Sega DRONE RACING GENESIS User manual

IMPORTANT
• Before using this product, read this Manual carefully to understand
the contents herein stated
•After reading this Manual, be sure to keep it near the product or in a
convenient place for easy reference when necessary
OWNER'S MANUALDrone racing genesis 420-0039UK
Sega Amusements International Limited.
42 Barwell Business Park, Leatherhead Road, Chessington, Surrey, KT9 2NY. United Kingdom.
Telephone: [phone] Facsimile: [phone]
email: [email protected] Web: http://www.segaarcade.com
© SEGA
Errors & Omissions Excepted (E&OE)
420-0039UK
2ND PRINTING

ii
INTRODUCTION
INTRODUCTION
This Manual is intended to provide detailed descriptions together with all necessary information covering the general
operation of electronic assemblies, electromechanical, servicing control, spare parts, etc. for the product:
"DRONE RACING GENESIS"
This Manual is intended for the owners, personnel managers in charge of operation of this product.
Operate the product after carefully reading and suciently understanding the instructions.
In the unlikely event that the product does not function correctly, DO NOT allow anyone other than a technician
to touch the internal system. Turn o the power to the machine, making sure to unplug the electrical cord from the
outlet, and contact the oce listed below or the point-of-purchase for this product.
Use of this product is unlikely to cause physical injuries or damage to property. However, points that require special
attention are indicated by bold text, the words "STOP”, “IMPORTANT” or “CAUTION” and the symbols below.
Indicates important information that, if ignored, may result in the mishandling
of the product and cause faulty operation or damage to the product
Indicates a warning or caution that, if ignored, may result in the mishandling
of the product and cause faulty operation or damage to the product
Sega Amusements International Limited
42 Barwell Business Park,
Leatherhead Road,
Chessington, Surrey,
KT9 2NY
United Kingdom
European Sales: [phone] Email: [email protected]
USA Sales: +00 (1) 224 265 4287 Email: [email protected]
STS (Spares): [phone] (Option 1) Email: [email protected]
Tech Support: [phone] (Option 2) Email: [email protected]
Prize & Merchandise: [phone] (Option 1) Email: [email protected]
Web: http://www.segaarcade.com

INTRODUCTION
iii
Parts replacement, maintenance inspections and troubleshooting should be carried out by site maintenance personnel
or other qualied professionals. This Manual includes directions for potentially dangerous procedures which should
only be carried out by professionals with the appropriate specialised knowledge.
The Site Maintenance Personnel or other qualied professionals mentioned in this Manual are dened as follows:
Site Maintenance Personnel:
Individuals with experience in maintaining amusement equipment, vending machines, etc., working under the
supervision of the owner/operator of this product to maintain machines within amusement facilities or similar
premises by carrying out everyday procedures such as assembly, maintenance inspections, and replacement of units/
expendable parts.
Activities to be carried out by Site Maintenance Personnel:
Amusement equipment/vending machine assembly, maintenance inspection and replacement of units/expendable
parts.
Other qualied professionals:
Persons employed by amusement equipment manufacturers, or involved in design, production, testing or
maintenance of amusement equipment. The individual should have either graduated from technical school or hold
similar qualications in electrical/electronics/mechanical engineering.
Activities to be carried out by other qualied professionals:
Amusement equipment/vending machine assembly, repair/adjustment of electrical/electronic/mechanical parts.
Denition of 'Site Maintenence Personnel’ or Other Qualied IndividualsDenition of 'Site Maintenence Personnel’ or Other Qualied Individuals
Electrical & Mechanical SpecicationsElectrical & Mechanical Specications
Procedures not described in this Manual or marked as ‘to be carried out by Site
Maintenance Personnel or other qualied professionals’ should not be carried
out by personnel without the necessary skill or technological experience. Work
carried out by unqualied persons may cause serious accidents, including
electrocution.
Standard Cabinet
Machine Dimensions: 1.07m (42.1in) [Width] x 1.83m (72.1in) [Depth]
Machine Height: 2.41m (94.8in) (Installed)
Machine Weight: 358kg Approx (Installed)
Power, maximum current: -350w-
Rating: 115/230VAC @ 50/60Hz
Fuse Rating: 3.15A
SPECIFICATIONS

iv
INTRODUCTION
Monitor Cabinet Seat Cabinet
Billboard
H = 1.88m
L = 0.91m W = 1.07m
L = 0.92m
W = 0.85m
H = 1.17m
H = 0.53m
L = 0.41m
W = 0.99m
INDIVIDUAL SPECIFICATIONS

INTRODUCTION
v
Waste of Electrical and Electronic Equipment (WEEE) StatementWaste of Electrical and Electronic Equipment (WEEE) Statement
The WEEE (Waste of Electrical and Electronic Equipment) directive places an obligation on all EU based
manufacturers and importers of Electrical and Electronic Equipment (EEE) to ensure waste equipment is disposed of
in accordance with the directive at the end of their useful life.
The symbol shown below will be placed on all products manufactured from 13th August 2005, which indicates this
product must NOT be disposed of with other normal waste. Upon purchasing any EEE from SEGA Amusements
International Ltd. The user accepts responsibility to dispose of their waste equipment by arranging to return it to a
designated UK collection point (AATF) or an Approved Exporter (AE) for the correct recycling of waste electrical
and electronic equipment.
For more information on Approved Authorised Treatment Facilities (AATF) within the UK please consult the
government website www.gov.uk
For users outside of the UK EEE should be disposed of in accordance with the local policy on the recycling of Waste
Electrical and Electronic Equipment.
Battery Recycling StatementBattery Recycling Statement
The EC Directive on Batteries and Accumulators (2006/66/EC) aims to minimise the impact of batteries on
the environment and encourage the recovery of the materials they contain. To achieve increased collection and
recycling of waste batteries, the Directive places ‘producer responsibility’ obligations on manufacturers and
importers of portable, industrial and automotive batteries.
The symbol shown below will be on all equipment tted with batteries from 26th September 2008 and indicates
they must NOT be disposed of with other normal waste. Instead, it is the user’s responsibility to dispose of used
batteries by arranging to return them to a designated collection point for the correct recycling.
For more information about where you can send your waste batteries for recycling contact your local authority
oce.
REGISTERED IN ENGLAND REGISTERED NO. 1711515
REGISTERED OFFICE: BLOCK C 42 BARWELL BUSINESS PARK, CHESSINGTON, SURREY KT9 2NY

TABLE OF CONTENTS
INTRODUCTION iii
HANDLING PRECAUTIONS 1
PRECAUTIONS REGARDING INSTALLATION 5
PRECAUTIONS REGARDING OPERATION
3-1 Before Operation
3-2 Paying Attention to Customers
8
8
10
PARTS DESCRIPTION 12
ACCESSORIES 13
ASSEMBLY AND INSTALLATION
6-1 Installing the Seat Cabinet
6-2 Installing the Billboard
6-3 Fixation to Site
6-4 Confirmation of Installation
6-5 Components that Change State
6-6 Linking Multiple Cabinets
16
16
19
21
24
25
26
PRECAUTIONS WHEN MOVING
7-1 Moving the Machine
28
28
GAME DESCRIPTION
8-1 Game Outline
8-2 Game Flow
30
30
30
TEST AND SERVICE DATA
9-1 Switch and Coin Meter
9-2 Game Test Mode
9-3 System Information
9-4 Input Test
9-5 Output Test
9-6 Calibration Test
9-7 Coin Test
9-8 Sound Test
9-9 Screen Test
9-10 Network Test
9-11 Bookkeeping
9-12 Clock Test
9-13 Game Assignments
34
35
36
37
38
39
40
41
42
43
44
45
51
52
MONITOR
10-1 General Description
10-2 Cleaning the Screen
10-3 On-Screen Adjustment Method
53
53
54
55
CONTROLLER UNIT
11-1 Replacing the Joystick
11-2 Greasing
61
62
64
22
33
44
55
66
77
88
99
1010
1111
11

COIN HANDLING
12-1 Cleaning the Coin Selector
12-2 Fault Finding
12-3 Adjusting the Price of Play (Excel)
12-4 Coin Region & Price of Play Settings
12-5 Price of Play Quick Start (USA)
65
65
68
69
70
72
LAMPS AND LIGHTING
13-1 Coin Door Lamp
13-2 Cabinet LED List
13-3 LED Diagrams
73
73
74
75
PERIODIC INSPECTION 78
TROUBLE SHOOTING
15-1 Troubleshooting (No Error Message)
80
80
GAME BOARD
16-1 How to Remove Game Board
82
83
DESIGN RELATED PARTS 85
PARTS LIST 86
COLOUR CODE 116
SCHEMATIC DIAGRAM 117
1212
1313
1414
1515
1616
1717
1818
1919
2020

BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain safety:
To ensure the safe operation of this product, be sure to read the following before usage:
The following instructions are intended for the users, operators and the personnel in charge of the
operation of the product. After carefully reading and suciently understanding the warning displays
and cautions, handle the product appropriately. Be sure to keep this Manual close to the product or
in a convenient place for future reference.
Herein, explanations which require special attention are enclosed with dual lines. Depending on
the potentially hazardous degrees, the terms of "DANGER", "WARNING", "CAUTION", etc. are
used. Be sure to understand the contents of the displays before reading the text.
Indicates that mishandling the product by disregarding this pictograph will
cause severe injury or death.
Indicates that mishandling the product by disregarding this warning will cause
a potentially hazardous situation which can result in death or serious injury.
Indicates that mishandling the product by disregarding this caution will cause
a slight hazardous situation which can result in personal injury and/or material
damage.
For the safe usage of the product, the following pictographs are used:
Indicates "HANDLE WITH CARE." In order to protect the human body and equipment,
this display is attached to places where the instruction manual should be referred to.
Indicates a "protective earth terminal." Before operating the equipment, be sure to connect
it to the ground (this step may be omitted for products in which a power cable with earth is
used).
• Perform work in accordance with the instructions herein stated
Instructions for work are explained by paying attention to the aspect of accident prevention.
Failing to perform work as per the instructions can cause accidents. In the case where only
those who have technical expertise should perform the work to avoid hazardous situation, the
instructions herein state that the site maintenance personnel should perform such work
• Be sure to turn o󰀨 the power before working on the machine
To prevent an electric shock, be sure to turn o the power and unplug the power cable before
carrying out any work that requires direct contact with the interior of the product. If the work is
to be performed in the power-on status, the instruction manual herein always states to that eect
• Be sure to ground the earth terminal (this is not required in the case where a
power cable with earth is used)
This product is equipped with the earth terminal. When installing the product, connect the earth
terminal to the "accurately grounded indoor earth terminal" by using an earth wire. Unless the
product is grounded appropriately, the user can be subject to an electric shock. After performing
repair, etc. for the control equipment, ensure that the earth wire is rmly connected to the control
equipment
• Ensure that the power supply used is equipped with an earth leakage breaker
Using a power supply which is not equipped with the earth leakage breaker can cause a re when
earth leakage occurs
• Be sure to use fuses which meet the specied rating (only for the machines which
use fuses)
Using fuses exceeding the specied rating can cause a re and an electric shock

• Specication changes (removal of equipment, conversions and additions) not
designated by SEGA are not allowed
The parts of the product include warning labels for safety, covers for personal protection, etc. It
is very hazardous to operate the product by removing parts and/or modifying the circuits. Should
doors, lids and protective parts be damaged or lost, refrain from operating the product, and
contact where the product was purchased from or the oce herein stated.
SEGA shall not be held responsible for any accidents or compensation for damage to a third
party resulting from the specications not designated by SEGA
• Ensure that the product meets the requirements of appropriate electrical
specications
Before installing the product, check for electrical specications. SEGA products have a
nameplate on which the electrical specications are described. Ensure that the product is
compatible with the power supply voltage and frequency requirements of the location. Using
any electrical specications dierent from the designated specications can cause a re and an
electric shock
• Install and operate the product in places where appropriate lighting is available,
allowing warning labels to be clearly read
To ensure safety for the customers, labels and printed instructions describing potentially
hazardous situations are applied to places where accidents can be caused. Ensure that where the
product is operated has sucient lighting allowing the warnings to be read. If any label is peeled
o, apply it again immediately. Please place an order with where the product was purchased from
or the oce herein stated
• When handling the monitor, be very careful (applies only to products with
monitors)
Some of the monitor parts are subject to high tension voltage. Even after turning o the power,
some portions are still subject to high tension voltage. Monitor repair and replacement should
be performed only by those technical personnel who have knowledge of electricity and technical
expertise
• Be sure to adjust the monitor properly (applies only to products with monitors)
Do not operate the product leaving on-screen ickering or blurring as it is. Using the product
with the monitor not properly adjusted may cause dizziness or a headache to an operator, a
player, or customer
• When transporting or reselling this product, be sure to attach this Manual to the
product
* In the case where commercially available monitors and printers are used in this product, only the
contents relating to this product are explained herein. Some commercially available equipment
has functions and reactions not stated in this manual. Read this manual together with the specic
instruction manual of such equipment
* Descriptions herein contained may be subject to improvement changes without notice
* The contents described herein are fully prepared with due care. However, should any question
arise or errors be found, please contact SEGA
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately
after transporting to the location. Nevertheless, an irregular situation may occur during
transportation. Before turning on the power, check the following points to ensure that the product
has been transported in a satisfactory status:
Are there any dented portions or defects (cuts, etc.) on the external surfaces of the Cabinet?
Are castors and adjusters damaged?
Do the power supply voltage and frequency requirements meet with those of the location?
Are all wiring connectors correctly and securely connected? Unless connected in the correct
way, connector connections can not be made accurately. Do not insert connectors forcibly.
Do power cables have cuts and dents?
Are all accessories available?
 Canalldoorsandlidsbeopenedwiththeaccessorykeys?Candoorsandlidsbermlyclosed?

HANDLING PRECAUTIONS
1
11
1HANDLING PRECAUTIONS
When installing or inspecting the machine, be mindful of the following points and pay attention to ensure that the
player can enjoy the game safely.
Noncompliance with the following points or inappropriate handling running counter to the cautionary matters herein
stated can cause personal injury or damage to the machine.
• Before performing work, be sure to turn the power off. Performing the work
without turning the power off can cause an electric shock or short circuit.
In cases where work should be performed in the status of power on, this
manual always states to that effect
• To avoid an electric shock or short circuit, do not plug in or unplug quickly
• To avoid an electric shock, do not plug in or unplug with a wet hand
• Do not expose power cords or earth wires on the surface, (oor, passage,
etc). If exposed, the power cords and earth wires are susceptible to
damage. Damaged cords and wires can cause an electric shock or short
circuit
• To avoid causing a re or an electric shock, do not put things on or damage
the power cords
• During or after installing the product, do not unnecessarily pull the power
cord. If damaged, the power cord can cause a re or an electric shock
• In the case that the power cord is damaged, ask for a replacement through
where the product was purchased from or the ofce herein stated. Using
the cord as is damaged can cause re, an electric shock or leakage
• Be sure to perform grounding appropriately. Inappropriate grounding can
cause an electric shock
• Be sure to use fuses meeting the specied rating. Using fuses exceeding the
specied rating can cause a re or an electric shock
• Be sure that connections such as IC BD are made properly. Insufficient
insertion can cause an electric shock
• Specication changes, removal of equipment, conversion and/or addition,
not designated by SEGA are not permitted
• Failure to observe this may cause a fire or an electric shock. Non-
compliance with this instruction can have a bad influence upon the
physical conditions of players or onlookers, or result in injury during play
• SEGA shall not be held responsible for damage or compensation for
damage to a third party caused by specication changes not designated
by SEGA
• Do not perform any work or change parts not listed in this manual. Doing so
may lead to an accident
• If you need to perform any work not listed in this manual, request work from
the ofce indicated in this Manual or the point of purchase, or inquires for
details. Be sure to perform periodic maintenance inspections herein stated

2
HANDLING PRECAUTIONS
11
• For the IC board circuit inspections, only the use of a logic tester is
recommended. Using a Multi-Tester or General Purpose Tester may result
in damage to IC Circuits
• Static electricity from your body may damage some electronic devices
on the IC board. Before handling the IC board, touch a grounded metallic
surface so that the static electricity can be discharged
• Some parts are not designed or manufactured specically for this game
machine. The manufacturers may discontinue or change the specications
of such general-purpose parts. If this is the case, SEGA cannot repair or
replace a failed game machine whether or not a warranty period has
expired
• Do not touch undesignated places. Touching places not designated can
cause electric shock or short circuit
• Whenever any fasteners (e.g. screws, nuts) have been lost, be sure to use
replacement fasteners with proper dimensions as specied in this Manual.
If fasteners of any other dimensions are used, it could cause damage
and/or separation of parts that result in secondary accidents
• Specification changes, removal of equipment, conversion and/or
addition, not designated by SEGA are not permitted
• Failure to observe this may cause a fire or an electric shock. Non-
compliance with this instruction can have a bad influence upon the
physical conditions of players and onlookers, or result in injury during
play
• SEGA shall not be held responsible for damage or compensation for
damage to a third party caused by specication changes not designated
by SEGA
• Performing work or parts replacements not described in this Manual
could result in accidents. If you need to perform any work not listed in
this manual, request work from the ofce indicated in this manual or the
point-of-purchase, or inquires for details
• Be sure to perform periodic maintenance inspections herein stated

HANDLING PRECAUTIONS
3
11
CONCERNING THE STICKER DISPLAY
This SEGA product has stickers attached describing the product manufacture No. (Serial No.) and Electrical
Specications. It also has a Sticker describing where to contact for repair and for purchasing parts.
When inquiring about or asking for repairs, mention the Serial No. and Name of Machine indicated on the
Sticker. The Serial Number indicates the product register. Identical machines could have dierent parts depending
on the date of production.
Also, improvements and modications might have been made after the publication of this Manual. In order to
ensure you order the correct parts, mention the Serial No. when contacting the applicable places.
CONCERNING WARNING DISPLAYS
This SEGA product has warning displays on stickers, labels and/or printed instructions adhered/attached to or
incorporated in the places where a potentially hazardous situation could arise. The warning displays are intended
for accident prevention for customers and for avoiding hazardous situations relating to maintenance and servicing
work. Some portions of the cabinet contain high voltage and may cause accidents if touched. When performing
maintenance, be very careful of the warning displays.
It is especially important that any complex repair and replacement work not mentioned herein should be performed
by those technical personnel who have knowledge of electricity and has technical expertise.
In order to prevent accidents, caution any customer ignoring the warnings to cease and desist immediately.

4
HANDLING PRECAUTIONS
11
CAUTION
QUALIFIED PERSONNEL
ONLY
Take care when servicing
within these areas
440-CS0010UK
WARNING
RISK OF SHOCK
Do Not Open!
Authorised Personnel
Only 440-WS0005UK
PORTABLE APPLIANCE TEST RECORD
AMUSEMENTS INTERNATIONAL 42 BARWELL BUSINESS PARK, CHESSINGTON,
SURREY, UNITED KINGDOM, KT9 2NY
DATE ENGINEER VISUAL PASS EARTH BOND INSULATION SIGNED
LB1046
If you or your child have experienced a convulsive attack, loss of
consciousness, etc. due to light stimulus or TV games, or fear
that you might experience such symptoms, be very careful of
using this machine.
If you feel sick while playing, immediately discontinue use and
take a rest.
440-CS0186-01UK
CAUTION
LB1097
On inside of AC Bracket
next to stud LB1046
LB1223
440-CS0186-01UK
440-CS0010UK
440-WS0005UK
LB1155
COIN IN
LB1155
LB1223
DANGER
High voltage can cause
an electric shock.
Remove power before
servicing.
440-DS0010UK
LB1131
3.15A
LB1126-3150-250
INDOOR USE ONLY
LB1212
440-CS0300UK
CAUTION
DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according with the
manufacturers guidelines.
On Game Board
Next to Earth Bridge
440-CS0300UK
440-CS0010UK
440-CS0010UK
440-WS0100UK
440-DS0010UK
LB1131
LB1097
LB1126-3150-250
LB1212
CAUTION
QUALIFIED PERSONNEL
ONLY
Take care when servicing
within these areas
440-CS0010UK
CAUTION
QUALIFIED PERSONNEL
ONLY
Take care when servicing
within these areas
440-CS0010UK

PRECAUTIONS REGARDING INSTALLATION LOCATION
5
22
2 PRECAUTIONS REGARDING INSTALLATION
• This product is an indoor game machine. Do not install it outside. Even indoors,
avoid installing in places mentioned below so as not to cause re, electric
shock, injury and/or malfunction:
• Places subject to rain/water leakage or places subject to high humidity, in the
proximity of an indoor swimming pool and/or shower, etc
• Places subject to direct sunlight or places subject to high temperatures, in the
proximity of heating units, etc
• Places filled with inflammable gas or vicinity of highly inflammable/volatile
chemicals or hazardous matter
• Dusty places
• Sloped surfaces
• Places subject to any type of violent impact
• Vicinity of anti-disaster facilities such as re exits and re extinguishers
• Areas where the temperature exceeds the applicable temperature (ambient
temperature) range of 5 to 30 degrees centigrade
LIMITATIONS OF USAGE
• Be sure to check the Electrical Specifications. Ensure that this product
is compatible with the location's power supply, voltage, and frequency
requirements. A plate describing Electrical Specications is attached to the
product. Noncompliance with the Electrical Specications can cause a re
and electric shock
• This product requires a breaker and earth mechanism as part of the location
facilities. Using the product without these can cause a re and electric shock
• Ensure that the indoor wiring for the power supply is rated at 15 A or higher
(AC single phase 100 V ~ 120 V area), and 7 A or higher (AC 220 V ~ 240 V
area). Noncompliance with the Electrical Specications can cause a re and
electric shock
• Be sure to use an independent power supply equipped with an earth leakage
breaker. Using a power supply without an earth leakage breaker can cause
an outbreak of re if a power surge occurs
• Putting many loads on one electrical outlet can cause generation of heat and
a re resulting from overload
• When using an extension cord, ensure that the cord is rated at 15 A or higher
(AC 100 V ~ 120 V area) and 7 A or higher (AC 220 V ~ 240 V area). Using a
cord rated lower than the specied rating can cause a re and electric shock

6
PRECAUTIONS REGARDING INSTALLATION LOCATION
22
Securing a safe area for operation as described in this Manual will ensure
safe operation for players and observers
SEGA shall not be held responsible for damage or compensation for damage
to a third party, resulting from the failure to observe this instruction
• For safe operation, use and operate this product in an area measuring at
least 1.77m (69.7in) in width and 2.53m (99.6in) in depth when the Cabinet is
installed. SEGA shall not be held responsible for damage or compensation for
damage to a third party, resulting from the failure to observe this instruction
• The ceiling where this product is installed must be at least 1.88m (74in) high. If
the ceiling is too low, the heat emitted from the product may cause it to catch
on re
• Be sure to provide the sufcient space specied in this Manual. Do not allow
objects to block the ventilation ports. This can cause generation of heat and a
re
• Put multiple Cabinets close together so that people cannot get through or
provide enough space between them that people can go both ways without
difficulty. If Cabinets are installed carelessly, people may bump into each
other or the Cabinets when passing between them or fall down. To prevent
people from walking between them, place them 0.15 m (5.9 in) apart
• If the machine does not t through the entryway to the installation location,
do not disassemble it without first consulting the instructions. Specific tools
and adjustment procedures are required to assemble and disassemble the
mechanical parts. Attempting to assemble or disassemble the machine
without consulting the instructions may result in accidents during assembly/
disassembly, electric shock, short circuits, and/or personal injury during
operation. If the machine still does not t through the entryway after following
the procedures in this Manual, contact your retailer or the ofce listed in this
Manual
• If the machine is still too large to t through the entryway after following the
procedures listed in this Manual, do not tip the machine on its side. Attempting
to transport the machine while it is tipped on its side may cause accidents. It
may also damage or warp parts of the machine, resulting in accidents during
operation
OPERATION AREA (SINGLE CABINET)

PRECAUTIONS REGARDING INSTALLATION LOCATION
7
22
• To install this product, the entrance must be at least 0.91m (35.8in) in width
and 1.88m (74in) in height. If the entrance is too narrow, do not tilt the product
carelessly. If all the product weight is put on the castors at one side only, there
could be damage or deformation, causing serious accidents such as workers
getting caught underneath
1.77m (69.7in)
Wall
2.53m (99.6in)
Wall Space
(0.15m)

8
PRECAUTIONS REGARDING PRODUCT OPERATION
33
3 PRECAUTIONS REGARDING OPERATION
To avoid injury and trouble, be sure to pay attention to the behaviour of visitors and players.
• In order to avoid accidents, check the following before starting the operation:
• To ensure maximum safety for the players and the customers, ensure that
where the product is operated has sufcient lighting to allow any warnings to
be read. Operation under insufcient lighting can cause bodily contact with
each other, hitting accident, and/or trouble between customers
• Be sure to perform appropriate adjustment of the display (LCD, Plasma, or
Projector). For operation of this machine, do not leave monitor's flickering
or deviation as is. Failure to observe this can have a bad inuence upon the
players' or customers' physical conditions
• It is suggested to ensure a space allowing the players who feel sick while
playing the game to take a rest
• Check if all of the adjusters are in contact with the surface. If they are not, the
Cabinet can move and cause an accident
• Do not put any heavy item on this product. Placing any heavy item on the
product can cause a falling down accident or parts damage
• Do not climb on the product. Climbing on the product can cause falling down
accidents. To check the top portion of the product, use a step/stepladder
• To avoid electric shock, check to see if door and cover parts are damaged
or omitted
• Do not place the following items on top of or near the product or hang them
from the ceiling. Doing so could result in electric shock, short circuits and/or
damage to the parts:
• Flower vases, flowerpots, cups, water tanks, cosmetics, and receptacles/
containers/vessels containing chemicals and water
3-1 BEFORE OPERATION

PRECAUTIONS REGARDING PRODUCT OPERATION
9
33
• To avoid injury, be sure to provide sufficient space by considering the
potentially crowded situation at the installation location. Insufcient installation
space can cause contact, collisions, and/or trouble between customers
• During daily cleaning, be sure to check the surface of the control units and
other parts that the player touches with his/her hands for damage, cracks, or
loose screws. If a player uses the machine while it is damaged, cracked, or
has a loose screw, the player may become injured
• Check carefully to make sure there are no gaps in the Cabinet joints and that
they are not loose. If there are gaps or looseness, players may get their hands
or ngers caught, resulting in an injury
• Make sure all the doors are locked securely and they do not rattle. If the doors
are not locked properly or there are gaps or rattling, players could get their
ngers or hands caught
• Be sure to perform appropriate adjustment of the LCD. For operation of this
machine, do not leave monitor’s ickering or deviation as is. Failure to observe
this can have a bad influence upon the players’ or customers’ physical
conditions
• Inspect for the following items during a trial run. If there is any type of error, use
the Test Mode, etc. to resolve the problem. If you continue use with an error, it
can cause an accident or irreparable parts damage:
- Is there any irregularity in the operability of the control units?
- Is there any improper adjustment of the LCD screen?
• Prepare a place where players can rest if they feel unwell

10
PRECAUTIONS REGARDING PRODUCT OPERATION
33
To avoid injury and trouble, be sure to constantly give careful attention to the behaviour and manner of the visitors
and players.
• For safety reasons, do not allow any of the following people to play the game:
- Those who have high blood pressure or a heart problem
- Those who have experienced muscle convulsion or loss of consciousness
when playing video games, etc.
- Those who have neck or spinal cord problems
- Those who are intoxicated or under the inuence of drugs
- Pregnant women
- Those who are not in good health
- Those who do not follow the attendant’s instructions
- Those who cannot grasp the Control Units securely because of immobility in
ngers, hands or arms
- Persons who disregard the product's warning displays
• Even players who have never been adversely affected by light stimulus might
experience dizziness or headache depending on their physical condition
when playing the game
Small children are especially likely to experience these symptoms. Caution
guardians of small children to keep watch over them during play
• Instruct those who feel sick during play to have a medical examination
• To avoid injury from falls and electric shocks due to spilled drinks, instruct the
player not to place heavy items or drinks on the product
• To avoid electric shocks and short circuits, do not allow customers to put
hands, ngers or extraneous matter in the openings of the product or small
openings in and around the doors
• To avoid falls and resulting injury, immediately stop the customer from leaning
against or climbing on the product, etc.
• To avoid electric shock and short circuit, do not allow customers to unplug the
power plug without a justiable reason
• Instruct the guardians of small children to keep watch over their children
Children cannot sense danger. Allowing small children to get near a player
who is playing the game could result in the children being bumped, struck or
knocked down
DURING OPERATION (PAYING ATTENTION TO CUSTOMERS)
3-2 PAYING ATTENTION TO CUSTOMERS

PRECAUTIONS REGARDING PRODUCT OPERATION
11
33
• Immediately stop such violent acts as hitting and kicking the product. Such
violent acts can cause parts damage or falling down, resulting in injury due to
fragments and falling down
• Persons other than the player should not be allowed to touch the controls
during play. They may brush against or collide with the controls or the player,
possibly resulting in accidents
• Instruct those who feel sick during play to have a medical examination
• Immediately stop users from leaning or sitting on the control panel. Such acts
can lead to injury or damage to parts or the shape of the Cabinet
• Items such as large nger rings can cause injury to the ngers while playing.
Instruct players to remove all accessories that could cause an accident before
playing
● Diligently clean the parts that players touch directly to ensure a pleasant game
playing experience
● Inspect the coin insertion slots to make sure no foreign objects have been
inserted and that they have not otherwise been tampered with as this will
prevent play
