Sharp UA-HG40E-T User manual

UA-HG60E, UA-HG50E, UA-HG40E
Operation Manual
Air Purifier
EN ESDE PT FR PL NL
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Sharp UA-HG40E-T o
cerca il tuo prodotto tra le migliori offerte di Trattamento Aria

"Plasmacluster" and "Device of a cluster of
grapes" are trademarks of Sharp Corporation.
UA-HG60E
UA-HG50E
UA-HG40E
* The number in this technology mark indicates an
approximate number of ions supplied into air of 1 cm3,
which is measured around the center of a room with the
“high-density plasmacluster 7000” applicable floor area
(at 1.2 m height above the floor) when the product is
placed close to a wall at the MED mode setting.
AIR PURIFIER
with Humidifying Function
OPERATION MANUAL
Free standing Type
ENGLISH

E-1
FEATURES
A unique Combination of Air Treatment
Technologies
Triple Filtration System + Plasmacluster +
Humidifi cation
TRAPS DUST
Pre-filter traps dust larger than approx 240 micron
particles.
DECREASES ODOURS
Deodorizing fi lter absorbs harmful gases*1
and many common household odours.
REDUCES TINY DUST, POLLEN & MOLD*2
HEPA fi lter traps 99.97% of particles as small as
0.3 microns.
FRESHENS
By emitting a balance of positive and negative ions,
Plasmacluster air treatment is a natural process.
HUMIDIFIES
Controls humidity by sensing temperature and
humidity automatically.
*1: VOC, NOx, SOx. The deodorizing performance
for a single component odours substance in a
1m3 test container may be different than the
deodorizing performance in actual use.
*2: When air is circulated through the fi lter system.
Sensor Technology continuously monitors air quality
and room condition, and automatically adjusts
operation.
• When in Intelligent mode you can manually switch
humidifying ON or OFF (Ref. E-8)
• Front Display and Air Outlet LED automatically switch ON
and OFF based on room brightness. (When light control
is set to "Auto". Ref. E-11)
• When the Motion Sensor senses that no one has been in
the room for a set interval of time it determines that the
room is unoccupied.
• You can change brightness of Display / Monitor, sensor
sensitivity, and Motion Sensor sensing time.
(Ref. E-11, E-12)
• Motion sensor may sense movement other than persons
or pets. (waving curtain etc.)
6 sensors sensing 7
factors precisely con-
trol automatic opera-
tion.
INTELLIGENT MODE When a person or pet is in the sensory area*4
(*4: Ref.E-5)
• When there is little movement of a person or pet
(example: when sleeping), automatically switches
to quiet air fl ow.
• When the room is dark, the Front Display, Cleanli-
ness Monitor and Air Outlet LED turn off automati-
cally.
When there is no movement in the sensory area
• The Front Display, Cleanliness Monitor and Air
Outlet LED turn off, humidifying stops, and the unit
switches to minimum airfl ow to save power con-
sumption.
• When room humidity is over 80% and the room is
bright, Plasmacluster Ions are emitted with strong
airfl ow.
Air Outlet LED
Front Display, Cleanli-
ness Monitor
NOTE
(UA-HG60E / UA-HG50E)
SENSOR DETECTION
Dust (sensitive)
PM2.5 (particulate matter
less than 2.5 microns), etc.
Tobacco smoke, house
dust (dirt, mite feces and
remains, mold spores,
pollen)
Odour Tobacco, cosmetic, alcohol,
spray, and other odours
Temperature Room temperature
Humidity Room humidity
Light Room brightness
Motion*3Movement of persons
or pets
*3: Senses only when Intelligent mode is in operation.
7detection by 6 sensors

E-2
ENGLISH
The air purifi er draws in room air through the
air intake, circulates it through a Pre-Filter, a
Deodorizing Filter and a HEPA Filter inside
the unit, and then discharges it through the air
outlet. The HEPA Filter can remove 99.97%
of dust particles as small as 0.3 microns that
pass through the fi lter and also helps absorb
odours. The Deodorizing Filter gradually ab-
sorbs odours as they pass through the fi lter.
Some odours absorbed by the fi lters will break
down over time, causing additional odours. De-
pending on usage conditions, and especially
if the unit is used in environments signifi cantly
more severe than a normal household, these
odours may become noticeable sooner than
expected. If these odours persist, replace the
fi lters. (Ref. E-15)
When minerals in tap water adhere to the fi l-
ters and become a hard and white, they
absorb
odours in the room that can cause the
emission
of an unpleasant odour when the humidifying
fi lter is dry. (Varies depending on water quali-
ty and other environmental factors)
If this occurs, perform humidifying fi lter mainte-
nance. (Ref. E-14)
• The air purifi er is designed to remove air-suspended dust
and the odours.
The air purifi er is not designed to remove harmful gases
such as carbon monoxide contained in cigarette smoke.
The air purifi er may not completely remove an odour if the
source of the odour is still present.
Please read before operating
your new Air Purifi er
Pre-Filter
Deodorizing Filter
HEPA Filter
ENGLISH
Thank you for purchasing this SHARP Air Purifi er.
Please read this manual carefully before using
the air purifi er.
After reading, keep the manual in a convenient
location for future reference.
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
...E-3
• WARNING
• NOTE
• CAUTIONS CONCERNING OPERATION
• INSTALLATION GUIDELINES
• FILTER GUIDELINES
PART NAMES .............................................E-5
• FRONT
• BACK
• OPERATION PANEL
• FRONT DISPLAY
PREPARATION ..........................................E-7
• FILTER INSTALLATION
OPERATION ...............................................E-7
• START / STOP
• CLEAN ION SHOWER MODE
• INTELLIGENT MODE (UA-HG60E / UA-HG50E)
• AUTO MODE (UA-HG40E)
• PLASMACLUSTER ION SPOT MODE
• SELECTING MODE
• CHILD LOCK
• HUMIDIFICATION SETTING
(REFILLING THE WATER TANK)
• ON TIMER
• OFF TIMER
• SELECTING DISPLAY
• PLASMACLUSTER ION ON / OFF
• PATROLLING FUNCTION
• HOW TO CHANGE VARIOUS SETTINGS
CARE AND MAINTENANCE .................E-13
• FILTER INDICATOR
• CARE INDEX
• WATER TANK
• UNIT / BACK PANEL
• HUMIDIFYING FILTER AND TRAY
• HEPA FILTER / DEODORIZING FILTER
• FILTER REPLACEMENT
TROUBLESHOOTING ............................E-16
SPECIFICATIONS ....................................E-17
NOTE

E-3
IMPORTANT SAFETY INSTRUCTIONS
Always follow basic safety precautions
when using electrical appliances,
including the following:
WARNING – Always observe the following
to reduce the risk of electrical shock, fi re, or
injury:
• Read all instructions before using the unit.
• Use only a 220-240 volt outlet.
• This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
• If the power cord is damaged, it must
be replaced by the manufacturer, its
service agent, a Sharp authorized
Service Centre or similarly qualifi ed
persons in order to avoid a hazard.
• Be sure to remove the power plug
when refi lling the Water Tank, before
performing maintenance, when
removing and attaching and replacing
the fi lter and when not using for a long
time. Failure to do so can cause a short
circuit resulting in electrical shock or
fi re.
• Do not use the unit if the power cord or
plug is damaged or if the connection to the
wall outlet is loose.
• Periodically remove dust from the plug.
• Do not insert fi ngers or foreign objects into
the air intake or air outlet.
• When removing the power plug, always
hold the plug and never pull on the cord.
Failure to do so can cause a short circuit
resulting in electrical shock or fi re.
• When removing the unit, do not damage
the power cord with the casters.
Failure to do so can cause electric shock,
heat generation, or fi re.
• Be careful not to damage the power cord, it
may cause electric shock, excess heat or
fi res.
• Do not remove the plug when your hands
are wet.
• Do not place the unit near gas appliances
or fi replaces.
• Only a Sharp Authorized Service Centre
should service this air purifi er. Contact the
nearest Service Centre for any problems,
adjustments, or repairs.
• Do not operate the unit in rooms where
aerosol insecticides are present. Do not
operate the unit in rooms where there
is oily residue, incense, sparks from lit
cigarettes, or chemical fumes in the air. Do
not operate the unit in places where it may
get wet, such as a bathroom.
• Be cautious when cleaning the unit. Strong
corrosive cleansers can damage the
exterior.
• When carrying the unit, fi rst remove the
Water Tank and Humidifying Tray, and then
hold the unit by the handles on both sides.
• Do not drink the water in the Humidifying
Tray or Water Tank.
• Do not expose the unit to water. Doing
so can cause a short circuit or electrical
shock.
• Replace the water in the Water Tank daily
with fresh tap water, and regularly clean
the Water Tank and Humidifying Tray (see
E-8, E-13, E-14). When the unit is not in
use, dispose of the water in the Water Tank
and Humidifying Tray. Leaving water in the
Water Tank or Humidifying Tray can cause
mold, bacteria, and bad odours.
In rare cases, such bacteria can be a
health hazard.
NOTE – What to do if the unit interferes with
radio or TV reception
If the air purifi er interferes with radio or
television reception, try one or more of the
following measures:
• Adjust or reposition the receiving antenna.
• Increase the distance between the unit and
the radio or TV.
• Connect the equipment into an outlet on a
circuit different from that of the radio or TV
receiver.
• Consult the dealer or a qualifi ed radio or
TV technician.
CAUTIONS CONCERNING
OPERATION
• Do not block the air intake or air outlet.
• Do not place the unit near or on hot
objects, such as stoves or heaters, or
where it may come into contact with steam.

E-4
ENGLISH
• Always operate the unit in an upright
position.
• When moving the unit, use the handles on
both sides.
Do not move the unit when it is in
operation.
• If the unit is on easily damaged fl ooring, an
uneven surface, or thick-piled carpet, lift it
up when moving.
• When moving the unit by its casters, move
it slowly and in a horizontal direction.
• Turn the unit off and remove the water tank
before moving, take care not to catch your
fi ngers.
• Do not operate the unit without the fi lters,
the Water Tank, and the Humidifying Tray
properly installed.
• Do not wash and reuse the HEPA fi lter and
the Deodorizing fi lter.
Doing so will not improve fi lter performance
and can also cause electric shock or
operating malfunctions.
• Clean the exterior with a soft cloth only.
Do not use volatile fl uids or detergents.
The unit surface may be damaged or
cracked with Benzene paint thinner or
polishing powder. In addition, the sensors
may malfunction as a result.
• The frequency of descaling maintenance
will depend on the hardness of and the
impurities in the water that you use; the
harder the water the more often descaling
will be necessary.
• Keep the unit away from water.
• When refi lling the Water Tank, make sure
of no water leaking from the Water Tank.
• Be sure to wipe off any excess water on
the outside of the Water Tank.
• Do not use hot water (40 ºC or more),
chemical agents, aromatic substances,
dirty water, or other damaging substances.
Doing so can deform the unit or cause it to
malfunction.
• Use only fresh tap water. Using other water
sources risks the growth of molds, fungi, or
bacteria.
• Do not shake the Water Tank with holding
the carrying handle.
• Do not remove the Humidifying Filter from
the fi lter frame except when replacing it.
• Avoid spilling water when removing or
cleaning the Humidifying Tray.
• Do not remove the Float.
If it comes off, refer to E-15.
• Do not use the detergents for maintenance
of the Humidifying Tray and Cover.
If cause deformation, tarnishing, cracking
(water leakage).
• Do not scrub the Back Panel hard during
its maintenance.
INSTALLATION GUIDELINES
• Avoid locations where the sensors are
exposed to direct wind.
Doing so can cause the unit to malfunction.
• Avoid locations where furniture, fabrics,
or other objects can come in contact with
the unit and interfere with the intake and
outtake of air.
• Avoid locations where the unit is exposed
to condensation or drastic changes in
temperature. Appropriate room temperature
is between 0 – 35 ºC.
• Place the unit on a level and stable surface
with suffi cient air circulation.
When placed on heavy carpet, the unit
may vibrate slightly.
Place the unit on a level surface to avoid
water leakage from the Water Tank and
Humidifying Tray.
• Avoid locations that generate grease or oily
smoke.
Doing so can cause the unit exterior to
crack and the sensors to malfunction.
• The dust collecting ability of the unit is
effective even when the unit is as close to
3 cm from the wall,the surrounding walls
and fl oor may get dirty. Please place the
unit at a distance from the wall.
The wall directly behind the air outlet may
become dirty over time. When using the
unit for an extended period of time at the
same location, periodically clean the walls
adjacent to it.
FILTER GUIDELINES
• Follow the instructions in this manual for
proper fi lter care and maintenance.
(Ref. E-13, E-14, E-15)

E-5
PART NAMES
FRONT
BACK
1Handle (2 Locations)
2Sensor (Internal)
Temperature / Humidity / Odour*
(*UA-HG60E / UA-HG50E)
3Air Outlet (Front)
4Caster Stopper (Right & Left)
5Operation Panel
6Front Louver (Adjustable)
7Front Display
8Unit
9Caster (4 Locations)
1Water Tank 7Back Louver
2Tank Cap 8Air Outlet (Back)
3Humidifying Filter 9Air Outlet LED(White)
4Float 10 HEPA Filter
5Humidifying Tray 11 Deodorizing Filter
6Dust(sensitive) Sensor /
Sensor Filter
12 Back Panel (Pre-Filter)
13 Air Inlet
14 Power Cord / Plug
To Lock a caster stopper (Right & Left)
Locked Unlocked Front
20°
20°
1
3
5
2
4
10
11
12
13
78
9
6
7
8
9
5
1
2
3
4
6
14
Detection range
Light Sensor
Motion Sensor
(UA-HG60E / UA-HG50E)
Do not install the unit in the
following places.
The Light Sensor may not sense
correctly.
Sensory range is the area shown
below.
1.6m
2m
30°
30°
2.3m
2m 30° 30°
Front
Right and Left
Directly under
a light fi xture.
In shadow
(Plug shape varies by country.)

E-6
ENGLISH
1
Humidity / Temperature Monitor
Indicates the approximate humidity level or tem-
perature in the room. The humidity setting cannot be
adjusted.
Wattage Monitor
Indicates wattage by current operation.
Timer Monitor
Indicates setting time or remaining time of ON/OFF
timer.
4Patrolling Light (Green / Orange / Red)
(Ref.E-9, E-10)
5Odour Light (White)
(UA-HG60E / UA-HG50E)
Indicates the Odour Sensor detects odours.
6Dust Light (White)
Indicates the Dust(sensitive) Sensor detects usual
dust.
7
PM2.5 Light (White)
Indicates the Dust(sensitive) Sensor detects micro-
scopic dust. (particulate matter less than 2.5 mi-
crons)
8Motion Sensor (UA-HG60E / UA-HG50E)
2Plasmacluster Ion Light (Blue)
9
Cleanliness Monitor
Indicates the air purity of the room in 7 levels with
colour changes.
Blue Red
Clean Impure
3
Humidify Light
Green Humidity ON
Off Humidity OFF
Red(Flashing) Unit needs water
1POWER ON / OFF Button 7
ON / OFF TIMER Button, Indicator Light (White)
<Press 3 sec.> FILTER RESET Button
2
INTELLIGENT MODE Button, Indicator Light (White)
3
CLEAN ION SHOWER Button, Indicator Light (White)
8DISPLAY SELECT Button
<Press 3 sec.> CHILD-LOCK Button
4Plasmacluster Ion SPOT Button,
Indicator Light (White) 9CHILD-LOCK Indicator Light (White)
5
HUMIDIFY ON / OFF Button, Indicator Light (White)
10 FILTER RESET Indicator Light (Orange)
6MODE Button, Indicator Light (White) 11 Light Sensor
OPERATION PANEL
FRONT DISPLAY
765 32 1
1234567
8
10911
Press the button with " " to start.
9Front Louver
8
Humidity 20% to 90% is displayed.
Temperature 0oC to 5 0oC is displayed.
20%
or less 90% or
more
50oC or
more
-1oC
or less
4
UA-HG40E

E-7
PREPARATION
1
2
3
4
Remove the Back Panel.
Remove the plastic bag from the each
fi lter.
Install the fi lters in the correct order as
shown.
Install the Back Panel.
OPERATION
START STOP
The fan speed is automatically controlled depending on the
5 detection. (PM2.5 / Usual dust / Temperature /Humidity /
Light)
The unit releases Plasmacluster ions with strong airfl ow and
collects dusts while decreasing static electricity for 10 min-
utes. After that, the DUST sensor sensitivity is automatically
set to ”HIGH”and quickly detects impurities
and clean the air powerfully for 50 minutes.
• When the operation fi nishes after
60 minutes, the unit will return
to the prior operation mode. It is
able to change the other mode
during this mode.
• The Plasmacluster Ion can not
be turned “OFF”. (Ref. E-10)
NOTE
2
1
3
3
Back Panel
HEPA Filter Deodorizing Filter
The fan speed is automatically controlled depending on the 7
detection. (Ref. E-1)
Click
Deodorizing Filter
HEPA Filter
Tag
• Front Display, Cleanliness Monitor and Air Outlet LED
automatically switch ON and OFF based on room
brightness. (When light control is set to "Auto". Ref. E-11)
NOTE
NOTE
• When replacing the fi lter, making a memo of the start of
use date is recommended.
START/STOP
CLEAN ION SHOWER MODE AUTO MODE (UA-HG40E)
INTELLIGENT MODE
(UA-HG60E / UA-HG50E)
FILTER INSTALLATION
Always be sure to remove the
power plug from the wall outlet.

E-8
ENGLISH
1
2
3
4
Remove the Water
Tank.
Fill the Water Tank
with the tap water.
Install the Water Tank.
ON OFF
Use this mode when you want to remove adhering odour,
germs, and other substances from cloths, sofas and curtains.
NOTE
Temperature
Humidity
ALL MODE
(Except MAX / MED / LOW /
SLEEP)
SLEEP
MODE
~18 ºC 65 % 65 %
18 ºC~24 ºC 60 % 65 %
24 ºC~ 55 % 60 %
SLEEPPOLLEN MAXMEDLOW
SLEEP
The unit will operate quietly, and the fan speed is automati-
cally switched depending on the amount of impurities in the
air.
The Front Display, Cleanliness Monitor and Air Outlet LED
go off automatically.
(When light control is set to "Auto". Ref.E-11)
POLLEN
The DUST SENSOR sensitivity is automatically set to “HIGH”
and quickly detects impurities such as dust and pollen and
clean the air powerfully.
NOTE
ON CANCELLATION
Operation of the operation panel will be locked.
2
1
2
1
Click
To prevent leaks ,
securely tighten the
Tank Cap.
more
3 sec.
• Emits highdensity Plasmacluster Ions only in the forward
direction.
• Discharges stronger air for 8 hours. When the operation
fi nishes, the unit will return to its prior operation mode.
• The Plasmacluster Ion can not be turned “OFF”. (Ref.E-10)
NOTE
PLASMACLUSTER ION
SPOT MODE
SELECTING MODE
CHILD LOCK
HUMIDIFICATION SETTING
more
3 sec.
When operating with Humidifi cation ON in the modes in the
table below, the unit automatically controls humidity by sens-
ing temperature and humidity. (Except MAX / MED / LOW
mode.)
REFILLING THE WATER TANK
Adjust Front Louver manually.

E-9
Select the length of time you want. The unit automatically
stops once the selected time is reached.
Select the length of time you want. The unit automatically
starts once the selected time is passes.
(with the unit OFF) (with the unit ON)
2hour
10hour
6hour
14hour
4hour
12hour
8hour
CANCELLATION
2hour1hour 4hour 8hour CANCELLATION
ON TIMER OFF TIMER
PATROLLING FUNCTION
The sensor detects a state requiring attention to room temperature and humidity during operation and tells it with
Patrolling Light. Both "Dry and Low temperature patrolling" and "High temperature and High humidity patrolling"
work. (This function informs a room condition. The unit cannot adjust temperature or lower humidity)
It tells that the room is dry or the room temperature is low.
When Patrolling Light turns to red, the unit operates with airfl ow a little stronger during Intelligent mode (Auto mode).
Material source: Dr. Makoto Shoji, Director of Shoji internal medicine and pediatrics clinic
in Sendai City, Miyagi Prefecture, Japan
Right fi g-
ure Absolute humidity*1 Virus environment Survival rate*2
(1) Over 11 g Environment which is less suitable for
viruses to survive
0 % to small per-
cent
(2) 11 g or less Environment where viruses can survive 5 %
(3) 7 g or less Environment which is suitable for
viruses to survive 20 %
• It does not notify of the existence of viruses themselves.
• Patrolling Light's illuminating "Green" does not assure
prevention of infection. Use it as a reference to make an
environment to prevent infection during typical daily life.
• While adjusting humidity to approximately 55 % to 65 %
during operation in Intelligent mode (Auto mode), the
unit controls humidifi cation, but does not make changes
according to the virus' environment.
*1 The absolute humidity is the total mass of water vapor present in 1 m3 of air regardless of temperature
and is expressed in g. While humidity generally used for a weather forecast is called relative humidity,
which is the ratio of the partial pressure of water vapor to the equilibrium vapor pressure of water at
a given temperature and is expressed in %. Therefore, the absolute humidity is approximately 8 g at
15
oC
and 18 g at 30
oC
even at the same relative humidity of 60 %.
*2 Survival rate of viruses emitted in air after 6 hours under each environment.
Patrolling
Light
If the beeping sound is set to "ON". (Ref. E-12)
Indoor environment
Temperature
and humidity
area (Figure
below)
Humidity / Temperature Mon-
itor (for 30 seconds) Beeping sound
Red "%" Light turns on Beep (once) Dry (3)
"oC" Light fl ashing Beep (once) Low temperature
Green (Normal) None Not dry or low tem-
perature (1)·(2)
DRY AND LOW TEMPERATURE PATROLLING
NOTE
When the room is dry and the room temperature is low, viruses survive more easily. We recommend
that you increase humidity with humidifi cation setting and temperature using heating appliances
according to your room environment.
          





































         



Temperature
(oC)
Relative humidity (%)

E-10
ENGLISH
Humidity Temperature Wattage
OFFON
When the Plasmacluster function is ON, the Plasmacluster
Ion light on the Front Display is on. (Ref.E-6)
SELECTING DISPLAY
PLASMACLUSTER ION ON/OFF
more
3 sec. more 3 sec.
(with the unit ON)
The beeping sound of Patrolling Function is set to "Off" at the default. You can change it to "On" or "Cancel
Patrolling Function". (Ref. E-11, E-12)
It tells high temperature and high humidity. When Patrolling Light turns to orange or red, the unit stops humidifi cation
automatically. (However, it is in MAX/MED/LOW mode, it does not stop humidifi cation)
We recommend that you drink some water or lower the room temperature.
Guideline for preventing heatstroke in daily life <Source: website of Japanese Society of
Biometeorology>
Temperature
standard
Overview of life
activities to be noted Precautions
D Danger
Risks that could occur
in all life activities
Elderly people are highly likely to suffer from
heartstroke even in a resting state. Avoid going out
and move to a cooler room.
C
Heavy alert
Avoid blazing sun when going out and pay attention
to an increase of room temperature when staying in
a room.
B Alert Risks that could occur
in middle level or higher
life activities
Rest regularly when doing exercise or intense work.
A Caution Risks that could occur
in hard life activities Generally the risk is low, but people may suffer
when doing hard exercise or hard work.
This is not a function to prevent heatstroke. Please use this function as an assistance.








































               

               

$
%
&
'
Relative humidity (%)
Temperature
(oC)
HIGH TEMPERATURE AND HIGH HUMIDITY PATROLLING
NOTE
Patrolling
Light
If the beeping sound is set to "ON". (Ref. E-12)
Indoor environment
Temperature
and humidity
area (Figure
below)
Humidity / Temperature Mon-
itor (for 30 seconds) Beeping sound
Red(Flashing) "oC" Light fl ashing Beep・・・(for 30 seconds) High temperature
and high humidity
D
Red "oC" Light turns on Beep・・・(for 30 seconds) C
Orange "oC" Light turns on None
Relatively high
temperature and high
humidity
B
Green (Normal) None
Not high
temperature nor
high humidity
A

E-11
HOW TO CHANGE VARIOUS SETTINGS
1
3
4
5
Select "Function number" from the
table in the following.
Select "Setting number" from the table
in the following.
Press Power button to fi nish the set-
ting.
Set
or
or
Forward
Forward
Reverse
Reverse
Set
…
You can change the functions in the "Type of setting" table in the following.
Turn off
more
3 sec.
Turn the unit power OFF.
2
UA-HG40E
UA-HG40E
Type of setting
Function Setting
Light Control
You can select the brightness of the
Front Display, Cleanliness Monitor
and Air Outlet LED.
Auto (default)
Light automatically switches ON or OFF based
on room brightness.
Room is bright: light is ON
Room is dark: light is OFF
Darker
Turn off
● When set to “Turn off”, the “Darker” light illumi-
nates for 3 seconds after operation starts and
then the light turns off.
● The Humidity Light fl ashes darker only when
the unit needs water.
● Patrolling Light fl ashes/lights dimmer only
when the room temperature or humidity re-
quires attention.

E-12
ENGLISH
Function Setting
Sound Indicator Setting
You can set the unit to make a
beeping sound when the Water
Tank is empty.
Cancellation (default)
ON
Auto Restart
If the unit is unplugged or if there is
a power failure, the unit will resume
operation with the previous settings
after power is restored.
Cancellation
ON (default)
Adjusting Sensor Sensitivity (F4-F7)
Light Sensor Low
Dust(sensitive) Sensor Standard (default)
Odour Sensor
(UA-HG60E / UA-HG50E) High
Motion Sensor
(UA-HG60E / UA-HG50E)
You can set the time until the Mo-
tion Sensor detects that no one is
in the room . You can also cancel
Motion Sensor sensing.
ON(Standard sensing time ) (default)
ON(Longer sensing time)
Cancellation
Patrolling FunctionSetting
You can set the unit to make a beep-
ing sound when Patrolling Light turn
to red.You can also cancel Patrolling
Function.
ON(notifi es with Patrolling Light and sound)
The beeping sound continues for 30 seconds at
maximum.
Pressing any button on the operation panel
stops the sound. When Patrolling Light is red,
the beeping sounds hourly.
ON(notifi es with Patrolling Light only)(de-
fault)
Cancellation

E-13
CARE AND MAINTENANCE
1. Remove the Back Panel.
2. Remove the sensor fi lter.
3. If the sensor fi lter is very dirty, wash
it with water and dry it thoroughly.
1. Add a small amount of kitchen
detergent to water and soak for
about 10 minutes.
2. Rinse off the kitchen detergent with
clean water.
3. Completely dry the fi lter in a well
ventilated area.
Clean the inside of
the Water Tank with
a soft sponge and
the Tank Cap with
a cotton swab or
toothbrush.
1
4
23
5
2
Place Ref.
1Water Tank
E-13
2Unit / Back Panel (Pre Filter)
3Sensors
4Humidifying Filter E-14
Humidifying Tray
5HEPA Filter E-15
Deodorizing Filter
The fi lter reset Indicator light will turn on after approximately
720 hours operating. (30 days × 24 hours =720 hours)
This is a reminder to perform the maintenance described be-
low. After performing maintenance, reset the Filter Indicator.
Do not apply excessive pressure
when scrubbing the back panel.
RESET
Rinse the inside
with water.
Wipe with a dry, soft cloth.
Remove the dust gently with
a cleaning tool such as a vac-
uum cleaner.
NOTE
NOTE
How to clean hard to remove dirt.
How to clean hard to remove dirt.
Tank Cap
Toothbrush
Sensors
Back Panel
(Pre Filter)
Sensor Filter
CAUTION
Back Panel
Sensor Filter
FILTER INDICATOR
CARE INDEX
WATER TANK
UNIT / BACK PANEL
more than
3 sec.

E-14
ENGLISH
2
1
After maintenance, correctly
reattach the parts.
Remove the Humidifying Tray Cover.
Rinse with plenty of water.
Rinse with plenty of water.
Reattach the Humidifying Tray Cover.
NOTE How to clean hard to remove dirt.
Kitchen detergent
(only Humidifying tray) Citric acid (available at some drugstores) 100% bottled lemon juice
with no pulp
1
1. Fill the tray half-way with water.
2. Add a small amount of kitchen
detergent.
2 1/2 cups of
water
3 teaspoons
3 cups of
water
1/4 cup
2
Soak for 30 min-
utes.
Soak for 30 minutes.
(When using lemon juice as your
descaling solution, allow for more
soak time.)
3
Rinse off the kitchen detergent or the descaling solution with clean water.
1
2
2
1
1
2
3
•
Do not remove the Float and the Tray Panel. If they
come off, refer to E-15.
2
1
HOW TO REMOVE THE
HUMIDIFYING FILTER AND
TRAY.
HOW TO ATTACH THE
HUMIDIFYING FILTER AND
TRAY.
Gray White
NOTE
2
1
If you remove the Humidifying Filter shaft,
be sure to reattach it to its original position.
Tray Cover
Click
Click
HUMIDIFYING FILTER AND TRAY
Humidifying Filter Humidifying Tray

E-15
How to install the Float and the Tray Panel
LIFE OF FILTERS
Filter life varies depending on the room environment,
usage conditions, and location of the unit.
Lifespan of HEPA fi lter and Deodorizing fi lter and
replacement suggestions are based on purifying a
room in which 5 cigarettes are smoked per day and the
unit's dust collection and deodorizing performance has
declined to half the level of a new fi lter.
We recommend replacing the fi lter more frequently if
the unit is used in conditions signifi cantly more severe
than a normal household.
•HEPA Filter About 10 years after opening
•Deodorizing Filter About 10 years after opening
•Humidifying Filter About 10 years after opening
Replacement Filter Model
Consult your dealer when purchasing a replacement
fi lter.
Disposing of fi lters
Dispose of used fi lters according to local laws and
regulations.
HEPA Filter material:
• Filter: Polypropylene
• Frame: Polyethylene
Deodorizing Filter material:
• Filter: Paper
• Frame: ABS resin
Humidifying Filter material:
• Filter: Rayon, polyester
Maintain only the tagged
surface. Do not clean up the
opposite surface. The fi lter
is fragile, so be careful not
to apply too much pressure.
Both surfaces can be main-
tained.
The fi lter may be broken
if being too much power
is applied on it, so please
handle it with care.
Remove the dust on the HEPA Filter and
Deodorizing Filter.
Tray Panel
Float
Replacement
Filter
UA-HG60E UA-HG50E UA-HG40E
HEPA Filter
(1 unit) UZ-HD6HF UZ-HD4HF UZ-HD4HF
Deodorizing
Filter (1
unit)
UZ-HG6DF UZ-HG4DF UZ-HG4DF
Humidifying
Filter (1
unit)
UZ-HG6MF UZ-HG6MF UZ-HG6MF
Humidifying Filter
Filter Frame (white)*
Filter Frame (gray)*
1. Insert the fl oat under
this tab.
3. Insert the tab on the
other side of the fl oat
into the hole.
Tab
Float
Cross-Section view
2.
Insert the tab of the
fl oat into the hole.
Tag
UA-HG60E
UA-HG50E / UA-HG40E
CAUTION
• Do not wash the fi lters. Do not expose to sunlight.
Some odours absorbed by the fi lters will break down over time,
causing additional odours. Depending on usage conditions, and
especially if the unit is used in environments signifi cantly more
severe than a normal household, these odours may become
noticeable sooner than expected.
Replace the fi lter in those cases or if dust is unable to be re-
moved after maintenance.
FILTER REPLACEMENT
HEPA FILTER /
DEODORIZING FILTER
HEPA FILTER
DEODORIZING FILTER
*Do not dispose these parts.
Shaft (gray)*
Shaft (white)*

E-16
ENGLISH
TROUBLESHOOTING
Before contact for service, review the troubleshooting chart below to make sure that the problem is not a unit malfunction.
SYMPTOM REMEDY (the following are not due to a malfunction)
Odour and smoke persists. • Check the fi lters. If they appear to be extremely dirty, clean or replace them. (Ref.
E-15)
The Cleanliness Monitor is blue
even when the air is not clean.
• The air may have been dirty when the unit was plugged in. Unplug the unit, wait
one minute, and then plug the unit in again.
The Cleanliness Monitor light is
red even when the air is clean.
• Dirty or clogged dust(sensitive) sensor openings interfere with sensor operation.
Gently clean the sensor fi lter or the back panel. (Ref. E-13).
The unit makes a clicking or
ticking sound.
• The unit may make clicking or ticking sounds when it is generating ions.
Air discharged from the unit
has an odour.
• Check to see if the fi lters are extremely dirty.
• Clean or replace the fi lters. (Ref. E-13, E-14, E-15)
• Use only fresh tap water. Using other water sources risks the growth of mold,
fungi, or bacteria.
The unit does not operate when
cigarette smoke is in the air.
• Make sure the unit is installed in a location in which the sensors can detect cig-
arette smoke.
• Check to see if the dust(sensitive) sensor openings are blocked or clogged. If
they are blocked or clogged, clean the sensor fi lter or the back panel.
(Ref. E-13)
The FILTER RESET Indicator
Light is on.
• Whenever after performing maintenance or replacing the fi lters, connect the
power cord to an outlet and then press the Filter Reset Button. (Ref. E-13)
The Front Display is turned off. • When Light control is set to "Auto", the light automatically turns off when the
room is dark. Moreover, when Light control is set to "Turn off", the light is always
off. If you do not want the light to be off, set Light control to the "Darker" setting.
(Ref. E-11)
The Humidify Light on the
Front Display does not light up
when the tank is empty.
• The room has reached the appropriate level of humidity and has stopped hu-
midifying.
• Check the styrofoam fl oat for impurities. Clean the Humidifying Tray. Make sure
that the unit is on a level surface. (Ref. E-14)
The water level in the tank
does not decrease or decreas-
es slowly.
• Check to see if the Humidifying Tray and Water Tank are correctly installed.
Check the Humidifying Filter. (Ref. E-14)
• If the fi lter is extremely dirty, clean or replace it. (Ref. E-15)
The Cleanliness Monitor
changes colour frequently.
• The Cleanliness Monitor automatically changes colour when the dust (sensitive)
sensor and odour sensor* detect impurities. If you are concerned about the
change, you can change sensor sensitivity.
(Ref. E-11,E-12) (*UA-HG60E / UA-HG50E)
There is a discrepancy between
the unit’s Humidity Monitor
and another hygrometer in the
room.
• There is a difference in the humidity level within the same room.
• The sensor have different measurement parameters.
• If the monitor indicates wattage or temperature, switch the display by pressing
the DISPLAY SELECT button. (Ref. E-10)
The unit PM2.5 Light does not
match weather report or other
local PM2.5 data.
• Outdoor and indoor as well as the home environment (the volume of traffi c near-
by, number of stories in home, etc.) may cause a reading different than local
PM2.5 data.
"oC" Light fl ashing • The room is suitable for viruses to survive due to low room temperature. We
recommend you adjust the temperature using heating appliances. (Ref. E-9)
• The room temperature and humidity is high. We recommend that you drink
some water or lower the room temperature. (Ref. E-10)
ERROR DISPLAY If error occurs repeatedly, contact the Sharp Service Centre.
DIGITAL INDICATION REMEDY
Make sure that the Humidifying Filter and Humidifying Tray are
properly installed, and then turn the power to ON again.
Unplug the unit, wait one minute, and then plug the unit in again.

E-17
SPECIFICATIONS
*1 • The amount of humidifi cation changes in accordance with indoor and outdoor temperature and humidity.
The amount of humidifi cation increases as temperatures rises or humidity decreases.
The amount of humidifi cation decreases as temperatures decrease or humidity rises.
• Measurement Conditions: 20 ºC, 30 % humidity (JEM1426)
*2 • The recommended room size is appropriate for operating the unit of maximum fan speed.
• The recommended room size is an area in which a given amount of dust particles can be removed in 30 minutes.
*3 • Room size in which approximately 7000 ions per cubic centimeter can be measured in the centre of the room when the unit is placed next
to a wall, is running at MED mode settings, and is at a height of approximately 1.2 meters from the fl oor.
Standby Power
When the unit’s power plug is inserted in a wall outlet it consumes about 1.2 watts of standby power in order to
operate electrical circuits.
To conserve energy, unplug the power cord when the unit is not in use.
Model UA-HG60E UA-HG50E UA-HG40E
Power supply 220-240 V 50-60 Hz
Fan Speed Adjustment MAX MED LOW MAX MED LOW MAX MED LOW
CLEAN
AIR
Fan Speed (m3/hour) 408 240 72 306 180 60 240 120 60
Rated Power (W) 72 38 5.0 53 26 5.0 31 12 5.0
Noise Level (dBA) 53 48 24 52 47 19 46 40 19
CLEAN AIR
&
HUMIDIFY
Fan Speed (m3/hour) 342 240 72 240 120 60 210 120 60
Rated Power (W) 55 40 6.5 33 14 6.5 24 14 6.5
Noise Level (dBA) 49 48 24 46 40 20 43 40 20
Humidifi cation
(mL/hour) *1630 470 200 450 300 150 400 300 150
Recommended Room Size (m2) *2~50 ~38 ~28
High density Plasmacluster ion
recommended room size (m2)
*3~35 ~28 ~21
Water Tank Capacity (L) 3.0 2.5 2.5
Sensors Dust(sensitive) / Odour / Light /
Temperature & Humidity / Motion
Dust(sensitive) / Light /
Temperature & Humidity
Cord Length (m) 2.0
Dimensions (mm) 370 (W) × 293 (D) × 660 (H) 345 (W) × 262 (D) × 631 (H) 345 (W) × 262 (D) × 631 (H)
Weight (kg) 10.5 9.2 9.2
