Sharp Plasmacluster fp-f30j User manual

Free standing type

FP-F30J AIR PURIFIER

OPERATION MANUAL

“Plasmacluster” and “Device of a cluster of grapes” are

trademarks of Sharp Corporation.

*The number in this technology mark indicates an

approximate number of ions supplied into air of 1 cm3,

which is measured around the center of a room with

the “high-density plasmacluster 7000” applicable oor

area (at 1.2 m height above the oor) at the medium

wind volume in air purifying mode, when an air purier

using the high-density plasmacluster ion evolving

device is placed close to a wall. This product is

equipped with a device corresponding to this capacity.

OM_FP-F30J.indd 1 2017/01/17 13:21:44

Please read before operating your new Air Purier

The air purier draws in room air from the air intake, passes the air through a pre-

Filter, a HEPA Filter inside of the unit, then discharges the air through the air outlet.

The HEPA Filter can remove 99.97% of dust particles as small as 0.3 microns that

pass through the lter.

Some odors absorbed by the lter may break down over time, resulting in additional

odor. Depending on the usage environment, especially when the product is used in

extreme environments (signicantly more severe than normal household use), this

odor may become strong in a shorter period than expected. If the odor persists, the

lter should be replaced.

NOTE

• The air purier is designed to remove air-suspended dust, but not harmful gases

(for example, carbon monoxide contained in cigarette smoke).

HEPA Filter

Back Panel

OM_FP-F30J.indd 2 2017/01/17 13:21:44

E-1

Thank you for purchasing the SHARP

Air Purier. Please read this manual carefully.

Before using this product, be sure to read the

section: “Important Safety Instructions.”

After reading this manual, keep it in a

convenient location for future reference.

For your reference, we recommend to keep

this manual in the place where you can read

at any time.

IMPORTANT SAFETY INSTRUCTIONS

.....E-2

PART NAMES...............................................E-4

FILTER INSTALLATION ............................. E-5

OPERATION .................................................E-6

CARE AND MAINTENANCE .....................E-8

TROUBLESHOOTING ..............................E-10

SPECIFICATIONS...................................... E-11

FOR CUSTOMER ASSISTANCE ............E-12

CONTENTS

FEATURES

Unique Combination of Air Treatment

Technologies

Filtration System + Plasmacluster

TRAPS DUST*

Pre-lter traps dust and other large

airborne particles.

REDUCES POLLEN & MOLD*

HEPA lter traps 99.97% of particles as

small as 0.3 microns.

FRESHENS

Plasmacluster treats the air similar to the

way nature cleans the environment by

emitting a balance of positive and negative

ions.

*When air is drawn through the lter

system.

OM_FP-F30J.indd 1 2017/01/17 13:21:44

E-2

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions should be followed,

including the following:

WARNING - To reduce the risk of electrical shock, re or injury to persons:

• Read all instructions before using the unit.

• Use only a 220-240 volt outlet.

• Do not use the unit if the power cord or plug is damaged or the connection to the

wall outlet is loosened.

•Periodically remove dust from the power plug.

• Do not insert ngers or foreign objects into the intake or air outlet.

• When removing the power plug, always hold the plug and never pull the cord.

Electrical shock and/or re from short circuit may occur as a result.

•Be careful not to damage the power cord, it may cause electric shock, excess heat or

res.

• Do not remove the plug when your hands are wet.

• Do not use this unit near gas appliances or replaces.

• Remove the power plug from the wall outlet before cleaning the unit and when not

using the unit.

Electrical shock from bad insulation and/or re from short circuit may occur as a result.

•When cleaning the unit, or when the unit is not in use, be sure to unplug the unit. Electrical

shock and/or re from a short circuit may result.

• If the power cord is damaged, it must be replaced by the manufacturer, its service

agent, Sharp Approved Service Centre or similarly qualified person in order to

avoid a hazard.

•Do not operate when using aerosol insecticides or in rooms where there is oily residue,

incense, sparks from lit cigarettes, chemical fumes in the air or in very high humidity

conditions, such as a bathroom.

•Be cautious when cleaning the unit. Corrosive cleansers may damage the exterior.

•Only a Sharp Authorized Service Centre should service this air purier. Contact the

nearest Service Centre for any problems, adjustments, or repairs.

• This appliance can be used by children aged from 8 years and above and persons with

reduced physical, sensory or mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

NOTE - Radio or TV Interference

If this air purier should cause interference to radio or television reception, try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the unit and radio/TV receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

OM_FP-F30J.indd 2 2017/01/17 13:21:44

E-3

CAUTIONS CONCERNING OPERATION

• Do not block the intake and/or air outlet.

• Do not use the unit near or on hot objects, such as stoves or heaters or where it may

come into contact with steam.

• Do not lay the unit down when using.

• Always hold the handle on the back of the unit when moving it.

• Do not use without the lter inside the unit.

•Do not wash and reuse the HEPA lter.

Not only does it not improve lter performance, it may cause electric shock or malfunction.

INSTALLATION GUIDELINES

•When using the unit, place it away from equipment utilizing electric waves such as

televisions or radios to avoid electrical interference.

• Avoid use in locations where furniture, fabrics or other items may come in contact

with and restrict the air intake and/or air outlet.

• Avoid use in locations where the unit is exposed to condensation or drastic

temperature changes. Appropriate conditions are when room temperature is

between 0 – 35 ºC.

• Place on a stable surface with sufcient air circulation.

When placing the unit on a heavily carpeted area, the unit may vibrate slightly.

• Avoid locations where grease or oily smoke is generated.

The unit surface may crack as a result.

•Place the unit about 30 cm(1 ft) away from the wall in order to ensure proper

airow.

The dust collecting performance will be the same even if using the unit 3cm away from

the wall, but place it as far as possible(30cm away recommended) because it may dirty

the wall or oor around.

FILTER GUIDELINES

• Follow the instructions in this manual for correct care and maintenance of the lter.

OM_FP-F30J.indd 3 2017/01/17 13:21:44

E-4

PART NAMES

1Main Unit 9 HEPA Filter

2Air Outlet 10 Upper Tabs

3Fan Speed Indicator Lights (green) 11 Back Panel (Pre-Filter)

4MODE Button / LIGHT ON/OFF Button(Press 3 sec.) 12 Bottom Tabs

5Plasmacluster Ion Indicator Light (blue) 13 Handle

6Plasmacluster Ion ON/OFF Button 14 Date Label

7POWER ON/OFF Button 15 Power Cord

8CLEAN ION SHOWER Button /

CLEAN ION SHOWER indicator Light (green) 16 Plug

FRONT

BACK

(Shape of plug depends on country.)

OM_FP-F30J.indd 4 2017/01/17 13:21:45

E-5

FILTER INSTALLATION

To maintain the quality of the lter, it is installed in the main unit and packed in plastic

bag. Be sure to remove the lter from the plastic bag before using the unit.

Remove the Back Panel.

Remove the plastic bag from

the Filter.

Place the Filter within the main

unit.

Do not install the lter backwards or the

unit will not operate properly.

Upper Tabs

• Do not operate the unit without the lter.

Date Label

Pull Push

Be sure to remove the power plug

from the wall outlet.

4Replace the Back Panel to the

main unit.

5Fill in the usage start date on the

Date Label.

Use the date as a guide for the filter re-

placement schedule.

Bottom Tabs

OM_FP-F30J.indd 5 2017/01/17 13:21:47

E-6

OPERATION

Releases high-density Plasmacluster ions and discharges strong air ow for 60 minutes.

CLEAN AIR

START

•Select the desired fan speed.

•Unless the power cord has been unplugged,

the operation starts in the previous mode it

was operated in.

STOP

CLEAN ION SHOWER

START

• If Plasmacluster Ion is OFF, Plasmacluster Ion will not be

released.

•When the operation nishes, the unit will return to the prior

operation mode.

It is able to change the other mode and during this

mode.

NOTE

FAN SPEED

MED MAX SLEEP

SLEEP

• The unit will operate very quietly with low fan speed.

Plasmacluster Ion Indicator goes off automatically.

Even though the indicator is off, Plasmacluster Ion is

dispersed into air unless Plasmacluster Ion is turned off

by .

NOTE

OM_FP-F30J.indd 6 2017/01/17 13:22:03

E-7

If the , , lamp Lights up for 10 seconds, the setting is completed.

Light Control

Plasmacluster Ion ON/OFF

You can set the Plasmacluster Ion Indicator to OFF when the Plasmacluster Ion Indicator is bright.

more than 3 sec. more than 3 sec.

OFF

When Plasmacluster Ion is ON, the Plasmacluster Ion Indicator Light will turn on. (blue)

ON OFF

Auto RESTART

If the unit is unplugged or if there is a power failure, the unit will resume operation with the previous

settings after power is restored.

ON OFF

(with the unit OFF)

more than 3 sec.

(with the unit OFF)

more than 3 sec.

3 sec.

OFF

•When the unit starts operation, the

Plasmacluster Ion Indicator always

lights.

•In SLEEP mode, Light Control

button doesn’t operate.

NOTE

Flashing

Lighting

When Indicator is off,

•If Plasmacluster Ion is ON,

•If Plasmacluster Ion is OFF,

Lighting Flashing

OM_FP-F30J.indd 7 2017/01/17 13:22:08

E-8

Gently remove dust from the back panel,

using a vacuum cleaner attachment or

similar tool.

Gently remove dust from the HEPA Filter with a vacuum clean-

er attachment or similar tool.

BACK PANEL (Pre-Filter)

HEPA Filter

To maintain optimum performance of this air purier, please clean the unit including the lter

periodically.

Be sure to disconnect the power cord from the wall outlet before performing any maintenance.

CARE AND MAINTENANCE

Back Panel

CAUTION

Do not apply excessive pressure, when

scrubbing the back panel.

CAUTION

• Do not WASH in water and DRY in the sun.

• Apply the maintenance only on the side with the tag.

Do not clean the opposite side; otherwise, the lter will be

damaged.

The lter is fragile, be careful not to apply too much force.

NOTE How to clean stubborn dirt

1. Add a small amount of kitchen

detergent to water and soak for about

10 minutes.

2. Rinse off the kitchen detergent with

clean water.

3. Completely dry the lter in a well-

ventilated area.

UNIT

Wipe with a dry, soft cloth

For stubborn stains or dirt, use a soft cloth dampened with warm water.

CAUTION

•Do not use volatile uids

Benzine, paint thinner, polishing powder, etc. , may damage the surface.

•Do not use detergents

Detergent ingredients may damage the unit.

Tag

OM_FP-F30J.indd 8 2017/01/17 13:22:10

E-9

FILTER REPLACEMENT GUIDELINES

Do not wash and reuse the lter

The lter life and replacement period are based on the condition of smoking 5 cigarettes per

day and the dust collection power is reduced by half compared with that of new lter.

Filter life varies depending on the room environment, usage, and location of the unit.

We recommend to replace the lter more frequently if the product is used in a condition signif-

icantly severer than normal household use.

REPLACING THE FILTER

Replacement Filter

Model : FZ-F30HFE

• HEPA Filter : 1 unit

• Please consult your dealer for purchase of replacement lter.

• Use only lter designed for this product.

Disposal of Filter

Please dispose of the replaced lter according to the local disposal laws and regulations.

Filter materials :

•Filter : Polypropylene

•Frame : Polyester

See page E-5 for directions on how to

install the lter when replacing.

Replacement timing About 2 years after operating

Be sure to remove the power plug from the wall outlet.

Date Label

OM_FP-F30J.indd 9 2017/01/17 13:22:10

E-10

Before calling for service, please review the Troubleshooting list below, since the problem may not

be a unit malfunction.

TROUBLESHOOTING

SYMPTOM REMEDY (not a malfunction)

Dust and smoke are not removed. •Clean or replace the filter if they appear to be heavily

soiled.(Ref. E-8,E-9)

A clicking or ticking sound is heard

from the unit.

• Clicking or ticking sound may be audible when the unit

is generating ions.

The discharged air has an odor. •Check to see if the lter are heavily soiled.

Replace the lter.

•Plasmacluster Air Purifiers emit small traces of ozone

which may produce an odor. These ozone emissions

are well below safety levels.

The Plasmacluster Ion Indicator

doesn’t Light on.

•Check to see if the SLEEP mode is selected.

The Plasmacluster Ion Indicator Light is turned off

3 seconds after the SLEEP mode is selected.

•Check to see if the Plasmacluster Ion OFF is selected.

Press to light on.

•Check to see if the Light Control is selected.

Press for 3 seconds to light on.

OM_FP-F30J.indd 10 2017/01/17 13:22:11

E-11

Power supply 220-240V 50-60Hz

Fan

Speed

Operation

Fan Speed Adjustment MAX MED SLEEP

Rated Power 51W 30W 13W

Fan Speed 180m3/hour 120m3/hour 60m3/hour

Recommended Room Size ~21m2*1

High density Plasmacluster ion recommended room size

~16m2*2

Cord Length 2.0m

Dimensions 400mm(W)x182mm(D)x463mm(H)

Weight 4.0kg

*1 Size of a room which is appropriate for operating the unit at maximum fan speed.

• It indicates the space where a certain amount of dust particles can be removed in 30 minutes(-

JEM1467).

*2 Size of a room in which approximately 7000 ions can be measured per cubic centimeter in the

center of the room (at a height of approximately 1.2 meters from the oor) when the product is

placed next to a wall and run at the MED operation position.

Standby Power In order to operate the electrical circuits while the power plug is inserted in the

wall outlet, this product consumes about 1.0W of standby power.

For energy saving, unplug the power cord when the unit is not in use.

SPECIFICATIONS

OM_FP-F30J.indd 11 2017/01/17 13:22:11

E-12

FOR CUSTOMER ASSISTANCE

Congratulations on Your Purchase!

This Sharp product is warranted against faults in material and manufacture for the

period as stated in the table below.

If service is required during the warranty period, please contact your nearest Sharp

Approved Service Centre. These repairs would be carried out at no charge to the

owner, subject to the conditions specified herein.

This warranty does not extend to defects or injuries caused by or resulting from causes

not attributable to faulty parts or the manufacture of the product, including but not

limited to, defect or injury caused by or resulting from misuse, abuse, neglect, lack of

maintenance, accidental damage, improper voltage, liquid spillage, vermin infestation,

software, or any alterations made to the product which are not authorised by Sharp.

Please retain your sales documentation, as this should be produced to validate a

warranty claim. This warranty is in addition to and in no way limits, varies or excludes

any implied rights and remedies under any relevant legislation in the country of sale.

WARRANTY PERIODS

Home Theatre Projector 12 months

Audio/Home Theatre 12 months

Microwave Oven 12 months

Steam Oven 12 months

Refrigerator 24 months

DVD/Blu-ray 12 months

Air Conditioner 60 months

Portable Air Conditioner 12 months

LCD Television 36 months

Air Purifier 12 months

IMPORTANT NOTICE: This warranty applies only to products sold in Australia&New Zealand

SHARP CORPORATION OF

AUSTRALIA PTY. LIMITED

ABN 40 003 039 405

2 Julius Avenue

North Ryde NSW 2113

SHARP CORPORATION OF

NEW ZEALAND LIMITED

59 Hugo Johnston Drive

Penrose, Auckland

WARRANTY

Consumer Electronic Products

SPform 040 (AUGUST 2011)

Australian customers: Our goods come with guarantees that cannot be excluded

under the Australian Consumer Law. You are entitled to a replacement or refund

for a major failure and for compensation for any other reasonably foreseeable

loss or damage. You are also entitled to have the goods repaired or replaced

if the goods fail to be of acceptable quality and the failure does not amount

to a major failure. The criteria of a major failure is defined in the Australian

Consumer Law. Should you require any assistance with a major failure please

contact Sharp Customer Care.

This warranty does not cover transportation to and from the Sharp Approved Service

Centre. Goods presented for repair may be replaced by refurbished goods of the same

type rather than being repaired. Refurbished parts may be used to repair the goods.

The repair of your goods may result in the loss of user generated data, please ensure

that you have saved this data elsewhere prior to repair.

(excluding lamps and air filters)

FOR CUSTOMER ASSISTANCE

FOR LOCATION ENQUIRIESWITHIN

NEW ZEALAND

REGARDING YOUR LOCAL

SHARP CORPORATION OF NEW ZEALAND LIMITED

VISIT OUR WEBSITE AT

SHARP CUSTOMER SERVICES

TELEPHONE: 09 573 0111

FACSIMILE: 09 573 0113

SPform019(AUGUST 2011)

SHARP APPROVED SERVICE CENTRE

www.sharp.net.nz

CONTACT YOUR SELLING DEALER/RETAILER

OR CALL

FOR LOCATION ENQUIRIES WITHIN

AUSTRALIA

REGARDING YOUR LOCAL

SHARP APPROVED SERVICE CENTRE

VISIT OUR WEBSITE AT

www.sharp.net.au

OR CALL SHARP CUSTOMER CARE

1300 135 022

SHARP CORPORATION OF AUSTRALIA PTY LTD

(LOCAL CALL COSTS APPLY WITHIN AUSTRALIA)

OM_FP-F30J.indd 12 2017/01/17 13:22:11

E-13
