1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working is
the observance of all safety instructions in this manual.
Illustrations in this manual are provided for basic understanding
and may differ from the actual product design.
In addition to these instructions, the documents listed under
Applicable documents [}5] are applicable.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
CAUTION
Material damage!
Information about avoiding material damage.
1.1.2 Applicable documents
• General terms of business*
• Catalog data sheet of the purchased product *
The documents marked with an asterisk (*) can be downloaded on
our homepage schunk.com

General
6
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
1.2 Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
• Observe the applicable documents, Applicable documents [}5]
• Observe the ambient conditions and operating conditions,
Environmental and operating conditions [}7]
Parts touching the workpiece and wear parts are not included in
the warranty.
The warranty of the battery is valid for 36 months from the
delivery date to the production facility if used appropriately.
1.3 Scope of delivery
The scope of delivery includes
• Transmitter RSS-T2
• Receiver RSS-R1
1.4 Accessories
The following accessories, which must be ordered separately, are
required for the product:
For Transmitter RSS-T2
• Sensors (max. 2 pieces per RSS-T2)
– either RMS 80, plus specific adapter kit of gripper
– or RMS 22
– or other sensors for normally open contact, without own
power consumption
For Receiver RSS-R1
• one antenna RSS-R-A
The complete system consists of:
• Transmitter RSS-T2 with two sensors
• Receiver RSS-R1 with antenna RSS-R-A
For information regarding which accessory articles can be used
with the corresponding product variants, see catalog data sheet.

Basic safety notes
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
7
2 Basic safety notes
2.1 Intended use
The RSS radio system serves to transmit the sensor states via a
radio link from the transmitter unit to the receiver.
NOTE
The RSS radio system does not have FCC/IC certification and must
therefore not be operated in the USA or Canada.
For operation in the USA and Canada, transmitter RSS-T2-US/CA
(ID-No. 377717) must be used.
• The product may only be used within the scope of its technical
data, Technical data [}12].
• The product is intended for industrial and industry-oriented use.
• The product is intended for installation in a machine/system.
The applicable guidelines must be observed and complied with.
• When implementing and operating components in safety-
related parts of the control systems, the basic safety principles
in accordance with DIN EN ISO 13849-2 apply. The proven safety
principles in accordance with DIN EN ISO 13849-2 also apply to
categories 1, 2, 3 and 4.
• Appropriate use of the product includes compliance with all
instructions in this manual.
2.2 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of the
product or damage it.
• Structural changes should only be made with the written
approval of SCHUNK.
2.3 Environmental and operating conditions
• Make sure that the product is a sufficient size for the application.
• Ensure that the area surrounding the receiver is free of sprayed
water and vapors, as well as free of dust from abrasion or
processing.
• The transmission path established by the system can be
disrupted by exterior influences temporarily or permanently.
This means that the conditions of the sensors at the receiver are
not updated for the duration of the interference. The
interference is only reported by the receiver once the watchdog
time has elapsed. It must be ensured that such interference
cannot cause damage. The watchdog time must be set for a
period of time suitable for the process.

Basic safety notes
8
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
• Within the range of 868.3 MHz, the system does not correspond
to the EMC regulation for radio wave penetration immunity. A
loss of wireless telegrams may occur in this range. If the
antenna is at a distance of over 25 cm from the receiver, the
probability of interference increases. The application must
therefore be tested before it is integrated into a machine.
• Wireless switching receivers may not be used in conjunction
with devices that directly or indirectly serve human, health or
life saving purposes or that may endanger people, animals or
property when operated! This is the result of the classification
of the radio switching receiver in "Class 2 Equipment" according
to ETSI EN 301 489-3 V1.4.1 (2202-08) "Specific conditions for
short-range devices (SRD)".
• The time lag between measurable telegrams must be at least 50
ms.
2.4 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
• All work may only be performed by qualified personnel.
• Before working with the product, the personnel must have read
and understood the complete assembly and operating manual.
• Observe the national safety regulations and rules and general
safety instructions.

Basic safety notes
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
9
The following personal qualifications are necessary for the various
activities related to the product:
Trained electrician Due to their technical training, knowledge and experience, trained
electricians are able to work on electrical systems, recognize and
avoid possible dangers and know the relevant standards and
regulations.
Qualified personnel Due to its technical training, knowledge and experience, qualified
personnel is able to perform the delegated tasks, recognize and
avoid possible dangers and knows the relevant standards and
regulations.
Instructed person Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.
Service personnel of
the manufacturer
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.
2.5 Notes on safe operation
Incorrect handling of the personnel
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Avoid any manner of working that may interfere with the
function and operational safety of the product.
• Use the product as intended.
• Observe the safety notes and assembly instructions.
• Do not expose the product to any corrosive media. This does
not apply to products that are designed for special
environments.
• Eliminate any malfunction immediately.
• Observe the care and maintenance instructions.
• Observe the current safety, accident prevention and
environmental protection regulations regarding the product's
application field.
2.6 Malfunctions
Behavior in case of malfunctions
• Immediately remove the product from operation and report the
malfunction to the responsible departments/persons.
• Order appropriately trained personnel to rectify the
malfunction.
• Do not recommission the product until the malfunction has
been rectified.
• Test the product after a malfunction to establish whether it still
functions properly and no increased risks have arisen.

Basic safety notes
10
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
2.7 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's safety
and cause serious injuries as well as considerable material and
environmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
2.8 Fundamental dangers
General
• Observe safety distances.
• Never deactivate safety devices.
• Before commissioning the product, take appropriate protective
measures to secure the danger zone.
• Disconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
• If the energy supply is connected, do not move any parts by
hand.
• Do not reach into the open mechanism or movement area of
the product during operation.
2.8.1 Protection against electric shock
Work on electrical equipment
Touching live parts may result in death.
• Work on the electrical equipment may only be carried out by
qualified electricians in accordance with the electrical
engineering regulations.
• Lay electrical cables properly, e. g. in a cable duct or a cable
bridge. Observe standards.
• Before connecting or disconnecting electrical cables, switch off
the power supply and check that the cables are free of voltage.
Secure the power supply against being switched on again.
• Before switching on the product, check that the protective
earth conductor is correctly attached to all electrical
components according to the wiring diagram.
• Check whether covers and protective devices are fitted to
prevent contact with live components.
• Do not touch the product's terminals when the power supply is
switched on.
Possible electrostatic energy
Components or assembly groups may become electrostatically
charged. When the electrostatic charge is touched, the discharge
may trigger a shock reaction leading to injuries.

Basic safety notes
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
11
• The operator must ensure that all components and assembly
groups are included in the local potential equalisation in
accordance with the applicable regulations.
• While paying attention to the actual conditions of the working
environment, the potential equalisation must be implemented
by a specialist electrician according to the applicable
regulations.
• The effectiveness of the potential equalisation must be verified
by executing regular safety measurements.

Technical data
12
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
3 Technical data
More technical data is included in the catalog data sheet.
Whichever is the latest version.
3.1 Technical Data RSS-R1
Receiver
ID number 0377700
Receiving frequency [MHz] 868.3
Nominal voltage [VDC] 24
Min. voltage [V] 10
Max. voltage [V] 30
Max. switching current per channel [mA] 500
Protocol Enocean Standard
Short-circuit-proof yes
IP rating 20
Installation type Snapping on to DIN track (EN50022)
Dimensions Assembly drawing
Connection method CAGE CLAMP® connection 0.08...2.5 mm²
WAGO multi-plug system series 722
Housing material Polycarbonate
Ambient temperature [°C]
Min.
Max.
0
55
Storage temperature
Min.
Max.
-25
+75
Electromagnetic radiation EN 61000-6-4
Electromagnetic interference EN 61000-6-2
Further normalise ETSI EN 301 489-1 (09/01), ETSI EN 301 489-3
(11/01), ETSI EN 300 220-1 (09/00)
Radio permit EnOcean
Receiver RCM 100
CETECOM Test report 2_3041-01-02/02
DAR Test report P0ZNNP1P
Antenna
ID number 0377730
Assembly Magnetic base
Cable length [m] 2
Connection at the cable tail SMA Mini
Use Connection on receiver RSS-R1

Technical data
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
13
3.2 Technical data - RSS-T2
ID number 0377715
Transmission frequency [MHz] 868.3
Sensor connection 2x M8
Integrated voltage supply Lithium batterie
Housing material PUR
Protocol Enocean Standard
IP rating 67
Ambient temperature [°C]
Min.
Max.
0
50
Weight [kg] 0,16

Technical data
14
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
3.3 Information on radio link and range
The transmitter sends telegrams with 868 MHz to the receiver. The
receiver checks the incoming telegrams and uses them to control
its outputs.
This radio link is principally prone to interferences by other radio
systems or systems emitting radio signals. For reasons of availability,
the presence of systems emitting radio waves – such as wireless or
mobile phones or PCs – in the immediate proximity of the transmitter
is to be avoided. We recommend observing a minimum air distance
of at least one meter between receiver and interference source or
between transmitter and interference source.
Since the radio signals represent electromagnetic waves, the signal is
damped on its route to the receiver. This means, the signal strength
decreases with increasing distance between transmitter and receiver.
Thus, the radio range is limited. In particular, the range will also be
significantly limited in case of irradiation above 400 MHz.
It must also be noted that the radio range is reduced by materials
between transmitter and receiver. For the practical application,
this means that the construction materials used in buildings and
facilities (machines) play an important role for the evaluation of
the radio range. Some reference values that can be used to
estimate the range are:
• Line of sight
– Typically 30 m range
• Concrete or brick walls
– Typically 20 m range
• Steel-reinforced concrete walls
– Typically 10 m range
• Fire protection walls, elevator shafts ..
– Can be considered blockages.
• Turning centres
– The radio waves penetrate to the outside through various
slots and especially through the viewing glasses. It is difficult
here to make an exact statement on the range. Based on our
experience, a range of at least 3 m must be expected.
• Cordless telephone at a distance of less than 1m
– Range approx. 25 cm
The distance from the receiver to other transmitting devices also
radiating high-frequency signals (computers, video systems, etc.)
should be at least 0.5 m.
Using the receiving strength LED (SI) to our receiver it is easy to
decide whether the system provides secure transmission for the
intended location or if strong interferences are present.

Assembly
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
15
4 Assembly
4.1 Assembly of the transmitter RSS T2
ØInstall the housing in a suitable position next to the sensor
fastening using two screws M4.
Ø- Install the sensor (closer) at the gripper.
ØFasten the M8 sensor plugs with screws to the transmitter.
ØFor adjustment of the sensors the magnetic brackets of the
transmitter can be plugged into ‘test mode‘ position. Now you
can see the individual sensors’ status on the LEDs. Position the
sensors at a suitable position and finally screw the magnetic
switch onto the ‚normal mode‘ position.
ØNever leave the magnetic bracket in ‘test mode‘ position,
otherwise the battery of the transmitter will be discharged
within a few days!
NOTE
Always use closers. Otherwise the system cannot recognize a
changing status of the sensors, i.e. if a sensor is open while the
signal of another sensor changes.

Assembly
16
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
4.2 Assembly and electrical connection of the RSS R1 receiver
ØMount the receiver in a switching cabinet located less then 10
m from the transmitter by snapping it onto a DIN track
(EN50022).
ØConnect the receiver:
Antenna socket X1:
- SMA socket for external antenna (we recommend our RSS-R-A
antenna, ID No. 0377730)
Connector X2:
- X2.1 FE Function ground
- X2.2 + Supply DC 24DCV+external
- X2.3 - Supply DC 24V-external
Connector X3:
- X3.1 WD Output watchdog, high signal, if radio IO
- X3.2 LC Output limit value, high signal, if battery IO, i.e. has
still more than 1 week capacity remaining.
- X3.3 DO1 Output 1, sensor signal 1, Low, if sensor actuated.
- X3.4 DO2 Output 2, sensor signal 2, Low, if sensor actuated.
- X3.5 GND Reference ground for the outputs
ØMount the antenna on the top of the switching cabinet using
the magnetic base.

Start-up
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
17
5 Start-up
5.1 General information on commissioning
Check for any damage caused during transport before
commissioning the product. In the case of mechanical damage, the
product may not be put into operation. Read the Assembly and
Operating Manual carefully, observe the technical information and
the applicable national legal requirements.
NOTE
The components are loaded with electronic components which
may be destroyed by electrostatic discharge. When dealing with
the components, a good earthing of the surroundings (people,
workstation, packaging) must be ensured. Do not touch electrical
components.
Installation notes
When installing the assembly group, antenna and antenna cable, it
is imperative to avoid proximity to sources with transient
interference, e.g., fluorescent tubes with a defective starter,
frequency converters and power cables. These may lead to
communication interference and in turn erroneous default
statuses.
Information on the antenna connection
Only use suitable antennas (e.g. WAGO 758-910 incl. 2.5 m RG174
connection cable and SMA connector; see accessories). The
antenna must be mounted on a metal sheet with minimum
dimensions of 25 x 25 cm. The antenna and antenna cable must be
at least 30 cm away from sources of interference and have at least
35 cm clearance between the side and the next wall. Under no
circumstances may sharp kinks be allowed to form in the antenna
cable, as this would cause irreversible damage to the antenna
cable (RG174 bending radius > 15 mm).
Prerequisites for commissioning
The voltage supply and the external antenna are connected.

Start-up
18
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
5.2 Programming the transmitter to the receiver
NOTE
Programming may fail in the event of an unfavorable combination
of transmitter and receiver or due to external interference. The
programming may therefore need to be repeated multiple times.
ØUnscrew the antenna of the RSS-R1 (receiver).
ØFor the best possible programming, deactivate all other RSS-T2
(transmitters) within 15meters.
ØPlace the RSS-T2 (transmitter) 0.5meters away from the RSS-R1
(receiver).
ØPut the RSS-T2 (transmitter) into test mode (recommended by
SCHUNK) or normal mode.
ØChange DIP switch 1 on the RSS-R1 (receiver) to "ON" and then
immediately back to "OFF".
✓The receiver is now in Teach mode.
ØToggle the input D01 on the RSS-T2 (transmitter) to establish a
connection between transmitter and receiver (e.g. by moving
the product to be received multiple times).
Register in the RSS-R1 (receiver)
The RSS-R1 (receiver) has an integrated register. It is used to save
learned transmission units. This can be deleted upon a battery
change, or as required. To do this, disconnect the voltage supply of
the receiver for at least one minute.
5.3 Testing the antenna position
ØObserve the LED ‘SI’. This LED signals the current quality of the
radio link. This LED should preferably light up or blink green.
ØIf necessary, move the antenna closer to the transmitter or
reposition the antenna to avoid any solid obstacles between
antenna and transmitter.
5.4 Adjusting the watchdog time at the receiver
ØAdjust watchdog time to best suit your process. The transmitter
transmits a presence signal every second to monitor the
transmission path. If no signal is received for longer than the set
watchdog time, the 'WD' LED lights up until the next signal is
received. The 'WD' output then signals through 0 VDC the
down-time of the transmission path.
ØSwitch Dip 4 to on.
ØTurn the potentiometer clockwise to extend the time. The set
time can be determined from the flash rate of the WD LED.
With DIP 8 switched off, the time can be varied between 0 and
one second. SCHUNK recommends setting the time to 15
seconds with DIP 8 switched on.
ØSwitch DIP 4 to 'off' (leave DIP 8 in the selected position!).

Functional description
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
19
6 Functional description
6.1 RSS-R1
6.1.1 General discription
Block diagram of the receiver
A power supply of 12 to 24 V DC is required to operate the
wireless receiver. It is connected using plug connectors with Cage
Clamp® connections. An external magnetic antenna is required to
receive wireless telegrams for the frequency range of 868 MHz.
The wireless receiver is based on the EnOcean STM 300 wireless
receiver, whose received data are processed with a downstream
micro-controller.
The program in the micro-controller can be divided into the teach-
in and operating modes.

Functional description
20
03.00 | Radio sensor system RSS | Assembly and Operating Manual | en | 0389609
Teach-in mode
In teach-in mode (activated by DIP 1 ON/OFF), the ID of a detected
EnOcean telegram is stored in the receiver and the teach-in mode
is automatically ended. If no valid telegram from a transmitter is
received in the teach-in mode after 15 s have elapsed, this is
signaled as a faulty status. Alternatively, the transmitter ID can be
taught manually in the INACTIVE status by actuating the DIP switch
3 & 4 (simultaneously!).
The monitoring time and limit value can either be set by specifying
the default values or by means of a potentiometer using a
diagram. The diagrams and DIP switches are described in the
subsequent chapters.
Operating mode
In operating mode, the receiver monitors the incoming signals of
the transmitter using the watchdog function. The watchdog LED
(WD) displays each incoming telegram of the taught-in transmitter
with a short flicker. If the watchdog time is exceeded, the WS LED
signals a fault with a continuous light; the WD output goes to LOW
status.
The DO1 and DO2 LEDs and outputs directly display the condition
of the two-channel sensor. For each telegram, the current battery
level is monitored using the level control to an adjustable limit
value. If the minimum limit value is not reached, the output goes
into the LOW status and the LED is OFF.
The signal strength of incoming telegrams is displayed by flashing
codes using SI LED, which can be used to establish an optimal radio
connection during commissioning.
