and impede signal strength performance. The printer's LCD shows the connection status of
the Wireless LAN:
- Indicates that the Wireless LAN is connected normally
- Indicates that the Wireless LAN password is wrong
- Indicates that the AP of the set SSID is not nearby

Rev. 1.00 - 4 -
Wireless LAN Connection Manua
l
3. How to Connect
Wireless LAN can be configured through the printer’s Wireless LAN interface. Likewise,
Wireless LAN can also be configured though the printer’s Serial/USB interfaces.
(1) Connecting Printer
1) Serial / USB cable
Connect Serial/USB cable to Printer, PC device.
When Serial cable use, baudrate between Device and printer should be the same.
2) Wireless LAN
Connect to the AP (Access Point) configured in Infrastructure mode in order to connect to
the LAN/wireless network
Infrastructure mode
In order to configure the network between the wireless host device and the printer, set the
printer to Soft AP Mode.
Soft AP mode
A P

Rev. 1.00 - 5 -
Wireless LAN Connection Manua
l
(2) Checking Network Setting
Self-test
While the printer is turned off, turn on the printer while pressing the feed button.
The printer setting values will then be printed.
Power
FEED

Rev. 1.00 - 6 -
Wireless LAN Connection Manua
l
3-1 Android Soft AP mode (default)
1) Select “Wi-Fi”. 2) Select the printer to connect
3) Select “CONNECT”. 4) Wi-Fi communication is available.

Rev. 1.00 - 7 -
Wireless LAN Connection Manua
l
3-2 iOS Soft AP mode (default)
1) Select “Wi-Fi”. 2) Wi-Fi ON and Select the printer to connect
3) Wi-Fi communication is available

Rev. 1.00 - 8 -
Wireless LAN Connection Manua
l
3-3 How to change infrastructure mode
1) Enter the IP address of the printer in the address bar, and the following login window will
pop up. Enter the ID and Password set for the printer, and then click [LOG IN] (Default
User Name: admin, Password: password)
2) Select “Wireless” to change Wireless LAN mode.

Rev. 1.00 - 9 -
Wireless LAN Connection Manua
l
3) Select “infrastructure”, and set SSID, WLAN Security Type.
4) Reboot the Printer.

Rev. 1.00 - 10 -
Wireless LAN Connection Manua
l
4. Factory Reset
This function changes the Wireless LAN settings of the printer to the initial factory settings.
Method
Select the wireless interface on the printer's LCD screen.
Wireless LAN Factory reset is available in WLAN> ON / OFF> Factory Reset
When the printer is turned off, the Wireless LAN setting is applied as the factory default
Factory Reset Values
System
Printer Name *Printer model
Printer Port Num 9100
User ID admin
User Password password
Enc / Auth Encryption None/Open
Network
Network Mode Soft AP mode
SSID PRINTER_{MAC address}
Inactivity time 10
IP Assignment Method Manual (DHCP server)
IP, Subnet, Gateway
IP : 192.168.1.1
Subnet : 255.255.255.0
Gateway : 192.168.1.2
Specification
Feature Implementation
Operation Mode Infrastructure, Soft AP, Ad-hoc, Wi-Fi Direct
Wireless Standard IEEE 802.11b/g/n, IEEE 802.11a/b/g/n
Range Up to 100m free space (Outdoor)
Security WEP64/128
WPA1/2 – PSK

Rev. 1.00 - 11 -
Wireless LAN Connection Manua
l
WPA 1/2 – Enterprise
(EAP-TLS, EAP-TTLS, PEAP, LEAP, EAP-FAST)
Management Net Configuration tool, HTTP, Smart connection APP
