Schaerer E6 User manual

Espresso machine E6
User manual
March 2005 - Version 01

Schaerer USA Corporation
2900 Orange Avenue, Suite 102
Signal Hill, CA 90755
USA
Phone: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.schaererusa.com
BAE6 - 02
Order number: 021‘301
Additional safety information
This Symbol requires special attention. It will inform you in detail on the safety instructions,
commissioning, usage, operation, handling and programming of the espresso machine E6.
It contains important safety instructions to ensure safe use and operation.
This symbol indicates a risk of fire and/or to life and health due to electric shock. Work on electric
system must be carried out by authorized service personnel only. The supply voltage must comply with
the information given on the machine’s serial plate.
Never open the machine or expose its internal parts.
Read the safety instruction chapter, page 9 to 14 inside this user manual.

Published by:
M. Schaerer Ltd., CH-3302 Moosseedorf
Version:
Version 01 / March 2005
Software:
V 1.00
Designed and edited by:
M. Schaerer Ltd., CH-3302 Moosseedorf
© Copyright by:
M. Schaerer Ltd., CH-3302 Moosseedorf
All rights reserved, including translation into other languages. This manual may not be copied,
photocopied or distributed, in whole or in part, by any means, nor transmitted electronically, without
the publishers written consent.
All information, illustrations, and specifications in this manual are based on the latest product
information available at the time of publication approval.
M. Schaerer Ltd. reserves the right to change the content at any time without any prior notice.
In case of disagreement (e.g. wrong translation) the English document is our reference!
Note that the pictures and display messages shown inside this manual are only examples!
Your machine and display messages may look different due to the options we offer.
Espresso machine E6
User manual

Introduction
4 User manual E6 - 01 USA
www.schaererusa.com Version 01 / 03.2005 / REWE
2 lined, illuminated
display with Status
lights (LED)
ON/OFF button
(Stand-by button)
with light (LED)
Cleaning- and plus
button with light (LED)
Programming button
(Memory button)
with light (LED)
DECAF button
with light (LED)
Small product- and minus
button with light (LED)
Meduim product button
with light (LED)
Large product button
with light (LED)
Bean container
DECAF (Decoffeinated)
Bean container
Regular beans
Operating panel
(see below)
Coffee outlet
Grounds container
Drip grid
Drip tray
Discharge tube
'Caution hot' Sticker

Introduction
User manual E6 - 01 USA 5
Version 01 / 03.2005 / REWE www.schaererusa.com
Introduction
Welcome
With this new coffee machine, you have purchased a Swiss quality product
especially designed for the catering trade.
This manual will inform you in detail on the programming, commissioning,
usage and cleaning of your new machine. It also contains important safety
instructions to ensure safe use.
Prior to commissioning the machine, carefully read the chapter
"Safety instructions". The manufacturer rejects any liability for damages that
are caused by improper usage of the machine.
Performance of the coffee machine depends to a great extent on
proper usage and careful maintenance of the machine. We therefore
recommend that you read all instructions carefully before commissioning
the machine.
Keep the user manual at hand for future reference.
We trust you will enjoy using your new coffee machine!

Introduction
6 User manual E6 - 01 USA
www.schaererusa.com Version 01 / 03.2005 / REWE
Table of contents
Introduction .................................................................................. 5
Welcome ................................................................................................. 5
Safety instructions .................................................................... 9
General ................................................................................................... 9
Designated use ........................................................................................ 9
Safety symbols ......................................................................................... 9
Prevention of accidents ......................................................................... 10
Operational safety ................................................................................. 11
Safety instructions during operation ........................................................ 11
Safety instructions during cleaning ......................................................... 12
Hygiene ................................................................................................. 13
Liability .................................................................................................. 14
Product description ............................................................. 16
Espresso machine overview ................................................................... 16
Espresso machine operating panel ........................................................ 16
Espresso machine bean container(s) ...................................................... 16
Espresso machine grounds container and drip tray ................................ 16
Serial plate ............................................................................................ 17
Operating information ........................................................................... 17
Performance characteristics .................................................................. 17
Dimensions and weight .......................................................................... 17
Power requirements ............................................................................... 17
Volumes ................................................................................................ 17
Equipment and accessories ................................................................... 18
Standard accessories (included in shipment) ......................................... 18
Installation layout E6 .............................................................................. 19
Commissioning ....................................................................... 21
Initial commissioning of the coffee machine .......................................... 21
Set-up conditions ................................................................................... 21
Location ................................................................................................ 21
Installation of the coffee machine ......................................................... 21
Safety instructions during commissioning ................................................ 22
Water supply/Drain ................................................................................ 22
Operation .................................................................................... 24
Introduction ........................................................................................... 24
Filling of coffee beans ............................................................................ 24
Making the coffee machine ready for operation ................................... 24
Switching on the coffee machine .......................................................... 24
Operation modes .................................................................................. 25
Begin daily routine operation ................................................................. 25
Beverage output ................................................................................... 26
Output of espresso beverages ............................................................... 26
Checking the beverage counters .......................................................... 27
Checking the cleaning counter ............................................................. 27
End of operation .................................................................................... 28
Switching off the coffee machine .......................................................... 28
Extended idle time ................................................................................. 28
Removal / Relocation / Disassembly ...................................................... 28

Introduction
User manual E6 - 01 USA 7
Version 01 / 03.2005 / REWE www.schaererusa.com
Programming ........................................................................... 30
Navigation on programming level .......................................................... 30
Programming overview .......................................................................... 31
Description for product programming .................................................... 32
Description for general settings programming ........................................ 32
Cleaning ...................................................................................... 34
Introduction ........................................................................................... 34
Daily cleaning procedure ...................................................................... 35
Error messages ........................................................................ 38
Display and error messages ................................................................... 38
Appendix .................................................................................... 41
Cleaning agent ..................................................................................... 41
Cleaning tablet for the espresso machine .............................................. 41
Technical data ...................................................................................... 42
Instant heater (Art.-No.: 068‘557) ............................................................ 42
Environmental aspects ........................................................................... 42

Introduction
8 User manual E6 - 01 USA
www.schaererusa.com Version 01 / 03.2005 / REWE

Safety instructions
User manual E6 - 02 USA 9
Version 01 / 03.2005 / REWE www.schaererusa.com
Safety instructions
This chapter warns about possible dangers when operating the machine.
The information contained herein enables to recognize hazardous
situations.
General
Prior to using the machine, read the operating instructions carefully.
Always comply with the local safety regulations and hygienic guidelines.
Be sure that only qualified personnel work with the machine!
Always keep this manual at hand!
Designated use
Use of the machine (including options and accessories) is subjected to the
agreement on use and the general terms and conditions of M.Schaerer
Ltd. The user manual is an integral part of the above agreement of use.
Any usage other than within the limits specified herein shall be regarded as
not in accordance with the designated use. The manufacturer shall not be
liable for any resulting damage.
Safety symbols
The following symbols appear next to all safety instructions in this manual.
Follow the instructions to the letter and proceed with outmost care.
This note indicates a risk of severe and/or fatal injury if specific procedural
rules are violated.
Whenever you see this symbol in the operating manual, take all necessary
safety precautions.
This note indicates a risk to life and health due to electric shock!
This note indicates possible damage to property as well as possible
financial and statutory penalties (e.g. loss of rights to claim under
guarantee, liability suits, etc.).
This section provides you with important information.
This section reminds you that all the beverages delivered by
the machine are hot!

Safety instructions
10 User manual E6 - 02 USA
www.schaererusa.com Version 01 / 03.2005 / REWE
Prevention of accidents
In case of incorrect operation or misuse, one or more of the following might
occur:
• Risk to life and health of the operator, third persons or animals that
are in proximity to the machine,
• Risk of damage to machine and other property of the operator or of
third parties,
• Inefficient performance of the machine.
Persons who are not familiar with these operating instructions, as well as
children or persons under the influence of alcohol, drugs or medication
may not operate the machine. On self-service units danger zones such as
the coffee outlet, the steam pipe and the hot water outlet must be clearly
labeled in such a manner that the warning is clearly visible to the customer.
Work on electric systems must be carried out by qualified engineers or
technicians only.
The machine must be connected to a grounded and fuse-protected circuit
in compliance with local laws and liability.
The country‘s or local safety rules and regulations apply.
Connection through a residual current operated circuit-breaker is
recommended.
The supply voltage must comply with the information given on the
machine‘s serial plate.
To prevent water damage caused by hose breakage, it is recommended
to run the water supply line through a water stop valve.
Parts of the coffee outlets, the hot water outlet and the steam wand
become very hot during product delivery and cleaning. Only touch the
outlets at the specially designated protective elements.
Never open the machine or expose its internal parts!
Malfunctions must be repaired by a qualified technician only.
Only use original Schaerer spare parts.
Immediately report visible damages and leakages, damaged cables and
plugs to an qualified technician and have them repaired or replaced.
In case of malfunctions or damage discontinue the usage of the machine
and switch the machine to Stand-by mode. Disconnect from mains- and
water supply!
Contact a qualified service technician!
When selecting cleaning agents, make sure that they are environmentally
safe and bear no health risks. Comply with local disposal regulations.
Use cleaning agents recommended by the manufacturer.

Safety instructions
User manual E6 - 02 USA 11
Version 01 / 03.2005 / REWE www.schaererusa.com
Operational safety
Safety instructions during operation
The installation, programming, service and repair of the machine must be
carried out by a qualified service technician.
The machine must be connected to the power supply system and drinking
water lines in compliance with local laws and regulations.
Never insert the power plug into a power socket when wet!
Never touch the plug with wet hands.
• The beverages delivered by the coffee machine are hot! To protect
yourself against scalding, keep hands and other body parts
away from the outlet area during the preparation and delivery of
beverages.
• Parts of the coffee outlets, the hot water outlet and the steam wand
become very hot during product delivery and cleaning. Only touch
the outlets at the specially designated protective elements.
• During product delivery, never move cups or other objects positioned
below the beverage outlet, the hot water outlet or the steam wand!
The beverages delivered by the machine are hot!
• Never aim steam or hot water jets against persons!
• The coffee machine does not stop dispensing when a cup is removed
from underneath an outlet during serving.
Pressing the [ON/OFF] button will only switch the machine to stand-by
mode, and does not physically separate it from the mains supply.
If your machine is equipped with a refrigerator, do not disconnect the
mains supply, as this will switch off the cooling system.
When the coffee machine is not used for a prolonged period of time (z.g.
Company holidays), follow the procedures outlined in the paragraph
"Extended idle times".
Do not operate the machine if the water supply is shut off or disconnected!
This might result in damage of the machine.
Proper installation and programming of the coffee machine by an qualified
service technician is crucial for a smooth operation and high product
quality.

Safety instructions
12 User manual E6 - 02 USA
www.schaererusa.com Version 01 / 03.2005 / REWE
Safety instructions during cleaning
• Never reach into the machine during the cleaning process and
always keep away from the beverage outlet(s).
• Never clean the machine with a hose or a high pressure cleaner!
• Do not use steam cleaning devices!
• Never immerse the machine in water or any other liquids!
• Parts of the coffee outlets, the hot water outlet and the steam wand
become very hot during product delivery and cleaning. Only touch
the outlets at the specially designated protective elements.
• During cleaning and usage of cleaning tools or products,
there is a risk of injury.
• Always follow hygiene regulations according to HACCP!
(refer to page 13).
• Only use cleaning agents recommended by the manufacturer.
• Never mix cleaning agents!
• Ask the manufacturer or a customer service for advice on the
cleaning tools you should use.
• Product delivery is disabled during the cleaning cycle.
• To ensure that all products are available at the best quality, careful
daily and weekly cleaning is imperative.
• The cleaning steps are shown on the display and the Quick reference
card which is supplied with the machine. Please follow these
instructions.
When selecting cleaning agents, make sure that they are environmentally
safe and bear no health risks. Comply with local disposal regulations.
Use cleaning agents recommended by the manufacturer.

Safety instructions
User manual E6 - 02 USA 13
Version 01 / 03.2005 / REWE www.schaererusa.com
Hygiene
Prior to using the machine, run the cleaning program
(see chapter "Cleaning").
Always follow hygiene regulations according to HACCP!
(HACCP= Hazard Analysis and Critical Control Point)
Coffee, Milk and other Ingredients:
• Do not use raw milk! Only use pasteurized- or UHT-milk! The milk must
be homogenized!
• Only use pre-refrigerated milk with a maximum temperature of 5 °C.
When the milk is over 5 °C it is not possible to dispense an optimal
product.
• For hygienic reasons it is recommended to use the milk directly from
the original packaging
• If using a milk container: Do not top up milk in the container, always
clean the container thoroughly before filling.
• Do not fill more coffee and milk than required for one day usage.
• It is recommended to throw away remains of milk at the end of the
day (in case the milk was in contact with the milk hoses).
• Check packages on damage before opening.
• Store coffee and ingredients in a dry, cool and dark place.
• Use the eldest ingredients first ("first-in-first-out" principle`).
• Finish the products before the expiry date.
• Seal an opened package properly to preserve freshness and to
prevent from contamination.
• Store coffee and ingredients seperately from cleaning agents.
• Close the cover of the bean container again immediately after filling
the beans!
Cleaning:
• Wash and disinfect your hands thoroughly before cleaning the
machine!
• Clean the machine daily after the coffee service has stopped.
• For daily and weekly cleaning, proceed as described in the User
Manual (chapter "Cleaning") and on the Quick Reference card.
• Never mix cleaning agents!
• Never use abrasives, scrubbers or cleaning tools made of metal!
• Never spray the machine with water or any other liquid!
• Never immerse the machine into water or any other liquid!
• Parts which come in contact with the beverage (during dispensing)
should not be touched after the cleaning.
• Follow the dosing instructions, safety notes and warnings included
with the cleaning products! Read the information on cleaning
agents in the chapter "Appendix".

Safety instructions
14 User manual E6 - 02 USA
www.schaererusa.com Version 01 / 03.2005 / REWE
Liability
Warranty and liability claims in the event of injury of people and damage
of property will not be entertained if they are due to one or more of the
following causes:
• Any use other than the designated one;
• Improper installation, usage, operation and service of the machine
and its options / accessories;
• Non-compliance with specified service intervals;
• Operating the machine with defective safety devices or with safety
devices that are not in place;
• Non-compliance with safety instructions in this manual with special
regard to storage, installation, usage, operation and service of the
machine;
• Operating the machine in other than perfect condition;
• Repairs not carried out by a qualified technician;
• Damage due to the influence of foreign bodies, accidents, vandalism
and force majeure;
• Intrusion into the machine with objects.
• Opening of the housing done by any other than a qualified
technician;
• Defects caused by the non-adherence to cleaning, operating and
similar guidelines;
• Defects due to the use of non-original parts or tampering with the
product
• Improper treatment and/or changes in the product.
• Service of the machine in accordance with maintenance regulations
set by the manufacturer.
Note that your machine is designed for professional use which has to be
maintained by a qualified service technician.
The maintenance rate is set in accordance with the output of the machine
and has to be carried out in minimum once per year!
Safety-relevant parts, such as safety valves, safety thermostats, boiler, etc.,
must be replaced and may not to be repaired under any circumstances.
The following parts must be replaced always:
• Safety valves every 12 months
• Boilers (steam generators, instant heaters) every 60 months.

Safety instructions
User manual E6 - 02 USA 15
Version 01 / 03.2005 / REWE www.schaererusa.com

Product description
16 User manual E6 - 03 USA
www.schaererusa.com Version 01 / 03.2005 / REWE
Product description
Espresso machine overview
(see page 4)
Espresso machine operating panel
(see page 4)
Espresso machine bean container(s)
Fill the container(s) on top of the machine with (freshly) roasted coffee
beans only. The machine grinds the beans freshly for each individual shot.
The front container is intended for regular espresso beans.
The rear container is intended for decafeinated espresso beans.
Espresso machine grounds container and drip tray
The grounds container is located below and behind the coffee spout.
It holds the used grounds which are disposed after each espresso shot .
The grounds container slides straight out from the machine and must be
emptied daily or when prompted by the display.
The drip tray should be checked regularly and drained when necessary.
The drip grid is removable for easy cleaning and access to the inside of the
drip tray.
The drip tray is removable for easy cleaning and draining.

Product description
User manual E6 - 03 USA 17
Version 01 / 03.2005 / REWE www.schaererusa.com
Serial plate
The serial plate contains the machine-specific data. The serial plate is on
the inside of the machine and is visible when the grounds container is
removed.
Operating information
Performance characteristics
The output per hour depends on the product type.
Output per hour: 60 Cups
Dimensions and weight
Width : 150 mm
Height : ± 801 mm
Depth : 669.5 mm
Coffee outlet height : 227 mm
Net weight : ± 20 kg
Subject to changes without notice!
Power requirements
Model: Connected load:
E6 1200 W / 15 A 120 VAC 60 Hz
The voltage on the serial plate must correspond to the local mains voltage.
For special voltages ask the manufacturer or one of your authorised after
sales people.
A qualified service technician must install or inspect the installation!
Volumes
1 hot water boiler:
0.35 l hot water
1 grounds container:
50 coffees
2 bean hoppers:
1,2 kg each hopper (regular and decaf)

Product description
18 User manual E6 - 03 USA
www.schaererusa.com Version 01 / 03.2005 / REWE
Equipment and accessories
Standard accessories (included in shipment)
Article: Order No.:
1 x User manual *
1 x Quick reference card *
1 x Installation Layout *
1 x Safety Data Sheet 020’822
1 x Measuring cup 061’020
1 x Cleaning brush 067’409
1 x Box Cleaning tablets 065’221
2 x Soft check strip 061’356

Product description
User manual E6 - 03 USA 19
Version 01 / 03.2005 / REWE www.schaererusa.com
Installation layout E6

Product description
20 User manual E6 - 03 USA
www.schaererusa.com Version 01 / 03.2005 / REWE
