Sega Clay Challenge User manual

BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain safety:
To ensure the safe operation of this product, be sure to read the following before usage.
The following instructions are intended for the users, operators and the personnel in charge of the
operation of the product. After carefully reading and sufficiently understanding the warning
displays and cautions, handle the product appropriately. Be sure to keep this manual close to the
product or in a convenient place for future reference.
Herein, explanations which require special attention are enclosed with dual lines. Depending on
the potentially hazardous degrees, the terms of DANGER, WARNING, CAUTION, etc. are used.
Be sure to understand the contents of the displays before reading the text.
Indicates that mishandling the
product by disregarding this
pictograph will cause severe
injury or death.
Indicates that mishandling the
product by disregarding this
warning will cause a potentially
hazardous situation which can
result in death or serious injury.
Indicates that mishandling the
product by disregarding this
caution will cause a slight
hazardous situation which can
result in personal injury and/or
material damage.
For the safe usage of the product, the following pictographs are used:
Indicates "HANDLE WITH CARE." In order to protect the human body and
equipment, this display is attached to places where the Owner's Manual, Serviceman
Manual and/or Service Manual should be referred to.
Indicates a "Protective Earth Terminal." Before operating the equipment, be sure to
connect it to the Ground.
(The step may be omitted for products in which a power cord with earth is used.)
❍Perform work in accordance with the instructions herein stated.
Instructions for work are explained by paying attention to the aspect of accident prevention.
Failing to perform work as per the instructions can cause accidents. In the case where only
those who have technical expertise should perform the work to avoid hazardous situation, the
instructions herein state that the site maintenance personnel should perform such work.
❍Be sure to turn off the power before working on the machine.
To prevent an electric shock, be sure to turn off the power before carrying out any work that
requires direct contact with the interior of the product. If the work is to be performed in the
power-on status, the Instruction Manual herein always states to that effect.
❍Be sure to ground the Earth Terminal.
(This is not required in the case where a power cord with earth is used.)
This product is equipped with the Earth Terminal. When installing the product, connect the
Earth Terminal to the "accurately grounded indoor earth terminal" by using an earth wire.
Unless the product is grounded appropriately, the user can be subject to an electric shock.
After performing repair, etc. for the control equipment, ensure that the Earth Wire is firmly
connected to the control equipment.
❍Ensure that the Power Supply used is equipped with an Earth Leakage Breaker.
This product does not incorporate the Earth Leakage Breaker. Using a power supply which is
not equipped with the Earth Leakage Breaker can cause a fire when earth leakage occurs.
❍Be sure to use fuses which meet the specified rating.
(Only for the machines which use fuses.)
Using fuses exceeding the specified rating can cause a fire and an electric shock.

❍Specification changes (removal of equipment, conversion and addition) not
designated by SEGA are not allowed.
The parts of the product include warning labels for safety, covers for personal protection, etc.
It is very hazardous to operate the product by removing parts and/or modifying the circuits.
Should doors, lids and protective parts be damaged or lost, refrain from operating the product,
and contact where the product was purchased from or the office herein stated.
SEGA shall not be held responsible for any accidents, compensation for damage to a third
party, resulting from the specifications not designated by SEGA.
❍Ensure that the product meets the requirements of appropriate Electrical
Specifications.
Before installing the product, check for Electrical Specifications. SEGA products have a
nameplate on which Electrical Specifications are described. Ensure that the product is
compatible with the power supply voltage and frequency requirements of the location. Using
any Electrical Specifications different from the designated Specifications can cause a fire and
an electric shock.
❍Install and operate the product in places where appropriate lighting is
available, allowing warning labels to be clearly read.
To ensure safety for the customers, labels and printed instructions describing potentially
hazardous situations are applied to places where accidents can be caused. Ensure that where
the product is operated has sufficient lighting allowing the warnings to be read. If any label is
peeled off, apply it again immediately. Please place an order with where the product was
purchased from or the office herein stated.
❍When handling the monitor, be very careful.
(Applies only to the product with a monitor.)
Some of the monitor (TV) parts are subject to high tension voltage. Even after turning off the
power, some portions are still subject to high tension voltage sometimes. Monitor repair and
replacement should be performed only by those technical personnel who have knowledge of
electricity and technical expertise.
❍Be sure to adjust the monitor/projector properly.
(Applies only to the product with a monitor/projector.)
Do not operate the product leaving on-screen flickering or blurring as it is. Using the product
with the monitor/projector not properly adjusted may cause dizziness or a headache to an
operator, a player, or the customers.
❍When transporting or reselling this product, be sure to attach this manual to
the product.
In the case where commercially available monitors and printers are used in this product, only
the contents relating to this product are explained herein. Some commercially available
equipment has functions and reactions not stated in this manual. Read this manual together
with the specific Instruction Manual of such equipment.
* Descriptions herein contained may be subject to improvement changes without notice.
* The contents described herein are fully prepared with due care. However, should any
question arise or errors be found, please contact SEGA.
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately
after transporting to the location. Nevertheless, an irregular situation may occur during
transportation. Before turning on the power, check the following points to ensure that the product
has been transported in a satisfactory status.
❐Are there any dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?
❐Are Casters and Adjusters damaged?
❐Do the power supply voltage and frequency requirements meet with those of the location?
❐Are all wiring connectors correctly and securely connected? Unless connected in the correct
way, connector connections can not be made accurately. Do not insert connectors forcibly.
❐Do power cords have cuts and dents?
❐Do the fuses used meet specified ratings? Is the Circuit Protector in an energized status?
❐Are all accessories available?
❐Can all Doors and Lids be opened with the Accessory Keys? Can Doors and Lids be firmly
closed?

TABLE OF CONTENTS
i
TABLE OF CONTENTS
BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
TABLE OF CONTENTS ....................................................................................... i
INTRODUCTION................................................................................................ iv
11HANDLING PRECAUTIONS ......................................................................... 1
22PRECAUTIONS REGARDING INSTALLATION LOCATION........................ 3
2-1 LIMITATIONS OF USAGE ................................................................................................4
33PRECAUTIONS REGARDING PRODUCT OPERATION ............................. 4
44PART DESCRIPTIONS.................................................................................. 6
8 5ACCESSORIES ............................................................................................. 8
66ASSSEMBLY AND INSTALLATION.............................................................. 9
6-1 INSTALLATION ..............................................................................................................11
6-2 TURNING ON THE POWER (SOFTWARE INSTALLATION) ........................................13
6-3 CHECKING ASSEMBLY (SETUP) .................................................................................14
7 PRECAUTIONS WHEN MOVING THE MACHINE...................................................16
88GAME DESCRIPTION ...........................................................................................................17
8-1 GAME OUTLINE.............................................................................................................17
8-2 GAME MODE..................................................................................................................18
8-3 BONUS SHOTS..............................................................................................................19
8-4 NUMBER OF PLAYERS.................................................................................................20
8-5 GAME FLOW..................................................................................................................21

ii
TABLE OF CONTENTS
99SYSTEM MENU ........................................................................................... 22
9-1 SWITCH UNIT AND COIN METER ................................................................................23
9-2 SYSTEM MENU..............................................................................................................24
9-3 TEST MODE ...................................................................................................................25
9-4 CONFIGURATION ..........................................................................................................31
9-5 BOOKKEEPING .............................................................................................................36
9-6 BACKUP CLEAR ...........................................................................................................39
10 PERIODIC INSPECTION ............................................................................. 42
11 TROUBLESHOOTING................................................................................. 43
11-1 TROUBLESHOOTING (WHEN NO ERROR MESSAGE IS SHOWN).........................43
11-2 ERROR MESSAGES ....................................................................................................44
12 GAME BOARD ............................................................................................ 45
13 CABINET PARTS DESCRIPTION ............................................................... 51
14 PARTS LIST, CONTROLLER ...................................................................... 52
15 WIRE COLOR CODE TABLE...................................................................... 53
16 WIRING DIAGRAM ...................................................................................... 54
17 LINCENSE MARK........................................................................................ 57

INTRODUCTION
iii
INTRODUCTION
This manual is intended to provide detailed descriptions together with all the necessary information covering the
general operation of electronic assemblies, electro-mechanicals, servicing control, spare parts, etc. for the product,
“SEGA CLAY SHOOTING, CVT KIT”.
This manual is intended for the owners, personnel and managers in charge of operation of the product.
Operate the product after carefully reading and sufciently understanding the instructions.
In the unlikely event that the product does not function correctly, DO NOT allow anyone other than a technician
to touch the internal system. Turn off the power to the machine, making sure to unplug the electrical cord from the
outlet, and contact the ofce listed below or the point of purchase for this product.
Use of this product is unlikely to cause physical injuries or damage to property. However, points that require special
attention are indicated by bold text, the word “IMPORTANT” and the symbol below.
Sega Amusements U.S.A., Inc.
800 Arthur Avenue, Elk Grove Village, IL 60007-5215, U.S.A.
TEL: [phone]
TOLL FREE: 1-888-877-2669
FAX: [phone]
Indicates important information that, if ignored, may result in the mishandling of
the product and cause faulty operation or damage to the product.

iv
INTRODUCTION
Denition of 'Site Maintenance Personnel or Other Qualied Individuals'
Procedures not described in this manual or marked as 'to be carried out by site
maintenance personnel or other qualied professionals' should not be carried
out by personnel without the necessary skill or technology. Work carried out by
unqualied persons may cause serious accidents, including electrocution.
Parts replacement, maintenance inspections and troubleshooting should be carried out by site maintenance personnel
or other qualied professionals. This manual includes directions for potentially dangerous procedures which should
only be carried out by professionals with the appropriate specialized knowledge.
The site maintenance personnel or other qualied professionals mentioned in this manual are dened as follows:
Site maintenance personnel:
Individuals with experience in maintaining amusement equipment, vending machines, etc., working under the
supervision of the owner/operator of this product to maintain machines within amusement facilities or similar
premises by carrying out everyday procedures such as assembly, maintenance inspections, and replacement of units/
expendable parts.
Activities to be carried out by site maintenance personnel:
Amusement equipment/vending machine assembly, maintenance inspection and replacement of units/expendable
parts.
Other qualied professionals:
Persons employed by amusement equipment manufacturers, or involved in design, production, testing or
maintenance of amusement equipment. The individual should have either graduated from technical school or hold
similar qualications in electrical/electronics/mechanical engineering.
Activities to be carried out by other qualied professionals:
Amusement equipment/vending machine assembly, repair/adjustment of electrical/electronic/mechanical parts.

HANDLING PRECAUTIONS
1
1
HANDLING PRECAUTIONS
1
• Beforeperformingwork,besuretoturnthepoweroff.Performingthework
withoutturningthepoweroffcancauseanelectricshockorshortcircuit.Inthe
caseworkshouldbeperformedinthestatusofpoweron,thismanualalways
statestothateffect.
• Toavoidanelectricshockorshortcircuit,donotpluginorunplugquickly.
• Toavoidanelectricshock,donotpluginorunplugwithawethand.
• Donotexposepowercordsorearthwiresonthesurface,(oor,passage,etc.).If
exposed,thepowercordsandearthwiresaresusceptibletodamage.Damaged
cordsandwirescancauseanelectricshockorshortcircuit.
• Toavoidcausingareoranelectricshock,donotputthingsonordamagethe
powercords.
• Whenorafterinstallingtheproduct,donotunnecessarilypullthepowercord.If
damaged,thepowercordcancauseareoranelectricshock.
• Incasethepowercordisdamaged,askforareplacementthroughwherethe
productwaspurchasedfromortheofcehereinstated.Usingthecordasis
damagedcancausere,anelectricshockorleakage.
• Besuretoperformgroundingappropriately.Inappropriategroundingcancause
anelectricshock.
• Besuretousefusesmeetingthespeciedrating.Usingfusesotherthanthe
speciedratingcancauseareoranelectricshock.
• BesurethatconnectionssuchasICBDaremadeproperly.Insufcientinsertion
cancauseanelectricshock.
• Specicationchanges,removalofequipment,conversionand/oraddition,not
designatedbySEGAarenotpermitted.
-Failuretoobservethismaycauseareoranelectricshock.Non-compliance
withthisinstructioncanhaveabadinuenceuponphysicalconditionsofthe
playersortheonlookers,orresultininjuryduringplay.
-SEGAshallnotbeheldresponsiblefordamage,compensationfordamagetoa
thirdparty,causedbyspecicationchangesnotdesignatedbySEGA.
• Donotperformanyworkorchangepartsnotlistedinthismanual.Doingsomay
leadtoanaccident.
 Ifyouneedtoperformanyworknotlistedinthismanual,requestworkfromthe
ofceindicatedinthismanualorthepointofpurchase,orinquiresfordetails.
• Besuretoperformperiodicmaintenanceinspectionshereinstated.
When installing or inspecting the machine, be very careful of the following points and pay attention to ensure that
the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the cautionary matters
herein stated can cause personal injury or damage to the machine.

1
HANDLING PRECAUTIONS
2
• FortheICboardcircuitinspections,onlythelogictesterisallowed.Theuseofa
multiple-purposetesterisnotpermitted,sobecarefulinthisregard.
• WhencleaningtheCRTsurfaces,useasoftanddrycloth.Donotapply
chemicalssuchasthinner,benzene,etc.
• StaticelectricityfromyourbodymaydamagesomeelectronicsdevicesontheIC
board.BeforehandlingtheICboard,touchagroundedmetallicsurfacesothat
thestaticelectricitycanbedischarged.
• Somepartsarenotdesignedandmanufacturedspecicallyforthisgame
machine.Themanufacturersmaydiscontinue,orchangethespecicationsof
suchgeneral-purposeparts.Ifthisisthecase,SEGAcannotrepairorreplacea
failedgamemachinewhetherornotawarrantyperiodhasexpired.

PRECAUTIONS REGARDING INSTALLATION LOCATION
2
3
PRECAUTIONS REGARDING INSTALLATION LOCATION
2
2-1 LIMITATIONS OF USAGE
Thisproductisanindoorgamemachine.Donotinstallitoutside.Evenindoors,
avoidinstallinginplacesmentionedbelowsoasnottocauseare,electricshock,
injuryand/ormalfunction.
- Placessubjecttorainorwaterleakage,orplacessubjecttohighhumidityinthe
proximityofanindoorswimmingpooland/orshower,etc.
- Placessubjecttodirectsunlight,orplacessubjecttohightemperaturesinthe
proximityofheatingunits,etc.
- Placeslledwithinammablegasorvicinityofhighlyinammable/volatile
chemicalsorhazardousmatter.
- Dustyplaces.
- Slopedsurfaces.
- Placessubjecttoanytypeofviolentimpact.
- Vicinityofanti-disasterfacilitiessuchasreexitsandreextinguishers.
- Areaswherethetemperatureexceedstheapplicabletemperature(ambient
temperature)rangeof5to30degreescentigrade.
• BesuretochecktheElectricalSpecications.Ensurethatthisproduct
iscompatiblewiththelocation'spowersupply,voltage,andfrequency
requirements.AplatedescribingElectricalSpecicationsisattachedtothe
product.Non-compliancewiththeElectricalSpecicationscancauseareand
electricshock.
• Thisproductrequiresabreakerandearthmechanismaspartofthelocation
facilities.Usingtheproductwithoutthesecancauseareandelectricshock.
• Ensurethattheindoorwiringforthepowersupplyisratedat15Aorhigher
(ACsinglephase100V~120Varea).Non-compliancewiththeElectrical
Specicationscancauseareandelectricshock.
• Besuretouseanindependentpowersupplyequippedwithanearthleakage
breaker.Usingapowersupplywithoutanearthleakagebreakercancausean
outbreakofreifapowersurgeoccurs.
• Puttingmanyloadsononeelectricaloutletcancausegenerationofheatanda
reresultingfromoverload.
• Whenusinganextensioncord,ensurethatthecordisratedat15Aorhigher(AC
100V~120Varea).Usingacordratedlowerthanthespeciedratingcancause
areandelectricshock.

3
PRECAUTIONS REGARDING PRODUCT OPERATION
4
To avoid injury and trouble, be sure to pay attention to the behavior of visitors and players.
BEFOREOPERATION
PRECAUTIONS REGARDING PRODUCT OPERATION
3
Inordertoavoidaccidents,checkthefollowingbeforestartingtheoperation:
• Toensuremaximumsafetyfortheplayersandthecustomers,ensurethatwhere
theproductisoperatedhassufcientlightingtoallowanywarningstoberead.
Operationunderinsufcientlightingcancausebodilycontactwitheachother,
hittingaccident,and/ortroublebetweencustomers.
• Besuretoperformappropriateadjustmentofthemonitor(projector).For
operationofthismachine,donotleavemonitor'sickeringordeviationas
is.Failuretoobservethiscanhaveabadinuenceupontheplayers'orthe
customers'physicalconditions.
• Itissuggestedtoensureaspaceallowingtheplayerswhofeelsickwhileplaying
thegametotakearest.
• Checkifalloftheadjustersareincontactwiththesurface.Iftheyarenot,the
Cabinetcanmoveandcauseanaccident.
• Duringdailycleaning,besuretocheckthesurfaceofthesteeringwheel,gear
shifter,andotherpartsthattheplayertoucheswithhishandsfordamage,
cracks,orloosescrews.Ifaplayerusesthemachinewhileitisdamaged,
cracked,orhasaloosescrew,theplayermaybecomeinjured.
• Duringdailycleaning,besuretochecktheseatforanyabnormality,wetness,
etc.Failuretodothismayresultindeliberatetamperingornegligencebeingleft
undetected.
• Toavoidinjury,besuretoprovidesufcientspacebyconsideringthepotentially
crowdedsituationattheinstallationlocation.Insufcientinstallationspacecan
causemakingbodilycontactwitheachother,hittingaccidents,and/ortrouble
betweencustomers.
• Donotputanyheavyitemonthisproduct.Placinganyheavyitemonthe
productcancauseafallingdownaccidentorpartsdamage.
• Donotclimbontheproduct.Climbingontheproductcancausefallingdown
accidents.Tocheckthetopportionoftheproduct,useastepladder.
• Toavoidelectricshock,checktoseeifdoor&coverpartsaredamagedor
omitted.
• Toavoidelectricshock,shortcircuitand/orpartsdamage,donotputthe
followingitemsonorintheperipheryoftheproduct.Flowervases,owerpots,
cups,watertanks,cosmetics,andreceptacles/containers/vesselscontaining
chemicalsandwater.

PRECAUTIONS REGARDING PRODUCT OPERATION
3
5
DURINGOPERATION(PAYINGATTENTIONTOCUSTOMERS)
• Forsafetyreasons,donotallowanyofthefollowingpeopletoplaythegame.
- Thosewhoneedassistancesuchastheuseofanapparatuswhenwalking.
- Thosewhohavehighbloodpressureoraheartproblem.
- Thosewhohaveexperiencedmuscleconvulsionorlossofconsciousnesswhen
playingvideogames,etc.
- Thosewhohaveneckorspinalcordproblems.
- Thosewhoareintoxicatedorundertheinuenceofdrugs.
- Pregnantwomen.
- Personssusceptibletomotionsickness.
- Personswhodisregardtheproduct'swarningdisplays.
• Evenplayerswhohaveneverbeenadverselyaffectedbylightstimulusmight
experiencedizzinessorheadachedependingontheirphysicalconditionwhen
playingthegame.Smallchildrenareespeciallylikelytoexperiencethese
symptoms.Cautionguardiansofsmallchildrentokeepwatchontheirchildren
duringplay.
• Instructthosewhofeelsickduringplaytohaveamedicalexamination.
• Toavoidinjuryfromfallsandelectricshocksduetospilleddrinks,instructthe
playernottoplaceheavyitemsordrinksontheproduct.
• Toavoidelectricshocksandshortcircuits,donotallowcustomerstoput
handsandngersorextraneousmatterintheopeningsoftheproductorsmall
openingsinoraroundthedoors.
• Toavoidfallsandresultinginjury,immediatelystopthecustomerfromleaning
againstorclimbingontheproduct,etc.
• Toavoidelectricshockandshortcircuit,donotallowcustomerstounplugthe
powerplugwithoutajustiablereason.
Immediatelystopsuchviolentactsashittingandkickingtheproduct.Suchviolent
actscancausepartsdamageorfallingdown,resultingininjuryduetofragments
andfallingdown.

4
PARTS DESCRIPTIONS
6
PART DESCRIPTIONS
4
ASSY ROM CTRG CLAY
Part#: 610-0752P + 551-30-211
SEGA CLAY SHOOTING, FULL KIT
KIT Part#: 551-00-003
Marquee CLAY SHOOTING
Part#: 551-30-100
Instruction AW25UR, CS
Part#: 551-30-210
Manual, Clay Shooting
Part#: 551-30-300

PARTS DESCRIPTIONS
4
7
SEGA CLAY SHOOTING, UPDATE KIT without GUNS
KIT Part#: 515-00-077
Instruction AW25UR, CS
Part#: 551-30-210
Manual, Clay Shooting
Part#: 551-30-300
ASSY ROM CTRG CS
Part#: 610-0752P +
551-30-211
Marquee CLAY SHOOTING
Part#: 551-30-100

5
ACCESSORIES
8
ACCESSORIES
5
Conrm that the accessories listed in the table below are present when setting up the product. Accessories marked
“Spare” in the note column are consumable items but included as spares.
OWNER’S MANUAL
XXX-30-300 (1)
This manual

ASSEMBLYANDINSTALLATION
6
9
ASSEMBLYANDINSTALLATION
6
• Performassemblyworkbyfollowingtheprocedurehereinstated.Failureto
complywiththeinstructionscancauseelectricshock.
• Performassemblingasperthismanual.Sincethisisacomplexmachine,
incorrectassemblingcancauseanelectricshock,machinedamageand/or
improperfunctioningasperspeciedperformance.
• Whenassembling,morethanonepersonisrequired.Dependingontheassembly
work,therearesomecasesinwhichworkingbyonepersonalonecancause
personalinjuryorpartsdamage.
• Ensurethatconnectorsareproperlyconnected.Improperconnectionscancause
electricshock.
• Thisworkshouldbecarriedoutbythesitemaintenancepersonnelorother
qualiedprofessionals.Workperformedbynon-technicalpersonnelcancause
asevereaccidentsuchaselectricshock.Failingtocomplywiththisinstruction
cancauseasevereaccidentsuchaselectricshocktotheplayerduring
operation.Ifnoonewithpropertechnologicalexpertiseisavailable,request
servicefromtheofceindicatedinthisdocumentorthepointofpurchasesoas
toensuresafety.
• Providesufcientspacesothatassemblingcanbeperformed.Performingwork
inplaceswithnarrowspaceorlowceilingmaycauseanaccidentandassembly
worktobedifcult.
• Toperformworksafelyandavoidseriousaccidentsuchasthecabinetfalling
down,donotperformworkinplaceswherestep-likegradedifferences,aditch,
orslopeexist.
• Becarefulnottodamagethewires.Damagedwiresmaycauseelectricshockor
shortcircuitorpresentariskofre.
• Donotleavepowercords,groundwires,ornetworkcablesexposedinareas
ofheavyfoottrafc.Doingsomaycausethemtobecomedamaged,possibly
resultinginelectricshockand/orshortcircuits.Whenlayingwiringacrossthe
oor,alwaysusesafetycoverstoprotectthewires.
• Thepowercordforthisproducthasagroundterminal.Makesuretousethis
groundterminalwhenpluggingitintoanindooroutlet.Failuretoproperly
groundtheproductcouldleadtoelectrocution.Itcanalsoleadtomalfunction.

6
ASSEMBLYANDINSTALLATION
10
• Whenopening/closing,attaching/removingdoorsorlids,becarefulthatyour
handorngerdoesnotgetcaughtinanything.
• Toperformtheoperationsafelyandaccuratelyyoumustuseasafe,steady
footstoolorstepladder.Workingwithoutthismayleadtoafallandpossible
injury.
• Wearappropriateworkclothingsothatworkcanbeperformedsafely.Usegloves
andsafetyshoestopreventaccidentsorinjuries.
• Wheninstallingawireprotectioncoveroveraoor,useamaterialshaped
sothatnoonepassingbywillstumbleoverit.Usingamaterialthatcouldbe
stumbledovermightleadtoanaccidentalfall.
• Handleplasticpartswithcare.Excessiveweightorpressuremaycausethemto
breakandthebrokenpiecesmaycauseinjury.

ASSEMBLYANDINSTALLATION
6
11
3 kinds as below.
FULL KIT
Atomiswave Main PCB included. This KIT will be able to install to Basic CRT monitor UR cabinets with
JAMMA connector on Main harness.
Installation:
1) Place New Overlay. Mount 28”Shotgun Assy (2), SOUND BD(1), START PUSH BUTTON (2) GUN
HOLSTER (2 sets) and harnesses to your cabinet.
2) Place NEW MARQUEE and INSTRUCTION.
3) Remove current GAME BOARDS from cabinet. Place ATOMISWAVE MAIN PCB with EX I/O
CARTRIDGE and GAME ROM CARTRIDGE.
UPDATEKITWITHGUNS
Your cabinet must have ATOMISWAVE MAIN PCB and EX I/O CARTRIDGE in the cabinet. .
Installation:
1) Place New Overlay. Mount 28"Shotgun Assy (2), SOUND BD(1), START PUSH BUTTON (2) GUN
HOLSTER (2 sets) and harnesses to your cabinet.
2) Place NEW MARQUEE and INSTRUCTION.
3) Remove current GAME CARTRIDGE from ATOMISWAVE MAIN PCB. Make sure EX I/O CARTRIDGE
on there.
UPDATEKITWITHOUTGUNS
Your cabinet must have ATOMISWAVE MAIN PCB, EX I/O CARTRIDGE and 28”Shotgun Assy (2) in your
cabinet.
Installation:
1) Place NEW MARQUEE and INSTRUCTION.
3) Remove current GAME CARTRIDGE from ATOMISWAVE MAIN PCB. Make sure EX I/O CARTRIDGE
on there.
6-1 INSTALLATION

6
ASSEMBLYANDINSTALLATION
12
Exampleofcabinetoverview
