Schaeffler SES Series Guide

Split Plummer Block Housings
Series SES
Mounting manual

Schaeffler Technologies MON 92 1
Page
Split plummer block housings SES
About the mounting manual Availability ............................................................................... 2
Legal guidelines ....................................................................... 2
Symbols ................................................................................... 2
Images ..................................................................................... 3
General safety guidelines Usage for the intended purpose ................................................ 3
Selection and qualification of personnel ................................... 3
Personal protective equipment.................................................. 3
Safety regulations..................................................................... 4
Transport specifications............................................................ 5
Scope of delivery ................................................................................................ 6
Product description ................................................................................................ 7
Preparation for mounting Preparing the locating surface................................................... 8
Checking the bearing seats on the shaft .................................... 9
Checking the requirement for horizontal location....................... 9
Cleanliness............................................................................... 10
Mounting housings
with split seals
Mounting using double lip seals EDH ........................................ 11
Special features of felt seals EFS ............................................... 16
Mounting housings
with unsplit seals
Mounting with labyrinth seals ETS ............................................. 17
Special features of V ring seals EDV........................................... 22
Special features of Taconite seals ETC ....................................... 24
In case of repair:
Dismounting and mounting
with split seals
Use in combination with split bearing........................................ 25
Dismounting ............................................................................. 26
Mounting with split seals .......................................................... 27
Operating guidelines Maintenance ............................................................................ 28
Relubrication ............................................................................ 28
Cleaning ................................................................................... 31
Replacement parts.................................................................... 31
Appendix Nominal screw sizes and tightening torques for foot screws....... 32
Tightening torques for connecting screws .................................. 33
Additional holes for foot screws and pins .................................. 33
Grease quantities for initial greasing ......................................... 35
Grease quantities for relubrication ............................................ 36

2 MON 92 Schaeffler Technologies
Split plummer block housings SES
About the mounting manual The purpose of this mounting manual is to assist the fitter in mount-
ing split plummer block housings SES safely and correctly.
It contains important information on mounting with the following
objectives:
■ to prevent personal injury or damage to property that may be
caused by errors in mounting
■ to facilitate, through correct mounting, a long operating life
of the housing and the bearing mounted therein
The original language of the manual is German.
All other languages are translations from the German language.
Availability A current electronic version (PDF) of this manual can be found at
https://www.schaeffler.de/std/1F87
The Safety Officer must ensure that this mounting manual is always
complete and legible and that any persons mounting, dismounting
or maintaining the plummer block housing have the mounting
manual available.
Keep the manual in a safe place for immediate reference.
Legal guidelines The information in this manual reflects the status as of
October 2022.
Unauthorised modifications to or improper use of the product are
not permitted. Schaeffler does not assume any liability in this
respect.
Symbols The warning and hazard symbols are defined in accordance with
ANSI Z535.6-2011.
WARNING
In case of non-compliance, death or serious injury may occur. 
CAUTION
In case of non-compliance, minor or moderate injury may occur. 
NOTICE
In case of non-compliance, damage or malfunctions in the product
or the adjacent construction may occur.


Schaeffler Technologies MON 92 3
Images The images in this manual are examples and may differ from
the delivered product.
Further information Please direct any mounting-related questions to your local
Schaeffler contact or to one of our certified sales partners.
General safety guidelines
Usage for the intended
purpose
The purpose of split plummer block housings SES is to support
rolling bearings. The function of the seals and covers available as
accessories is the sealing of the bearing position.
Functionality can be expanded through the connection of systems
for condition monitoring and for automatic relubrication.
Usage for any other purpose is not permissible.
Selection and qualification
of personnel
Mounting of split plummer block housings SES must be carried out
by qualified personnel only.
A person defined as qualified personnel:
■ is authorised to perform mounting of the housings
■ has all the knowledge necessary for mounting of the housings
■ is familiar with the safety regulations
Personal protective equipment Personal protective equipment is intended to protect personnel
against health hazards. This comprises safety shoes, safety gloves
and protective goggles and must be used in the interests of personal
safety.
Depending on the mounting location and on the machine or
equipment in which the housings are to be mounted, it may be
necessary to use additional personal protective equipment.
The applicable regulations relating to occupational safety must
be observed.

4 MON 92 Schaeffler Technologies
Split plummer block housings SES
Safety regulations In order to prevent personal injury or damage to property, the follow-
ing safety regulations must be observed during mounting.
Fundamental specifications Secure heavy components such as upper and lower housing
sections, seals, covers and rolling elements against toppling or
falling. Pay particular attention to limbs when setting down or
fitting heavy components together, in order to prevent crushing.
Mounting and maintenance work of all types should only be
carried out when the machine or equipment is stationary.
Environmental hazards Depending on the ambient conditions, safety risks may be present
at the mounting location that are not associated with the housing
but must be taken into consideration in mounting of the housing.
Consult a local safety engineer before starting mounting work.
Observe all safety regulations that are applicable to the mounting
location and to the machine or equipment affected by the
mounting work.
Seal assembly When fitting O rings, use rounded tools only, such as a screwdriver
with rounded edges. A tool with sharp edges may damage the O ring.
Grease Lubricating greases must not be mixed. Use the same grease for
relubrication as for initial lubrication.
CAUTION
Hazard in case of contact with the skin or eyes, or if swallowed.
The grease contains components that are hazardous to health.
Avoid direct bodily contact and wear protective gloves.
Observe the safety data sheet for the grease. 
Cleaning We recommend using volatile solvents to clean the housing com-
ponents since these allow cleaning without leaving a residue.
In this case, pay attention to the compatibility of the solvent used
with the paint coating of the housing. If compatibility is inadequate,
the paint coating may be damaged with the result that protection
of the housing against corrosion is no longer ensured.
WARNING
Risk of injury due to volatile solvents. Hazard through ignition
of vapours or in the case of skin or eye contact, inhalation or
swallowing.
Avoid direct bodily contact and wear protective gloves.
Observe the safety information provided by the manufacturer. 

Schaeffler Technologies MON 92 5
Disposal Dispose of any cloths soaked with grease or solvents, as well as
excess grease, packaging material and any other waste generated in
connection with mounting, by environmentally acceptable methods,
observing the respective legal regulations.
Transport specifications In order to prevent the occurrence of personal injury or damage
to property during transport, observe the following transport
specifications.
WARNING
Swivelling out or falling apart of rolling bearings. Severe personal
injury or damage to property as a result of falling components.
Before transport, secure rolling bearings against swivelling out or
falling apart.

Lifting of heavy components Use suitable technical accessories to lift heavy components.
Familiarise yourself with correct usage of the accessories and
observe all safety regulations relating to the handling of
suspended loads.
Securing for transport after
prior mounting
When transporting a premounted unit comprising a shaft,
bearings and housing, we recommend using a transport restraint.
The shaft should be radially clamped against the housing.
Securing for transport assists in preventing transport damage
such as standstill marks on the rolling bearing.
Attachment point In the case of housings of size SES524-620 and larger, the upper
housing section has an eye bolt in accordance with DIN 580. This is
intended as an attachment point for mounting and dismounting
the housing. The load carrying capacity of the eye bolt allows the
housing, complete with a bearing fitted in the housing, to be lifted.
WARNING
Rupture of the eye bolt in case of overload. Severe personal injury or
damage to property as a result of falling housing.
Aways screw the eye bolt all the way into the housing.
Only use the eye bolt to lift the housing complete with fitted bearing.
During lifting by means of the eye bolt, no other machine or plant
components should be connected to the housing.


6 MON 92 Schaeffler Technologies
Split plummer block housings SES
Scope of delivery ■ Split plummer block housing SES
■ Grease nipples with dust caps:
– taper type lubrication nipples in accordance with DIN 71412
– button head lubrication nipples in accordance with DIN 3404
Accessories The following accessories are available to order:
■ Seals:
– double lip seals EDH
– felt seals EFS
–labyrinthsealsETS
– V ring seals EDV
– Taconite seals ETC
■ Covers:
– cover EDK made from plastic
– cover EDKT made from steel and FKM
■ Locating rings FRM
Not included in the scope
of delivery
The scope of delivery does not include the following:
■ Foot screws and associated support washers
for fastening the housing to the locating surface.
For the required foot screw size, see page 32.
■ Spacer sleeves
■ Lubricating grease. The choice of lubricating grease
is determined by the application.
Suitable rolling bearing greases:
TPI 168, Arcanol rolling bearing greases,
https://www.schaeffler.de/std/1F66
Further information Ordering examples and detailed information on combinations
and the appropriate bearings:
■ TPI 247, Split plummer block housings SES,
https://www.schaeffler.de/std/1F92

Schaeffler Technologies MON 92 7
Product description The housings are designed in accordance with a modular concept.
Each housing can be fitted with rolling bearings of various diameter
and width series if they have the correct outside diameter for the
housing.
Depending on their design, the bearings can be located either
directly on the shaft or by means of an adapter sleeve. This gives
different shaft diameters for the same bearing size. The spacings
between the shaft and housing body are compensated by means
of appropriately matched seals.
 Lower housing section
 Upper housing section
 Connecting screws
 Eye bolt
(from housing size SES524 and larger)
 Lubrication holes with closing plugs
 Dust cap
 Cylindrical pins
 Indentations
 Grease outlet hole
 Grease nipples with dust caps
Figure 1
Split plummer block housing SES
7
6
5
10
2
34
8
9
8
1
0019FD410019FD41
 Seals
 Cover
 Locating ring
Figure 2
Accessories
for plummer block housing SES
1
2
3
0019FD430019FD43

8 MON 92 Schaeffler Technologies
Split plummer block housings SES
Preparation for mounting
Preparing the locating surface The locating surface on which the housing will be mounted must
be checked before mounting.
The requirements for the locating surface are as follows:
■ sufficiently robust to withstand the static and dynamic loads
occurring in operation over the long term
■ surface roughness Ra ⬉ 12,5
■ flatness tolerance to IT7, measured across the diagonal
■ free from colouration
■ compensation of differences in level between locating surfaces
Level of mounting surfaces A difference in level between the locating surfaces of bearing
housings will lead to misalignment of the shaft,
Figure 3 .
The seals in SES plummer block housings allow misalignments
of up to 0,5° in both directions.
Differences in level must therefore be compensated such that
the misalignment of the shaft is not greater than 0,5°.
Levelling shims can be used for this purpose.
In addition, it must be ensured that the bearings mounted can
compensate the misalignments present.
␺ = misalignment of the shaft
h = difference in level between
locating surfaces
Figure 3
Misalignment of the shaft
(schematic)
h
␺⬉0,5°
0019620A0019620A

Schaeffler Technologies MON 92 9
Checking the bearing seats
on the shaft
The bearing seats on the shaft must be free from impact marks
and burrs and must have adequate dimensional and geometrical
accuracy.
The requirements for dimensional and geometrical accuracy
of the bearing seats for a tapered bearing bore and location by
adapter sleeve are as follows:
■ diameter in tolerance class h9
■ cylindricity tolerance within IT5/2
The requirements for dimensional and geometrical accuracy of
the bearing seats for a cylindrical bearing bore and direct seating of
the bearing on the shaft are dependent on the operating conditions.
They are generally defined for the specific application by the
designer.
Checking the requirement
for horizontal location
In addition to the foot screws, horizontal location of the housing is
necessary if one of the following conditions is fulfilled:
■ The load angle is between 55° and 120°, Figure 4 .
■ An axial load is present.
The designer of the machine or equipment should check whether
horizontal location of the housing is necessary.
Horizontal location can be achieved by means of pins or preferably
stops in the load direction.
 Load angle range within
which horizontal location
of the housing is necessary
Figure 4
Load directions
in plummer block housing SES
F
55⬚
F
120⬚
F
180⬚
F
0⬚
1
00195A4200195A42

10 MON 92 Schaeffler Technologies
Split plummer block housings SES
Cleanliness
NOTICE
Contaminants and residues from cleaning agents can shorten
the operating life of rolling bearings.
Ensure that no foreign bodies can enter the bearing housing
during the mounting process.
Only use volatile solvents and lint-free cloths for cleaning.

Ensure cleanliness  Keep the mounting area and tools clean.
 Clean the locating surface.
 Clean the housing, seals and cover, paying particular attention
to any machining or moulding sand residues.
 Do not remove rolling bearings and adapter sleeves from their
packaging until immediately before mounting.
 Remove excess anti-corrosion protection using a lint-free cloth.
Additional measures  Dispose of the dust caps.

Schaeffler Technologies MON 92 11
Mounting housings
with split seals
The procedure for mounting housings with split seals is described
using the example of double lip seals EDH. If individual mounting
procedures deviate from this for other seal types (EFS), only these
special features are shown below.
Mounting
with double lip seals EDH
Locating and greasing
the lower housing section
WARNING
Rupture of the eye bolt in case of overload. Severe personal injury
or damage to property possible as a result of falling housing.
Aways screw the eye bolt fully into the upper housing section.
Only lift the housing and bearing with the eye bolt. 
 Place the lower housing section in the correct mounting position
on the locating surface. The complete housing can first be set
down and the upper housing section can then be lifted off again.
 Insert the foot screws with one support washer each in the lower
housing section and tighten until finger tight.
 Introduce a portion of the grease to be used for initial greasing
into the lower housing section on both sides of the ultimate
bearing position.
Grease quantity for initial greasing, see page 35.
 Lower housing section
 Foot screws with support washers
 Locating surface
 Annular slot
 Area for grease
(in bearing position)
Figure 5
Locating and greasing
the lower housing section
4
8
9
5
1
00195CB800195CB8

12 MON 92 Schaeffler Technologies
Split plummer block housings SES
Inserting the lower halves
of double lip seals EDH
The mounting procedure for felt seals EFS differs, see section
Inserting the lower halves of felt seals EFS , page 16.
 For all double lip seals, fill the area between the two seal lips
with grease.
 Insert one half of the seal into each of the two annular slots in
the lower housing section. In housings closed on one side,
insert one half of the seal into one annular slot only and leave
the other annular slot free for the cover.
Mounting and greasing
the bearings
Bearings with a tapered bore can be mounted on a cylindrical shaft
using an adapter sleeve.
Bearings with a cylindrical bore are mounted on a stepped shaft.
If this is a continuous shaft, a spacer sleeve is necessary on the side
with the smaller shaft diameter. The outside diameter of the spacer
sleeve must be identical to the larger shaft diameter. In the case of
a housing closed on one side, a spacer sleeve is not used.
Detailed information on the mounting of rotary bearings:
MH 1, Mounting handbook,
https://www.schaeffler.de/std/1F86
 Mount the bearing on the shaft as per the instructions.
 With the outer ring swivelled out, fill the free cavities of the
bearing fully with grease.
 Lower housing section
 Double lip seal
 Area between the seal lips
 Annular slot
Figure 6
Inserting the lower halves
of the double lip seals
5
8
5
5
6
5
1
0019613A0019613A

Schaeffler Technologies MON 92 13
Inserting the shaft and bearing
into the housing
 Insert the subassembly, comprising the shaft and bearing
(and spacer sleeve where applicable), into the lower housing
section.
 For a non-locating bearing arrangement:
Position the bearing centrally on the bearing seating surface
of the housing. As a result, the drive-up distance of the bearing
in the housing is equally large on both sides.
 For a locating bearing arrangement:
Insert the locating rings into the housing, using equal numbers
on both sides of the bearing, and position them so that their
opening faces upwards.
For the number of locating rings required:
TPI 247, Split plummer block housings SES,
https://www.schaeffler.de/std/1F92
For a housing closed on one side:
Inserting the cover
 Insert the cover from above into the free annular slot in the lower
housing section. For easier maintenance access, we recommend
placing the cover on the side of the housing which has the grease
outlet hole.
 Lower housing section
 Shaft
 Drive-up distance of bearing in housing
 Locating ring
Figure 7
Inserting the shaft
(and locating rings)
=
6
6
1 7
5
0019613F0019613F
 Lower housing section
 Cover
 Annular slot
 Grease outlet hole
Figure 8
Inserting the cover
6
51 7
0019613D0019613D

14 MON 92 Schaeffler Technologies
Split plummer block housings SES
Aligning the housing  Align the housing. Use the indentations in the lower housing
section, which indicate the shaft and bearing centres
in the housing, as a guide.
 Tighten the foot screws finger tight.
Greasing the upper housing section  Introduce a portion of the grease to be used for initial greasing
into the upper housing section on both sides of the ultimate
bearing position.
Grease quantity for initial greasing, see page 35.
Inserting the upper halves
of double lip seals EDH
The mounting procedure for felt seals differs, see section
Inserting the upper halves of felt seals EFS , page 16.
 Insert one half of the double lip seal into each of the two annular
slots in the upper housing section. In housings closed on one
side, insert one half of the seal into one annular slot only and
leave the other annular slot free for the cover.
 Foot screws
 Alignment by means of indentations
Figure 9
Aligning the housing
15
54
5
0019614000196140
 Upper housing section
 Area for grease
(in bearing position)
Figure 10
Greasing the upper housing section
2
9
001A151F001A151F
 Upper housing section
 Double lip seal
 Annular slot
Figure 11
Inserting the upper halves
of the double lip seals
5
5
2 2
8
0019614300196143

Schaeffler Technologies MON 92 15
Mounting
the upper housing section
 Check whether the serial numbers on the upper and lower
housing sections match.
WARNING
Rupture of the eye bolt in case of overload. Severe personal injury
or damage to property possible as a result of falling housing.
Aways screw the eye bolt fully into the upper housing section.
Only lift the housing and bearing with the eye bolt. 
 Drive in the cylindrical pins to connect the upper and lower
housing sections.
 Place the upper housing section on the lower housing section.
 Check the alignment of the housing and adjust if necessary.
 Tighten the connecting screws to the recommended tightening
torque, see page 33.
Screw mounting the housing
on the locating surface
 Tighten the foot screws to the recommended tightening torque,
in a crosswise sequence for 4 foot screws.
Checking
the tightening torques
Settling of screw connections leads to a reduction in screw preload.
 Check the tightening torques of the foot screws
after 24 operating hours, see page 32.
 Check the tightening torques of the connecting screws
after 24 operating hours, see page 33.
 Mounting of the housing is now complete.
 Lower housing section
 Upper housing section
 Connecting screws
 Cylindrical pins
 Serial number
Figure 12
Mounting
the upper housing section
6
5
3
2
1
XXXXXXX
0019614500196145

16 MON 92 Schaeffler Technologies
Split plummer block housings SES
Special features
of felt seals EFS
The procedure for mounting housings with split seals is described
using the example of double lip seals EDH. Only individual deviating
mounting procedures for felt sealing rings EFS are shown below.
 Follow the mounting instructions for double lip seals EDH,
page 11, and note the deviations from the mounting procedure
for felt ring seals EFS.
Inserting the lower halves
of felt seals EFS
In housings closed on one side, insert one seal into one annular slot
only and leave the other annular slot free for the cover.
 Ensure that all felt strips are soaked with oil.
 Press the oil-soaked felt strips into the slots in the adapter
halves.
 Insert the halves of the O ring into the two annular slots
in the lower housing section.
 Insert the adapter halves with the felt strips into the two annular
slots.
 The lower halves of the felt seals are mounted.
 Continue with section Mounting and greasing the bearings ,
page 12.
Inserting the upper halves
of felt seals EFS
 Insert the O rings and the adapters with the felt strips into the
two annular slots in the upper housing section. In housings
closed on one side, insert these into one annular slot only and
leave the other annular slot free for the cover.
 The upper halves of the felt seals are mounted.
 Continue with section Mounting the upper housing section ,
page 15.
 Lower housing section
 Felt strip
 Adapter
 O ring
 Annular slot
Figure 13
Inserting the lower halves
of the felt seals
8
6
5
5
1
6
7
5
001961AA001961AA
 Upper housing section
 Adapter with felt strip
 O ring
 Annular slot
Figure 14
Inserting the upper halves
of the felt seals
6
7
7
6
2 2
8
001961AD001961AD

Schaeffler Technologies MON 92 17
Mounting housings
with unsplit seals
The procedure for mounting housings with unsplit seals is described
using the example of labyrinth seals ETS. If individual mounting pro-
cedures differ from this for other seal types (EDV, ETC), only these
special features are shown below.
Mounting
with labyrinth seals ETS
The labyrinth seal comprises the labyrinth ring and the mating
contour, which is located in the upper and lower housing section.
Locating and greasing
the lower housing section
WARNING
Rupture of the eye bolt in case of overload. Severe personal injury
or damage to property possible as a result of falling housing.
Aways screw the eye bolt fully into the upper housing section.
Only lift the housing and bearing with the eye bolt. 
 Place the lower housing section in the correct mounting position
on the locating surface. The complete housing can first be set
down and the upper housing section can then be lifted off again.
 Insert the foot screws with one support washer each in the lower
housing section and tighten until finger tight.
 Introduce a portion of the grease to be used for initial greasing
into the lower housing section on both sides of the ultimate
bearing position.
Grease quantity for initial greasing, see page 35.
 For labyrinth seals:
Introduce grease additionally into the annular slots in the lower
housing section.
 Lower housing section
 Foot screws with support washers
 Locating surface
 Annular slot
 Area for grease
(in bearing position)
Figure 15
Locating and greasing
the lower housing section
4
8
9
5
1
00195CB800195CB8

18 MON 92 Schaeffler Technologies
Split plummer block housings SES
Mounting inner labyrinth seal ETS The mounting procedure for V ring seal EDV differs, see section
Mounting inner V ring seal EDV , page 23.
The mounting procedure for Taconite seal ETC differs, see section
Mounting inner Taconite seal ETC , page 24.
 Lightly coat the labyrinth ring with grease.
 Slide the labyrinth ring onto the shaft or (in the case of a stepped
shaft) the larger diameter of the shaft so that the slot for the O ring
is on the side facing away from the bearing.
The O ring is only fitted in the slot of the labyrinth ring at a later
stage, see section Final mounting of labyrinth seals ETS , page 22.
As a result, the labyrinth ring can initially still be displaced on
the shaft.
Mounting and greasing
the bearings
Bearings with a tapered bore can be mounted on a cylindrical shaft
using an adapter sleeve.
Bearings with a cylindrical bore are mounted on a stepped shaft.
If this is a continuous shaft, a spacer sleeve is necessary on the side
with the smaller shaft diameter. The outside diameter of the spacer
sleeve must be identical to the larger shaft diameter. In the case of
a housing closed on one side, a spacer sleeve is not used.
Detailed information on the mounting of rotary bearings:
MH 1, Mounting handbook,
https://www.schaeffler.de/std/1F86
 Mount the bearing on the shaft as per the instructions.
 For stepped shaft:
Slide on the spacer sleeve.
 With the outer ring swivelled out, fill the free cavities of the
bearing fully with grease.
 Shaft (not stepped)
 Stepped shaft
 Planned bearing location
 Labyrinth ring
 Slot for O ring
Figure 16
Mounting the inner labyrinth seal
3
1 2
5
4
3
4
4
00195CBB00195CBB
