This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
Parts marked with “ “ are important for maintaining the safety of the set.
Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.
SHARP CORPORATION
SERVICE MANUAL
DIGITAL COPIER
MODEL AR-800
[ 1 ] SPECIFICATIONS•ACCESSORIES•OPTIONS•SUPPLIES. . . 1 - 1
[14] FUSER UNIT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 - 1
CODE : 00ZAR800//A1E
CONTENTS
(Maintenance tables)

GENERAL
The major differences between the AR-800 and the AR-650 are
described below.
1. Specifications
The major differences between the AR-800 and the AR-650
lie in the copy (print) speed and the maintenance cycle.
(Max. copy (print) speed)
AR-650: 65CPM (PPM)
AR-800: 80CPM (PPM)
The process speed is the same, but the paper feed interval
differs.
(Maintenance cycle and consumable parts replacement cycle)
AR-650: Every 400K
AR-800: Every 440K
2. Hardware
Differences between the AR-800 and the AR-650
1) The PWA-F-LGC PWB differs.
AR-650: PWA-F-LGC-300
AR-800: PWA-F-LGC-304
(Different parts): Connector, EEPROM, FLASH ROM
The above two PWBs are not compatible each other.
2) Front cabinet
3) Model badge
3. Options
The AR-P13 (printer unit) is also revised for either of two
models, the AR-650 and the AR-800.
The differences between the old and new versions are as
follows:
(AR-P13 for AR-650)
Characters printed on the packing case are in black.
Firmware version: 1.43
Software version: (CD-ROM) 1.10
(Printed on the packing case)
(AR-P13 for AR-650/800)
Characters printed on the packing case are in blue.
Firmware version: 1.44
Software version: (CD-ROM) 1.20
(Printed on the packing case)
4. Others
The temperature control in the fusing section differs between
the AR-650 and the AR-800.
Except the above, the AR-800 and the AR-650 are the same.
The service documents are based on the above contents.
A. Service manual
Chapter 1. SPECIFICATIONS, ACCESSERIES, OPTIONS,
SUPPLIES
Comprehensive contents of the AR-800 and the AR-650
(Complete version)
Chapter 14. FUSER UNIT
Since the temperature control of the fusing section on page
14-5 differs between the AR-800 and the AR-650, the
temperature control of the AR-800 is added.
Only the contents of page 14-5 are described.
B. Actual wiring diagram
Since the PWA-F-LGC-304 (for AR-800) is newly employed,
the connector wiring is changed and the actual wiring
diagram is changed. The actual wiring diagram for the AR-
800 is newly prepared.
C. Service Handbook
Though the maintenance cycle and the consumable parts
replacement cycle differ between the AR-800 and the AR-
650, the contents of the Service Handbook are not changed.
Be sure to note the maintenance cycle of both models for
servicing.
AR-650: Every 400K
AR-800: Every 440K
D. Parts Guide
Only the different sections between the AR-650 and the AR-
800 are prepared.
Sections 1, 2, 5, 6, 13, 31, 39, 47, 62, 86, 101, 203, 204
(including the contents of both models, AR-800/AR-650)
For servicing of the AR-800, use these documents as well
as the service document of the AR-650.

1 - 1 SPECIFICATIONS
1. SPECIFICATIONS • ACCESSORIES • OPTIONS • SUPPLIES
1.1 Specifications
1. System
Copy system Indirect electronic photo system (Dry type)
Body type Console type
Original table type Fixed type (Left center reference)
Original cover RADF standard provision
Frame structure Fixed frame type
Photoconductor OPC drum (ø100)
Scan sensor CCD line sensor (7500 pixel)
Scan resolution 600 x 600dpi
Original scan system
Scan light source Halogen lamp (180W)
Scan data output system 1-scan multi-copy system
Exposure light source Semiconductor laser
Exposure resolution 600dpi
Exposure system
Scan system Using polygon mirror
Developing system 2-component magnetic brush developing system
Discharging system Photo discharging by red LED
Charging system Negative corona system (Scorotron)
Transfer system Transfer belt system
Separation system Transfer belt system
Transfer belt cleaning system Fur brush system + Blade system
Drum cleaning system Blade system + Fur brush system
Toner supply system Toner hopper system, right top side toner bottle supply
system
Toner density adjustment system Magnetic auto toner system
1. Mechanical sensor system
Note 1: When detecting, the toner supply lamp flashes.
Toner empty detection system
2. Electrical system (Using auto toner sensor)
Note 1: When detecting toner empty, the toner supply
lamp flashes and the message is displayed.
Heat roller system
Infrared heater (Upper) 2 pcs.
700W + 600W
Fusing system
Rollerdia. (Upper) ø 60mm
Rollerdia. (Lower) ø 60mm

SPECIFICATIONS 1 - 2
2. Basic specifications
A. Copy speed
(1) Continuous copy
Note 1: The above specifications are for manual feed, single and continuous copy.
Note 2: The state which is other than the toner supply mode.
(2) First copy
Note 1: The above specification is for manual feed, normal size, A4/LT size, LCF feed.
Note 2: When APS is not used.
B. Warming up time
C. Original
Normal About 420sec at 20°C
Max. size A3 or LD
Kind Sheet, cubic material, book
Glass surface: Provided
Note 1: Fixed detection system with the platen cover open
Original size detection
RADF: Provided
Note: The original width and length are detected in RADF feed.
Note 2: Only the first sheet is detected except when the mixed original mode is
selected.
AB series: A3,A4,A4-R,A5-R,B4,B5,B5-RAllowable original size for
auto detection
Fixed size
LT series: LD,LG,LT,LT-R,ST-R
Paper size
A4,B5,A5-R,LT,ST-R
A4-R,B5-R,LT-R
B4,FOLIO,LG,COMP
A3,LD
LCF
AR-650
65(55)
-
-
-
AR-800
80
-
-
-
Cassette
AR-650
65
51
44
38
AR-800
74
61
52
43
Manual feed
Size specified
AR-650
48
42
37
33
AR-800
48
42
37
33
Size not specified
AR-650
33
33
33
33
AR-800
33
33
33
33
Paper feed system
First copy time
AR-650
3.9sec or less
AR-800
3.6sec or less

1 - 3 SPECIFICATIONS
D. Paper
(1) Size
Note 1: Postcards cannot be used.
Note 2: Name cards cannot be used.
Note 3: Same surface copy cannot be used.
Note 4: Envelopes cannot be used.
Note 5: The paper width of fixed size is detected with the manual tray guide width.
Note 6: The upper stage of B5 cassette cannot be used.
Note 7: SFB mixed size paper cannot be used.
(2) Kind
Note 1: Only one sheet feed is allowed except for PPC paper.
Note: Special paper such as postcards and PPC paper with punch holes cannot be used.
(3) Weight
(4) Curl level
AB series: A3,A4,A4-R,A5-R,B4,B5,B5-R,FOLIO
Cassette
LT series: LD,LG,LT,LT-R,ST-R,COM
AB series: A3,A4,A4-R,A5-R,B4,B5,B5-R,FOLIOSFB
LT series: LD,LG,LT,LT-R,ST-R,COM
Fixed size
LCF : A4,LT,B5
LCF
Cassette
PPC paper
PPC paper
Tracing paper: Out of warranty
OHP film: Out of warranty
SFB
Label sheet: Out of warranty
Cassette, LCF 64~ 80 g/m2,17~ 22 lbs
64~ 80 g/m2,17~ 22 lbs Continuous feed allowedSFB
80~157g/m2,22~ 41 lbs Only one sheet feed allowed
Curl level PPC paper: The highest point when paper is put on a flat surface must be 5mm or less.

SPECIFICATIONS 1 - 4
E. Paper feed
F. Continuous copy
G. Density adjustment
H. Picture quality mode
I. Magnification ratio
(1) Reduction and enlargement
LCF
Cassettes: 3 steps (Drawers of the copier)
Paper feed means
SFB
LCF: 4,000 sheets (Load height: max. 415mm)
Cassette: 500 sheets (Load height: max. 55mm)
SFB: 100 sheets (Load height: max. 11mm)
Capacity
Note 1: 50 sheets for SFB duplex copy.
Note 2: However, the cassette load height is displayed as
53mm.
Note 3: however, the SFB load height is displayed as 10mm.
Manual feed start Start key start
Priority feed means LCF priority
Note 1: By data input of the adjustment mode, another paper
feed means can have priority to be selected.
Factory setup: LCF
priority
Manual feed size
specification
After setting paper, press the paper size key to specify the
paper size.
Note 1: By specifying the paper size, the binding margin,
duplex edge erase, and continuous page copy can be
performed. For APS and AMS, invalid.
No. of sheets Increment of 1 sheet up to max. 999 sheets
Input system 10-key input
Count system Reduction system
Note 1: “1”is displayed in auto clear and warming up.
Auto density adjustment Available
Manual density adjustment 11-step adjustment (Operated with
keys on the control panel LCD)
Priority mode Auto density adjustment
Note 1: By data input of the adjustment
mode, selection of auto/manual is
allowed.
Factory setup: Auto
Picture process mode Standard/Photo/Text mode
Priority mode Standard mode
Note: By data input of the adjustment mode, the mode can be selected.
Reduction and enlargement Auto setup system depends on selecting the original
size and paper size.
Note 1: A desired fixed-size series (including a different
series) can be selected: Japan A5, UNIVERSAL,
OTHER.

1 - 5 SPECIFICATIONS
(2) Selected magnification ratio
a. AB series
b.LT series
Note 1: The above numbers show magnification ratios.
(3) Other
J. Counter display
Paper
Original
A3 B4 FOLIO A4 B5 A5
A3 100 86 71 71 61 50
B4 115 100 82 82 71 57
FOLIO 127 110 100 90 78 63
A4 141 122 100 100 86 71
B5 163 141 115 115 100 82
A5 200 173 141 141 122 100
Paper
Original
LD COMP LG LT ST
LD 100 82 78 65 50
COMP 108 100 84 78 54
LG 121 100 100 78 60
LT 129 119 100 100 65
ST 200 165 154 129 100
Zoom 20 –400%, increment of 1%
Copy allow area display Available
Auto paper selection (APS)/Auto magnification
ratio selection
Available Factory setup: APS
priority
Total counter Mechanical system 7 digits
Displayed on the control panel.
A3/LD double count mode Available (Electronic counter) Factory setup: ON
PM counter Available (Electronic counter) Factory setup:
 400,000 (AR-650)
 440,000 (AR-800)
Resettable counter Available (Electronic counter) Factory setup
Europe: Used.
Others: Not used.
Original counter Available (Electronic counter) Factory setup
Europe: Used.
Others: Not used.
Copy job counter Available (Electronic counter)
Print job counter Available (Electronic counter)

SPECIFICATIONS 1 - 6
K. Charger wire cleaning
Note 1: The charging wire is cleaned.
L. Special functions
Charger wire cleaning Available (Auto cleaning system)
Interruption Available
Available Key input is accepted
during warming up and in
the ready state.
Note 1: Auto pre-heat function can be set in the adjustment
mode.
Note 2: By data input of the adjustment mode, time can be
set in the increment of 5min (5 –60min).
Factory setup (Note 2)
North America, Europe:
15min
Others: Cancel
Pre-heat
Note 3: The fuser temperature in pre-heat can be set in the
adjustment mode.
Factory setup (Note 3); 170
C
AvailableAuto clear
Setup can be changed in the adjustment mode.
(15 –150sec, in the increment of 15sec, and cancel of
setup)
Factory setup: 45sec
Available
Note 1: Time up to OFF can be changed in the adjustment
mode or in the adjustment screen setup. (Max. 240min.
Only the adjustment code can be canceled.)
Note 2: Use or non-use can be selected in the adjustment
mode.
Factory setup (Note 1, 2)
North America, Europe:
90min
Others: Not used.
Auto off
Note 3: For time setup, selection of User adjustment
Allow/Not Allow can be made.
Factory setup (Note 3)
North America, Europe:
Available
Others: Not Available
Self diag Available
Error code history Available
Password code Available Factory setup: OFF
Dew-prevention Available (Optional in some destinations)
Message Available
Note 1: Graphic LCD, backlight provided.
All clear Available AC key
Mode memory Available (4 modes)
Cover paper mode Available (in the following 4 modes)
(1) White cover mode
(2) Copy cover mode
(3) White cover/white back cover mode
(4) Copy cover/white back cover mode
Sheet insertion mode Available (in the following 2 modes)
(1) White paper insertion mode
(2) Copy paper insertion mode
Weekly timer Available
Pre-heat start Available
Pre-heat copy Available
Auto duplex auto
selection
Available Factory setup: OFF

1 - 7 SPECIFICATIONS
M. Edit function
N. Digital edit functions
Timer display Available Factory setup: Display
provided
Auto sort Available Factory setup: ON
Auto cassette selection Available Factory setup: Available
Paper feed means which
allow selection:
(1) LCF
(2) Cassette
Network printer Allows connection of network printer board (option).
Language selection Available (3 languages)
Note 1: Language selection of DSS display must be
initialized.
FROM update Available
Note 1: Download from PC
Performed by a
serviceman.
Adjustment code output Available (05, 08 code) Performed by a
serviceman.
Mixed original load Available
Continuous page copy Available
Edge erase Available
By data of the adjustment mode, the edge erase priority
mode can be selected.
Factory setup: No
priority
Binding margin (Image shift) Available
Trimming, masking Available
2in1 Available
4in1 Available
Electronic sort Available
Magazine sort Available
Page numbering Available
Rotational copy Available
Document storage Available
Date write Available
Independent zoom of magnification ratio Available
Mirror image Available
Black-white reversion Available

SPECIFICATIONS 1 - 8
O. Operation panel
P. Environmental conditions
Q. Noises
R.
S. Conforming standards
Hard key
Note 1: There are following 19 keys.
Start
0 –9 (10 keys)
Clear
Stop
All clear
Interruption
Pre-heat
HELP
Copy
Operation key
Printer
Displayed with the message display and LED.
Note 1: There are following 6 LED’s.
All clear
Interruption
Pre-heat
Copy
Printer
Status display
Timer
Message display Graphic LCD with touch panel (with backlight)
Note 1: Details of LCD
Display dot: 320 x 240 (1/4 VGA)
Display area: 115.7mm c 86.37mm
Normal use 10~30˚C,20~85%RH,without dew
(1)-5~10˚C,20~85%RH,without dewSpecial use
(2)30~35˚C,20~85%RH,without dew
Transit or storage with consumable parts
packed together
-10~35˚C,85%RH or less, without dew
Transit or storage without consumable parts
packed together
-40~50˚C,85%RH or less, without dew
Transit or storage of consumable parts -10~35˚C,85%RH or less, without dew
Ready state 45dB(A)or less
Continuous copy 65dB(A)or less
1) Electrical appliances regulations (S mark)
2)UL
3)CSA
4)CDRH
5)CE mark
Safety standards
6)TUV
1)VCCI
2)FCC(IC)
3)CE mark
Interruption wave standards
4)C-TICK(Australia)

1 - 9 SPECIFICATIONS
T. Power source
U. External view
V. Packing
W. Maintenance
(1) Periodic inspection
(2) Overhaul
Power voltage,
frequency
100V-50/60Hz,115V-50/60Hz,220V-50/60Hz,230~240V-50/60Hz,240V-50Hz
Power consumption 2.0kW or less
Power cord 2m
Note 1: For 200 series, detachable.
(1) Body: W920 X D742 X H1111 mm
(2) Body + Finisher: W1735 X D742 X H1111 mm
External dimensions
(3) Body + Finisher + DSSC: W1735 X D905 X H1111 mm
Weight Body only: 250 kg
External dimensions W1015 X D845 X H1290 mm (with palette)
Weight 285 kg
Operation Manual
Drum
Operation Manual Pocket
Original feed tray
Maintenance management table (Card, sheet)
Delivery installation contract (EU only)
MSDS card (USA,UK only)
Warranty for Australia
Packed items
Warranty registration (EU only)
Periodicinspection interval 400,000 sheets(AR-650) 440,000 sheets (AR-800)
Overhaul interval 800,000 sheets (AR-650) 880,000 sheets (AR-800)

SPECIFICATIONS 1 - 10
X. Automatic original feeder
(1) Functions
Y. Auto duplex function
(1) Auto duplex function
Automatic original feeder ADF conforming to duplex original (Standard provision)
Loaded originals are automatically separated and fed.
a) Auto magnification ratio/Paper selection
b) Conforming to duplex original
Functions
c) SADF/ADF
Size: A3 –A5R, or LD –STR
Weight: 60~90g/m
2
(16~24 Lbs)
Allowable original
Kind: High quality paper
A4, A4R, B5, B5R, A5R, LT, LTR, STR: 60 sheets
B4, LG, COMP, FOLIO: 35 sheets
Original capacity
A3, LD: 30 sheets
Setup method: The final page is at the bottom, and the front surface is up.
Paper feed method: The paper at the bottom (the last page) is fed first to
the copy section.
Original process method
Paper exit method: The last page is put in face-up, and the others are
stacked on it.
Original position Center reference
Power source Supplied from the copier.
Applicable paper
Paper conditions
Capacity
Separation system
Transfer reference
Load system
Refeed system
Refeed process speed
Jam process system
Stack quantity
Size
Weight
Curl level
A4,B5,A5-R,LT,ST-R
A4-R,B5-R,LT-R
B4,LG
A3,LD:
AR-650
Standard provision
A3,A4,A4-R,B4,B5,B5-R,A5-R
LD,LG,LT,LT-R,ST-R
64 80g/ m2(17~22 Lbs)
5mm or less
A4,A4R,B5,LT,LT-R:60 sheets
A3,B4,LD,LG,COMP,FOLIO,B5-R,A5-R,ST-R:35 sheets
Separation belt system
Center reference
Face-down
Take-up from the bottom
65 cpm
51 cpm
44 cpm
38 cpm
Open the front cover and pull out the unit.
Remove all paper in M/C.
1 set
AR-800
70 cpm
57 cpm
50 cpm
42 cpm

1 - 11 SPECIFICATIONS
Z. Reverse paper exit function
4Picture and picture quality specifications
A. Picture quality
Reverse paper exit Available
A4,B5,A5-R,LT,ST-R:65cpm
A4-R,B5-R,LT-R:45cpm
B4,LG:36cpm
Process speed
A3,LD:30cpm
A3,B4,A4,A4-R,B5,B5-R,A5-RSize
LD,LG,LT,LT-R,ST-R
Applicable paper
Weight 64~80g/m217~22 Lbs
5mm or less (Paper feed section)Paper conditions Curl level
20mm or less (Refeed section)
Use conditions In duplex paper exit of the first set in Single Duplex mode, with an odd number of the
quantity of originals.
Picture density 1.0 or above Original density: 1.0
Background copy 3.0 or less
Normal: Vertical 4.0mm or above/Horizontal 4.0mm or above
Enlargement 200%: Vertical 4.5mm or above/Horizontal 4.0mm
or above
Resolution
Reduction 50%: Vertical 2.0mm or above/Horizontal 1,7mm or
above
Normal: 1.0%Magnification ratio error
Enlargement 200%/Reduction 50% 1.5%
Lead edge shift Body 0 2mm, system 0 4.0mm
Side shift Body 0 3.0mm, system 0 4.0mm
Inclination Body 1.0mm or less, system 3.0mm or less/200mm
➔
±
±
±±
±
±

SPECIFICATIONS 1 - 12
1.2 Accessories
1.3 Options
Operation Manual
Drum
Operation Manual Pocket
Original feed tray
Maintenance management table (Card, sheet)
Delivery installation contract (EU only)
MSDS card (USA,UK only)
Warranty for Australia
Warranty registration (EU only)
Finisher
Finisher
Punch unit
Printer kit
Network Card(NIC)
Memory
MODEL
AR-FN8
AR-FN9
AR-PN2A
AR-PN2B
AR-PN2C
AR-PN2D
AR-P13
AR-NC4T
AR-SM3
NOTE
Finsher with Saddle Stitching
2 holes (80mm pitch) Europe
2 holes (70mm pitch) 3 holes (108mm pitch) USA/Canada
4 holes (80mm pitch) France
4 holes (70/21mm pitch) Sweden
Expansion Memory for Printer
ITEM
This kit is available in two kinds.
One for the AR-650 has black characters printed on the
packing case.
The other is applicable to all the models, and has blue
characters printed on the packing case.

1 - 13 SPECIFICATIONS
No. ITEMS CONTENTS LIFE MODEL Pack Remark
Drum cleaning Blade x1
Drum Separation Claw x2
Drum Cleaning Roller x1
Charger Wire (Main) x1
Charger Wire Cleaning Pad x1
Charger Grid x1
Transfer belt x1
Transfer belt charger roller x1
Transfer belt brush roller x1
Transfer belt cleaning blade x1
Ozone filter x1
Air filter (toner filter) x1
Pick up roller for large capacity feeder x1
Feed roller for large capacity feeder x1
Separation roller for large capacity feeder x1
Heat roller upper x1
Heat roller lower x1
Heat roller scraper (upper) x1
Heat roller silicone roller (upper) x1
Heat roller cleaning roller x1
Heat roller cleaning roller (lower) x1
Heat roller cleaning roller (silicon roller ) (lower) x1
Picck up roller for Auto document Feeder x1
Feed roller for auto document feeder x1
Separation roller for auto document feeder x1
Transport belt for auto document feeder x1
5 Waste toner bottle Waste toner bottle x4 AR-650HB 1
6Stapler for Finisher
5000 sheets Staple Cartrige x1 5000x3 SF-SC11 20 Cartridge for AR-FN8 and AR-FN9 Common with S55,S55N
7Stapler for Finisher
2000 sheets Staple Cartrige x1 2000x3 SF-SC3 40 (For AR-FN9 Saddle Stitch)
Note: Maintenance parts other than above items must be ordered through the parts department using the proper part number.
400K/440K AR-650FU 1
400K/440K
400K/440K AR-650LC 1
Maintenance Kit 11
Fusing Kit3
2 Maintenance Kit 2
1AR-650KA
DF Kit4 400K/440K AR-650DF 1
1.4 Supplies
USA/CANADA
No. Name Content Life MODEL Pack Remark
1 Toner (Black) Toner (AR-650NT) 240K AR-650MT 1*Life: By A4 6% documents.
* Life for use with the AR-650: 400K
Life for use with the AR-800: 440K
* Life for use with the AR-650: 400K
Life for use with the AR-800: 440K
* Life for use with the AR-650: 400K
Life for use with the AR-800: 440K
* Life for use with the AR-650: 400K
Life for use with the AR-800: 440K
Toner: Net 1500g: 60K (MT=NT x 4)
2 Developer (Black) Developer
400K/440K
AR-650ND 4
(Developer: Net 1500g: 400K)
3 Drum Drum
400K/440K
AR-650DR 10
Note 1) Print on Master/individual carton:
Toner/Developer in 2 languages (English/French), DR in 4 languages (English/French/German/Spanish).
Packed with machine: DR 400K/440K Developer 400K/440K
OTHER COUNTRY
No. Name Content Life MODEL Pack Remark
1 Toner (Black) Toner (AR-650T) 240K AR-650LT 1*Life: By A4 6% documents.
Toner: Net 1500g:60K (LT=T x 4)
2 Developer (Black) Developer
400K/440K
AR-650DV 4
(Developer: Net 1500g: 400K)
3 Drum Drum
AR-650DM
10
Note 1) Print on Master/individual carton:
4 languages (English/French/German/Spanish).
Packed with machine: DR 400K/440K Developer 400K/440K
* Life for use with the AR-650: 400K
Life for use with the AR-800: 440K
* Life for use with the AR-650: 400K
Life for use with the AR-800: 440K
* Life for use with the AR-650: 400K
Life for use with the AR-800: 440K
* Life for use with the AR-650: 400K
Life for use with the AR-800: 440K
*
*
*
*
*
400K/440K
*
*
*

SPECIFICATIONS 1 - 14
Staple
cartridge Finisher
AR-FN8
AR-FN9
Supplies
Drum
Toner bag Toner
Developer
1.5 System List

14 - 1 FUSER UNIT
1. The Thermistor status counter normally has a value of between 0 and 9.
•At the power on, if the heater is not turned ON and the copier goes into C41 CALL SERVICE, check the
Thermistor status counter to see if it is 2 or more. If it is 2 or more, be sure to check the thermistor and
heater lamp, and after repair, reset the Thermistor status counter (08-code 400) to 0 and then turn ON
the power switch.
•
2. Relationship between the output voltage and the fusing temperature.
• 200°C corresponds to approx. 2.5V and 0.25 V corresponds to approx. 40°C.
3. Relationship between heat roller surface temperature and fuser lamp operation.
14. FUSER UNIT
4. Temperature control at heat roller ends
During multicopying, the temperature at each end (no paper-contact area) of the heat roller normally tends
to rise higher than the controlled temperature of the paper-contact area. Therefore, the circuit is designed so
that if the temperature in the no paper-contact area rises to 240°C, the second thermistor detects this,
causing the heater to be turned OFF immediately regardless of the temperature in the paper-contact area.
Temperature
(AR-650)
(AR-800)
Heater lamp state
Less than 200°C ON
200°C Maintains previous status
More than 200°C OFF
Temperature Fusing control
200°C or above Heater lamp OFF
170~200°C Heater lamp ON
Normal copy speed
160~170°C Copying is continued at a
lower speed.
160°C or below Copying is interrupted and
the machine is reset to the
ready state.
˚C
Copying
Copying
Waiting
Heater lamp
ON
Copy speed
OFF
0 0 0 80 65 80 65 0 80 65 0
OFF ON ON ON ON ONON ON
Warm up Standby(200 )
200
170
160
ON ON
Standby
(200 )
Reference
Copying (200°C)
Heat roller
temperature
distribution
Heater lamp
ON OFF OFF OFF
ON ON ON ON
Warm-up Standby (200°C)
C
200
OFF OFF
ON
OFF
If the counter has a value 10 or greater (11 for example), the BC-RAM or the data in it have been
destroyed by charger leakage, etc. In this case, check the guide bias, high-voltage transformers,
charger wires, etc. for any defects. Also, all the data inside BC-RAM needs to be rechecked.

PERIODICAL MAINTENANCE (AR-800)
Inspection every 440,000 Copies
(1) Preparation
1
Ask the copier operator about the present machine conditions and note them down.
2
Before starting the maintenance work, make and retain a few sample copies for comparison
reference purposes.
3Turn the power switch OFF and disconnect the power cord plug.
(2) The periodic inspection should be conducted in accordance with the Periodic Inspection Check list
shown below.
Perform the inspection by referring to the figures, as well as to the explanation in the Service Manual
when necessary.
(3) After the inspection has been completed, plug in the machine and turn the power switch ON, and
check the general operation of the machine by making a few copies and comparing them to those
made previously.
Inspection and Overhaul every 880,000 Copies
(1) Replace all the consumables.
(2) Check that if there is any damage to the parts in the driving section (gear, pulley, timing belt, etc.). In
principle, replace those parts at this time.
(3) Check to see if there is any damage or peeling of adhered parts (tape, Mylar sheet, etc.). Replace
any affected parts if necessary.
(4) Check that if all the switches and sensors operate properly. Replace them if they are not operating
properly.
(5) Clean the inside of the machine thoroughly.
Note: Before inspecting and overhauling the feed section of the 3-cassette feed unit, remove the
PFP upper aligning unit and PFP feed unit from the copier.
Explanation of the items in the “Remarks” column of the Periodic Inspection Check List
Periodic Inspection Check List
Symbols used in the Periodic Inspection Check List
Cleaning Lubrication Replacement Operation check Date
A:Cleaning with alcohol L:Launa 40 110: Every 110,000 copies :Check for User’s
:Cleaning with soft Application 440: Every 440,000 copies abnormalities name
pad, cloth, or cleaner SI :Silicon Oil Same from here on after cleaning Machine
(vacuum cleaner) W:White grease : Replace in event of defor- or No.
(Molycoat) mation or other damage replacement. Inspector
AV
:Alvania No.2
Remarks
MAINTENANCE
