Fastening Solutions™
FramePro®601
Clipped Head Framing/Sheathing Nailer
Clipped head nailers provide all the important features you want at an
affordable price. These compact framers are easy to handle, and easy
on the arm. Their 30˚ short, in-line magazines provide excellent
maneuverability and line of sight. These powerful framers drive a
wide range of fasteners in four gauges (.113 – .148) from 2" to 3-1⁄2" to
handle virtually any job.
Applications:
Framing, truss building, subflooring, sheathing, decking, siding,
fencing, pallets and crate assembly
.
Features and Benefits:
• Sawtooth safety that digs in for precision toenailing
• Shorter, straight-line 30˚ magazine for better line of sight
and superior maneuverability
• Drives ring and smooth shank nails in four gauges (.113 –.148)
from 2" to 3-1⁄2"
• Reliable internal design with full round driver
• Adjustable exhaust
• Lightweight and powerful
• Adjustable depth-of-drive control
• Soft comfort grip handle reduces fatigue
• One-year warranty
Tool Specifications:
FramePro 601
Power: 884 in/lbs
Tool Weight: 8 lbs (3.6 kg)
Height: 13.5" (343 mm)
Length: 14.8" (376 mm)
Nail Capacity: 65
Reg. Operating Pressure: 70-120 psig
Mode of Operation: Available with either Dual Action or Restrictive
Trigger activating mechanisms.
Fastener Specifications:
The 601 nailers drive 2" – 3- 1⁄2" smooth shank nails (Sencote®
or plain) and 2"–3" ring shank nails. Shank diameters include
.113, .120, and .131.
Best Value in the Industry!
Always read the Operators Manual and Safety Instructions with all tools to ensure
proper use and safety precautions or contact SENCO for more information on our
trigger systems. Choose the right trigger system for your specific needs!
For additional information on how SENCO Fastening Solutions will save you time,
reduce costs, and increase quality, call our toll-free Action Line: 1-800-543-4596 to
find your nearest Authorized Senco Dealer or Distributor.
Visit our web site at: www.senco.com
Sequential Actuation Trigger (also known as restrictive trigger or trigger fire) operates
in the following a sequence - depress the safety element at the nose of tool against the
work surface then pull the trigger. After each fastener is driven, release the trigger and
lift the tool off the work surface before starting the sequence again. This trigger is
recommended and acceptable for most applications.
Contact Actuation Trigger (also known as dual action, bounce or bottom fire)
operates in the following sequence- pull the trigger first and keep the trigger pulled
while moving the tool along the work surface with a bouncing motion, depressing the
safety element at the nose of the tool against the work surface where the fastener is to
be driven. This trigger is recommended for use by trained professionals only in high
production or volume applications.
The only way to work.®
Safety First.
©2005 SENCO Products, Inc. www.senco.com
•

Fastening Solutions™
The only way to work.®
Safety First.
©2005 SENCO Products, Inc. Litho in U.S.A. www.senco.com
Adjustable Exhaust
Ergonomic
Design
Superb
balance for use
all day
Reliable
Proven design for
long trouble-free
operation
Adjustable
Depth-of-Drive
Drives nails
to a consistent and
controllable depth
Toenail Safety
Teeth grip studs for precise positioning
Dry Fire Lockout
Prevents dry firing,
missed operations and
signals when to reload
In-line Magazine
Better line of sight for
right and left handers
improves balance and
reduces fatigue
Power to Perform
Consistently drives a full
range of nails
Full Comfort Grip
Resilient grip reduces
fatigue
Rear Two-Step
Loading
Quick and easy for
right or left handers
For additional information on how SENCO Power Fastening Systems will save you time, reduce costs, and increase quality,
call our toll-free Action Line: 1-800-543-4596 to find your nearest Authorized Senco Dealer or Distributor.
Visit our web site at: www.senco.com
No-Mar Pad
Protects work surface
FramePro®601
Clipped Head Framing/Sheathing Nailer
