Schlage L-SERIES User manual

Service Manual L
i
Table of Contents
Introduction....................................................................... 1-2
Standard Features ............................................................1
Dot Charts .........................................................................2
Lock Assembly Drawing Index ......................................3-14
Trim Assemblies ...........................................................15-34
Single Dummy Trim: L0170 ............................................15
Double Dummy Trim: L0172 ...........................................16
L400-Series Deadbolt Trim: L460, L462, L463, L464,
L480, L496 ......................................................................17
Passage Latch Trim: L9010 ............................................18
Emergency Button x Turn Trim: L9040, LV9040,
L9440*, LV9440* .............................................................19
Privacy x Turns Both Sides Trim: L9040 x XL11-446,
LV9040 x XL11-446 ........................................................20
Coin Turn Outside x Turn Trim: L9044, LV9044,
L9444*, LV9444* .............................................................21
Cylinder x Turn Trim: L9050, LV9050, L9056, LV9056,
L9453**, LV9453**, L9456*, LV9456*, L9473* ...............22
Double Cylinder Trim: L9060, LV9060, L9071, LV9071,
L9077, LV9077, L9082, LV9082, L9457*, LV9457*,
L9462 x XL11-886**, L9466* ..........................................23
Cylinder Outside Trim: L9070, LV9070, L9076, LV9076,
L9080, LV9080, L9080EL/EU, LV9080EL/EU,
L9080EL/EU-RX, L9464 x XL11-886**, L9465* ..............24
Electrically Locked/Unlocked Both Sides
Trim: L9082EL/EU ..........................................................25
Active Double Dummy Trim: L9110 x XL11-741 .............26
Single Dummy with Case Trim: L9175, L9177 ...............27
Double Dummy with Case Trim: L9176, L9178 ..............28
L9000-Series Deadbolt Trim: L9460, L9462, L9463,
L9464 ..............................................................................29
Deadbolt with Fixed Double Dummy
Trim: L9460 x XL11-635 .................................................30
Fixed Outside x Turn Trim: L9460 x XL11-886*, L9480,
LV9480, L9485, LV9485 .................................................31
Institution Deadbolt Trim: L9482 x XL11-543,
LV9482 x XL11-543 ........................................................32
Prison Lock Trim: L9485 x XL11-557 .............................33
Hotel with Indicator Trim: L9486, LV9486, L9486 x
L583-375, LV9486 x L583-375, L9496*, LV9496* ..........34
Trim Assemblies Chart .................................................36-47
Lock Case Assemblies .................................................48-85
L460, L462, L463, L464, L480, L496 ..............................48
L9010 ..............................................................................49
L9040, L9040 x XL11-446, L9044 ..................................50
LV9040, LV9040 x XL11-446, LV9044 ...........................51
L9050, L9060, L9070, L9071 ..........................................52
LV9050, LV9060, LV9070, LV9071 ................................53
L9056 ..............................................................................54
LV9056 ...........................................................................55
L9076, L9077 ..................................................................56
LV9076, LV9077 .............................................................57
L9080 ..............................................................................58
LV9080 ...........................................................................59
L9080EL, L9080EL-RX ...................................................60
LV9080EL .......................................................................61
L9080EU, L9080EU-RX ..................................................62
LV9080EU ......................................................................63
L9082 ..............................................................................64
LV9082 ...........................................................................65
L9082EL .........................................................................66
L9082EU .........................................................................67
L9110 x XL11-741 ..........................................................68
L9175 ..............................................................................69
L9176 ..............................................................................70
L9440, L9444 ..................................................................71
LV9440, LV9444 .............................................................72
L9453 ..............................................................................73
LV9453 ...........................................................................74
L9456, L9457, L9496 ......................................................75
LV9456, LV9457, LV9496 ...............................................76
L9460, L9462, L9463, L9464 ..........................................77
L9460 x XL11-635 ..........................................................78
L9460 x XL11-886, L9462 x XL11-886,
L9464 x XL11-886 ..........................................................79
L9465, L9466, L9473 ......................................................80
L9480, L9485, L9486, L9486 x L583-375 .......................81
LV9480, LV9485, LV9486, LV9486 x L583-375 .............82
L9482 x XL11-543 ..........................................................83
LV9482 x XL11-543 ........................................................84
L9485 x XL11-557 ..........................................................85
Lock Case Compatibility Chart .........................................86
Assembly of Lock Case Parts ..................................... 87-88
Turn Hub Spring and Transfer Lever ..............................87
Locking Catch / Retractor Catch and Locking Link .........87
L FUNCTIONS ONLY Fire Door Fuse, Fire Door
Catch and Hub Spring ....................................................88
LV FUNCTIONS ONLY Fire Door Fuse, Fire Door
Catch and Hub Spring ....................................................88
Trim Options .................................................................89-90
Cast or Forged Lever Designs ........................................89
Bent Extruded Bar Lever Design.....................................89
Inside Lever Assembly ....................................................89
Outside Lever Assembly .................................................89
Wrought Knob Designs ...................................................90
Inside Knob Assembly ....................................................90
Outside Knob Assembly .................................................90
Rose Trim A or B ...............................................................91
Inside Rose .....................................................................91
Blank Outside Rose ........................................................91
Outside Rose Dimensions ..............................................91
L Escutcheon Trim .......................................................92-93
Outside Escutcheon Dimensions ....................................92
Outside Escutcheons ......................................................92
Inside Escutcheons .........................................................93
N Escutcheon Trim ............................................................94
Outside Escutcheon Dimensions ....................................94
Inside Escutcheons .........................................................94
Decorative Trim ..................................................................95
Decorative Levers ...........................................................95
Decorative Roses ...........................................................95

LService Manual
ii
Decorative Trim ..................................................................95
Inside Lever Assembly ....................................................95
Outside Lever Assembly .................................................95
Danmark Stainless Steel Levers .......................................96
Trim Options ................................................................. 97-98
Coin Turn ........................................................................97
Coin Turn and Plug .........................................................97
“Do Not Disturb” Indicator ...............................................97
“Occupied” Indicator ........................................................97
09-900 x XL12-196 .........................................................97
Thumbturn .......................................................................97
ADA Cylinder Turn ..........................................................97
Cylinder Turn ..................................................................97
“EZ” Thumbturn (ADA) for Rose Trim .............................97
“EZ” Thumbturn (ADA) x Knob/Lever with
L or N Escutcheon ..........................................................97
“EZ” Thumbturn (ADA) x Blank with L Escutcheon .........97
Emergency Turn .............................................................98
Emergency Button ..........................................................98
Modified Inside and Outside 03 Lever for Folger
Adam Co.® Lever TrakTM ..............................................98
Tactile Warning (Knurling) ..............................................98
Trim Assembly Parts .........................................................99
Escutcheon Thru-Bolt/Screws .........................................99
Standard Screw Packs ....................................................99
Tamper Resistant Torx Screw Packs ..............................99
Mounting Posts .............................................................100
Mounting Plate for Trim One Side Only ........................100
Armor Fronts ....................................................................101
Strikes ...............................................................................102
Strike Dimensions and Components .............................102
Cylinder Lengths and Specifications .............................103
How to Measure Cylinder Lengths ................................103
Cylinder Length Dimension Chart .................................103
Cylinder and Length Requirements ..............................103
Full Face Cylinders .................................................. 104-105
Exploded View—Everest® Mortise Cylinder .................104
Exploded View—Classic Mortise Cylinder.....................104
Exploded View—Hotel Mortise Cylinder ........................104
L-Series (except L9060/LV9060 Outside) .....................105
L-Series L9060/LV9060 Outside .................................. 105
Concealed Cylinders ................................................ 106-107
Exploded View—Everest® Mortise Cylinder .................106
Exploded View—Hotel Mortise Cylinder .......................106
L-Series (except L9060/LV9060 Outside) .....................107
L-Series L9060/LV9060 Outside ...................................107
Full Size Interchangeable Cores ............................. 108-110
Exploded View – Full Size Classic ................................108
Exploded View – Full Size Hotel Classic ......................108
L-Series (except L9060/LV9060 Outside) .....................109
L-Series L9060/LV9060 Outside ...................................109
Full Size Cores ..............................................................110
Full Size Core Parts...................................................... 110
Small Format Interchangeable Cores ..................... 111-112
Exploded View – Small Format Everest® Keyways ......111
Everest® Patented Keyway Cores ................................111
L-Series (except L9060/LV9060 Outside) .....................112
L-Series L9060/LV9060 Outside ...................................112
Other Straight Cam Applications ...................................112
Blocking and Compression Rings .................................113
Dimensions for Blocking Rings .....................................113
Full Size Core Blocking Ring Requirements .................113
SFIC Blocking Ring Requirements ...............................113
Special Options ................................................................114
Solid Latchbolt ..............................................................114
Armor Front w/Deadbolt Hole .......................................114
Lead Lining XL11-515 ...................................................114
Special Cylinder Applications ........................................114
Electrically Locking .........................................................115
L9080/LV9080 EL Electrically Locked: .........................115
L9080/LV9080 EU Electrically Unlocked: ..................... 115
Request to Exit (RX) Feature*: .....................................115
L9082 EL or EU Electrically Locked or
Unlocked Both Sides: ....................................................115
Cylinders: ......................................................................115
Replacement Kit: ...........................................................115
Electrical Requirements: ...............................................115
Typical Installation: .......................................................115
Lubrication Specifications ..............................................116
Door Handing ...................................................................117
Changing the Lock Hand ..............................................117
L9000-Series Installation Sheet............................... 118-133
L400-Series Installation Sheet................................. 134-135
Ordering Procedures .......................................................136
Finishes ............................................................................137
Finish Codes and Descriptions .....................................137
Limited Warranty ..............................................................138
Notes ......................................................................... 139-140

Service Manual L
1
Introduction
This manual contains a complete listing of parts and assemblies for L-Series mortise locks manufactured by Schlage
Lock Company. This edition lists components of L-Series locks manufactured after June, 2001. All lock case covers are
labeled with dates to identify year of manufacture. Example: 12507 = the 125th day of 2007.
Exploded views of each lock function and trim assembly are provided with accompanying charts to identify parts for
replacement purposes. Exploded views of trim are shown with parts for standard size doors. In addition, this manual
provides lock trim ordering procedures, cylinder length charts by door range, and all auxiliary components of the
L/LV9000 and L400-Series mortise locks.
Standard Features
Certifications L/LV9000: ANSI A156.13, 1994, Series 1000, Grade 1 Operational, Grade 1 Security, UL Listed for 3 hour fire door (except L9076
and L9077). With Interchangeable Core Cylinders: Grade 2 Security
L400: ANSI A156.5, 2001, Grade 1, UL Listed for 3 hour fire door.
Case Size L/LV9000: 4⁷⁄₁₆'' x 6¹⁄₁₆'' x 1''; L400: 4⁷⁄₁₆'' x 3⁵⁄₈'' x 1''
Armor Front L/LV9000: 1¹⁄₄'' x 8''; L400: 1¹⁄₄'' x 5¹⁹⁄₃₂''
Deadbolt 1'' Throw stainless steel
Latchbolt ³⁄₄'' Throw stainless steel with anti-friction tongue
Strike L/LV9000: 1¹⁄₄'' x 4⁷⁄₈'' Square corner, 1³⁄₁₆'' lip, box; L400: 1¹⁄₈'' x 3⁵⁄₈'' square corner, box
Backset 2³⁄₄''
Cylinder 6-Pin solid brass, keyed 5-pin, C123 keyway, keyed different (KD)*
Door Range 1³⁄₄''
Keys Two nickel silver cut keys per lock, 6-pin, C123-section*
* Items specified in C keyway will be furnished with cylinders keyed 5-pin and with 5-pin keys unless otherwise specified.
NOTE: Locks are furnished with standard features unless otherwise specified.
Strike
1¹⁄₄" (32)
or
1¹⁄₁₆"
(27)
1¹⁄₄"
(32)1³⁄₁₆"
(30)
⁵⁄₈"
(16)
³⁄₈"
(10)
³⁄₈"
(10)
⁵⁄₈"
(16)
³⁄₈"
(10)
⁵⁄₃₂"
(4)
3"
(76) 2⁹⁄₆₄"
(54)
1²³⁄₃₂"
(44)
Cylinder
cut-out
Height
Line
2²³⁄₃₂"
(69)
¹⁵⁄₁₆"
(24) 1¹⁄₈"
(29)
⁷⁄₃₂"
(6)
1" (25)
Bevel ¹⁄₈" in 2" (3in 51)
2³⁄₄" (70)
Backset
4⁷⁄₁₆" (113)
⁵⁄₈"
(16) ³⁄₄"
(19)
³⁄₄"
(19)
⁵⁄₈"
(16) Lock
Front
C
L
¹⁷⁄₃₂"
(14)
Mounting
Holes
Knobor Lever
Cut-out
Turn Piece
and
Occupancy
Indicator
3⁵⁵⁄₆₄"
(98)
3"
(76)
4"
(102)
4⁷⁄₈"
(124)
⁷⁄₈"
(22)
⁷⁄₈"
(22)
C
L
³⁄₈"
(10) C
L
4"
(102)
C
L
C
L
3³⁄₈"
(86)
(Standard)
(Optional)

LService Manual
2
Introduction
Dot Charts
• = (1) part
2 = (2) parts
Example:
All parts shown in dot charts are standard. Additional options may be available. See current Schlage Commercial Price
Book for available options, pricing and ordering procedures.
Lock Assembly Drawing Index
The Lock Assembly Drawing Index provides representations and descriptions of available functions. Page numbers for
full trim and chassis drawings are referenced.
P/N Description
L9110/XL11-741
L9175 L9176
L9177 (disc) L9178 (disc) L9410 (disc)
L9440
LV9440
L9444*
LV9444*
L9453
LV9453
L9456
LV9456
L9457
LV9457
L9460
L9460/XL11-635 L9460/XL11-886
L9462
L9462/XL11-886
L9463 L9464
L9464/XL11-886
L9465 L9466 L9473 L9480
LV9480
L9482/XL11-543
LV9482/XL11-543
L9485
LV9485
L9485/XL11-557**
LV9485/XL11-557
L9486***
LV9486***
L9496
LV9496
30-001 Clover leaf cam • ••••22•••22••••2•••22•• ••
Outside Inside
EmergencyTurn
Latchbolt
CoinTurn
Deadbolt
Thumbturn
Cylinder Auxiliary
Latch
Electrified
Cylinder
CylinderTurn
Occupancy
Indicator
Two-piece Spindle
Solid Spindle
One-piece Outside Spindle
DO NOT DISTURB
Electrified

Service Manual L
3
Lock Assembly Drawing Index
† Not sold separately as a part.

Available with Request to Exit feature. See page 114 for Request to Exit information.
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Non-Keyed Locks
SCHLAGE® ANSI
L0170 Single Dummy Trim
Knob/lever on one side is fixed by mounting bar. 15 — —
L0172 Double Dummy Trim
Knob/lever on both sides is fixed by mounting bar. 16 — —
L9010 F01 Passage Latch 
Latchbolt is always retracted by knob/lever from either side. 18 48 L283-131
L9040 F22 Bath/Bedroom Privacy Lock
Latchbolt is retracted by knob/lever from either side unless
outside is locked by inside turn piece. Turning inside knob/lever
or closing door unlocks outside knob/lever. To unlock from
outside, remove emergency button, insert emergency turn in
access hole and rotate.
19 49 L283-132
LV9040 Bath/Bedroom Privacy Lock with Vandlgard®
Latchbolt is retracted by knob/lever from either side unless
outside is locked by inside turn piece. Turning inside knob/lever
or closing door unlocks outside knob/lever. To unlock from
outside, remove emergency button, insert emergency turn in
access hole and rotate. Vandlgard function allows exterior lever
to rotate freely down, while remaining securely locked.
19 50 L283-171†
L9040 x XL11-446 Privacy with Turns Both Sides
Latchbolt is retracted by knob/lever from either side unless
outside is locked by inside or outside turn piece. Turning inside
knob/lever or closing door unlocks outside knob/lever.
Specify per XL11-446.
20 49 L283-132
L9044 Privacy with Coin Turn Outside
Latchbolt is retracted by knob/lever from either side unless
outside is locked by inside turn piece or outside coin turn.
Operating inside knob/lever, closing door, rotating inside turn
piece or outside coin turn unlocks outside knob/lever. Available
in rose trim only. Specify per L283-056 for Torx screws.
(Previously XL11-868)
21 49 L283-132
LV9044 Privacy with Coin Turn Outside with Vandlgard®
Latchbolt is retracted by knob/lever from either side unless
outside is locked by inside turn piece. Operating inside
knob/lever, closing door, rotating inside turn piece or outside
coin turn unlocks outside knob/lever. Available with rose trim
only. Vandlgard function allows exterior lever to rotate freely
down while remaining securely locked. Specify per L283-056 for
Torx screws.
21 50 L283-171†

LService Manual
4
Lock Assembly Drawing Index
† Not sold separately as a part.
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Non-Keyed Locks
SCHLAGE® ANSI
L9110 x XL11-741 Double Dummy with Active Trim
Knob/lever is always active on both sides. Includes lock case
and armor front. Specify XL11-741 for use on active door, or
specify XL11-743 for use on inactive door (furnished with armor
front with cutout to receive deadbolt).
26 — —
L9175 Single Dummy with Lock Case
Inoperable knob/lever on one side. Includes lock case and
armor front.
27 68 L283-144
L9176 Double Dummy with Lock Case
Inoperable knob/lever on both sides. Includes lock case and
armor front.
28 69 L283-145
L9440 Privacy with Deadbolt
Latchbolt is retracted by knob/lever from either side. Deadbolt is
thrown or retracted by inside turn piece. Throwing deadbolt locks
outside knob/lever. Rotating inside knob/lever simultaneously
retracts deadbolt and latchbolt and unlocks outside knob/lever.
To unlock from outside, remove emergency button, insert turn
piece in access hole and rotate. (Previously XL11-761)
19 70 L283-062
LV9440 Privacy with Deadbolt with Vandlgard®
Latchbolt retracted by knob/lever from either side. Deadbolt is
thrown or retracted by inside turn piece. Throwing deadbolt locks
outside knob/lever. Rotating inside knob/lever simultaneously
retracts deadbolt and latchbolt and unlocks outside knob/lever. To
unlock from outside, remove emergency button, insert turn piece
in access hole and rotate. Vandlgard function allows exterior lever
to rotate freely down while remaining securely locked.
19 71 L283-181†
L9444 Privacy with Deadbolt and Coin Turn
Latchbolt is retracted by knob/lever from either side. Deadbolt is
thrown or retracted by inside turn piece or outside coin turn.
Throwing deadbolt locks outside knob/lever. Rotating inside
knob/lever simultaneously retracts deadbolt and latchbolt and
unlocks outside knob/lever. Rotating outside coin turn retracts
deadbolt and unlocks outside knob/lever. Available with rose trim
only. Specify per L283-056 for Torx screws.
(Previously XL11-868)
21 70 L283-062
LV9444 Privacy with Deadbolt and Coin Turn with Vandlgard®
Latchbolt is retracted by knob/lever from either side. Deadbolt is
thrown or retracted by inside turn piece or outside coin turn.
Throwing deadbolt locks outside knob/lever. Rotating inside
knob/lever simultaneously retracts deadbolt and latchbolt and
unlocks outside knob/lever. Rotating outside coin turn retracts
deadbolt and unlocks outside knob/lever. Available with rose trim
only. Vandlgard function allows exterior lever to rotate freely
down while remaining securely locked. Specify per L283-056 for
Torx screws.
21 71 L283-181†

Service Manual L
5
Lock Assembly Drawing Index
† Not sold separately as a part.

Available with Request to Exit feature. See page 114 for Request to Exit information.
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Keyed Locks
SCHLAGE ANSI
L9050 F04 Office and Inner Entry Lock 
Latchbolt is retracted by knob/lever from either side unless
outside is made inoperative by key outside or inside turn piece.
When outside is locked, latchbolt is retracted by key outside or
by knob/lever inside. Outside knob/lever remains locked until
thumbturn is returned to vertical position or unlocked by key.
Auxiliary latch deadlocks latchbolt when door is closed. Inside
knob/lever is always free for immediate exit.
22 51 L283-133
LV9050 Office and Inner Entry Lock with Vandlgard® 
Latchbolt is retracted by knob/lever from either side unless
outside is made inoperative by key outside or inside turn piece.
When outside is locked, latchbolt is retracted by key outside or
by knob/lever inside. Outside knob/lever remains locked until
turn piece is returned to vertical position or unlocked by key.
Auxiliary latch deadlocks latchbolt when door is closed. Inside
knob/lever is always free for immediate exit. Vandlgard function
allows exterior lever to rotate freely down while remaining
securely locked.
22 52 L283-170†
L9056 L9050 with Automatic Unlocking 
Latchbolt is retracted by knob/lever from either side unless
outside is made inoperative by key outside or inside turn piece.
Outside knob/lever is unlocked by key outside or turn piece.
Rotating inside knob/lever simultaneously retracts latchbolt and
unlocks outside knob/lever. Auxiliary latch deadlocks latchbolt
when door is closed. Inside knob/lever is always free for
immediate exit. (Previously XL11-776)
22 53 L283-126
LV9056 L9050 with Automatic Unlocking with Vandlgard®
Latchbolt is retracted by knob/lever from either side unless
outside is made inoperative by key outside or inside turn piece.
Outside knob/lever is unlocked by key outside or turn piece.
Rotating inside knob/lever simultaneously retracts latchbolt and
unlocks outside knob/lever. Auxiliary latch deadlocks latchbolt
when door is closed. Inside knob/lever is always free for
immediate exit. Vandlgard function allows exterior lever to rotate
freely down while remaining securely locked.
22 54 L283-180†
L9060 F09 Apartment Entrance Lock 
Latchbolt is retracted by knob/lever from either side unless
outside is locked by key from inside. When locked, latchbolt is
retracted by key outside or knob/lever inside. Auxiliary latch
deadlocks when door is closed. Inside knob/lever is always free
for immediate exit.
23 51 L283-133
LV9060 Apartment Entrance Lock with Vandlgard®
Latchbolt is retracted by knob/lever from either side unless
outside is locked by key from inside. When locked, latchbolt is
retracted by key outside or knob/lever inside. Auxiliary latch
deadlocks when door is closed. Inside knob/lever is always free
for immediate exit. Vandlgard function allows exterior lever to
rotate freely down while remaining securely locked.
23 52 L283-170†

LService Manual
6
Lock Assembly Drawing Index
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Keyed Locks
SCHLAGE ANSI
L9070 F05 Classroom Lock 
Latchbolt is retracted by knob/lever from either side unless
outside is locked by key. Outside is unlocked by key. Inside
knob/lever is always free for immediate exit. Auxiliary latch
deadlocks latchbolt when door is closed.
24 51 L283-133
LV9070 Classroom Lock with Vandlgard® 
Latchbolt is retracted by knob/lever from either side unless
outside is locked by key. Outside is unlocked by key. Inside
knob/lever is always free for immediate exit. Auxiliary latch
deadlocks latchbolt when door is closed. Vandlgard function
allows exterior lever to rotate freely down while remaining
securely locked.
24 52 L283-170†
L9071 Classroom Security Lock 
Latchbolt is retracted by knob/lever from either side unless
locked by key from either side. When locked, latchbolt is
retracted bykey outside or knob/lever inside. Inside knob/lever is
always free for immediate exit. Auxiliary latch deadlocks
latchbolt when door is closed.
23 51 L283-133
LV9071 Classroom Security Lock with Vandlgard® 
Latchbolt is retracted by knob/lever from either side unless
locked by key from either side. When locked, latchbolt is
retracted bykey outside or knob/lever inside. Inside knob/lever is
always free for immediate exit. Auxiliary latch deadlocks
latchbolt when door is closed. Vandlgard function allows exterior
lever to rotate freely down while remaining securely locked.
23 52 L283-170†
L9076 F06 Classroom Holdback Lock* 
Latchbolt is retracted by knob/lever from either side unless
locked by key outside. When locked, latchbolt is retracted by key
outside or knob/lever inside. Inside knob/lever is always free for
immediate exit. Auxiliary latch deadlocks latchbolt when door is
closed. Depress inside knob/lever and turn key 360° for
holdback feature.
24 55 L283-039
LV9076 Classroom Holdback Lock* with Vandlgard® 
Latchbolt is retracted by knob/lever from either side unless
locked by key outside. When locked, latchbolt is retracted by key
outside or knob/lever inside. Inside lever is always free for
immediate exit. Auxiliary latch deadlocks latchbolt when door is
closed. Depress inside knob/lever and turn key 360° for
holdback feature. Vandlgard function allows exterior lever to
rotate freely down while remaining securely locked.
24 56 L283-172†
L9077 Classroom Security Holdback Lock* 
Latchbolt is retracted by knob/lever from either side unless
locked by key from either side. When locked, latchbolt is
retracted by key outside or knob/lever inside. Auxiliary latch
deadlocks latchbolt when door is closed. Depress inside
knob/lever and turn key 360° for holdback feature.
23 55 L283-039
LV9077 Classroom Security Holdback Lock* with Vandlgard® 
Latchbolt is retracted by knob/lever from either side unless locked
by key from either side. When locked, latchbolt is retracted by key
outside or knob/lever inside. Auxiliary latch deadlocks latchbolt
when door is closed. Depress inside knob/lever and turn key
360° for holdback feature. Vandlgard function allows exterior
23 56 L283-172†
* Locks with holdback feature are not UL listed. Installation should be in accordance with existing codes only.
† Not sold separately as a part.
 Available with Request to Exit feature. See page 114 for Request to Exit information.

Service Manual L
7
Lock Assembly Drawing Index
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Keyed Locks
SCHLAGE ANSI
L9080 F07 Storeroom Lock 
Latchbolt is retracted by key outside or by knob/lever inside.
Outside knob/lever is always inoperative. Auxiliary latch
deadlocks latchbolt when door is closed. Inside knob/lever is
always free for immediate exit.
24 57 L283-134
LV9080 Storeroom Lock with Vandlgard® 
Latchbolt is retracted by key outside or by knob/lever inside.
Outside knob/lever is always inoperative. Auxiliary latch
deadlocks latchbolt when door is closed. Inside knob/lever is
always free for immediate exit. Vandlgard function allows exterior
lever to rotate freely down while remaining securely locked.
24 58 L283-173†
L9080EL Electrically Locked (Fail Safe) 
Outside knob/lever is continuously locked. Latchbolt is retracted
by key outside or by knob/lever inside. Switch or power failure
allows outside knob/lever to retract latchbolt. Auxiliary latch
deadlocks latchbolt when door is closed. Inside knob/lever is
always free for immediate exit.
24 59 L283-142
LV9080EL Electrically Locked (Fail Safe) with Vandlgard® 
Outside knob/lever is continuously locked. Latchbolt is retracted
by key outside or by knob/lever inside. Switch or power failure
allows outside knob/lever to retract latchbolt. Auxiliary latch
deadlocks latchbolt when door is closed. Inside knob/lever is
always free for immediate exit. Vandlgard function allows exterior
lever to rotate freely down while remaining securely locked.
24 60 L283-174†
L9080EU Electrically Unlocked (Fail Secure) 
Outside knob/lever is continuously unlocked. Latchbolt is
retracted by key outside or by knob/lever inside. Inside
knob/lever is always free for immediate exit. Auxiliary latch
deadlocks latchbolt when door is closed.
24 61 L283-143
LV9080EU Electrically Unlocked (Fail Secure) with Vandlgard® 
Outside knob/lever is continuously unlocked. Latchbolt is
retracted by key outside or by knob/lever inside. Inside
knob/lever is always free for immediate exit. Auxiliary latch
deadlocks latchbolt when door is closed. Vandlgard function
allows exterior lever to rotate freely down, while remaining
securely locked.
24 62 L283-175†
L9080EL-RX Request to Exit Electrically Locked
Same as L9080EL function. In addition, a microswitch
positioned inside the lock case is activated when either inside or
outside knob/lever is rotated. The switch signals the use of that
opening to security systems, allowing a non-disruptive means of
immediate exit. Specify L283-059 for normally closed or
L283-125 for normally open. (Previously XL11-807)
24 59 L283-142
per L283-059
for normally
closed.
L283-142
per L283-125
for normally
open.
† Not sold separately as a part.
 Available with Request to Exit feature. See page 114 for Request to Exit information.

LService Manual
8
Lock Assembly Drawing Index
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Keyed Locks
SCHLAGE ANSI
L9080EU-RX Request to Exit Electrically Unlocked (Fail Secure)
Same as L9080EU function. In addition, a microswitch
positioned inside the lock case is activated when either inside or
outside knob/lever is rotated. The switch signals the use of that
opening to security systems, allowing a non-disruptive means of
immediate exit. Specify L283-059 for normally closed or
L283-125 for normally open. (Previously XL11-807)
24 61 L283-143
per L283-059
for normally
closed.
L283-143
per L283-125
for normally
open.
L9082 Institution Lock*
Latchbolt is retracted by key on either side. Knob/lever on both
sides is always inoperative. Auxiliary latch deadlocks latchbolt
when door is closed.
23 63 L283-146
LV9082 Institution Lock* with Vandlgard®
Latchbolt is retracted by key on either side. Inside and outside
knob/lever are always inoperative. Auxiliary latch deadlocks
latchbolt when door is closed. Vandlgard function allows exterior
lever to rotate freely down while remaining securely locked.
23 64 L283-182†
L9082EL Electrically Locked (Fail Safe) Both Sides 
Outside and inside knob/lever are continuously locked. Latchbolt
is retracted by key on either side. Switch or power failure allows
inside and outside knob/lever to retract latchbolt. Auxiliary latch
deadlocks latchbolt when door is closed. (Previously XL11-452)
25 65 L283-085
L9082EU Electrically Unlocked (Fail Secure) Both Sides* 
Outside and inside knob/lever are continuously unlocked.
Latchbolt is retracted by key on either side. Switch or power
failure prevents retraction of latchbolt by inside and outside
knob/lever. (Previously XL11-452)
25 66 L283-086
L9453 F20 Entrance Lock 
Latchbolt is retracted by knob/lever from either side unless
outside is locked by 20° rotation of turn piece. Deadbolt is
thrown or retracted by 90° rotation of turn piece. When locked,
key outside or knob/lever inside retracts deadbolt and latchbolt
simultaneously. Outside knob/lever remains locked until turn
piece is returned to vertical position. Throwing deadbolt
automatically locks outside knob/lever. Auxiliary latch deadlocks
latchbolt when door is closed. Inside knob/lever is alwaysfree for
immediate exit.
22 72 L283-137
LV9453 Entrance Lock with Vandlgard® 
Latchbolt is retracted by knob/lever from either side unless
outside is locked by key outside or 20º rotation of turn piece.
Deadbolt is thrown or retracted by 90º rotation of turn piece.
When locked, key outside or knob/lever inside retracts deadbolt
and latchbolt simultaneously. Outside knob/lever remains locked
until turn piece is returned to vertical position. Throwing
deadbolt automatically locks outside knob/lever. Auxiliary latch
deadlocks latchbolt when door is closed. Vandlgard function
allows exterior lever to rotate freely down while remaining
securely locked.
22 73 L283-176†
* CAUTION: Double cylinder locks on residences—or on any door in any structure which are used for egress—are a life safety hazard in times of
emergency, and their use is not recommended. Installation should be in accordance with existing codes only.
† Not sold separately as a part.
 Available with Request to Exit feature. See page 114 for Request to Exit information.

Service Manual L
9
Lock Assembly Drawing Index
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number Lock Case Part Number
Keyed Locks
SCHLAGE ANSI
L9456 F13 Corridor Lock 
Latchbolt is retracted by knob/lever from either side. Deadbolt is
operated by key outside or inside turn piece. Engaging deadbolt
locks outside knob/lever. Turning inside knob/lever
simultaneously retracts deadbolt and latchbolt and unlocks
outside knob/lever. Inside knob/lever is always free for
immediate exit.
22 74 L283-138
LV9456 Corridor Lock wtih Vandlgard® 
Latchbolt is retracted by knob/lever from either side. Deadbolt is
operated by key outside or inside turn piece. Engaging deadbolt
locks outside knob/lever. Turning inside knob/lever
simultaneously retracts deadbolt and latchbolt and unlocks
outside knob/lever. Inside knob/lever is always free for
immediate exit. Vandlgard function allows exterior lever to
rotate freely down while remaining securely locked.
22 75 L283-177†
L9457 Classroom Security Lock 
Latchbolt is retracted by knob/lever from either side. Deadbolt is
operated by key from either side. Engaging deadbolt locks
outside knob/lever. Turning inside knob/lever simultaneously
retracts deadbolt and latchbolt and unlocks outside knob/lever.
Inside knob/lever is always free for immediate exit.
23 74 L283-138
LV9457 Classroom Security Lock with Vandlgard® 
Latchbolt is retracted by knob/lever from either side. Deadbolt is
operated by key from either side. Engaging deadbolt locks
outside knob/lever. Turning inside knob/lever simultaneously
retracts deadbolt and latchbolt and unlocks outside knob/lever.
Inside knob/lever is always free for immediate exit. Vandlgard
function allows exterior lever to rotate freely down while
remaining securely locked.
23 75 L283-177†
L9460 x XL11-635 L9460 with Fixed Dummy Trim
Knob/lever is always fixed on both sides. Deadbolt is operated
by key outside or turn piece inside. Specify per XL11-635.
30 77 XL11-661†
L9460 x XL11-886 Deadbolt with Retraction by Inside Knob/Lever
Deadbolt is operated by key outside or turn piece inside.
Rotating inside knob/lever retracts deadbolt. Outside knob/lever
is always fixed. Specify per XL11-886.
31 78 —
L9462 x XL11-886 Double Cylinder Deadbolt with Retraction by Inside
Knob/Lever
Deadbolt is operated by key either side. Rotating inside
knob/lever retracts deadbolt. Outside knob/lever is always fixed.
Specify per XL11-886.
23 78 —
† Not sold separately as a part.
 Available with Request to Exit feature. See page 114 for Request to Exit information.

LService Manual
10
Lock Assembly Drawing Index
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Keyed Locks
SCHLAGE ANSI
L9464 x XL11-886 Single Cylinder Deadbolt with Retraction by Inside
Knob/Lever
Deadbolt is operated by key outside. Rotating inside knob/lever
retracts deadbolt. Outside knob/lever is always fixed.
Specify per XL11-886.
24 78 —
L9465 Closet/Storeroom Lock
Latchbolt is operated by knob/lever from either side. Deadbolt is
operated by key outside.
24 79 L283-140
L9466 F14 Storeroom/Utility Room Lock*
Latchbolt is operated by knob/lever from either side. Deadbolt is
operated by key from either side.
23 79 L283-140
L9473 F21 Dormitory/Bedroom Lock
Latchbolt is operated by knob/lever from either side. Deadbolt is
operated by key outside or turn piece inside.
22 79 L283-140
L9480 Storeroom Lock with Deadbolt
Latchbolt is operated by key outside or by knob/lever inside.
Outside knob/lever is always fixed. Deadbolt is operated by key
outside or turn piece inside. Turning inside knob/lever
simultaneously retracts both deadbolt and latchbolt. Auxiliary
latch deadlocks latchbolt when door is closed. Inside knob/lever
is always free for immediate exit. (Previously XL11-591)
31 80 L283-141
LV9480 Storeroom Lock with Deadbolt with Vandlgard®
Latchbolt is operated by key outside or by knob/lever inside.
Outside knob/lever is always inoperativef. Deadbolt is operated
by key outside or turn piece inside. Turning inside knob/lever
simultaneously retracts both deadbolt and latchbolt. Auxiliary
latch deadlocks latchbolt when door is closed. Inside knob/lever
is always free for immediate exit. Vandlgard function allows
exterior lever to rotate freely down while remaining securely
locked. (Previously XL11-591)
31 81 L283-178†
* CAUTION: Double cylinder locks on residences—or on any door in any structure which are used for egress—are a life safety hazard in times of
emergency, and their use is not recommended. Installation should be in accordance with existing codes only.
† Not sold separately as a part.

Service Manual L
11
Lock Assembly Drawing Index
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Keyed Locks
SCHLAGE ANSI
L9482 x XL11-543 Institution Lock with Deadbolt*
Latchbolt is operated by key from either side. Knob/lever on both
sides is always fixed. Deadbolt is operated by key either side.
Auxiliary latch deadlocks latchbolt when door is closed.
Specify per XL11-543.
32 82 —
LV9482 x XL11-543 Institution Lock with Deadbolt* with Vandlgard®
Latchbolt is operated by key from either side. Inside and outside
knob/lever are always inoperative. Deadbolt is operated by key
either side. Auxiliary latch deadlocks latchbolt when door is
closed. Vandlgard function allows exterior lever to rotate freely
down while remaining securely locked. Specify per XL11-543.
32 83 —
L9485 Hotel or Restroom Lock
Latchbolt is operated by key outside or by knob/lever inside.
Outside knob/lever is always fixed. Deadbolt is operated by
inside turn piece. When deadbolt is thrown all keys become
inoperative except emergency keys. Turning inside knob/lever
simultaneously retracts both deadbolt and latchbolt. Auxiliary
latch deadlocks latchbolt when door is closed.
31 80 L283-141
LV9485 Hotel or Restroom Lock with Vandlgard®
Latchbolt is retracted by key outside or by knob/lever inside.
Outside knob/lever is always inoperative. Deadbolt is thrown or
retracted by inside turn piece. When deadbolt is thrown, all keys
become inoperative except emergency or display keys. Turning
inside knob/lever simultaneously retracts both deadbolt and
latchbolt. Auxiliary latch deadlocks latchbolt when door is
closed. Vandlgard function allows exterior lever to rotate freely
down while remaining securely locked.
31 81 L283-178†
L9485 x XL11-557 Prison Lock
Latchbolt is operated by key outside or by knob inside. Outside
knob is always free spinning. Inside knob is fixed when deadbolt
is thrown. Deadbolt is operated by guard’s key. Prisoner’s key
only operates latchbolt. Furnished with Torx screws. No longer
available with the XPO prison knob. Specify per XL11-557.
33 84 —
L9486 F15 Hotel Lock with “Do Not Disturb” Indicator
Latchbolt is operated by key outside or by knob/lever inside.
Outside knob/lever is always fixed. Deadbolt is operated by
inside turn piece. When deadbolt is thrown, “DO NOT DISTURB”
plate is displayed. Deadbolt is operated by turn from inside which
shuts out all keys except emergency keys. Inside knob/lever
simultaneously retracts both deadbolt and latchbolt. Auxiliary
latch deadlocks latchbolt when door is closed.
34 80 L283-141
* CAUTION: Double cylinder locks on residences—or on any door in any structure which are used for egress—are a life safety hazard in times of
emergency, and their use is not recommended. Installation should be in accordance with existing codes only.
† Not sold separately as a part.
DO NOT DISTURB

LService Manual
12
Lock Assembly Drawing Index
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Keyed Locks
SCHLAGE ANSI
LV9486 Hotel Lock with “Do Not Disturb” Indicator with
Vandlgard®
Latchbolt is operated by key outside or by knob/lever inside.
Outside knob/lever is always inoperative. Deadbolt is operated
by inside turn piece. When deadbolt is thrown, “DO NOT
DISTURB” plate is displayed. Deadbolt is operated by turn from
inside which shuts out all keys except emergency keys. Inside
knob/lever simultaneously retracts both deadbolt and latchbolt.
Vandlgard function allows exterior lever to rotate freely down
while remaining securely locked.
34 81 L283-178†
L9486 x L583-375 Hotel Lock with “Occupied” Indicator
Latchbolt is operated by key outside or by knob/lever inside.
Outside knob/lever is always inoperative. Deadbolt is operated
by inside turn piece. When deadbolt is thrown, “OCCUPIED”
plate is displayed. Deadbolt is operated by turn from inside
which shuts out all keys except emergency keys. Inside
knob/lever simultaneously retracts both deadbolt and latchbolt.
Auxiliary latch deadlocks latchbolt when door is closed. Specify
per L583-375. (Previously XL11-580)
34 80 L283-141
LV9486 x L583-375 Hotel Lock with “Occupied” Indicator with Vandlgard®
Latchbolt is operated by key outside or by knob/lever inside.
Outside knob/lever is always inoperative. Deadbolt is operated
by inside turn piece. When deadbolt is thrown, “OCCUPIED”
plate is displayed. Deadbolt is operated by turn from inside
which shuts out all keys except emergency keys. Inside
knob/lever simultaneously retracts both deadbolt and latchbolt.
Auxiliary latch deadlocks latchbolt when door is closed.
Vandlgard function allows exterior lever to rotate freely down
while remaining securely locked. Specify per L583-375.
34 81 L283-178
L9496 Privacy Lock with “Occupied” Indicator 
Latchbolt is operated by knob/lever on either side. Deadbolt is
operated by key outside (retraction by key required in the event
of an emergency) or inside turn piece. Throwing deadbolt locks
outside knob/lever and displays “OCCUPIED” plate. Rotating
inside knob/lever simultaneously retracts both deadbolt and
latchbolt and unlocks outside knob/lever. (Previously XL11-885)
34 74 L283-138
LV9496 Privacy Lock with “Occupied” Indicator 
Latchbolt is operated by knob/lever either side. Deadbolt is
operated by key outside (retraction by key required in the event
of an emergency) or inside turn piece. Throwing deadbolt locks
outside knob/lever and displays “OCCUPIED” plate. Rotating
inside knob/lever simultaneously retracts both deadbolt and
latchbolt and unlocks outside knob/lever. Vandlgard function
allows exterior lever to rotate freely down while remaining
securely locked.
34 75 L283-177†
† Not sold separately as a part.

Available with Request to Exit feature. See page 114 for Request to Exit information.
DO NOT DISTURB
OCCUPIED
OCCUPIED
OCCUPIED
OCCUPIED

Service Manual L
13
Lock Assembly Drawing Index
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Keyed L400-Series
SCHLAGE ANSI
L460 E06071 Cylinder by Thumbturn Lock
Deadbolt is operated by key outside or thumbturn inside.
Available with rose trim only.
17 47 L283-099
L462 E06061 Double Cylinder Lock*
Deadbolt is operated by key on either side. Available with rose
trim only.
17 47 L283-099
L463 E06091 Classroom Lock
Deadbolt is operated by key from outside. Inside cylinder turn
retracts deadbolt but cannot extend it. Door hand must be
specified. Available with rose trim only.
17 47 L283-099
L464 E06081 Cylinder Lock
Deadbolt is operated by key from one side. No trim on opposite
side. Available with rose trim only.
17 47 L283-099
L496 Deadbolt with “Occupied” Indicator
Deadbolt is operated by key outside or turn piece inside.
Furnished with 09-611 per L583-375 indicator.When deadbolt is
thrown “OCCUPIED” plate is displayed. Available with rose trim
only. (Previously XL11-911)
17 47 L283-099
Non-Keyed L400-Series
SCHLAGE ANSI
L480 F14 Door Bolt
Deadbolt is operated by thumbturn one side. No trim on
opposite side.
17 47 L283-099
* CAUTION: Double cylinder locks on residences—or on any door in any structure which are used for egress—are a life safety hazard in times of
emergency, and their use is not recommended. Installation should be in accordance with existing codes only.

LService Manual
14
Lock Assembly Drawing Index
Functions
ANSI A156.13, 1994 Series 1000
Trim
Assembly
Page Number
Lock
Assembly
Page Number
Lock Case
Part Number
Keyed L9000-Series Deadbolts
SCHLAGE ANSI
L9460 F17 Cylinder by Thumbturn Lock
Deadbolt is operated by key outside or turn piece inside. 29 76 L283-139
L9462 F16 Double Cylinder Lock*
Deadbolt is operated by key either side. 29 76 L283-139
L9463 Classroom Lock
Deadbolt is operated by key outside. Inside cylinder turn retracts
deadbolt but cannot extend it.
29 76 L283-139
L9464 F18 Cylinder Lock
Deadbolt is operated by key from one side. No trim on
opposite side.
29 76 L283-139
* CAUTION: Double cylinder locks on residences—or on any door in any structure which are used for egress—are a life safety hazard in times of
emergency, and their use is not recommended. Installation should be in accordance with existing codes only.

Service Manual L
15
Trim Assemblies
Single Dummy Trim: L0170
B
C
YII
AA GG
B
S
B
SICC V
GG
AA
HH
C
B
ICC V
22
22
Levers
Knobs

LService Manual
16
Trim Assemblies
Double Dummy Trim: L0172
B
S I
CC
V
B
C
Y II GG
AA II
EE X D
A
E
A
J
X
G
B
B
S I
CC
V
GG
AA
EE U U
E
D
U
A
A
U
G
J
U
U
C
HH
2
2 2
2
2 2
Levers
Knobs
