INSTRUCTIONS FOR
BLUETOOTH ® BATTERY TESTER
MODEL NO: BT3000
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used
according to these instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL
REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE
PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL
INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instructions
Electrical
shock
hazard
Wear eye
protection
Wear protective
gloves
Warning:
corrosive
substance
Warning:
explosive
material
Keep away
from sources of
ignition
Use in well
ventilated areas
Keep in dry area
protect from rain
BT3000 | Issue 1 12/04/17
Original Language Version
© Jack Sealey Limited
1. SAFETY
9Read the entire manual before using this product. Failure to do so could result in serious injury or death.
9The tester is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning the use of the tester by a person responsible for their safety.
8DO NOT operate the tester if it has received a sharp blow, been dropped or otherwise damaged in any way.
8DO NOT not disassemble the tester.
9Batteries generate explosive gases during normal battery operation. To reduce the risk of a battery explosion,
follow these instructions and those published by the battery manufacturer or any equipment you intend to use
in the vicinity of the battery. Review the cautionary markings on these products and on the engine.
8DO NOT smoke or allow a spark or ame in the vicinity of a battery or engine.
9Remove personal metal items such as rings, bracelets, necklaces and watches when working with a lead-acid
battery. A lead-acid battery can produce a short-circuit current high enough to weld a ring or the like, to metal,
causing a severe burn.

9Reduce the risk of dropping a metal tool onto the battery. It might spark or short-circuit the battery or other
electrical part that may cause an explosion.
9Have someone nearby to come to your aid when you work near a lead-acid battery.
9Have plenty of fresh water and soap nearby in case battery acid contacts your skin, clothing or eyes.
9If battery acid contacts your skin or clothing, immediately wash the area with soap and water. If acid enters
your eye, immediately ood the eye with cold water and obtain medical attention immediately.
9If battery acid is accidentally swallowed, drink milk or water. DO NOT induce vomiting. Seek medical attention.
2. INTRODUCTION
Perform battery and charging system tests from your smartphone or tablet. Fast and accurate diagnosis with facility
to forward results via email or text to workshop reception or customer. Waterproof (IP65) rating and 50cm cable.
Rechargeable internal Li-ion battery, allowing testing of batteries with as little as 1.5V of residual charge. Fast
Bluetooth® pairing, can store up to 2,000 detailed test reports. Suitable for automotive (including start/stop), motorcycle,
marine and leisure batteries.
3. SPECIFICATION
Model No: .................................................................................................. BT3000
Internal Battery: ........................................................... Lithium ion 3.7V, 1150mAh
Rated Battery Voltage:.................................................................................. 6/12V
Charging System Capability: ...................................................................... 12/24V
Rating System: .........................................................DIN, EN, IEC, SEA, CA/MCA
Test Range: ............................................................................ 25-1300 CCA* DIN
..................................................................................................40-2100 CCA* EN
.................................................................................................30-1500 CCA* IEC
................................................................................................40-2000 CCA* SEA
...................................................................................................50-2400 CA/MCA
Voltage Range:..........................................................................................1.5-32V
Wireless Connection Range: ........................................................................ 10mtr
Operating System:.................(Apple) iOS 8.0 and later, Android OS 4.3 and later.
Note:................................... Free App download required from relevant App store.
BT3000 | Issue 1 12/04/17
Original Language Version
© Jack Sealey Limited

4. PREPARING THE BATTERY
4.1. Be sure the area around the battery is well ventilated while the battery is being tested.
4.2. Clean the battery terminals. Be careful to keep corrosion from coming in contact with your eyes, nose and mouth.
4.3. Inspect the battery for a cracked or broken case or cover. If the battery is damaged, do not use the tester.
4.4. If the battery is not a sealed maintenance-free battery, check the level of each cell and if necessary, add distilled
water until the battery acid reaches the level specied by the manufacturer. This helps purge excessive gas from
the cells. DO NOT overll.
4.5. If necessary to remove the battery from vehicle to test it, always remove the ground terminal from the battery rst.
Make sure all accessories in the vehicle are off to ensure you DO NOT cause any arcing.
4.6. Modern vehicles contain extensive electronic systems. You are required to check with the vehicle Manufacturer, for
any specic instructions regarding the use of this type of equipment on each vehicle. No liability will be accepted for
damage / injury, where this product is not used in accordance with all instructions.
4.7. Note: The internal battery is charged during the connection to the battery being tested.
1. Battery Clamps (not shown)
2. Bluetooth Status (blue) LED
3. Battery Status (green) LED
4. Check (red) LED.
5. Reset power button.
5. INSTALLING THE APP
5.1. Download and install the App “SEALEY BT3000”. (App Store or Google Pay). Look for the icon. Note: for
Apple devices it requires iOS 8.0 or latter, Android devices, OS 4.3 or later.
5.2. New Use Setup
When us ing the App for th e r st t ime, yo u mu st com plete Reg istra tion.
1. Run the App on your mobile device.
2. Select “NEW USER” (g.2)
3. Fill in all of the required elds, and then check the box for “AGREE TO TERMS AND CONDITIONS”. Press
“CONTINUE” (g.3)
4. Log in: Enter the email address provided during registration. Check the box for” REMEMBER ACCOUNT”.
Press “LOG IN”. (g.4)
g.1
BT3000 | Issue 1 12/04/17
Original Language Version
© Jack Sealey Limited

#
6. CONNECTING THE TESTER
6.1. Before testing a battery in a vehicle, turn off the ignition, all accessories and loads. Close all of the vehicle`s
doors and boot lid.
6.2. Make sure the battery terminals are clean. Use a wire brush to clean them if necessary. Note: This tester works
best if the battery connects have been removed and the battery posts have been cleaned. Any corrosion between
the tester clamps and the battery connectors, or between the battery connectors and the battery posts, will
degrade the tester`s efciency.
6.3. Connect the positive (red) clamp to the positive (POS,P,+) battery post. Connect the negative (black) clamp to the
negative (NEG,N,-) battery post.
7. OPERATING INSTRUCTIONS
7.1. Battery Test
7.1.1. Run the App on your mobile device and log in.
7.1.2. Press “Scan+” in the upper right corner of the HOME screen. (If the TEST icon is red, the tester is connected; no
need to proceed to Scan+.) The system will scan and nd the tester.
7.1.3. Once the tester shows on the screen, select “Press To Start” to connect.
7.1.4. When connected, press “CONNECTED CONTINUE” (g.6). In this screen, the user may create a name for the
tester. (g.9) Swipe the “TEST>” area (g.7) of the active tester to bring up the Edit option. (g.8)
g.2 g.3 g.4 g.5
BT3000 | Issue 1 12/04/17
Original Language Version
© Jack Sealey Limited

7.1.5. Press “TEST” to enter the testing process.
7.1.6. Select “Battery Test” Set up test on each icon to select Battery Type, Rating and Set Capacity (or Rated CCA)
7.1.7. Press “START TEST” to begin testing. At any time in the process
press “<” to return to the previous screen. (g.10)
7.1.8. Conrm whether the battery has been charged. (g.11)
g.6 g.8 g.7 g.9
g.10
BT3000 | Issue 1 12/04/17
Original Language Version
© Jack Sealey Limited
g.11

7.1.9. The test report is displayed. (g.12) User may select “RETEST BATTERY”
7.1.10. Press “EMAIL/TEXT RESULTS” and then select the application.
Note: Your mobile device must have E-Mail capability to use the EMAIL/TEXT RESULTS function. (g.13/14)
7.1.11. Results will be sent.
7.2. System Test
7.2.1. From the TEST menu, select , Select Battery Type, Rating and Set Capacity (or Rated CCA) (g.15)
7.2.2. Press “START TEST” to begin the system test. At any time in the process, press “<” to return to the previous
screen.
7.2.3. Follow all screen prompts. (g.16 to g.21)
7.2.4. The test report is displayed. (g.22)
7.2.5. Press “EMAIL/ TEXT RESULTS”, and then select the application. Note: Your mobile device must have E-Mail
capability to use the EMAIL/TEXT RESULTS function.
7.2.6. Results will be sent.
7.3. EV Battery Test
7.3.1. From the TEST menu, select “EV BATTERY TEST” Set up the test by swiping up or down on each column
to select the battery brand and model. (g.23)
7.3.2. Press “START TEST” to begin testing. At any time in the process, press “<” to return to the previous screen.
Set up test by swiping up or down on each column to select Battery Type, Rating and Set Capacity (or Rated
CCA)
7.3.3. Follow all screen prompts.
7.3.4. The test report is displayed.
7.3.5. Press “EMAIL/TEXT RESULTS” and then select the application. Note: Your mobile device must have E-Mail
capability to use the EMAIL/TEXT RESULTS function.
7.3.6. Results will be sent.
g.12 g.14 g.13
BT3000 | Issue 1 12/04/17
Original Language Version
© Jack Sealey Limited
g.15

BT3000 | Issue 1 12/04/17
Original Language Version
© Jack Sealey Limited
g.16 g.17 g.18 g.19
g.20 g.21 g.22 g.23

7.4. Start-Stop Test
7.4.1. From the TEST menu select.
7.4.2. Press “START TEST” to begin testing. (g.24)
7.4.3. Follow all screen prompts.
7.4.4. The test report is displayed.
7.4.5. Press “EMAIL/TEXT RESULTS” and then select the application.
Note: Your mobile device must have E-Mail capability to use the EMAIL/TEXT RESULTS function.
7.4.6. Results will be sent.
7.5. Accessing Test Results.
7.5.1. From the HOME screen, scroll down and select “TEST RECORDS”.(g.25)
7.5.2. Select from stored test records to view, email/text or delete.(g.26)
BT3000 | Issue 1 12/04/17
Original Language Version
© Jack Sealey Limited
g.24 g.25 g.26

BT3000 | Issue 1 12/04/17
© Jack Sealey Limited
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and
component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Original Language Version
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging
should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the
environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids
(if applicable) into approved containers and dispose of the product and the fluids according to local
regulations.
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required, it must be
disposed of in an environmentally protective way. Contact your local solid waste authority for recycling
information.
Battery Removal
The battery is not intended for removal
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform
potential purchasers of products containing batteries (as dened within these regulations), that they are
registered with Valpak’s registered compliance scheme. Jack Sealey Ltd’s Batteries Producer
Registration Number (BPRN) is BPRN00705.
