SCHUNK FTE-AXIA Training manual

Translation of original commissioning instructions
Commissioning instructions
FTE-AXIA
Force/torque sensor system

Imprint
2 04.00 | FTE-AXIA | Commissioning instructions | en | 1009369
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 1009369
Version: 04.00|30/05/2022|en
Dear Customer,
thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
Customer Management
Tel. [phone]
Fax [phone]
[email protected]
Please read the operating manual in full and keep it close to the product.

Table of Contents
Table of Contents
1 General.................................................................................................................... 5
1.1 About this manual ................................................................................................ 5
1.1.1 Presentation of Warning Labels ...............................................................5
1.1.2 Applicable documents ..............................................................................5
1.2 Warranty .............................................................................................................. 6
1.3 Scope of delivery .................................................................................................. 6
2 Basic safety notes ................................................................................................... 7
2.1 Intended use......................................................................................................... 7
2.2 Inappropriate use ................................................................................................. 7
2.3 Constructional changes ........................................................................................ 7
2.4 Spare parts ........................................................................................................... 7
2.5 Personnel qualification......................................................................................... 7
2.6 Disposal ................................................................................................................ 8
2.7 Notes on particular risks....................................................................................... 8
3 Technical data.......................................................................................................... 9
3.1 Ambient conditions and operating conditions .....................................................9
3.2 Force-torque sensor ............................................................................................. 9
4 Design and description............................................................................................10
4.1 Design ................................................................................................................. 10
4.2 Description ......................................................................................................... 10
4.3 Status LEDs ......................................................................................................... 11
5 Assembly and settings ............................................................................................13
5.1 Installing and connecting.................................................................................... 13
5.2 Electrical connection .......................................................................................... 14
5.2.1 Connecting the force/torque sensor ......................................................20
6 Start-up ..................................................................................................................21
6.1 Low-pass filter .................................................................................................... 21
6.2 EtherCAT bus interface....................................................................................... 24
6.2.1 PDO interface .........................................................................................24
6.2.2 EtherCAT Dictionary Objects (SDO data) ................................................24
6.3 Establishing communication with the sensor..................................................... 39
304.00 | FTE-AXIA | Commissioning instructions | en | 1009369

Table of Contents
7 Troubleshooting .....................................................................................................40
7.1 LED error............................................................................................................. 40
7.2 Signal noise......................................................................................................... 40
7.3 Measurement data deviation / drift................................................................... 40
7.4 Status code object 0x6010 ................................................................................. 41
7.5 Sensor and/or the EtherCAT program is not responding ................................... 41
7.6 Data output rate lower than expected............................................................... 42
7.7 Sensor does not transmit data ........................................................................... 42
7.8 Sensor does not report accurate force/torque data .......................................... 42
7.9 Fluctuating force/toque data ............................................................................. 43
7.10 Force/torque values are not equal to zero......................................................... 43
8 EU Declaration of Conformity .................................................................................44
9 Appendix to the declaration of conformity .............................................................45
4 04.00 | FTE-AXIA | Commissioning instructions | en | 1009369

General
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working is
the observance of all safety instructions in this manual.
Illustrations in this manual are provided for basic understanding
and may differ from the actual product design.
In addition to these instructions, the documents listed
under }1.1.2 [/5] are applicable.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
CAUTION
Material damage!
Information about avoiding material damage.
1.1.2 Applicable documents
• General terms of business *
• Catalog data sheet of the purchased product *
• Assembly and operating manual of the sensor*
The documents labeled with an asterisk (*) can be downloaded
from schunk.com.
504.00 | FTE-AXIA | Commissioning instructions | en | 1009369

General
6 04.00 | FTE-AXIA | Commissioning instructions | en | 1009369
1.2 Warranty
If the product is used as intended, the warranty is valid for 12
months from the ex-works delivery date under the following
conditions:
• Observe the ambient conditions and operating conditions
Parts touching the workpiece and wear parts are not included in
the warranty.
1.3 Scope of delivery
The scope of delivery includes
• FTE-AXIA force/torque sensor in the ordered variant
• Sensor cablein the version ordered
• Control line
• Commissioning instructions

Basic safety notes
2 Basic safety notes
2.1 Intended use
The product is used to record, convert and evaluate analog output
signals into electrical signals.
• Appropriate use of the product includes compliance with all
instructions in this manual.
2.2 Inappropriate use
The product is not a safety component in accordance with the EC
Machine Directive 2006/42/EC and must not be used in safety-
relevant parts of machine control units.
2.3 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of the
product or damage it.
• Structural changes should only be made with the written
approval of SCHUNK.
2.4 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
• Use only original spare parts or spares authorized by SCHUNK.
2.5 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
• All work may only be performed by qualified personnel.
• Before working with the product, the personnel must have read
and understood the complete assembly and operating manual.
• Observe the national safety regulations and rules and general
safety instructions.
704.00 | FTE-AXIA | Commissioning instructions | en | 1009369

Basic safety notes
8 04.00 | FTE-AXIA | Commissioning instructions | en | 1009369
2.6 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's safety
and cause serious injuries as well as considerable material and
environmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
2.7 Notes on particular risks
DANGER
Danger from electric voltage!
Touching live parts may result in death.
•Switch off the power supply before any assembly, adjustment
or maintenance work and secure against being switched on
again.
•Only qualified electricians may perform electrical installations.
•Check if de-energized, ground it and hot-wire.
•Cover live parts.
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
•Before starting any work on the product: Switch off the power
supply and secure against restarting.
•Make sure, that no residual energy remains in the system.
CAUTION
Risk of damage to the sensor!
If the single-axis overload values of the sensor are exceeded,
irreparable damage will occur.
•Do not overload the sensor.
CAUTION
Material damage due to incorrect grounding!
Damage to the sensor due to electrostatic discharge possible.
•Make sure that all components are properly grounded.

Technical data
3 Technical data
3.1 Ambient conditions and operating conditions
Ambient and operating conditions for sensor cable
Designation Sensor cable
during operation
min.
max.
-5
70
Protection class IP 64
The catalog data sheet contains more information.
3.2 Force-torque sensor
NOTE
All forces and torques acting on the sensor must be within the
specified range of measurement. Exceeding the range of
measurement will reduce the maximum number of load cycles
and may lead to damage of the sensor.
Information on the range of measurement of each individual
force-torque sensor is provided in the catalog data sheet. The
latest version is always applicable.
Dimensions and max. loads on the force-torque sensor
Detailed information on the mounting, installation and
maintenance of the sensor is provided in the Assembly and
Operating Manual for the sensor, }1.1.2 [/5].
904.00 | FTE-AXIA | Commissioning instructions | en | 1009369

Design and description
10 04.00 | FTE-AXIA | Commissioning instructions | en | 1009369
4 Design and description
4.1 Design
1 Sensor cable connection
2 Sensor cable Power and EtherCAT cable to the sensor
3 Power and EtherCAT cable to the
customer's control system
3.1 RJ45 connection for EtherCAT
3.2 Non-terminated end for voltage supply
4.2 Description
The force/torque sensor is connected to the system via EtherCAT.

Design and description
4.3 Status LEDs
LED self-test
sequence
The force/torque sensor has three LEDs: Link/Activity, Run, and
Sensor Status.
When the power supply is switched on, the sensor performs a self-
test, during which the LEDs switch on individually as part of the
firmware control.
Sequence
order
LED Status Duration
0 All When switching on, transient activity
may be observed for only a few
milliseconds.
1 All Off Approx. one second
for each LED.
2 Status Red
3 Error Red
4 EtherCAT
Link/Activity
Red
5 Status Green
6 Run Green
7 EtherCAT
Link/Activity
Green
8 All Off
9 All Normal operation
Sensor status LED An LED indicates the status of the sensor as follows:
LED color Status Description
Off No power supply The sensor is not supplied
with power.
Green Normal operation The electronics of the sensor
are working and can
communicate.
Yellow Detection range
exceeded
The forces and torques
applied to the sensor exceed
the permitted ranges.
Red
(flashing at
10 Hz)
Communication error The sensor is not able to
transmit data via the
communication protocol.
Red
(flashing at
1 Hz)
Calibration error The calibration was not
saved in the EEPROM.
Red Status code error Information on the error
record,}6.2.2.8 [/31].
1104.00 | FTE-AXIA | Commissioning instructions | en | 1009369

Design and description
12 04.00 | FTE-AXIA | Commissioning instructions | en | 1009369
Run (error) LED An LED indicates the connection/activity of the communication
port as follows:
LED color Status Description
Off No power supply The sensor is not supplied
with power.
Flashes
green
Before operation Defined in the
communication/protocol
standard record of the
EtherCAT® Technology
Group.
Flashes 1x
green
Safe operation
Green Ready for operation
Red Error Indicates an error reported
by the sensor. LED remains
red for five seconds after
each error.
EtherCAT L/A LED An LED indicates the communication status of the sensor interface
as follows:
LED color Status Description
Off No power or
connection activity
Either no connection activity
has occurred within 5
seconds or the sensor is not
supplied with power.
Green Link activity Remains green for five
seconds after the connection
activity.

Assembly and settings
5 Assembly and settings
5.1 Installing and connecting
DANGER
Danger from electric voltage!
Touching live parts may result in death.
•Switch off the power supply before any assembly, adjustment
or maintenance work and secure against being switched on
again.
•Only qualified electricians may perform electrical installations.
•Check if de-energized, ground it and hot-wire.
•Cover live parts.
CAUTION
Risk of damage to the electronics!
A faulty connection can cause damage to the internal electronics.
•Observe the PIN allocation of the connecting terminals.
•Make sure that all components are grounded correctly.
1. Connect components of the force-torque sensor system with
each other, }5.2 [/14].
2. Check for functionality.
3. Mount the force-torque sensor on the robot, see the
installation and operating instructions for the sensor.
1304.00 | FTE-AXIA | Commissioning instructions | en | 1009369

Assembly and settings
14 04.00 | FTE-AXIA | Commissioning instructions | en | 1009369
5.2 Electrical connection
Power supply
requirements
Designation Sensor
Supply voltage [VDC] 12-30
Max. Power consumption [W] 1.5
Designation Sensor cable
Nominal voltage [V] > 30
Nominal power current [A] > 0.25
Sensor connections
FT-AXIA 80
M8 sensor connector, 6-pin
Pin Signal
1 TX+
2 TX-
3 RX+
4 RX-
5 V+
6 V- / 0V / Ground
Housing Shielding
FT-AXIA 90
M8 sensor connector, 8-pin
Pin Signal
1 Reserved
2 V+
3 V- / ground
4 TX-
5 RX+
6 TX+
7 Reserved
8 RX-
Housing Shielding

Assembly and settings
FT-AXIA 130
M12 sensor connector, 8-pin
Pin Signal
1 Reserved
2 V+
3 V- / ground
4 TX-
5 RX+
6 X+
7 Reserved
8 RX-
Housing Shielding
1504.00 | FTE-AXIA | Commissioning instructions | en | 1009369

Assembly and settings
16 04.00 | FTE-AXIA | Commissioning instructions | en | 1009369
Sensor cable connections
FT-AXIA 80
M8 socket, 6-pin
Pin Signal
1 TX+
2 TX-
3 RX+
4 RX-
5 V+
6 V-
Housing Shielding
M12 connector, 8-pin
Pin Signal
1 Reserved
2 V+
3 V-
4 TX-
5 RX+
6 TX+
7 Reserved
8 RX-
Housing Shielding

Assembly and settings
FT-AXIA 80/90
M8 socket, 8-pin
Pin Signal
1 Reserved
2 V+
3 V-
4 TX-
5 RX+
6 TX+
7 Reserved
8 RX-
Housing Shielding
M12 connector, 8-pin
Pin Signal
1 Reserved
2 V+
3 V-
4 TX-
5 RX+
6 TX+
7 Reserved
8 RX-
Housing Shielding
1704.00 | FTE-AXIA | Commissioning instructions | en | 1009369

Assembly and settings
18 04.00 | FTE-AXIA | Commissioning instructions | en | 1009369
FT-AXIA 130
M12 socket, 8-pin
Pin Signal
1 Reserved
2 V+
3 V-
4 TX-
5 RX+
6 TX+
7 Reserved
8 RX-
Housing Shielding
M12 connector, 8-pin
Pin Signal
1 Reserved
2 V+
3 V-
4 TX-
5 RX+
6 TX+
7 Reserved
8 RX-
Housing Shielding

Assembly and settings
EtherCAT cable
Non-terminated end Wire sheath color Signal
Braided metal shielding Shielding (connect to ground)
Brown V+
Brown/White V-
Blue/White (TP1+) Reserved
Blue (TP1-) Reserved
EtherCAT connector, RJ45, 8-pin, socket
Pin Color Signal
1 White/Orange TX+
2 Orange TX-
3 White/Green RX+
4 - -
5 -
6 Green RX-
7 - -
8 -
1904.00 | FTE-AXIA | Commissioning instructions | en | 1009369

Assembly and settings
20 04.00 | FTE-AXIA | Commissioning instructions | en | 1009369
5.2.1 Connecting the force/torque sensor
Connecting the force/torque sensor (shown on FT-AXIA130 as an example)
1. Connect the supplied sensor cable(2) to the force/torque
sensor(1).
2. Connect the supplied control line (3) to the sensor cable (2).
3. Connect the control line (3) to the customer's control system.
