SECO-LARM SD-998C-D3Q User manual

Surface-Mount Electric Rim Strikes
Installation Manual
SD-998C-D3AQ shown
43RG
Model Housing thickness Latch Throw Material
SD-998C-D3Q 3/4" (19mm) 3/4" (19mm) Aluminum
SD-998C-BD3 3/4" (19mm) 3/4" (19mm) Black (Anodized)
SD-998C-D3AQ 1/2" (13mm) 1/2" (13mm) Aluminum
SD-998C-BD3A 1/2" (13mm) 1/2" (13mm) Black (Anodized)
 12/24 VDC Operating voltage
 Non-polarized connection
 Horizontal adjustment
 Accommodates up to 3/4" Pullman latch
 Reversible non-handed design fits either right-hand or left-handed doors
 Surface-mount on metal or wood frames
 Works with standard rim-type exit devices including SECO-LARM SD-962xR-36A and SD-962xR-36G
 For Indoor Use Only
 Static strength – 1,500-lb (6673N)
 Tested for 250,000 cycles (UL Tested)
 Low current draw: 540mA@12VDC, 270mA@ 24VDC
 Field-selectable for fail-safe or fail-secure operation
 The SD-998C series is intended to be used with UL Listed Exit Hardware
 The SD-998C series shall not impair the intended operation of an emergency unit
 The SD-998C series shall not impair the operation of panic hardware mounted on the door

Surface-Mount Electric Rim Strikes
2 SECO-LARM U.S.A., Inc.
Parts List
1x
Strike
1x
Dead latch ramp adapter
1x
Blind nut kit
1x
12VDC cable connector
2x
Blind nuts
1x
24VDC cable
connector
1x
Hex wrench
Spacers
2x
Hex socket head cap screws
3x
1
/
32
" (0.9mm)*
2x
Phillips flat head screws
1x
1
/
16
" (1.5mm)
2x
1
/
8
" (3mm)
†
2x
Crimp connectors
*SD-998C-D3Q and SD-998C-BD3 only
†SD-998C-D3AQ and SD-998C-BD3A only
Specifications
Model SD-998C-D3Q SD-998C-BD3 SD-998C-D3AQ SD-998C-BD3A
Operating voltage 12~24 VDC
Current draw 540mA@12VDC, 270mA@24VDC
Maximum latch throw 3/4" (19mm) 1/2" (13mm)
Static strength 1,500-lb (6673N)
Dynamic strength 70ft-lb (95J)
Endurance 250,000 cycles (UL Tested), Level IV
Destructive attack Level I
Line security Level I
Standby power Level I
Operating humidity 0~85%
Operating temperature 14°~120° F (-10°~49° C)
Dimensions 9"x3/4"x13/4" (229x19x45 mm) 9"x1/2" x13/4" (229x13x45 mm)
Overview
63/8"
(162mm)
1/2"(13mm)
13/4"
(45mm)
81/4"
(210mm)
9"
(229mm)
Cover 3/4"(19mm)
11/2" (38mm)
SD-998C-D3Q
SD
-
998
C
-
BD3
SD-998C-D3AQ
SD-998C-BD3A

Surface-Mount Electric Rim Strikes
SECO-LARM U.S.A., Inc. 3
Installation
1. Set either fail-safe or fail-secure operation. See "Selecting Fail-
Safe/Fail-Secure," below.
2. Measure the center line of the latch, labeled "Y" (see Fig.1).
3. With the door closed, measure and mark the latch line on the door
frame, labeled "X" (see Fig. 2). This will correspond with the inside
of the strike keeper as shown in Figs. 3 and 4.
4. Remove the four cover screws and remove the cover.
5. Using the strike as a template centered on the latch center line
"Y," and so that the inside of the strike keeper is aligned with the
door latch line "X," mark and drill the two outer mounting holes
and the cable access hole.
6. Make the wire connections (see "Wiring Diagram" on pg. 4)
and then mount the strike to the frame with the Philips flat-
head screws. Check the location and ensure that the door
latches properly and adjust the strike horizontally as needed.
7. Tighten the two mounting screws and mark the locking hole
locations (the two inner holes, see Fig. 5).
8. Remove the strike and drill the two locking holes. Insert the
blind nuts into the locking holes. Reinstall the strike as before
and lock into place with the hex socket head cap screws into
the blind nuts.
9. Replace the cover and reinstall the screws.
Selecting Fail-Safe/Fail-Secure
1. Remove both locking screws #1.
2. Loosen both sliding screws #2, slide to
the desired fail safe or fail secure setting
(factory default), and retighten.
3. Reinsert and tighten locking screws #1 to
lock the desired fail safe or fail secure
setting.
NOTE: SD-998C-D3AQ SD-998C-BD3A shown.
Latch
Center line
Y
Fig. 1
Door closed
Fig. 2
Door
X
Door
frame
Door latch line
Pullman
Latch
Inside of
strike
keeper
Fig. 4
Fig. 5
Mounting
screw holes
63/8"
(162mm)
81/4"
(210mm
)
Locking screw holes
Locking screw #1
Sliding screw #2
Fail-Safe
Fail-Secure
Inside of
strike
keeper
Fig. 3

Surface-Mount Electric Rim Strikes
IMPORTANT:
Users and installers of this product are responsible for ensuring that the installation and configuration of this product com
plies with all national, state,
and local laws and codes. SECO-LARM will not be held responsible for the use of this product in violation of any current laws or codes.
California Proposition 65 Warning:
These products may contain chemicals which are known to the State of California to cause cancer and birth defects or other
reproductive harm. For more information, go to www.P65Warnings.ca.gov.
WARRANTY:
This SECO
-
LARM product is warranted against defects in material and workmanship while used in normal service for
one
(
1
)
year from the date of sale
to the original customer. SECO-LARM’s obligation is limited to the repair or r
eplacement of any defective part if the unit is returned, transportation prepaid, to
SECO-LARM. This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, negl
ect, repair or alteration, improper
or abnormal usage, or faulty installation, or if for any other reason SECO-
LARM determines that such equipment is not operating properly as a result of causes other
than defects in material and workmanship. The sole obligation of SECO-LARM and the purchaser’s e
xclusive remedy, shall be limited to the replacement or repair
only, at SECO-LARM’s option. In no event shall SECO-
LARM be liable for any special, collateral, incidental, or consequential personal or property damage of any
kind to the purchaser or anyone else.
NOTICE:
The SECO
-
LARM policy is one of continual development and improvement. For that reason,
SECO
-
LARM
reserves the right to change specifications without
notice. SECO-LARM is also not responsible for misprints. All trademarks are the property of SECO-LARM U.S.A., Inc. or their respective owners. Copyright © 2023
SECO LARM U.S.A., Inc. All rights reserved.
Wiring Diagram
For 12VDC operation
1. Use the included wiring connector marked 12VDC.
2. Plug the male wiring connector into the female
wiring harness connector of the door strike.
For 24VDC operation
1. Use the included wiring connector marked 24VDC.
2. Plug the male wiring connector into the female
wiring harness connector of the door strike.
Dead latch Ramp Adapter
1. Remove cover by removing 4 screws.
2. Remove 2 screws holding latch ramp and remove.
3. Install Dead latch ramp adapter and replace the 2
screws to hold it in place.
4. Replace the cover and replace the 4 screws.
Troubleshooting
Electric strike does not
activate
 Dismount the strike and check that the wiring connector is connected
properly.
 Ensure the wiring connector is connected to a 12 or 24VDC source.
 Use a multimeter to test that the strike is receiving the proper voltage
and amperage. If it is not, it may be necessary to use heavier gauge
wires, or increase the output of the power supply.
 Make sure the activation device (keypad or push-button switch) is
working properly
Door does not open when the
electric strike is activated
 Check that the door latch is operating properly, and replace if
necessary.
 The position of the electric strike may need to be adjusted by moving it
or adding washers or shims.
Strike makes a buzzing sound  Connect the strike to a DC power supply.
12VDC
24VDC
Black Wire
Red
Wire
White Wire
SECO-LARM ® U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Website:
www.seco
-
larm.com
Phone: [phone] | [phone] Email: [e-mail]
PITGW1
MI_SD-998C-xxxx_230801.docx
