Seca 286 User manual

seca 286

• 55
English
English
CONTENTS
1. Device description . . . . . . . . . . . . . . . . . . . . . . . . 56
1.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . 56
1.2 Description of function . . . . . . . . . . . . . . . . . . . 56
1.3 User qualification . . . . . . . . . . . . . . . . . . . . . . . 56
Administration/network operation . . . . . . . . 56
Measuring mode . . . . . . . . . . . . . . . . . . . . . 56
2. Safety information . . . . . . . . . . . . . . . . . . . . . . . . . 56
2.1 Safety precautions in these Instructions for
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
2.2 Basic safety precautions . . . . . . . . . . . . . . . . . . 57
Handling the device . . . . . . . . . . . . . . . . . . . 57
Preventing electric shock . . . . . . . . . . . . . . . 58
Preventing injuries and infections . . . . . . . . . 58
Preventing device damage . . . . . . . . . . . . . 59
Using the measured results . . . . . . . . . . . . . 59
Handling the packing material . . . . . . . . . . . 60
3. Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
3.1 View of device . . . . . . . . . . . . . . . . . . . . . . . . . 61
3.2 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
3.3 Symbols in the display . . . . . . . . . . . . . . . . . . . 64
3.4 Menu structure for multifunctional display . . . . . 65
3.5 Device signals and voice output . . . . . . . . . . . . 66
3.6 Identification on the device ID label . . . . . . . . . . 66
3.7 Identification on the packaging . . . . . . . . . . . . . 68
4. Before you really get started ... . . . . . . . . . . . . . . 69
4.1 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . 69
4.2 Assembling the device . . . . . . . . . . . . . . . . . . . 70
Fitting the second column element . . . . . . . 70
Fitting the multifunctional display . . . . . . . . . 71
Fitting the third column element . . . . . . . . . . 72
Fitting the ultrasound head . . . . . . . . . . . . . 73
Setting up the device . . . . . . . . . . . . . . . . . . 74
Quick guide . . . . . . . . . . . . . . . . . . . . . . . . . 76
Disinfecting the device . . . . . . . . . . . . . . . . . 76
4.3 Transporting the device . . . . . . . . . . . . . . . . . . 76
4.4 Establishing power supply . . . . . . . . . . . . . . . . 77
5. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
5.1 Calibrating height measurement . . . . . . . . . . . . 78
5.2 Measuring . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Switching on the device . . . . . . . . . . . . . . . . 79
Performing the measuring operation . . . . . . 79
Activating/deactivating key lock . . . . . . . . . . 80
Weighing babies/toddlers (2-in-1) . . . . . . . . 80
Keep the weight permanently in the display
(HOLD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Entering patient data (input) . . . . . . . . . . . . . 81
Enter patient's gender . . . . . . . . . . . . . . . . . 82
Determining body mass index (BMI) . . . . . . 82
Determining body fat rate (BFR) . . . . . . . . . . 82
Sending measured results to wireless
receivers . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Printing measured results . . . . . . . . . . . . . . 83
Switching weighing range automatically . . . . 83
Switching off the device . . . . . . . . . . . . . . . . 84
5.3 Navigating in the menu . . . . . . . . . . . . . . . . . . . 84
5.4 Configuring voice output (menu) . . . . . . . . . . . . 85
Selecting language (LAng) . . . . . . . . . . . . . . 85
Setting volume (VOL) . . . . . . . . . . . . . . . . . . 85
Activating/deactivating announcement of
measured results (reSUL) . . . . . . . . . . . . . . 86
Activating/deactivating the announcement
“Take your printed ticket” (Print) . . . . . . . . . 86
Activating/deactivating announcement of
patient instructions (InStr) . . . . . . . . . . . . . . 86
Configuring beeps . . . . . . . . . . . . . . . . . . . . 86
5.5 Other functions (menu) . . . . . . . . . . . . . . . . . . . 87
Deleting values automatically (ACLr) . . . . . . 88
Deactivating ultrasound measurement . . . . . 88
Switching between BMI and BFR . . . . . . . . 88
Setting display backlighting (LCD) . . . . . . . . 89
Permanently saving additional height (ZEro) . 89
Permanently saving additional weight (Pt) . . 90
Activating the Autohold (AHOLd) function . . 91
Activating/deactivating beeps (bEEP) . . . . . 91
Setting filtering (FIL) . . . . . . . . . . . . . . . . . . . 91
Switching unit of weight (Unit) . . . . . . . . . . . 92
Switching unit of height (HUnit) . . . . . . . . . . 92
Restoring factory settings (rESEt) . . . . . . . . 93
6. The seca 360° wireless network . . . . . . . . . . . . . 94
6.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
seca wireless groups . . . . . . . . . . . . . . . . . . 94
Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Device registration . . . . . . . . . . . . . . . . . . . . 95
6.2 Operating the measuring station in a wireless
group (menu) . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Setting up a wireless group (Lrn) . . . . . . . . . 95
Activating automatic transmission (ASEnd) . 96
Activating/deactivating the wireless module
(system) . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Selecting print option (APrt) . . . . . . . . . . . . . 97
Setting time (tIME) . . . . . . . . . . . . . . . . . . . . 97
7. Hygiene treatment . . . . . . . . . . . . . . . . . . . . . . . . 98
7.1 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
7.2 Disinfecting . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
7.3 Sterilizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
8. Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
9. What do I do if...? . . . . . . . . . . . . . . . . . . . . . . . . . 99
10. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
11. Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . 102
11.1 General technical data . . . . . . . . . . . . . . . . . 102
11.2 Weighing data . . . . . . . . . . . . . . . . . . . . . . . 103
12. Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
13. Optional accessories . . . . . . . . . . . . . . . . . . . . 104
14. Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
15. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
16. Declaration of conformity . . . . . . . . . . . . . . . . 104

56 •
1. DEVICE DESCRIPTION
1.1 Intended use
The seca 286 measuring station is used in accordance with national regula-
tions primarily in hospitals, medical practices, in-patient care facilities and in
so-called "self-screening", in which patients perform measurements them-
selves.
The seca 286 measuring station is for conventional determination of weight
and height and for determining the general state of nutrition; it supports the
attending physician in making a diagnosis or deciding on a course of treat-
ment.
To make an accurate diagnosis, however, the physician needs to commission
other specific examinations and take their results into account, in addition to
determining weight and height.
1.2 Description of function
The seca 286 measuring station measures height using ultrasound. Weight is
recorded using four load cells. The device guides the patient through the
measuring process with configurable voice output. A poster and a label
explaining the correct measuring operation are also enclosed.
Height is transmitted to the multifunctional display. This allows body mass
index (BMI) and body fat rate (BFR) to be calculated automatically.
Measured results can be transmitted wirelessly to a seca wireless printer or to
a PC equipped with a seca USB wireless adapter and compatible seca PC
software via the seca 360° wireless network.
Use the measuring station only for the purpose mentioned in the section enti-
tled "Intended use".
1.3 User qualification
Administration/network operation The device may only be set up and incorporated in a network by experienced
administrators or hospital technicians.
Measuring mode The device may only be operated by healthcare professionals.
The patient can perform the measuring operation independently.
2. SAFETY INFORMATION
2.1 Safety precautions in these Instructions for Use
DANGER!
Used to identify an extremely hazardous situation. If you fail to take
note of this information, serious irreversible or fatal injuries will occur.
WARNING!
Used to identify an extremely hazardous situation. If you fail to take
note of this information, serious irreversible or fatal injuries may result.
CAUTION!
Used to identify a hazardous situation. If you fail to take note of this
information, minor to moderate injuries may result.

Safety information • 57
English
NOTICE!
Used to identify possible incorrect usage of the device. If you fail to
take note of this information, you may damage the device, or the mea-
sured results may be incorrect.
NOTE
Includes additional information about use of the device.
2.2 Basic safety precautions
Handling the device ►Please take note of the information in these instructions for use.
►Keep the instructions for use in a safe place. The instructions for use are a
component of the device and must be available at all times.
DANGER!
Risk of explosion
Do not use the device in an environment in which one of the following
gases has accumulated:
►oxygen
►flammable anesthetics
►other flammable substances/air mixtures
CAUTION!
Patient hazard, damage to device
►Additional devices which are connected to electrical medical
devices must provide evidence of compliance with the relevant IEC
or ISO standards (e.g. IEC 60950 for data-processing devices).
Furthermore, all configurations must comply with the requirements
of standards for medical systems (see IEC 60601-1-1 or Section 16
of the 3rd edition of IEC 60601-1 respectively). Anyone connecting
additional devices to electrical medical devices is considered a
system configurer and is therefore responsible for ensuring that the
system complies with the requirements of standards for systems.
Your attention is drawn to the fact that local laws take precedence
over the above-mentioned requirements of standards. In the event
of any queries, please contact your local specialist dealer or
Technical Service.
►Have servicing carried out regularly as described in the relevant
section of this document.
►Technical modifications may not be made to the device. The device
does not contain any parts for servicing by the user. Only have
servicing and repairs performed by an authorized seca service
partner.
►Only use original seca accessories and spare parts, otherwise seca
will not grant any warranty.
CAUTION!
Patient hazard, malfunction
►Keep other electrical medical devices, e.g. high-frequency surgical
devices, a minimum distance of approx. 1 meter away to prevent
incorrect measurements or wireless transmission interference.
►Keep HF devices such as cell phones a minimum distance of
approx. 1 meter away to prevent incorrect measurements or
wireless transmission interference.
►The actual transmission output of HF equipment may require
minimum distances of more than 1 meter.

58 •
Preventing electric shock WARNING!
Electric shock
►Set up the device so that the power supply socket is easy to reach
and the device can be disconnected from the power supply quickly.
►Ensure that your local power supply matches the information on the
power supply unit.
►Do not touch the power supply unit with wet hands.
►Do not use extension cables or power strips.
►Make sure that cables are not pinched or damaged by sharp edges.
►Make sure that cables do not come into contact with hot objects.
►Do not operate the device at an altitude of more than 3000 m above
sea level.
Preventing injuries and infections WARNING!
Injury from falls
►Ensure that the device is positioned firmly and level.
►Route connecting cables (if present) in such a way that neither user
nor patient can trip over them.
►The device is not designed as a standing aid. Assist people with lim-
ited motor skills when they are getting up, e.g. from a wheelchair.
►Make sure that the patient does not step onto and off the weighing
platform right at the edges.
►Make sure that the patient steps onto and off the weighing platform
slowly and safely.
WARNING!
Danger of slipping
►Ensure that the weighing platform is dry before the patient steps
onto it.
►Ensure that the patients feet are dry before he or she steps onto the
weighing platform.
►Make sure that the patient steps onto and off the weighing platform
slowly and safely.
CAUTION!
Hazard to patient, damage to device
The area where the patient stands consists of a glass plate. Damage
to the glass plate, e.g. as a result of scratches, cracks and chips,
presents a risk of injury and can lead to the glass plate breaking.
►Do not put any sharp-edged objects on the glass plate.
►Before using the device each time, check the glass plate for
scratches, cracks and chips. If you find damage of this kind, have
the glass plate replaced with a new one.
►Do not use the device if the glass plate is damaged.
WARNING!
Risk of infection
►Before and after every measurement, wash your hands to reduce
the risk of cross-contamination and nosocomial infections.
►Hygienically reprocess the scale regularly as described in the re-
spective section in this document.
►Make sure that the patient has no infectious diseases.
►Make sure that the patient has no open wounds or infectious skin
alterations, which may come into contact with the device.

Safety information • 59
English
Preventing device damage NOTICE!
Damage to device
►Ensure that fluids and dust never get inside the device and the sen-
sors. They can damage the electronics.
►Switch off the device before disconnecting the power supply unit
from the mains socket.
►Disconnect the power supply unit from the mains socket if you in-
tend to not use the device for a longer period of time. Only this way
it can be ensured that the device is currentless.
►Make sure not to drop the device.
►Do not expose the device to any impacts or vibrations.
►Perform function controls regularly as described in the relevant sec-
tion in this document. Do not operate the device if it is damaged or
not working properly.
►Ensure that there is no heat source in the immediate vicinity. Do not
expose to direct sunlight. The excessive temperature could damage
the electronics.
►Avoid rapid temperature fluctuations. When the device is transport-
ed so that a temperature difference of more than 20 °C occurs, it
must stay turned off for at least 2 hours before it can be turned on
again. Otherwise, condensation water will form which can damage
the electronics.
►Use the device only in the ambient conditions outlined in "Intended
use".
►Store the device only in the storage conditions outlined in "Intended
use".
►Use only chlorine and alcohol-free disinfectants which are explicitly
suitable for acrylic sheet and other sensitive surfaces (active ingre-
dient: quaternary ammonium compounds, for example).
►Do not use aggressive or abrasive cleaning agents.
►Do not use organic solvents (e.g. white spirit or petroleum spirit).
Using the measured results WARNING!
Patient hazard
This device is no diagnostic device. It simply assists the treating phy-
sician in establishing a diagnosis.
►In order to make a precise diagnosis and initiate therapeutic mea-
sures, besides determination of the weight, further targeted exam-
inations must be set up by the physician, and their results must be
considered.
►The responsibility for diagnosis and treatment lies with the treating
physician.
CAUTION!
Patient hazard
In order to avoid misinterpretations, test results for medical use must
be displayed and used in SI units (weight: kilogrammes, length:
metres) only. Some devices offer the ability to display test results in
other units. This is only an additional function.
►Use the results exclusively in SI units.
►The use of measurement results in non-SI units is the sole respon-
sibility of the user.

60 •
NOTICE!
Inconsistent measuring results
►Before you electronically save measurement values determined us-
ing this device and use them further (e.g. in seca PC software or in
a hospital information system), make sure that the measurement
values are plausible.
►If measurement values are transmitted to seca PC software or a
hospital information system, make sure prior to further use that the
measurement values are plausible and are assigned to the correct
patient.
NOTICE!
Malfunction caused by other ultrasonic emitters
If there are other ultrasonic emitters in the immediate vicinity of the
device - automatic door openers, for example - faulty measurements
or wireless transmission interference will occur.
►Ensure that there are no other ultrasonic emitters in the same room
or in the immediate vicinity of the device.
WARNING!
Incorrect measurement due to reflections
If there are objects or people in the immediate vicinity of the device,
incorrect measurements will result.
►Ensure that there are no objects or people within 0.5 meter of the
front or side of the scale during the measuring process.
►Ensure that the device is at least 0.2 meter away from the wall.
►Ensure that the patient is not wearing any kind of hair accessory on
top of the head.
Handling the packing material WARNING!
Risk of suffocation
Packaging material made of plastic foil (bags) is a choking hazard.
►Keep packaging material out of reach of children.
►In the event that the original packing material may not be available
anymore, only use plastic bags with security holes in order to reduce
the risk of suffocation. Use recyclable materials if possible.
NOTE
Keep the original packing material for future use (e.g. returning for
maintenance service).

Overview • 61
English
3. OVERVIEW
3.1 View of device
4
3
6
7
9
10
11
13
18
1
14
15
5
2
8
12
17
16
No. Device component Function
1Ultrasound head For measuring height
2Status LED Indicates the status of the measuring operation
3Ultrasound sensors For measuring height
4Loudspeaker For voice output
5Modular socket For connecting the modular cable (transmission of data to the
multifunctional display)
6Service interface For use by seca Service
7Cable brackets For stowing the modular cable
8Notice Refers to assembly notes in the operating instructions
9Assembly opening For assembling the measuring head on the column
10 Cable duct For threading the modular cable into the ultrasound head

62 •
3.2 Controls
11 Multifunctional
display Central control and display element
12 Casters 2 pcs, for transporting short distances
13 Spirit level Indicates whether the device is horizontal
14 Power supply
connection For connecting the device
15 Foot screw 4 pcs, for precise alignment
16 Weighing platform Acts as weighing element
17 Column For measuring height
18 Label:
"Correct posture" Information on the correct posture
No. Device component Function
YEARS
PAL
AGE
BMI
BFR
HOLD
HOLD NET PT
kg
lbs
ZERO
ft:in
cm
MONTH
%
1
2
kg/m²
1
/8
1
/
4
1
/2
5
/8
3
/
4
7
/8
3
/
8
2
3
4
5
6
7
8
91
No. Control Function
1
send arrow key
• During weighing (if wireless network is set up):
- send measured result to reception-ready devices (wireless printer, PC with USB wireless
adapter)
•Inthemenu:
- select submenu, select menu item
- increase value
2
print arrow key
• During weighing (if wireless network is set up):
- print out measured result (wireless printer)
•Inthemenu:
- select submenu, select menu item
- reduce value
3
input Enter key:
• During weighing:
- enter patient data (age, gender, PAL)
•Inthemenu:
- confirm selected menu item
- save set value

Overview • 63
English
4
menu key:
• During weighing:
- call up control unit menu.
•Inthemenu:
- press briefly: go back one menu level
- press and hold: exit menu
5Start key, multifunctional display:
switch multifunctional display and scale on and off
6clear key:
for deleting data (patient data, height, BMI, BFR) entered manually or received wirelessly
7gender key:
for entering patient's gender
82 in 1 key:
for starting the 2 in 1 function to weigh babies and toddlers
9hold key:
for activating the hold function
No. Control Function

64 •
3.3 Symbols in the display
YEARS
PAL
AGE
BMI
BFR
HOLD
HOLD NET PT
kg
lbs
ZERO
ft:in
cm
MONTH
%
1
2
kg/m²
1
/8
1
/
4
1
/2
5
/8
3
/
4
7
/8
3
/
8
B
D
E
C
F
H
I
J
K
M
N
O
P
Q
R
A
S
T
G
L
Symbol Meaning
Akg / gWeight value in kilograms/grams
Blb / lbs Weight value in pounds (on non-verified models)
CMother-and child symbol (2 in 1 function active) to weigh babies and toddlers
DPT Pre-tare function active
ENET Tare function active
Fcm Height in centimeters
Gft:in Height in feet and inches (on non-verified models)
Hzero Zero point set, all heights are measured relative to this zero point. If the zero point is
undershot, the measured values will be shown with a minus sign in front.
Ikg/m2Unit of measurement for body mass index
J%Unit of measurement for body fat rate
KOperation with power supply unit
LBFR Body fat rate (proportion of body fat)
MBMI Body mass index
NHOLD Hold function active
OPatient's gender
PPAL Patient's physical activity level
QAGE Patient's age
RNon-verifiable function active
SHOLD Hold function is activated
T
Weighing range currently in use:
1: finer divisions of the weight display at a lower capacity
2: maximum capacity

Overview • 65
English
3.4 Menu structure for multifunctional display
Other functions are available to you in the device menu. This enables you to
configure the device perfectly to suit your needs (details from page 87 and
from page 95).
rF
Reset
Autosend
Sytem
Autoprint
Time
•On
•Off
BMI
BFR
Duration
Brightness
Net Weight
Zero Height
•On
•Off
Press
Hold
Measure
•0
•1
•2
Language
Instruction
Volume
Filter
Beep
LCD
Pre-Tara
Zero
Autohold
Body
Autoclear
Unit
HUnit
Voice Output
1...100
•On
•Off
•cm
•ft:in
•kg
•lbs
•On
•Off
•On
•Off
•On
•Off
•50 %
•100 %
•Off
•Short
•Long
•Permanent
•Year
•Month
•Day
•Hour
•Minute
•HI_MA
•Off
•On
•Off
•On
•Off
Learn Group (ID) Stop Reg. Devices (mo)
•Channel 1 (C1)
•Channel 2 (C2)
•Channel 3 (C3)
**
***
*
CAL Auto
Erkannte Geräte (Mo):
-1: Personenwaage
-2: Längenmessstab
-3: Funkdrucker
-4: PC mit USB-Funkmodul
-7: Säuglingswaage
Group (ID):
Max. drei seca Funkgruppen: 0, 1, 2
Maximal-Konfiguration pro Funkgruppe:
-1 Säuglingswaage
-1 Personenwaage
-1 Längenmessstab
-1 Funkdrucker
-1 PC mit USB-Funkmodul
Kanal (C1, C2, C3):
-3 Kanäle pro Funkgruppe (insg. 9 Kanäle)
-Kanalzahlen: 0-99
-Jede Kanalzahl nur einmal verwenden
- Empfohlener Abstand: 30
Beispiel-Konfiguration:
-Gruppe 0: C1 0, C2 30, C3 60
-Gruppe 1: C1 10, C2 40, C3 70
-Gruppe 2: C1 20, C2 50, C3 80
(Hinweis: Im Display keine Leerzeichen)
*Funknetzwerk seca 360° wireless:
** Nur für Gewichtsmessung
*** Für Gewichts- und Längenmessung
•Off
Ultra
Results •On
•Off
•
•DE
•EN (US/GB)
•
ES (ES/ME)
•
•ZH
ID •
KO
•
RU
•
FR •
TH
•PT
YUE
•
•
DA
•
FI
IT
•
•
JA
•
NL
PL
•
•
SV
TR
*seca 360° wireless network:
Group (ID):
Max. three seca wireless groups: 0, 1, 2
Maximum configuration per wireless
group:
- 1 baby scale
- 1 personal scale
- 1 length measuring device
- 1 wireless printer
- 1 PC with USB wireless adapter
Channel (C1, C2, C3):
- Three channels per wireless group
(total 9 channels)
- Channel numbers: 0 - 99
- Only use each channel number once
- Recommended spacing: 30
Example configuration:
- Group 0: C1 0, C2 30, C3 60
- Group 1: C1 10, C2 40, C3 70
- Group 2: C1 20, C2 50, C3 80
(Note: there are no spaces in the display)
Registered devices (Mo):
- 1: personal scale
- 2: length measuring device
- 3: wireless printer
- 4: PC with USB wireless adapter
- 7: baby scale
Navigation:
Call up menu:
** For measuring weight only
*** For measuring weight and height

66 •
3.5 Device signals and voice output
The automatic weight and height detection of the device allows the patient to
perform a measurement independently.
During the measuring operation, the device supports measurement by means
of acoustic and visual signals, as well as voice output.
NOTE
The acoustic signals and voice output of the device can be configu-
red. Details can be found in the section entitled "Configuring voice
output (menu)" on page 85.
The table below is a summary of the signals and voice output of the device in
the sequence of the measuring operation:
3.6 Identification on the device ID label
Signal/voice output Meaning
Status LED on ultrasound head continuously
on
The device is ready for
measurement
"Please stand upright and look straight." Instruction to the patient
Status LED on ultrasound head goes off The measuring operation
is in progress
"Do not move. The measurement starts
now." Instruction to the patient
Short beeps The measuring operation
is in progress
Long beep The measuring operation
is complete
"Your weight is (...) kilograms. Your height is
(...) centimeters. Your Body Mass Index is
(...)."
Announcement of the
measured results
"The measurement is completed. Please
step off the platform." Instruction to the patient
"Take your printed ticket." Instruction to the
patient/to staff
Text/symbol Meaning
Name and address of manufacturer, date of manufacture
Model number
Serial number, consecutive
GAL
Value in m/s² (verified models)
• Gravitational acceleration on earth
• Depends on the intended location
ProdID Product identification number, consecutive
Approval Type Type designation of design approval
Observe user manual
Electrical medical device, type B
Insulated device, protection class II

Overview • 67
English
e
Value in mass units (verified models)
• States the difference between two consecutive display values
• Used to classify and verify a scale
dValue in mass units (non-verified models)
States the difference between two consecutive display values
Weighing range (verified models)
Device conforms to EC directives.
•M: Conformity symbol in compliance with directive 2014/31/EU for non-automatic scales
(verified models)
•16: (Example: 2016) year in which the EC calibration was performed and the CE mark was
applied (verified models)
•0102: appointed office for metrology (verified models)
•0123: appointed office for medical devices
Class III scale to Directive 2009/23/EC and OIML R76-1 (verified models)
FCC symbol (USA)
FCC ID For USA: device license number from the Federal Communications Commission (FCC)
IC For Canada: device license number from Industry Canada
The device meets the requirements of the Instituto Nacional de Metrologia, Qualidade e
Tecnologia [National Institute of Metrology, Quality and Technology (Inmetro, Brazil)] for
weighing technology
The device meets the requirements of the Agência Nacional de Telecomunicações [National
Telecommunications Agency (ANATEL), Brazil]. Details of the wireless device license:
- HHHH: license number of device
- AA: year of license
- FFFF: identification number of the manufacturer
The device meets the regulatory requirements of GOST R certification (Russia)
The device is licensed by the Russian federal institute for technical regulation and metrology
(Russia
License number of the Chinese Pharmaceutical Association (CPA)
Rating plate on the power supply connection socket
•x-y V: required supply voltage
•max xx A: maximum current consumption
• : note polarity of device plug
• : operate device with direct current
Do not dispose of device with household waste
Text/symbol Meaning
x
M160102
0123
use compatible
seca adapter only
x-y V
max. xxx mA

68 •
3.7 Identification on the packaging
Protect from moisture
Arrows indicate top of product.
Transport and store in an upright position.
Fragile
Do not throw or drop.
Permitted min. and max. temperature for transport and storage
Permitted min. and max. moisture for transport and storage
Open packaging here
Packaging material can be disposed of through recycling programs

Before you really get started ... • 69
English
4. BEFORE YOU REALLY GET STARTED ...
4.1 Scope of delivery
High Accuracy
Ultrasonic Sensors
54321
How to Use
Age
19+
Age
5-19
Age
5-19
25
*BMI-for-agepercentiles.
Source:WorldHealth Organization (WHO), 2007.
97th* 97th*
85th*
85th*
50th*
50th*
15th*
15th*
3rd*
3rd*
WHO,1995,WHO, 2000 and WHO, 2004.
5678910111213141516171819
5678910111213141516171819
Age
(CompletedYears)
30
18.5
5678910111213141516171819
5678910111213141516171819
Age
(CompletedYears)
32
30
28
26
24
22
20
18
16
14
12
BMI
(kg/m²)
32
30
28
26
24
22
20
18
16
14
12
BMI
(kg/m²)
32
30
28
26
24
22
20
18
16
14
12
BMI
(kg/m²)
a
bcd
e
f
g
h
i
k
l
t
s
r
q
po
n
m
j
No. Component Pcs.
aLower part of housing, first column element preassembled 1
bColumn element 2
cThreaded rod, short 1
dThreaded rod, long 1
eUltrasound head 1
fUltrasound head cover 1
gMultifunctional display with power supply connection cable and modular cable 1
hPower supply unit with adapters 1
iColumn connector 1
jReference measuring device 1
kPoster: "Quick guide to measuring" 1
lOpen-ended wrench 1
mHex socket wrench, large 1
nHex socket wrench, small 1
oLabel: "Correct posture" 1
pCable clips 5

70 •
4.2 Assembling the device
The first column element is fitted to the lower part of the device at the factory.
Use an assistant to perform the rest of the assembly. Because the assembled
product is very tall, we recommend placing the components on the floor and
only standing the device up once it is fully assembled. Proceed as outlined
below.
Fitting the second column element ATTENTION!
Device damage as a result of assembly error
If the long and short threaded rods are switched, it will not be possible
to assemble the device so that it is fit for purpose.
►Ensure that the short threaded rod is fitted when assembling the
second column element (see "Scope of delivery" on page 69).
To fit the second column element, proceed as outlined below.
1. Screw the short threaded rod hand-tight into the connecting nut of the
first column element.
qCylinder bolt for ultrasound head cover 1
rHex socket bolts for multifunctional display 2
sPlain washer 1
tConnecting nut 2
-Optional cover for the multifunctional display 1
-Operating instructions, not shown 1
No. Component Pcs.

Before you really get started ... • 71
English
2. Push the column element over the threaded rod onto the first column
element.
3. Place the column connector on the second column element in such a way
that the threaded rod protrudes out of the bore in the column connector.
4. Screw the connecting nut onto the threaded rod.
5. Tighten the connecting nut.
Fitting the multifunctional display The multifunctional display is suspended in the groove of the column
elements and fixed in position with a screw clamp.
ATTENTION!
Malfunction as a result of reflecting multifunctional display
If the multifunctional display is fitted to the first column element, faulty
measurements will result.
►Fit the multifunctional display to the second column element.
1. Insert the tenon block of the multifunctional display in the groove of the
second column element.
2. Slide the display until it is at the right height for you.

72 •
3. Tighten up the two hex socket bolts to fix the multifunctional display in the
desired position.
4. Route the power supply connection cable of the multifunctional display in
the groove of the column elements as far as the lower part of the device.
5. Draw the power supply connection cable through the bore of the lower
part of the device.
ATTENTION!
Malfunction as a result of assembly error
If the cables are fitted under severe mechanical load, faulty displays
and failure of the display may result.
►Lay all cables so that they are not excessively bent and so that
connectors are not snapped off.
6. Wind the free end of the power supply connection cable onto the cable
store in the lower part of the housing.
7. Plug the connector of the power supply connection cable into the
appropriate socket of the weighing platform.
8. Fix the power supply connection cable in the groove of the column
elements using the two cable clips.
9. Swivel the multifunctional display so that is convenient for you to read.
Fitting the third column element ATTENTION!
Device damage as a result of assembly error
If the long and short threaded rods are switched, it will not be possible
to assemble the device so that it is fit for purpose.
►Ensure that the long threaded rod is fitted when assembling the third
column element (see "Scope of delivery" on page 69).
To fit the third column element, proceed as outlined below.

Before you really get started ... • 73
English
1. Screw the long threaded rod hand-tight into the connecting nut of the
second column element.
2. Push the third column element over the threaded rod onto the column
connector of the second column element.
Fitting the ultrasound head The ultrasound head is fitted to the third column element and connected to
the modular cable of the multifunctional display.
ATTENTION!
Device damage as a result of assembly error
The third column element is loose on the second column element.
►Hold the third column element firmly as you lay the device on the
floor.
►Ensure that the third column element is in the right position before
you fit the ultrasound head.
ATTENTION!
Malfunction as a result of faulty multifunctional display
When the device is laid down, the multifunctional display is directly on
the floor and may be damaged.
►Lay the device down slowly and carefully on a soft surface, a
blanket, for example.
1. Tilt the device and carefully lay it on the floor.
2. Push the ultrasound head onto the free end of the threaded rod.
3. Put the plain washer onto the threaded rod.
4. Screw the connecting nut onto the threaded rod.
5. Tighten the connecting nut.
ATTENTION!
Damage to device and malfunction as a result of assembly error
If the connecting nut in the ultrasound head is not tightened enough,
the column elements will be too loosely connected. The device will be
unstable and faulty measurements will occur.
►Tighten up the connecting nut so that the columns are firmly located
on one another and there is no gap between the column connector
and the third column element.
