Seneca R-PASS User manual

MI00555-2-EN INSTALLATION MANUAL 1/4
INSTALLATION MANUAL
SENECA s.r.l.; Via Austria, 26 – 35127 – PADOVA – ITALY; Tel. [phone] - Fax [phone]
DOCUMENTATION
PRELIMINARY WARNINGS
The word WARNING preceded by the symbol indicates conditions or actions that put the user’s safety at
risk. The word ATTENTION preceded by the symbol indicates conditions or actions that might damage the
instrument or the connected equipment. The warranty shall become null and void in the event of improper use or
tampering with the module or devices supplied by the manufacturer as necessary for its correct operation, and if
the instructions contained in this manual are not followed.
WARNING: The full content of this manual must be read before any operation.
The module must only be used by qualied electricians.
Specic documentation is available using the QR-CODE shown on page 1.
Electrical and electronic waste disposal (applicable in the European Union and other countries with recycling).
The symbol on the product or its packaging shows the product must be surrendered to a collection centre
authorized to recycle electrical and electronic waste.
The module must be repaired and damaged parts replaced by the Manufacturer.
The product is sensitive to electrostatic discharges. Take appropriate measures during any operation.
CONTACT INFORMATION
Technical support [email protected] Product information [email protected]
This document is the property of SENECA srl. Copies and reproduction are prohibited unless authorised.
The content of this document corresponds to the described products and technologies.
Stated data may be modied or supplemented for technical and/or sales purposes.
R-PASS

MI00555-2-EN INSTALLATION MANUAL 2/4
MODULE LAYOUT
Weight: 170 g; Enclosure: UL94-V0 self-extinguishing PC/ABS material, black.
SIGNALS VIA LED ON FRONT PANEL
LED STATUS LED meaning
DO1....DO4 On Output enabled
Off Output disabled
DI1...DI4 On Input activated
Off Input deactivated
DO AUX On Auxiliary supply active
Off Fault or wiring error
STS
(Status)
Flashing The module is working correctly
Off Locking system
On Locking system
VPN On VPN connection active
Flashing VPN connection problems
SRV On VPN BOX “SERVICE” connection is working correctly
Flashing VPN BOX “SERVICE” connection in error
UPS On UPS active (only in the presence of the R-COMM accessory)
Off UPS inactive
LOG / RUN
(only R-PASS-0 / -W)
On Data Logger active and working correctly
Flashing Data Logger in error
Off Data logger not active
LOG / RUN
(only R-PASS-S / -E)
On PLC up and running
Flashing PLC in STOP
Off PLC not active
WIFI
(only R-PASS-W)
On WiFi enabled in Station mode
Flashing WiFi enabled in access-point mode
(only R-PASS-W) On WiFi signal strength in Station mode
PWR On Device powered correctly
RX1 / RX2 On Incorrect RS485 / RS232 connection
Flashing Reception of data packet completed on RS485 / RS232
TX1 / TX2 Flashing Transmission of data packet completed on RS485 / RS232
ETH ACT (Yellow) Flashing Packet transit on Ethernet port
ETH LNK (Green) Flashing Ethernet port connected
32.2 mm
mm
0.09
106.6 mm

MI00555-2-EN INSTALLATION MANUAL 3/4
Through the lateral connection, it is possible to add optional modules.
For more information on accessories and optional modules, visit the website on page 1 or scan the QR-CODE.
CERTIFICATIONS
https://www.seneca.it/products/r-pass/doc/CE_declaration
ENVIRONMENTAL
CONDITIONS
Operating temperature: from -25°C to +65 °C
Humidity: 10% ÷ 90% non condensing.
Storage temperature: from -30°C to +80°C
Protection rating: IP20
ASSEMBLY 35mm DIN rail IEC EN60715
CONNECTIONS Removable 3.5mm pitch terminal block, 1.5mm2 max cable section
COMMUNICATION
PORTS
1 USB A connector
4 RJ45 Ethernet ports (only version with 4 Ethernet ports)
2 RJ45 Ethernet ports (only version with 2 Ethernet ports)
1 RS485/RS232 serial port congurable via software
1 RS485 serial port
1 micro USB dedicated to debugging
POWER SUPPLY 10 ÷ 40Vdc; 19 ÷ 28Vac; 8W max
INSULATION
DIGITAL OUTPUTS OptoMOS® 30Vdc, 25mA max
Number of channels: 4
DIGITAL
INPUTS
Number of channels: 4, Absorbed current: 2.2mA
Input voltage: 0÷30V, Threshold ON > 9V, Threshold OFF < 8V
IEC6113-2 Type 1 & 3 compliant
ANALOGUE
INPUTS
Voltage 0 ÷ 30Vdc, impedance 20kΩ
Current 0 ÷ 25mA, impedance ~ 50Ω
AUXILIARY
VOLTAGE OUTPUT 12Vdc; Max. 50mA
WI-FI
(only R-PASS-W) Integrated WiFi 802.11 b/g/n, 2.4 ÷ 2.4835GHz band, max Output Power: 17dBm (50mW)
ELECTRICAL CONNECTIONS
POWER SUPPLY ANALOG INPUT
VOLTAGE
ANALOG INPUT
CURRENT
mA
mA
55 - AI2
53 - GND
54 - AI1
23 -
25 -
24 -
+
+
55 - AI2
53 - GND
54 - AI1
The upper power supply limits must not be exceeded, as this could cause serious damage to the module.
Switch the module off before connecting inputs and outputs.
To meet the electromagnetic immunity requirements:
- use shielded signal cables;
- connect the shield to a preferential instrumentation earth system;
- separate shielded cables from other cables used for power installations (transformers, inverters, motors, etc...).
CAUTION
TECHNICAL SPECIFICATIONS

MI00555-2-EN INSTALLATION MANUAL 4/4
DIP-SWITCH
The DIP-SWITCHES on the back of the device have the following functions:
To access the DIP-SWITCH it is necessary to remove the bottom of the instrument.
RS232 / RS485 (COM1)
62 - B (RS485)
61 - A (RS485)
60 - Rx (RS232)
59 - Tx (RS232)
58 - CC (COMUNE)
AUXILIARY
POWER SUPPLY
50 - GND
52 - +12V
51 - +12V
RS485 (COM2)
63 - CC (COMUNE)
65 - B
64 - A
CAN OPEN
53 - GND
57 - H
56 - L
(COMMON) (COMMON)
ETHERNET CONNECTION RULES
For the Ethernet cabling between the devices, the use of the unshielded CAT5 or CAT5e cable is required.
FACTORY IP ADDRESS
The default module IP address is static: 192. 168. 90. 101 (LAN)
WEB SERVER
To access the conguration web server with the factory IP address above, use the following credentials:
Username: admin; Password: admin; Port: 8080
Example: To access the web server from LAN port: http://192. 168. 90. 101:8080
CAUTION
DO NOT USE DEVICES WITH THE SAME IP ADDRESS IN THE SAME ETHERNET NETWORK.
SW1
DIP1 RESERVED DIP3 ON DEFAULT
SETTINGS
DIP2 RESERVED DIP4 ON
DIGITAL OUTPUT
PNP
DIGITAL INPUT DIGITAL OUTPUT
NPN
40 - CI
41 - DI1
42 - DI2
43 - DI3
44 - DI4
12÷24Vdc
49 - DO4
48 - DO3
47 - DO2
46 - DO1
45 - CO
12÷24Vdc
LOAD
LOAD
LOAD
LOAD 49 - DO4
48 - DO3
47 - DO2
46 - DO1
45 - CO
12÷24Vdc
LOAD
LOAD
LOAD
LOAD
