SCHOTT KL 1500 compact User guide

System diagram KL 1500 LCD | KL 2500 LCD
Light guide adapter 02.03.02
to connect Volpi-, Photonic- and
SCHOTT Fostec light guides to
SCHOTT KL 1500 e, KL 1500 LCD
and KL 2500 LCD P/N 158 320
KL 1500 LCD 01.30.01
230 V P/N 150 200
120 V P/N 150 201
Insert filter with holder 17.50.03
blue P/N 158 302
red P/N 158 303
green P/N 158 304
yellow P/N 158 305
daylight filter P/N 158 306
Polarisation filter 17.01.01
for annular ring light Øi= 66 mm P/N 158 430
for annular ring light Øi= 58 mm P/N 158 440
Holder for Maxi ringlight 17.03.01
Øi= 58 mm P/N 157 445
Gooseneck light guide
1-branch 17.25.01
Ø = 4.5 mm/600 mm P/N 154 101
Gooseneck light guide
2-branch 17.25.01
Ø = 4.5 mm/600 mm P/N 154 202
Gooseneck light guide
3-branch 17.25.01
Ø = 4.5 mm/600 mm P/N 154 302
Flexible light guide
1-branch, M-PVC 17.20.01
Ø = 3.0 mm/1000 mm P/N 155 101
(only for KL 1500 LCD)
Ø = 5.0 mm/1000 mm P/N 155 100
Ø = 5.0 mm/1600 mm P/N 155 102
Ø = 8.0 mm/1000 mm P/N 155 103
Flexible light guide
2-branch, M-PVC 17.21.01
Ø = 4.5 mm/1000 mm P/N 155 204
Ø = 5.0 mm/1600 mm P/N 155 205
Flexible light guide
3-branch, M-PVC 17.21.01
Ø = 4.5 mm/1000 mm P/N 155 206
Annular ringlight for
incident darkfield 17.05.01
flexible length
approx. 1000 mm P/N 157 405
4-point ringlight 17.06.01
flexible length approx. 1000 mm
Øi= 30 mm P/N 157 401
Øi= 66 mm P/N 157 402
Mini ringlight 17.04.01
flexible length approx. 1000 mm
M-PVC, with changeable adapter
for connecting on KL 200/KL 750
or KL 1500 LCD/KL 2500 LCD
Øi= 18.5 mm P/N 157 018
Øi= 22.0/25.0 mm P/N 157 025
Øi= 30.0 mm P/N 157 030
Øi= 40.0 mm P/N 157 040
Annular ringlight 17.01.01
flexible length approx. 1000 mm
Øi= 58 mm P/N 157 410
Øi= 66 mm P/N 157 420
Maxi ring light 17.03.01
Øi= 150 mm P/N 157 440
Lightline with adjustable front
lens,17.30.01
flexible length approx. 1000 mm,
M-PVC
Slit 50 x 1.2 mm P/N 160 100
Slit 100 x 0.6 mm P/N 160 110
Slit 200 x 0.3 mm P/N 160 120
Combi light guide „Flash“ 17.50.02
P/N 300 201
Flashport 17.50.02
P/N 300 100
Objective adapter for ringlights onto microscope
objectives of major microscope manufacturers
available.
For details refer to system diagrams of microscope
manufacturer or referenced SCHOTT datasheets.
All datasheets available on SCHOTT’s Standard
product catalog CD-ROM or on SCHOTT’s website
under www.us.schott.com/fiberoptics
