Screen Int LEONARDO User manual

RELEASE ER2019_05_22
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
INSTALLATION MANUAL
FRAME SCREEN
LEONARDO
ORIGINAL INSTRUCTIONS IN ITALIAN LANGUAGE
Translation into English language

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
1.0 GENERAL INFORMATION
1.1 Frame screen description
1.2 Manufacturer’s rights
1.3 Contents and map of this manual
1.4 Warnings
1.5 Warranty - General information
1.6 Screen labels
2.0 FRAME SCREEN DESCRIPTION
2.1 General description
3.0 ASSEMBLY
3.1a Leonardo with Oyster surfaces packaging content
3.1b Leonardo with Pvc surfaces packaging content
3.2 Structural frame assembly
3.3 Projection cloth mounting
3.3a Oyster surface mounting
3.3b Pvc surfaces mounting
3.4 Thin bezel assembly
4.0 INSTALLATION
4.1 Wall mounting
INDEX
In order to guarantee the best performances of your screen, please
READ CAREFULLY this installation manual.

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
1.1 FRAME SCREEN DESCRIPTION
1.0 GENERAL INFORMATION
This installation manual contains the description of “frame screen” as it is produced
by the manufacturer. This manual contains information about installation, use
and maintenance of the screen.
It also contains the information about the technical features and safe use of the
product.
The installation manual is composed from:
1.0 General information
2.0 Frame screen description
3.0 Assembly
4.0 Installation
1.2 MANUFACTURER’S RIGHTS
Copyrights of this installation manual are exclusively of:
EUROSCREEN SRL
Via Stiria 45/16
33100 Udine - Italy
Tel. [phone]
Fax [phone]
[email protected]
www.screenint.com
1.3 CONTENTS AND MAP OF THIS MANUAL
The frame screen LEONARDO is entirely manufactured in Italy, with high quality
materials and projection cloths that guarantee to your system excellent quality
performances in compliance with CE legislation.
The screen is designed specifically for home cinema or professional projections.
The LEONARDO screen is available in different formats and with different
projection surfaces.

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
Before assembling and installing the frame screen read carefully the installation
manual. Please, store this installation manual so that you can consult it whenever
necessary.
When opening the screen packaging, USE VERY CAREFULLY EVENTUAL
CUTTERS OR SHARP TOOLS that can damage its content. It is recommended
to wear working gloves during the opening of the packaging and the installation
of the product.
According to the weight of the product it has to be handled by two or three or more
people, based on the relation KG/PERSON: MALE 25 kg. - FEMALE 15 kg.
Install the screen in a location with a temperature between 20°C and 24°C.
The manufacturer does not take responsibility for any damage to property or
personal injury if the screen is used outside of recommended specifications or in
case of incorrect/poor quality installation.
This projection screen is guaranteed 2 years from the purchase date for
manufacturing defects.
Responsibility is limited to repairing or substitution of the defected components
and without any other charge at our expense.
Components that show obvious signs of normal wear and tear caused by particular
environmental and installation situations are excluded from warranty.
Warranty is officially voided if:
1) the screen has been dismantled or it is returned with collision damage or
defective due to incorrect installation;
2) the screen results damaged due to repairing or modifications made by non
authorized people;
3) the sticker regarding the serial number of the product has been altered, deleted,
removed or is illegible.
DO NOT install this screen nearby or over heating or air conditioning systems.
DO NOT install this screen either facing direct sun light or blocking a window.
We advise you to wait 2 hours for the screen to acclimatize before using the screen
after delivery, especially if screen is brought into a warm environment from cold.
DO NOT WASH the projection surface with alcohol or solvent nor with commercial
cleaners. Every now and then, dust the surface with a dry and clean duster. Please,
be very careful because any kind of stain on the cloth is inerasable.
DO NOT HANG TO THE SCREEN and DO NOT HANG ANY OBJECT to it. Please
take care that children DO NOT PLAY with the screen as they can get severely
injured.
The manufacturer will not accept returns of screens for repair without manufacturer’s
authorization (RMA number) and without a suitable packaging.
1.4 WARNINGS
1.5 WARRANTY - GENERAL INFORMATION

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
This screen is equipped with product identification labels that indicate its essential
technical specifications.
1.6 SCREEN LABELS
1.6.1 Label n. 01
This label reports the following
information:
A) Serial number
SERIAL N. ( A )
MANUFACTURED BY
EUROSCREEN SRL-ITALY
MADE IN ITALY
1.6.2 Label position
Looking at the screen from the
front it. The label is sticked on
the rear side of the frame, on the
bottom right hand side.

RELEASE ER2019_05_22
Mod. LEONARDO
14 14
14 14
106 106
106 106
H
Installation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
2.0 FRAME SCREEN DESCRIPTION
The figures below describe the main elements of the product.
Front view
Rear view
2.1 GENERAL DESCRIPTION
Structural
frame
Mounting brackets
Bezel
Velvet covered
bezel
Projection
surface
W

RELEASE ER2019_05_22
Mod. LEONARDO
54
106
28
14
Installation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
Profiles combination
Bezel covered with velvet
Bezel aluminium
profile
Structural frame
aluminium profile
Projection
cloth Mounting bracket

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
Structural frame segments (A)
Metal corners (C) Projection surface (D)
Rubber bands (E)
Bezel segments (B)
Projection cloth
Screws + wall plugs (G)
Pcs. 04
Pcs. 16
Pcs. 2
Pcs. 01
Pcs. 01
Pcs. 04
3.0 ASSEMBLY
3.1a LEONARDO WITH OYSTER SURFACE
PACKAGING CONTENT:

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
Structural frame segments (A)
Metal corners (C) Projection surface (D)
Rubber bands (E)
Projection cloth
Galvanized rods (E)
Bezel segments (B)
Screws + wall plugs (G)
Pcs. 04
Pcs. 16
Pcs.04
Pcs. 01
Pcs. 02Pcs. 01
Pcs. 04
3.1b LEONARDO WITH PVC SURFACES
PACKAGING CONTENT:
Pvc surfaces: White, HD Performer, Microperforated,
Lumi Grey Microperforated, Lumi Grey

RELEASE ER2019_05_22
Mod. LEONARDO
X
1
2
3
Installation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
The first step of Leonardo screen installation consists in assembling the structural
frame.
The slots to be used to insert the metal corners (C) are n.
1 and n. 3 as shown in the drawing on the right. Do not use
slot n. 2 because this is for the cursors only.
Step 1a
Step 1b
Place the metal corners (C) near the slots n. 1 e n. 3
of one long structural frame segment (A).
Insert the metal corners (C).
3.2 STRUCTURAL FRAME ASSEMBLY

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
Put the short structural frame segments (A) close to the metal corners (C).
Insert the short structural frame segments (A).
Step 2a
Step 2b

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
Step 3b
Step 3a
Insert the metal corners (C) to this frame segment.
Place the remaining metal corners (C) close to the remaining long structural frame seg-
ment.

RELEASE ER2019_05_22
Mod. LEONARDO
L1
L2
L1 = L2
Installation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
Before tightening all the dowels, in order to perfectly close the metal corners to the
structural frame segments, check that the measurements L1 and L2 are the same. The
maximum tolerance is 2 mm.
Step 4b
Step 4a
Insert the long structural frame segment, in order to complete mounting of the frame.

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
Check carefully as above and proceed with tightening the dowels on each corner.
For a perfect assembly, it is necessary to check carefully the fixing of the metal corners
(C), because, as shown in the figures below, mistakes will compromise the whole
installation, causing permanent damages to the cloth.
Mistake B
Outside the
structural frame
Mistake A
Inside the
structural frame
Mistake A
Internal corner
OPEN
Mistake B
External corner
OPEN

RELEASE ER2019_05_22
Mod. LEONARDO
1MT 1MT
1MT 1MT
Installation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
3.3 PROJECTION SURFACE MOUNTING
Before xing the cloth, make sure to have enough moving space for all the operations,
as indicated by the gure below. Before laying the projection cloth down, make sure that
the floor where you will lay is perfectly clean and smooth. It is mandatory to lay a
protective equipment cloth over the oor, before laying on it the projection cloth.
3.3a OYSTER SURFACE MOUNTING
Handling of the projection cloth has to be carried out by at least two people. The cloth
has to be layed down with the projection side facing downward.
Do not move the projection cloth once it is layed down.
Check the area where you
are laying the projection
cloth.
Projection cloth
Protective cloth
Projection cloth
FRONT
Check the surface on which
the projection cloth is lying.
Moving
limit
Protective cloth
dimensions limit
Protective
cloth

RELEASE ER2019_05_22
Mod. LEONARDO
X
Installation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
After laying the protective cloth, make sure that the projection cloth is not damaged.
Moreover, it is advised to leave the cloth layed down for at least 10 minutes, before
proceeding with fixing it to the pre-assembled structural frame, as per chapter 3.2.
Now, lay the pre-assembled structural frame on the projection cloth, making sure that the
rear side of the frame is facing upwards.
Check that every green centre indicator on each frame corresponds to the central ring on
the projection surface.
Correct position
cursors facing upwards Wrong position cursors facing downwards
Check the cloth
Green
indicator
Green
indicator
Green
indicator
Green
indicator

RELEASE ER2019_05_22
Mod. LEONARDO
L1
L4
L2
L3
L1=L2=L3=L4
Installation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
For an easy installation of the projection cloth to the structural frame, this frame has to be
centered in the most precise way, pairing the green centre indicators applied
on the cloth and the fixed centre indicator.
Now we are ready to fix the first 4 rubber bands. In order to soften them, it is necessary to
stretch them as shown on the figures below.
Moreover, before proceeding with fixing the cloth, it is
necessary to place the structural frame so that the
distances L1, L2, L3 e L4 are the same. This guarantees
that the frame is centered compared to the cloth.
At the end of this procedure, you will notice that the rubber band is softer and its length is
increased of about 5 mm.
This procedure has the aim to make the screen fixing and eventual regulations easier.
Press strongly the rubber
bands extremities Stretch the rubber band moving it from the centre
to the extremities
Fixed centre indicator

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
Proceed now with xing the screen to the structural frame.
The drawings below describe how to x the rubber bands.
This operation has to be carried out by at least two professional people, taking care
that the Oyster surface is very delicate and any damage on it will be permanent.
Step 1 Step 2
Step 3 Step 4

RELEASE ER2019_05_22
Mod. LEONARDO
2 2
55
6 6
1
4
3
1
34
Installation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
IMPORTANT:
The sequence for fixing the rubber bands is shown below.
The first rubber bands that have to be fixed are those necessary for centring the cloth.
It is important that fixing is carried simultaneously starting from the opposite sides because
this defines the exact central position of the cloth.
After having checked the exact centre, proceed with fixing all the rubber bands, following
the sequence indicated below: from the centre outwards and the rubber bands on the
corner have to be fixed as last ones.

RELEASE ER2019_05_22
Mod. LEONARDOInstallation manual
This document is property of Euroscreen Srl.
Any reproduction without authorization is prohibited
After having fixed the cloth to the structural frame, lift the screen in vertical position, as
shown by the figure below and check that there are not waves or folds on the projection
cloth.
If there are waves it is enough to detach and fix again the rubber bands.
Waves can appear because of different factors, among the others the wrong centring and
the wrong sequence of the rubber bands fixing.
For example: waves can appear, if the sequence of rubber bands fixing is carried out from
the sides towards the centre.
Check for
possible waves
Before proceeding with the bezel assembly, it is mandatory to wait for about 10 minutes.
During this time, both the screen and the bands have time to settle.
This time is necessary because, after the bezel is mounted on the structural frame, it is not
possible to make adjustments on the rubber bands any more.
