Sharp AR-650 User manual

DIGITAL COPYING MACHINE
OPERATION MANUAL
MODEL
AR-650

❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧
❧
❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧
❧
❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧
❧
❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧
❧
➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣
➢
➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣
➢
➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣
➢
➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣
➢
➣
The power switch positions are marked “ ” to indicate power “ON” and
“” to indicate stand-by.
In the stand-by position, power is being supplied to a drying heater within
the optical system of the copier.
Caution:
For complete electrical disconnection, pull out the main plug.
The socket-outlet shall be installed near the equipment and shall be
easily accessible.
FOR YOUR RECORDS ...
To protect against loss or theft, record and retain for reference the
copier’s serial number located on the left hand side at the rear corner of
the copier.
Model Number AR-650
Serial Number
Date of Purchase
Place of Purchase
Authorized Sharp Copier
Service Department Number

FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonableprotectionagainstharmfulinterferencewhentheequipmentisoperatedina
commercialenvironment.Thisequipmentgenerates,uses,andcanradiateradiofrequency
energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
This Class [A] digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [A] est conforme á la norme NMB-003 du Canada.
WARNING:
FCC Regulations state that any unauthorized changes or modifications to this
equipment not expressly approved by the manufacturer could void the user’s
authority to operate this equipment.

EPA ENERGY STAR ® (MFD)
EPA ENERGY STAR Program-
The United States Environmental Protection Agency (EPA) has introduced a voluntary program, the
ENERGYSTARProgram,toenouragethewidespreadandvoluntaryuseofenergy-efficienttechnologies
thatenhancetheworkplace,improveproductperformanceandpreventpollution.AsanENERGYSTAR
Partner,theSharpCorp.hasdeterminedthatthiscopiermodelmeetstheENERGYSTARguidelinesfor
energy efficiency.
ENERGY STAR guidelines for this class of copier require ENERGY STAR copiers to have an 'Off Mode'
feature that automatically turns the copier off after a period of inactivity, ensuring night and weekend
shut-off. The copier must also automatically change to a 'Low Power Mode' (Automatic Energy Save)
after a period of time since the last usage.
For Copier+Printer or FAX model, ENERGY STAR guidelines for this class of copier require ENERGY
STAR Multifunction copiers to have a 'Sleep Mode' feature that automatically makes the copier enter
thesleepmode afteraperiod ofinactivity. The copiermust also automaticallychange to a'Low Power
Mode' (Automatic Energy Save) after a period of time since the last usage.
Specifically, this copier complies with the following requirements-
The AR-650 Copier model (Base model)
'Off Mode'-
The copier consumes less than 20 watts in the 'Off Mode'.
'Off Mode' Default Time-
The default time for the 'Off Mode' is 90 minutes.
'Automatic Energy Save'-
The copier consumes less than 255 watts during Energy Save.
'Automatic Energy Save' Default Time-
The default time for the 'Automatic Energy Save' is 15 minutes.
The AR-650 Copier + Printer model (Multifunction model)-
'Sleep Mode'-
The copier consumes less than 95 watts in the 'Sleep Mode'.
'Sleep Mode' Default Time-
The default time for the 'Sleep Mode' is 90 minutes.
'Automatic Energy Save'-
The copier consumes less than 300 watts during Energy Save.
'Automatic Energy Save' Default Time-
The default time for the 'Automatic Energy Save' is 15 minutes.
Note1- The default setting for the 'Off Mode' or 'Sleep Mode' and 'Automatic Energy Save' can be
changed. If you want to increase the default setting, contact your authorized Sharp dealer.
Note2- For Copier model (Base model), to restart the copier after an automatic shut-off, return the
power switch to the 'On' position.
Note3- ForCopiermodel(Basemodel),afteranautomaticshut-off,theweeklytimerfeaturecannotbe
activated. If you prefer to activate this feature, contact your authorized Sharp dealer.
In accordance with the EPA ENERGY STAR Program guidelines, Sharp recycled paper.
Ifyouhaveanyquestionsregardingtheuseofrecycledpaperorsomerecommendedtypesofrecycled
paper, please contact your authorized Sharp dealer.
ENERGY STAR is a U. S. registered mark.

1
PREFACE
CONTENTS
PRECAUTIONS
PREFACE
Thank you for purchasing the Sharp Digital Copier AR-650. This Operator’s Manual describes the
following:
•how to use the digital copier
•how to make copies
•how to inspect and carry out maintenance on the digital copier
•how to remedy mechanical and copying problems.
Beforeusingthedigitalcopier,thoroughlyreadandunderstandthisOperator’sManual.Toensurethat
cleancopies aremadeat alltimesand tomakesure thatthedigital copierisin optimumworkingorder,
keep this Operator’s Manual in a handy place for future reference.
COPYRIGHT 2000
SHARP CORPORATION
nTo ensure correct and safe use of the Sharp Digital Copier AR-650, this Operator’s Manual
describes safety precautions according to the following three levels of warning:
BeforereadingthisOperator’sManual,youshouldfullyunderstandthemeaningandimportance
of these signal words.
Warning ------ Indicatesapotentiallyhazardoussituation which,if notavoided, couldresult in
death,seriousinjury,orseriousdamage,orfireintheequipmentorsurrounding
area.
Caution ------- Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury, partial damage of the equipment or surrounding
area, or loss of data.
Note------------ Indicates a procedure you should follow to ensure the optimal performance of
the digital copier and problem-free copying.
Tip -------------- Describes information useful to know when operating the digital copier.
Advice--------- Describesan operationyou shouldfollow tomaintain thedigital copierin good
working order.
User Safety
ThisSharpdigitalplainpapercopierdoesnotproducelaserradiationhazardoustotheuser. Itiscertified
as a Class 1 laser product under the U.S. Department of Health and Human Services (DHHS) Radiation
Performance Standard according to the Radiation Control for Health and Safety Act of 1968.
Protectivehousingandexternalcoverscompletelyconfinethelaserlightemittedinsidetheplainpaper
copier. The laser beam cannot escape from the machine during any phase of user operation.
RegulationsimplementedonAugust2,1976bytheBureauofRadiologicalHealth(BRH)oftheU.S.Food
and Drug Administration apply to laser products manufactured from August 1, 1976. Laser products
marketed in the United States must comply with these regulations.
CAUTION: Using controls or adjustments or performing procedures, other than those specified
herein may result in hazardous radiation exposure.

2
The copier is a plain paper digital copier.
The copier scans originals and stores the resulting data in its memory as digital images. The
copierallowsyounotonlytoprocessandeditthesedigitalimagedata,butalsoenablescopies
to be sorted and grouped quietly, quickly and easily. The copier incorporates a large-size
display with a touch panel and menu buttons that graphically represent copier functions. As
a result, anybody can make clear-looking copies quickly and easily.
Thecopieralsohas thefollowingconvenientfeatureswhichallowthe digitalcopiertobeused
in many applications.
.Copying speed is 65 copies (Letter) per minute for the copier.
.The automatic original density function automatically reads the density of the original to
set the ideal copy density.
.Thesizeoftheoriginalisautomaticallyreadandtheappropriatepapersizeandreproduction
ratio are automatically selected.
.Wide reproduction range (25% to 400%).
.Duplexcopiesor single-sidedcopiescanbemade automaticallyfromtwo-sidedoriginals.
Duplex copies can also be made automatically from single-sided originals.
.Comes with the following digital editing functions:
Trimming, masking, negative/positive reversal, X-Y zoom and mirror image, etc.
.Comes with the following memory editing functions:
2 in 1, 4 in 1, document storage, annotation and page numbering.
.With the electronic sort function, you can also sort at high speed without damaging the
originals.
.The cover-sheet mode allows you to add cover pages at the first and/or last pages of the
copies. The sheet-insertion mode allows you to insert copied and/or blank sheets at user-
specified pages.
.Copy sizes from Statement up to Ledger are acceptable.
.Addingtheoptionalfinisherpermitsthestaplingandsortingofcopiesaswellasmagazine
sorting (AR-FN9: with the saddle stitching function, AR-FN8 : without the function). An
optional hole punching unit can be installed.
.Comes with a weekly timer. This timer allows automatic turning ON or OFF of the power
supply at the specified startup or shutdown times, respectively.
.An automatic job start mode. This mode allows you to start copying when warming-up is
completed after you have set the desired copy modes and pressed the START key.
Installing an optional printer unit allows you to print out data from PCs.
Features of theAR-650 copier
PREFACE

3
TABLE OF CONTENTS
■PREFACE .................................................................................................................... 1
■TABLE OF CONTENTS ............................................................................................. 3
■PRECAUTIONS .......................................................................................................... 5
1. INSTALLATION..................................................................................................................... 5
2. GENERAL PRECAUTIONS ................................................................................................... 6
■DESCRIPTION OF THE DIGITAL COPIER ............................................................... 7
1. NAMES OF MAIN COMPONENTS..................................................................................... 8
2. DESCRIPTION OF OPTIONAL EQUIPMENT ...................................................................... 9
3. DESCRIPTION OF THE CONTROL PANEL ...................................................................... 10
4. DESCRIPTION OF THE GRAPHIC DISPLAY .................................................................... 13
■HOW TO MAKE COPIES........................................................................................ 15
1. TURNING ON THE POWER SWITCH / AUTO JOB START .......................................... 16
2. USING THE REVERSING AUTOMATIC DOCUMENT FEEDER...................................... 19
3. COPYING IN THE AUTOMATIC PAPER SELECTION MODE ........................................ 24
4. ACTUAL-SIZE COPYING BY SPECIFYING THE COPY SIZE.......................................... 27
5. REDUCTION AND ENLARGEMENT COPYING................................................................ 29
6. DUPLEXED COPIES FROM SINGLE-SIDED ORIGINALS ............................................... 34
7. DUPLEXED COPIES FROM TWO-SIDED ORIGINALS .................................................... 39
8. SINGLE-SIDED COPIES FROM TWO-SIDED ORIGINALS .............................................. 41
9. DUPLEXED COPIES FROM BOOK ORIGINALS .............................................................. 43
10. COPYING WITH COPY DENSITY SELECTION ................................................................ 46
11. COPYING IN THE TEXT OR PHOTO MODE ................................................................... 47
12. BYPASS COPYING ............................................................................................................. 48
13. BYPASS COPYING BY SPECIFYING THE COPY SIZE................................................... 50
14. INTERRUPT COPYING ....................................................................................................... 52
15. PRESETTING OF COPY MODES ...................................................................................... 53
16. ALL CLEAR KEY ................................................................................................................. 54
■USING THE EDITING FUNCTIONS....................................................................... 55
1. IMAGE SHIFT COPYING.................................................................................................... 56
2. EDGE ERASE COPYING .................................................................................................... 58
3. DUAL-PAGE COPYING ...................................................................................................... 60
4. X-Y ZOOM .......................................................................................................................... 61
5. TRIMMING/MASKING........................................................................................................ 62
6. MIRROR IMAGE ................................................................................................................. 66
7. NEGATIVE/POSITIVE REVERSAL...................................................................................... 67
8. 2 IN 1 / 4 IN 1.................................................................................................................... 69
9. ANNOTATION..................................................................................................................... 73
10. PAGE NUMBER .................................................................................................................. 75
11. MAGAZINE SORT .............................................................................................................. 78
12. COVER SHEET COPYING .................................................................................................. 80
13. SHEET INSERTION COPYING........................................................................................... 84
14. SETTING A CASSETTE FOR COVER SHEET/SHEET-INSERTION COPYING............... 87
15. DOCUMENT STORAGE ..................................................................................................... 89
PREFACE
CONTENTS
PRECAUTIONS
DESCRIPTION
OF THE DIGITAL
COPIER
HOW TO
MAKE
COPIES
WHEN THE
GRAPHIC SYMBOLS
FLASH
MAINTE-
NANCE
SPECIFICATIONS,
ACCESSORIES &
OPTIONS
USING THE
EDITING
FUNCTIONS
USING THE
SPECIAL
FUNCTIONS
USING THE
OPTIONAL
FINISHER

4
■USING THE SPECIAL FUNCTIONS....................................................................... 93
1. ACCOUNT NUMBER.......................................................................................................... 94
2. JOB MEMORY .................................................................................................................... 95
3. WEEKLY TIMER.................................................................................................................. 99
4. COPYING USING PAPER OF OTHER SIZES................................................................. 101
5. SETTING THE DATE AND TIME .................................................................................... 102
6. CHANGING AUTOMATIC ENERGY SAVE TIME/AUTOMATIC SHUTOFF TIME....... 104
7. CHANGE OF LANGUAGE ON THE DISPLAY PANEL.................................................. 105
■USING THE OPTIONAL FINISHER.......................................................................107
1. NAMES OF THE MAIN COMPONENTS ........................................................................ 108
2. NON-SORT COPYING ...................................................................................................... 109
3. SORT COPYING................................................................................................................ 110
4. GROUP COPYING ............................................................................................................ 114
5. STAPLING ......................................................................................................................... 118
6. HOLE PUNCHING MODE ................................................................................................ 122
7. MAGAZINE SORT & SADDLE STITCHING MODE....................................................... 124
■WHEN THE GRAPHIC SYMBOLS FLASH ...........................................................127
1. ADD PAPER SYMBOL ..................................................................................................... 128
2. REPLACE TONER BAG SYMBOL ................................................................................... 130
3. ADD TONER SYMBOL..................................................................................................... 132
4. CLEAR PAPER SYMBOL.................................................................................................. 136
5. CHECK ORIGINAL SYMBOL ........................................................................................... 147
6. FINISHER/HOLE PUNCHING UNIT MISFEED SYMBOL............................................... 149
7. SADDLE STITCHER JAM SYMBOL................................................................................ 152
8. REPLACING STAPLES (OPTIONAL) ............................................................................... 154
9. REMOVING JAMMED STAPLES (OPTIONAL) .............................................................. 159
10. CLEARING ACCUMULATED PUNCHED PAPER BITS.................................................. 164
11. CALL SERVICE SYMBOL................................................................................................. 165
12. PERIODIC MAINTENANCE .............................................................................................. 166
■MAINTENANCE ......................................................................................................167
1. DAILY INSPECTION ......................................................................................................... 168
2. SIMPLE TROUBLESHOOTING ........................................................................................ 169
■SPECIFICATIONS, ACCESSORIES & OPTIONS..................................................171
1. SPECIFICATIONS.............................................................................................................. 172
2. FINISHER SPECIFICATIONS (OPTIONAL)...................................................................... 174
TABLE OF CONTENTS (Cont.)

5
PREFACE
CONTENTS
PRECAUTIONS
PRECAUTIONS
1. INSTALLATION
3
2
1
The copier should be installed by a qualified service technician.
Note: The packing material should be disposed of properly.
To obtain the best possible results, this copier should be used in conjunction with a
dedicated AC power line at the following ratings:
115V–60 Hz, 16 A
Notes:
1. The use of other appliances or other equipment on the same line as this copier may adversely
affect performance and copy quality.
2. Be sure to use a 3-conductor, grounded wall outlet.
3. In areas where a 2-pin plug is used, the copier must be grounded for safety.
Never ground it to a gas pipe, a water pipe, or any other object not suitable for grounding.
After a suitable place has been selected for the installation of the copier, please do not
change it. Avoid excessive heat, dust, vibration and direct sunlight. Also, provide
proper ventilation as the copier emits a small amount of ozone.
Notes:
1. Recommended environmental range for use is as follows:
•Temperature: 10~30˚C/50~86˚F
•Humidity: 20~85% RH
2. To insure optimal operation, allow clearances of at least 32" on the left, 32" on the right
and 4" in the rear (refer to the illustration below).
The socket-outlet shall be installed near the equipment and shall be easily accessible.
4 inches
32 inches
32 inches

6
1
2. GENERAL PRECAUTIONS
Handle and use the copier gently and carefully.
.Do not place anything on the paper cassettes or the original feed tray.
.Never allow the power cable to be trampled on or pinched between hard objects, otherwise
an accident or electrical trouble might occur.
.Do not allow any metal items such as paper clips to fall into the copier.
Be sure to turn OFF the power switch (unless using the automatic timer mode):
.When you leave your office at night.
.If a power failure occurs.
Caution: When turning OFF the power switch, be sure to do so only after the machine cycling
has come to a complete stop.
Be sure to disconnect the power-cord plug:
.when you do not intend to use the copier for an extended period of time.
Be sure to turn OFF the power switch immediately and call for service:
.If an unusual noise is heard from the copier.
.If the outside of the copier becomes unusually hot.
.If any part of this copier is damaged, or if it has been dropped.
.If the copier has been exposed to rain or liquid.
It is recommended that only supplies made or designated by Sharp be used for the
copierinordertooptimizecopyquality. Allsuppliesshouldbestoredinacool,dryarea.
For optimum performance, it is recommended that 22lb. xerographic bond paper of high quality
be used.
Paper of lower quality may contain inherent properties such as excess paper dust and may
lead to premature servicing.
WARNING–DO NOT LEAN ON, APPLY FORCE OR PLACE HEAVY OBJECTS ON THE
FINISHER. PERSONAL INJURY OR PROPERTY DAMAGE MAY RESULT.
2
PRECAUTIONS (Cont.)
3
"BATTERY DISPOSAL"
CONTAINS MANGANESE DIOXIDE LITHIUM BATTERY. MUST BE DISPOSED OF
PROPERLY. CONTACT YOUR SHARP DEALER OR SERVICER FOR INSTRUCTIONS.
This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury.
Disposal of these materials may be regulated due to environmental considerations.
For disposal or recycling information, please contact your local authorities or the Electronics Industries
Alliance:www.eia.org

7
DESCRIPTION
OF THE DIGITAL
COPIER
DESCRIPTION OFTHE DIGITAL COPIER

8
1. NAMES OF MAIN COMPONENTS
Cassette
Control panel
Automatic
document feeder
(ADF)
Glass
Original scale
Right-hand front door
Large capacity feeder
Used toner bag door
Tray-down key
Toner hopper lid
Left-hand front
door Operator's manual
pocket (back side)
Power switch
Sheet bypass
CLASS
1
LASER
PRODUCT
LASER
KLASSE1
APPAREIL
A
LASER
DE
DLASSE1
'
PRODUCT
IS
CERTIFIED
BY
THE
MANUFACTURER
TO
COMPLY
WITH DHHS
RULE 21
CFR
SUBCHAPTER
J APPLICABLE
AT
THE DATE OF MANUFACTURE
.
JS
MANUFACTURED
:Y
Certification Label
Explanatory Label
CLASS 1 LASER PRODUCT
LASER KLASSE 1
APPAREIL
A LASER DE DLASSE 1
'
PRODUCT IS CERTIFIED BY THE
MANUFACTURER TO COMPLY WITH DHHS
RULE 21
CFR SUBCHAPTER J APPLICABLE
AT
THE DATE OF MANUFACTURE . JS
MANUFACTURED : Y
Identification Label
Warning Label
Touch panel contrast
adjustment volume

9
DESCRIPTION
OF THE DIGITAL
COPIER
2. DESCRIPTION OF OPTIONAL EQUIPMENT
1. Finisher (AR-FN8, AR-FN9)
The finisher allows SORT, GROUP, STAPLE copying, MAGAZINE SORT, MAGAZINE SORT
& SADDLE STITCH, SADDLE STITCH and HOLE PUNCH as well as NON-SORT copying.
2. Hole Punching Unit
The hole punching unit is the option for the finishers.
* The saddle stitching function is available when the AR-FN9 is installed.
12

10
3. DESCRIPTION OF THE CONTROL PANEL
Clip tray
Put any paper clips re-
movedfromtheoriginals
here.
INTERRUPT key
When you want to make
a copy of a different ori-
ginal during a multicopy
run,pressthiskey.During
interrupt-copying, you
canmakecopiesonlyone
atatime. Toreturnto the
previous multicopying
run, press this key again.
ENERGY SAVER key
When you are not using
thecopierforafairlylong
period of time, press this
key.Thecopierentersthe
energy-savingmode,and
all display lamps go out.
Toresumecopying,press
this key again. After a
short while, the copier
becomes ready for
copying.
TOTAL COUNTER
Displaysthetotalnumber
of copies made after the
copier was installed.
PRINTER/NETWORK key
If you have an optional
printer installed, press
this key to access the
printer function.
COPY key
If you have an optional
printer installed, press
thiskeytoselectthecopy
function.
 
HELP
ENERGY SAVER
TIMER
INTERRUPT
COPY
PRINTER/NETWORK


11
DESCRIPTION
OF THE DIGITAL
COPIER
 
 
OPERATION GUIDE key
Pressing the HELP key
displays the appropriate
operation procedure.
Pressing this key after a
function has been set
displays the features
available.
MESSAGE display
Displays the status of the
copier, operation proce-
dures and various
instructionstotheuserin
short sentences and
graphics.
DIGITAL keys
Use these keys to enter
thedesiredcopyquantity.
You can set up to 999
copies.
 ALL CLEAR key
When you press this key,
all the modes you have
selectedareclearedtothe
default settings.
 STOP key
Press this key to stop a
copy run.
 START key
Press this key to start
copying.
 CLEAR key
Use this key to correct the
entered copy quantity.
1 2 3
4 5 6
7 8 9
0C
ALL CLEAR
STOP
START
CLEAR

12
The Message Display panel shows operation status,error messages and function menus.
.Each function item displayed is shown in the form of a touch key.You can select the function
by touching the key lightly with your finger.
.Touching one of the function items will show the next display.
The function items shown on the right can be selected directly on the Message Display panel.
* The brightness of the touch panel can be adjusted with the touch panel contrast adjustment
volume. Open the front doors and find it on the back side of the control panel. (Refer to the
illustration on the page8.)
3. DESCRIPTION OF THE CONTROL PANEL (Cont.)
Note: All the numbers are approximate. The
numbersinparenthesesareforthelarge-
capacity feeder.
: 500 ~ 376 (4000 ~2001)
: 375 ~ 251 (2000 ~1001)
: 250 ~ 126 (1000 ~ 501)
: 125 ~ 1 ( 500 ~ 1)


Message
Reproduction Ratio
Copy Quantity
Paper size of the currently selected paper source
Paper Indicator: Indicates the remaining number of sheets.

The table to show the relation between the paper size display on this
machine and the actual dimensions is as follows:
Paper Size Dimensions
LT 8-1/2" x 11"
LD 11" x 17"
LG 8-1/2" x 14"
ST-R 5-1/2" x 8-1/2"R
COMP 10-1/8" x 14"
FOLIO 8.27" x 13"
LG13 8-1/2" x 13"

13
DESCRIPTION
OF THE DIGITAL
COPIER
The graphic display shows the status of the copier. When one of the graphic symbols flashes,
take the appropriate action referring to the page shown.
4. DESCRIPTION OF THE GRAPHIC DISPLAY












14
4. DESCRIPTION OF THE GRAPHIC DISPLAY (Cont.)
SADDLE STITCHER JAM
Symbol
Thissymbolflasheswhen
paper is misfed in the
saddlestitcher.(Seepage
152.)
CLEAR PAPER symbol
Thissymbolflasheswhen
paper is misfed in the
automatic duplexer. (See
page 141~144.)
FINISHER/HOLE
PUNCHING
UNIT MISFEED symbol
Thissymbolflasheswhen
paper is misfed in the
optional finisher or hole
punching unit. (See page
149.)
CLEAR PAPER symbol
Thissymbolflasheswhen
paper is misfed on the
paper path inside the
copier. (See page 136.)
CALL SERVICE symbol
Thissymbolflasheswhen
maintenanceby aservice
technician is necessary.
(See page 165.)
CHECK ORIGINAL
symbol
Thissymbolflasheswhen
an original is misfed
inside the automatic
document feeder. (See
page 147.)
ADD TONER symbol
Thissymbolflasheswhen
thetonerhopperisempty.
(See page 132.)
BYPASS MISFEED
symbol
Thissymbolflasheswhen
no paper is fed into the
copierinbypasscopying.
Remove and reset the
sheets on the sheet
bypass. (See page 146.)
CLEAR PAPER symbol
Thissymbolflasheswhen
a sheet of paper fed from
the large-capacity feeder
ismisfedinthepaperfeed
section. (See page 146.)
 REPLACE TONER BAG
symbol
Thissymbolflasheswhen
the toner bag in use
becomes full of used
toner. (See page 130.)
 CLEAR PAPER symbol
Thissymbolflasheswhen
a sheet of paper fed from
the selected cassette is
misfed in the paper
feedingsection.(Seepage
145.)

15
HOW TO
MAKE
COPIES
HOW TO MAKE COPIES

16
1
2
3
1. TURNING ON THE POWER SWITCH / AUTO JOB START
Turn ON the power switch.
Turning ON the Power Switch
Themessage“WaitWarmingUp”appears.
.Wait until the copier becomes ready.
About 7 minutes later, the message
“READY”appears.
.This message indicates that you can make
copies at any time.
