Adapter Plate
Optional component used to adapt the
OPR Body or Stem to the user’s robot
or tooling.
Body
Cylindrical aluminum housing and air
pressure chamber. An adap-ter plate to
the user’s robot is usually attached
here.
Cam
A hardened steel ring mounted inside
the cover on which the hardened steel
ball segments mounted to the stem are
nested.
Collision
The accidental impact between a tool
and some obstruction in its path.
Collision Sensing Switch
A switch that changes state to an
circuit when a crash is detected. It is
mounted in a threaded hole in the side
of the body under the connector block.
The steel target moves out of range in
the event of a crash.
Cover Plate
Disk-shaped aluminum cover for OPR
Body.
M8, 3-Pin Male Threaded Connector
8mm electrical connector mounted in a
block attached to the side of the Body.
Piston
The component which, together with
the Body, creates a pressure chamber.
Varying the pressure in this chamber
varies the load required to move the
piston.
Stem
Round, conical steel element with
threaded holes and dowel pin holes. An
adapter plate to the user’s tooling is
usually attached here.
503.00 | OPR 048 | Assembly and operating manual | en | 389630

About this manual
6 03.00 | OPR 048 | Assembly and operating manual | en | 389630
1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working is
the observance of all safety instructions in this manual.
In addition to these instructions, the documents listed
under }1.2 [/7] are applicable.
NOTE: The illustrations in this manual are intended to provide a
basic understanding and may deviate from the actual version.
1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
NOTICE
Material damage!
Information about avoiding material damage.

About this manual
1.2 Applicable documents
• General terms of business *
• Catalog data sheet of the purchased product *
The documents labeled with an asterisk (*) can be downloaded
from schunk.com.
1.3 Scope of delivery
The scope of delivery includes:
• Collision and overload sensor OPR in the ordered variant
• Connection cable (5 m, straight connector, open wire strands)
703.00 | OPR 048 | Assembly and operating manual | en | 389630
